USER’S GUIDE
Agilent Technologies
Model N3280A
Component Test DC Source
"A
Agilent Part No. 5964-8248
Microfiche No. 5964-8249
Printed in Malaysia: September, 2004
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

2
Warranty Information
CERTIFICATION
Agilent Technologies certifies that this product met its published specifications at time of shipment from the factory.
Agilent Technologies further certifies that its calibration measurements are traceable to the United States National
Institute of Standards and Technology, to the extent allowed by the Bureau's calibration facility, and to the calibration
facilities of other International Standards Organization members.
WARRANTY
This Agilent Technologies hardware product is warranted against defects in material and workmanship for a period
of one year from date of delivery. Agilent Technologies software and firmware products, which are designated by
Agilent Technologies for use with a hardware product and when properly installed on that hardware product, are
warranted not to fail to execute their programming instructions due to defects in material and workmanship for a
period of 90 days from date of delivery. During the warranty period Agilent Technologies will, at its option, either
repair or replace products which prove to be defective. Agilent does not warrant that the operation for the software
firmware, or hardware shall be uninterrupted or error free.
For warranty service, with the exception of warranty options, this product must be returned to a service facility
designated by Agilent Technologies. Customer shall prepay shipping charges by (and shall pay all duty and taxes)
for products returned to Agilent Technologies for warranty service. Except for products returned to Customer from
another country, Agilent Technologies shall pay for return of products to Customer.
Warranty services outside the country of initial purchase are included in Agilent Technologies' product price, only if
Customer pays Agilent Technologies international prices (defined as destination local currency price, or U.S. or
Geneva Export price).
If Agilent is unable, within a reasonable time to repair or replace any product to condition as warranted, the
Customer shall be entitled to a refund of the purchase price upon return of the product to Agilent Technologies.
LIMITATION OF WARRANTY
The foregoing warranty shall not apply to defects resulting from improper or inadequate maintenance by the
Customer, Customer-supplied software or interfacing, unauthorized modification or misuse, operation outside of the
environmental specifications for the product, or improper site preparation and maintenance. NO OTHER
WARRANTY IS EXPRESSED OR IMPLIED. AGILENT TECHNOLOGIES SPECIFICALLY DISCLAIMS THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
EXCLUSIVE REMEDIES
THE REMEDIES PROVIDED HEREIN ARE THE CUSTOMER'S SOLE AND EXCLUSIVE REMEDIES. AGILENT
TECHNOLOGIES SHALL NOT BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, WHETHER BASED ON CONTRACT, TORT, OR ANY OTHER LEGAL THEORY.
ASSISTANCE
The above statements apply only to the standard product warranty. Warranty options, extended support contacts,
product maintenance agreements and customer assistance agreements are also available. Contact your nearest
Agilent Technologies Sales and Service office for further information on Agilent Technologies' full line of Support
Programs.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

3
Safety Summary
The
f
ollowin
g
g
eneral sa
f
et
y
p
recautions must be observed durin
g
all
p
hases o
f
o
p
eration o
f
this instrument.
F
ailure to com
p
l
y
with these
p
recautions or with s
p
eci
f
ic warnin
g
s elsewhere in this manual violates sa
f
et
y
s
tandards o
f
desi
g
n, manu
f
acture, and intended use o
f
the instrument. A
g
ilent Technolo
g
ies assumes no liabilit
y
for the customer's failure to comply with these requirements.
GENERAL
This product is a Safety Class 1 instrument (provided with a protective earth terminal). The protective features of
this product may be impaired if it is used in a manner not specified in the operation instructions.
Any LEDs used in this product are Class 1 LEDs as per IEC 825-1.
ENVIRONMENTAL CONDITIONS
This instrument is intended for indoor use in an installation category II, pollution degree 2 environment. It is
designed to operate at a maximum relative humidity of 95% and at altitudes of up to 4500 meters. Refer to the
specifications tables for the ac mains voltage requirements and ambient operating temperature range.
BEFORE APPLYING POWER
Verify that the product is set to match the available line voltage, the correct fuse is installed, and all safety
precautions are taken. Note the instrument's external markings described under "Safety Symbols".
GROUND THE INSTRUMENT
To minimize shock hazard, the instrument chassis and cover must be connected to an electrical ground. The
instrument must be connected to the ac power mains through a grounded power cable, with the ground wire firmly
connected to an electrical ground (safety ground) at the power outlet. Any interruption of the protective (grounding)
conductor or disconnection of the protective earth terminal will cause a potential shock hazard that could result in
personal injury.
ATTENTION: Un circuit de terre continu est essentiel en vue du fonctionnement sécuritaire de l'appareil.
Ne jamais mettre l'appareil en marche lorsque le conducteur de mise … la terre est d‚branch‚.
FUSES
Only fuses with the required rated current, voltage, and specified type (normal blow, time delay, etc.) should be
used. Do not use repaired fuses or short-circuited fuseholders. To do so could cause a shock or fire hazard.
Vous devrez impérativement utiliser des fusibles calibrés aux spécifications de courant, tension et type
(coupure, délai de coupure, etc ...). N'utilisez jamais de fusibles réparés et ne court-circuitez pas les supports
de fusibles. Sinon, vous risquez de provoquer un choc électrique ou un incendie.
DO NOT OPERATE IN AN EXPLOSIVE ATMOSPHERE
Do not operate the instrument in the presence of flammable gases or fumes.
DO NOT REMOVE THE INSTRUMENT COVER
Operating personnel must not remove instrument covers. Component replacement and internal adjustments must be
made only by qualified service personnel.
Instruments that appear damaged or defective should be made inoperative and secured against unintended
operation until they can be repaired by qualified service personnel.
This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme à la norme NMB-001 du Canada.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

4
SAFETY SYMBOLS
Direct current
Alternating current
Both direct and alternating current
Three-phase alternating current
Earth (ground) terminal
Protective earth (ground) terminal
Frame or chassis terminal
Terminal is at earth potential. Used for measurement and control circuits designed to be
operated with one terminal at earth potential.
Terminal for Neutral conductor on permanently installed equipment
Terminal for Line conductor on permanently installed equipment
On (supply)
Off (supply)
Standby (supply). Units with this symbol are not completely disconnected from ac mains when
this switch is off. To completely disconnect the unit from ac mains, either disconnect the power
cord or have a qualified electrician install an external switch.
In position of a bi-stable push control
Out position of a bi-stable push control
Caution, risk of electric shock
Caution, hot surface
Caution (refer to accompanying documents)
WARNING The WARNING sign denotes a hazard. It calls attention to a procedure, practice, or the like,
which, if not correctly performed or adhered to, could result in personal injury. Do not proceed
beyond a WARNING sign until the indicated conditions are fully understood and met.
Caution The CAUTION sign denotes a hazard. It calls attention to an operating procedure, or the like,
which, if not correctly performed or adhered to, could result in damage to or destruction of part
or all of the product. Do not proceed beyond a CAUTION sign until the indicated conditions
are fully understood and met.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

5
Declaration Page
DECLARATION OF CONFORMITY
According to ISO/IEC Guide 22 and CEN/CENELEC EN 45014
Manufacturer’s Name and Address:
Responsible Party Alternate Manufacturing Site
Agilent Technologies, Inc.
550 Clark Drive, Suite 101
Budd Lake, New Jersey 07828
U.S.A
Agilent Technologies (Malaysia) Sdn. Bhd
Malaysia Manufacturing
Bayan Lepas Free Industrial Zone, PH III
11900 Penang,
Malaysia
Declares under sole responsibility that the product as originally delivered
Product Name: Component Test dc Source
Model Number: N3280A
Product Options: This declaration covers all options of the above product(s).
Complies with the essential requirements of the Low Voltage Directive 73/23/EEC and the EMC
Directive 89/336/EEC (including 93/68/EEC) and carries the CE Marking accordingly.
EMC Information ISM Group 1 Class A Emissions
As detailed in Electromagnetic Compatibility (EMC), Certificate of Conformance Number
TCF CC/TCF/01/016-2 based on Technical Construction File (TCF) ANJ13, dated
June 21, 2001.
Assessed by: Celestica Ltd, Appointed Competent Body
Westfields House, West Avenue
Kidsgrove, Stoke-on-Trent
Straffordshire, ST7 1TL
United Kingdom
Safety Information and Conforms to the following safety standards.
IEC 61010-1:2001 / EN 61010-1:2001
Canada: CSA C22.2 No. 1010.1:1992
UL 61010B-1:2003
This Doc applies to the above-listed products placed on the EU market after:
January 1, 2004
Date Bill Darcy / Regulations Manager
For further information, please contact your local Agilent Technologies sales office, agent or distributor, or
Agilent Technologies Deutschland GmbH, Herrenberger Stra
β e 130, D71034 Böblingen, Germany
Revision: B.00.00 Issue Date: Created on 11/24/2003 3:03
PM Document No. DOC.11.24.doc
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

6
Acoustic Noise Information
Herstellerbescheinigung
Diese Information steht im Zusammenhang mit den Anforderungen der
Maschinenläminformationsverordnung vom 18 Januar 1991.
* Schalldruckpegel Lp <70 dB(A)
* Am Arbeitsplatz
* Normaler Betrieb
* Nach EN 27779 (Typprüfung).
Manufacturer's Declaration
This statement is provided to comply with the requirements of the German Sound Emission Directive,
from 18 January 1991.
* Sound Pressure Lp <70 dB(A)
* At Operator Position
* Normal Operation
* According to EN 27779 (Type Test).
Printing History
The edition and current revision of this manual are indicated below. Reprints of this manual containing
minor corrections and updates may have the same printing date. Revised editions are identified by a new
printing date. A revised edition incorporates all new or corrected material since the previous printing
date.
Changes to the manual occurring between revisions are covered by change sheets shipped with the
manual. In some cases, the manual change applies only to specific instruments. Instructions provided on
the change sheet will indicate if a particular change applies only to certain instruments.
This document contains proprietary information protected by copyright. All rights are reserved. No part
of this document may be photocopied, reproduced, or translated into another language without the prior
consent of Agilent Technologies. The information contained in this document is subject to change
without notice.
Copyright 2001, 2004 Agilent Technologies, Inc. Edition 1 March, 2001
Update 1 June, 2001
Update 2 September, 2004
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

7
Table of Contents
Warranty Information 2
Safety Summary 3
Declaration Page 5
Acoustic Noise Information 6
Printing History 6
Table of Contents 7
GENERAL INFORMATION 13
Document Orientation 13
Safety Considerations 13
Options and Accessories 14
Description 14
Remote Programming 14
Output Characteristics 15
Voltage Priority Operation 15
Current Priority Operation 16
Measurement Characteristics 17
Start of a Measurement 18
INSTALLATION 19
Inspection 19
Damage 19
Packaging Material 19
Additional Items 19
Cleaning 19
Location 20
Bench Operation 20
Rack Mounting 20
Power Connections 21
Connect the Power Cord 21
Output Connections 22
Outputs 1 - 4 22
Current Ratings 23
Voltage Drops and Lead Resistance 23
Coaxial Guard Connections 24
Maintaining Stability 25
OVP Considerations 25
External Trigger Connections 25
Computer Connections 25
GPIB Interface 25
GPIB Address 26
TURN-ON CHECKOUT 27
Front Panel Description 27
Checkout Procedure 28
In Case of Trouble 29
Selftest Error Messages 29
Runtime Error Messages 29
Line Fuse 29
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

8
INTRODUCTION TO PROGRAMMING 31
External References 31
GPIB References 31
SCPI References 31
GPIB Capabilities of the DC Source 31
Introduction to SCPI 32
Conventions Used in This Guide 32
Types of SCPI Commands 32
Multiple Commands in a Message 33
Moving Among Subsystems 33
Including Common Commands 33
Using Queries 33
Types of SCPI Messages 34
The Message Unit 34
Channel List Parameter 34
Headers 35
Query Indicator 35
Message Unit Separator 35
Root Specifier 35
Message Terminator 35
SCPI Data Formats 35
Numerical Data Formats 35
Suffixes and Multipliers 36
Response Data Types 36
SCPI Command Completion 36
Using Device Clear 37
PROGRAMMING THE DC SOURCE 39
Introduction 39
Programming the Output 39
Power-on Initialization 39
Enabling the Output 39
Output Voltage 39
Overvoltage Protection 40
Output Current 40
Output Mode 40
Oscillation Protection 41
Triggering Output Changes 41
Output Trigger Model 41
Setting the Voltage and Current Trigger Levels 42
Enabling the Output Trigger System 42
Selecting the Output Trigger Source 42
Generating Output Triggers 43
Making Measurements 43
Average Measurements 43
Power Line Cycles 44
Measurement Samples and Time Interval 44
Current Ranges 45
Window Functions 45
Returning All Measurement Data From the Data Buffer 45
Triggered Measurements 45
Measurement Trigger Model 46
Enabling the Measurement Trigger System 46
Selecting the Measurement Trigger Source 46
Selecting the Sensing Function 47
Output Settling Delay 47
Generating Measurement Triggers 47
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

9
Pre-trigger and Post-trigger Data Acquisition 48
Programming the Status Registers 49
Operation Status Group 50
Questionable Status Group 51
Standard Event Status Group 51
Status Byte Register 51
Determining the Cause of a Service Interrupt 52
Servicing Operation Status and Questionable Status Events 52
LANGUAGE DICTIONARY 53
Introduction 53
Subsystem Commands 53
Common Commands 53
Programming Parameters 53
SCPI Programming Commands - At a Glance 54
Calibration Commands 57
CALibrate:CURRent 57
CALibrate:CURRent:LIMit[:POSitive] CALibrate:CURRent:LIMit:NEGative 57
CALibrate:CURRent:MEASure 57
CALibrate:DATA 58
CALibrate:DATE 58
CALibrate:LEVel 58
CALibrate:PASSword 58
CALibrate:SAVE 59
CALibrate:STATe 59
CALibrate:VOLTage 59
Measurement Commands 60
FETCh:ARRay:CURRent? FETCh:ARRay:VOLTage? 60
FETCh:CURRent? FETCh:VOLTage? 60
MEASure:ARRay:CURRent? MEASure:ARRay:VOLTage? 61
MEASure:CURRent? MEASure:VOLTage? 61
SENSe:CURRent:RANGe 61
SENSe:FUNCtion 62
SENSe:SWEep:NPLCycles 62
SENSe:SWEep:OFFSet:POINts 62
SENSe:SWEep:POINts 63
SENSe:SWEep:TINTerval 63
SENSe:WINDow 63
Output Commands 64
OUTPut 64
OUTPut:OSCProtect 64
OUTPut:PROTection:CLEar 64
[SOURce:]CURRent[:IMMediate] [SOURce:]CURRent:TRIGgered 65
[SOURce:]CURRent:LIMit[:IMMediate] [SOURce:]CURRent:LIMit:TRIGgered 65
[SOURce:]CURRent:LIMit:BWIDth 65
[SOURce:]CURRent:MODE [SOURce:]CURRent:LIMit:MODE 66
[SOURce:]DELay 66
[SOURce:]DELay:MODE 66
[SOURce:]FUNCtion:MODE 67
[SOURce:]VOLTage:ALC:BWIDth 67
[SOURce:]VOLTage[:IMMediate] [SOURce:]VOLTage:TRIGgered 67
[SOURce:]VOLTage:MODE 68
[SOURce:]VOLTage:PROTection:STATe 68
Status Commands 69
STATus:OPERation[:EVENt]? 69
STATus:OPERation:CONDition? 69
STATus:OPERation:ENABle 69
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

10
STATus:OPERation:NTR STATus:OPERation:PTR 70
STATus:PRESet 70
STATus:QUEStionable[:EVENt]? 70
STATus:QUEStionable:CONDition? 71
STATus:QUEStionable:ENABle 71
STATus:QUEStionable:NTR STATus:QUEStionable:PTR 71
System Commands 72
SYSTem:ERRor? 72
SYSTem:VERSion? 72
Trigger Commands 73
ABORt 73
INITiate:NAME 73
TRIGger:ACQuire 73
TRIGger:ACQuire:SOURce 74
TRIGger[:TRANsient]:SOURce 74
TRIGger[:TRANsient] 74
Common Commands 75
*CLS 75
*ESE 75
*ESR? 75
*IDN? 76
*OPC 76
*OPT? 76
*RST 77
*SRE 77
*STB? 77
*TRG 78
*TST? 78
*WAI 78
SPECIFICATIONS 79
Introduction 79
PERFORMANCE TESTS AND CALIBRATION 83
Introduction 83
Equipment Required 83
Performance & Verification Tests 84
Measurement Techniques 84
Electronic Load 85
Programming 85
Test Setup 85
Voltage Priority Tests 86
Voltage Programming and Readback Accuracy 86
Positive Current Limit (+CL) 86
Negative Current Limit (-CL) 87
Current Priority Tests 88
Current Programming and Readback Accuracy 88
Load Effect Tests 89
Voltage Priority, Constant Voltage Load Effect 89
Voltage Priority, +Current Limit Load Effect 90
Voltage Priority, -Current Limit Load Effect Test 90
Current Priority Constant Current Test 91
Source Effect Tests 91
Voltage Priority, Constant Voltage Source Effect 91
Voltage Priority, +Current Limit Source Effect 92
Voltage Priority, -Current Limit Source Effect 92
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

11
Current Priority, Constant Current Source Effect 93
Ripple and Noise Tests 94
Voltage Priority Ripple and Noise 94
Current Priority Ripple and Noise 95
Transient Response Tests 95
Voltage Priority, Transient Recovery Time 95
Current Priority Transient Recovery Time 96
Performance Test Equipment Form 97
Performance Test Record Form 98
Performing the Calibration Procedure 99
Enable Calibration Mode 99
Voltage Priority Mode Programming and Measurement Calibration 99
Negative Current Limit Calibration 100
Positive Current Limit Calibration 100
0.5A Range Current Measurement Calibration 100
15mA Range Current Measurement Calibration 101
Current Priority Mode Programming and 0.5mA Range Measurement Calibration 101
Saving the Calibration Constants 101
Changing the Calibration Password 102
Calibration Error Messages 102
ERROR MESSAGES 103
Error Number List 103
LINE VOLTAGE SELECTION 107
EARLIER VERSION OUTPUT CONNECTORS 109
Mating Connector Part Numbers 109
Rear Panel Pinout Assignments 109
INDEX 111
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

13
1
General Information
Document Orientation
This manual describes the operation of the Agilent Model N3280A Component Test DC Source. Unless
otherwise noted, the unit will be referred to by the description "dc source" throughout this manual.
The following Getting Started Map is a general guide to the location of information in this manual. Refer
to the table of contents or index for a complete list of information.
Getting Started Map
Task Where to find information
General information
Capabilities and characteristics
Chapter 1
Installing the unit
Line connections
Load connections
Computer connections
Chapter 2
Checking out the unit
Verifying proper operation
Chapter 3
Using the programming interface
GPIB interface
Chapter 4
Programming the unit using SCPI commands
SCPI commands
SCPI programming examples
SCPI language dictionary
Chapters 5 and 6
Specifications Appendix A
Verifying and Calibrating the Unit Appendix B
Safety Considerations
This dc source is a Safety Class 1 instrument, which means it has a protective earth terminal. That
terminal must be connected to earth ground through a power source equipped with a ground receptacle.
Refer to the Safety Summary page at the beginning of this guide for general safety information. Before
installation or operation, check the dc source and review this guide for safety warnings and instructions.
Safety warnings for specific procedures are located at appropriate places in the guide.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 - General Information
14
Options and Accessories
Table 1-1. Options
Option Description
100 87−106 Vac, 47−63 Hz
220 191−233 Vac, 47−63 Hz
230 207−253 Vac, 47−63 Hz
8ZL Add instrument feet - for bench mounting (p/n 5041-9167)
AXS1Rack mount kit for two side-by-side N3280A units. Consists of:
Lock-link kit (p/n 5061-9694), Flange kit (p/n 5063-9212), Tie bracket (p/n 5002-1587)
1CM1Rack mount kit for one unit (p/n 5063-9240)
1Support rails are required when rack mounting units. Use E3663A support rails for Agilent rack cabinets. If you are
using non-Agilent rack cabinets, contact the rack manufacturer to obtain support rails for your cabinet.
Table 1-2. Accessories
Item Part Number
GPIB cables 1.0 meter (3.3 ft) Agilent 10833A
2.0 meters (6.6 ft) Agilent 10833B
4.0 meters (13.2 ft) Agilent 10833C
0.5 meters (1.6 ft) Agilent 10833D
Rack mount with slide - for two side-by-side units Order 5063-9255 and 1494-0015
Rack mount with slide - for one unit Order 5063-9255, 1494-0015, and 5002-3999
Description
The Agilent Model N3280A Component Test DC Source is a quad output dc power supply designed to
simplify the testing of integrated circuits. It has the following key features and performance capabilities:
♦High density – four isolated outputs in a 2U half-rack package
♦Four quadrant bipolar output
♦High programming and measurement accuracy (refer to Appendix A)
♦Active guard available for accurate current measurements
♦Solid-state output and sense terminal disconnect relays
♦High GPIB throughput
Additional features include:
♦Positive and negative overvoltage protection shutdown
♦Over-temperature and oscillation protection
♦Programmable current limit in voltage priority mode
Remote Programming
NOTE: With the exception of the power switch, there are no front panel controls for the Agilent
N3280A dc source. The N3280A can be controlled only with SCPI programming commands.
The dc source may be remotely programmed via the GPIB bus. GPIB programming is with SCPI
commands (Standard Commands for Programmable Instruments), which make dc source programs
compatible with those of other GPIB instruments. Dc source status registers allow remote monitoring of a
wide variety of operating conditions. Refer to chapters 5 and 6 for more information.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

General Information - 1
15
Output Characteristics
Voltage Priority Operation
Each Agilent N3280A output is a four-quadrant bipolar dc source that can be operated in either voltage
or current priority mode. In voltage priority mode the output is controlled by a bi-polar constant voltage
feedback loop, which maintains the output voltage at its positive or negative programmed setting. The
output voltage will remain at its programmed setting as long as the load current remains within the
positive or negative current limit. A single positive value programs both the positive and negative current
limit.
Figure 1-1 shows the voltage priority operating characteristics of the dc source. The area in quadrants 1
and 3 shows the characteristics of the output when it is being operated as a source (sourcing power). The
area in quadrants 2 and 4 shows the characteristics of the output when it is being operated as a load
(sinking power).
Output
Current
+ 512.5mA
+ 10.25V
V setting
1+
-
+
-
- 512.5mA
- 10.25V
Output
Voltage
3
2
4
- OV
+ OV
-I limit
+I limit
Key
Sourcing power
Sinking power
Programmable
Figure 1-1. Output Characteristic (Voltage Priority)
The heavy line illustrates the locus of possible operating points as a function of the output load, which
may be purely resistive, or possibly include external voltage or current sources. In voltage priority mode,
the constant voltage loop will regulate the output voltage as the load changes, unless the output current
attempts to exceed the current limit setting.
If this occurs, either the negative or the positive current limit loop will regulate the output current at the
programmed value. Either a CV (constant voltage), CL+ (positive current limit), or CL−(negative current
limit) status flag is set to indicate which loop is presently controlling the output.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 - General Information
16
If the output voltage exceeds either the positive or negative overvoltage set point, the output will shut
down and be disabled, automatically opening the output and sense relays. This leaves the output in a
high-impedance state.
The full ±512.5 milliampere output current is available only in voltage priority mode. In this mode, the
output voltage should be programmed to the desired positive or negative value. A positive current limit
value should also be programmed. Note that the negative current limit tracks the positive current limit set
point. The output will regulate at the desired voltage level, provided that the current limit has been set
higher that the actual output current requirement of the external load. Note that if the current limit is set
to a value between zero and 75 µA, the actual current limit will be ±75 µA. Thus, it is not possible to
program current limit values less than 75 µA in voltage priority mode. (This limitation does not apply in
current priority mode.)
Current Priority Operation
Each Agilent N3280A output is a four-quadrant bipolar dc source that can be operated in either voltage
or current priority mode. In current priority mode the output is controlled by a bi-polar constant current
feedback loop, which maintains the output current (source or sink) at its programmed setting. The output
current will remain at its programmed setting as long as the load voltage remains within the positive and
negative voltage limits. The voltage limits are not programmable and vary somewhat with the output
current. When the output current is zero, the voltage limits are typically ±10.75 V.
Figure 1-2 shows the current priority operating characteristics of the dc source. The area in quadrants 1
and 3 shows the characteristics of the unit when it is being operated as a source (sourcing power). The
area in quadrants 2 and 4 shows the characteristics of the unit when it is being operated as a load (sinking
power).
Output
Voltage
Output
Current
+ 0.5125mA
+ 10.75V
+
-
+
-
I setting
- 0.5125mA
+ 9.5V
+VL status set
Key
Sourcing power
Sinking power
Programmable
1
3
2
4
+ 12V
- 10.75V
-VL status set
- 12V
- 9.5V
-V limit
+V limit
Figure 1-2. Output Characteristic (Current Priority)
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

General Information - 1
17
The heavy line illustrates the locus of possible operating points as a function of the output load, which
may be purely resistive, or possibly include external voltage or current sources. In current priority mode,
the constant current loop will regulate the output current as the load changes, until the positive or
negative voltage limit is reached. A CC (constant current) status flag indicates when the current loop is
controlling the output.
If the output voltage reaches either the positive or negative voltage limit, the unit no longer operates in
constant current mode and the output current is no longer held constant. Instead, the output current is
limited at either the positive or negative voltage limit line. When the unit is sinking power, the output
voltage will continue to increase in the positive or negative direction as more current is forced into the
unit. Note that a VL+ (positive voltage limit) or VL−(negative voltage limit) status bit will be set to
register a voltage limit at about 0.8 V before the positive or negative voltage line is reached.
The maximum current available in current priority mode is about 0.5 mA, which is ideal for testing
sensitive devices such as input diodes. In this mode, the output current must be programmed to the
desired positive or negative value. However, the positive and negative voltage limits are not
programmable, and vary with the actual output current as shown in the figure. The typical positive
voltage limit ranges from about 10.75V at no load to about 9.5V at full load. The typical negative voltage
limit ranges from about –10.75V to about –9.5V.
NOTE: Overvoltage protection is not functional in current priority mode.
Measurement Characteristics
The N3280A uses a digitizing measurement system with a single timebase for all output channels. The
number of measurement samples and the sampling interval of the timebase can be explicitly programmed.
These values will apply to measurements taken on all outputs. For example, if simultaneous
measurements are made on four output channels and one of the three channels is set to one power line
cycle (PLC), then all three channels will be set to one power line cycle per measurement.
Conversely, each output channel of the N3280A has its own measurement buffer. This means that each
output can be configured to measure a different parameter (either voltage or current), and a different
current range. However, the number of measurement samples and sampling interval for each type of
measurement is the same for all channels.
There is one voltage measurement range and three current measurement ranges. The current range must
be selected explicitly. If a measured value exceeds the presently selected range, an error message is
returned. Voltage measurements and current measurements using the 0.5A or 15mA range can be made to
full accuracy using the default measurement sample (5 data points @30.4µs intervals = 152 µs). To
achieve full accuracy on the 0.5mA current range, a longer sampling interval of one power line cycle
(PLC) is required to filter out line noise. Thus, a full accuracy measurement on the 0.5mA current range
will typically take between 18 and 21.3 ms, depending on the line frequency.
Note that faster measurements using lower PLC values (<1) are only appropriate for loads that do not
draw currents with a significant noise component. If the load current is noisy, it may be necessary to
increase the sampling interval to provide additional filtering.
All voltage and current measurements return the average value of the samples taken. Measurements can
be made using either a Rectangular or Hanning window. The default Rectangular window is used on all
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

1 - General Information
18
measurement ranges to make fast measurements. The Hanning window can be used to reduce errors
caused by other periodic noise sources, provided that the sample period is long enough to capture three or
more noise waveform cycles. Using a Hanning window will result in slower measurement speed.
Start of a Measurement
The dc source delays the start of a measurement until a previous output voltage or current change has
settled. When voltage or current settings are changed in either voltage priority or in current priority
mode, an internal timer is started that delays any subsequent measurements. At power-on or after *RST
this delay allows the output to settle to better than 0.1% of its final value. In voltage priority mode, the
final value is based on a 20 ohm load. In current priority mode, the final value is based on a short-circuit
load.
The settling delay can also be explicitly programmed. This may be required, for example, if the load
requires more or less delay than the representative load or if the measurement requires less accuracy.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

19
2
Installation
Inspection
Damage
When you receive your dc source, inspect it for any obvious damage that may have occurred during
shipment. If there is damage, notify the shipping carrier and the nearest Agilent Sales and Support Office
immediately. The list of Agilent Sales and Support Offices is at the back of this guide. Warranty
information is printed in the front of this guide.
Packaging Material
Until you have checked out the dc source, save the shipping carton and packing materials in case the unit
has to be returned. If you return the dc source for service, attach a tag identifying the owner's name and
address, the model number, and a brief description of the problem.
Additional Items
Table 2-1. Items Supplied
Item Part Number Description
Power Cord contact the nearest Agilent
Sales and Support Office
A power cord appropriate for your location.
4 - Output
connectors
1253-4893 A 6-terminal connector plug for connecting the output,
sense, ground, and guard. The connector installs in the
back of the unit.
Trigger
connector
1252-8670 3-terminal digital plug for connecting the trigger input
signal. The connector installs in the back of the unit.
Line Fuse 2110-0638
2110-0773
3.15 AT (time delay) for 100/120 Vac operation
1.6 AT (time delay) for 220/230 Vac operation
User's Guide 5964-8248 This manual.
Cleaning
Use a dry cloth or one slightly dampened with water to clean the external case. Do NOT open the unit.
WARNING: To prevent electric shock, unplug the unit before cleaning.
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
