azur 851N User manual

Your music, our passion
851N
Network Player
azur

Contents
Important!
The 851N is largely a software based product and new features and
updates will be made available from time to time. See the Upgrade
Firmware section at the end of this manual for how to check for and then
automatically update your unit via the internet. The process takes only a
few minutes.
We would encourage you to check for any updates before using your 851N
for the rst time and then from time to time afterwards.
Also please do check the support page for the 851N at http://support.
cambridgeaudio.com for details of any new features, advice on
compatibility with other products and audio formats and the most recent
copy of this manual.
Make sure you register your purchase.
Visit: www.cambridge-audio.com/sts
By registering, you’ll be the rst to know about:
Future product releases
Software upgrades
News, events and exclusive offers plus
competitions!
This guide is designed to make installing and using this product as easy
as possible. Information in this document has been carefully checked for
accuracy at the time of printing; however, Cambridge Audio’s policy is one
of continuous improvement, therefore design and specications are subject
to change without prior notice.
This document contains proprietary information protected by copyright.
All rights are reserved. No part of this manual may be reproduced by any
mechanical, electronic or other means, in any form, without prior written
permission of the manufacturer. All trademarks and registered trademarks
are the property of their respective owners.
© Copyright Cambridge Audio Ltd 2015.
Cambridge Audio and the Cambridge Audio logo are trademarks of
Cambridge Audio.
Stream Magic is a trademark of Audio Partnership Plc and is registered in
the European Community and other countries.
This product contains software licensed under version 2 of the GNU Public
License and version 2.1 of the GNU Lesser Public License. The source code
for this software is available from:
http://gpl.stream-magic.com/
This product includes technology owned by Microsoft Corporation and
under a licence from Microsoft Licensing GP. Use or distribution of such
technology outside of this product is prohibited without a license from
Microsoft Corporation and/or Microsoft Licensing, GP as applicable.
The Spotify software is subject to third party licenses found here:
www.spotify.com/connect/third-party-licenses.
Important safety instructions ......................................................................................3
Wi-Fi information ..........................................................................................................4
Limited warranty...........................................................................................................5
Rear panel connections...............................................................................................6
Front panel controls.....................................................................................................7
Remote control.............................................................................................................8
Overview .......................................................................................................................9
Getting connected........................................................................................................9
Operating instructions ...............................................................................................10
Presets........................................................................................................................10
Radio...........................................................................................................................10
Music Library ..............................................................................................................11
Inputs ..........................................................................................................................12
USB audio...................................................................................................................12
BT100 and Bluetooth audio streaming ....................................................................12
Spotify .........................................................................................................................13
Settings menu ............................................................................................................14
Network.......................................................................................................................14
Wired/Wireless connection .......................................................................................15
Display brightness......................................................................................................15
Device name...............................................................................................................15
Audio ...........................................................................................................................15
USB audio class .........................................................................................................15
System remote control...............................................................................................15
Instant on....................................................................................................................16
Automatic power down...............................................................................................16
Edit digital input names.............................................................................................16
Factory reset...............................................................................................................16
Technical specications.............................................................................................17
Troubleshooting..........................................................................................................18
2

851Nazur
For your own safety please read the following important safety instructions carefully
before attempting to connect this unit to the mains power supply. They will also
enable you to get the best performance from and prolong the life of the unit:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding-type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. If the provided plug does not t into your
outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, particularly at plugs,
convenience receptacles and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the manufacturer.
12. Use with only the cart, stand, tripod, bracket, or table specied
by the manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/ apparatus
combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods
of time.
14. Refer all servicing to qualied service personnel. Servicing is required when
the apparatus has been damaged in any way, such as the power-supply cord or
plug having been damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
WARNING
– To reduce the risk of re or electric shock, do not expose this unit to rain or
moisture.
– Batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, re or the like.
The unit is of Class 1 construction and must be connected to a mains socket outlet
with a protective earthing connection.
The unit must be installed in a manner that makes disconnection of the mains
plug from the mains socket outlet (or appliance connector from the rear of the unit)
possible. Where the mains plug is used as the disconnect device, the disconnect
device shall remain readily operable. Only use the mains cord supplied with this
unit.
Please ensure there is ample ventilation (at least 10cm clearance all round). Do
not put any objects on top of this unit. Do not situate it on a rug or other soft surface
and do not obstruct any air inlets or outlet grilles. Do not cover the ventilation grilles
with items such as newspapers, tablecloths, curtains, etc.
This unit must not be used near water or exposed to dripping or splashing water
or other liquids. No objects lled with liquid, such as vases, shall be placed on the
unit.
Important safety instructions
The lightning ash with the arrowhead symbol within an equilateral triangle is
intended to alert the user to the presence of un-insulated ‘dangerous voltage’
within the product’s enclosure that may be of sufcient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to
the presence of important operating and maintenance instructions in the service
literature relevant to this appliance.
WEEE symbol
The crossed-out wheeled bin is the European Union symbol for
indicating separate collection for electrical and electronic equipment.
This product contains electrical and electronic equipment which
should be reused, recycled or recovered and should not be disposed
of with unsorted regular waste. Please return the unit or contact the
authorised dealer from whom you purchased this product for more
information.
CE mark
This product complies with European Low Voltage (2006/95/EC),
Electromagnetic Compatibility (2004/108/EC) and Environmentally-
friendly design of Energy-related Products (2009/125/EC) Directives when used
and installed according to this instruction manual. For continued compliance only
Cambridge Audio accessories should be used with this product and servicing must
be referred to qualied service personnel.
C-Tick mark
This product meets the Australian Communications Authority’s Radio
communications and EMC requirements.
CU-TR Mark
This product meets Russia, Byelorussia and Kazakhstan electronic
safety approvals.
Ventilation
IMPORTANT – The unit will become hot when in use. Do not stack multiple units
on top of each other. Do not place in an enclosed area such as a bookcase or in a
cabinet without sufcient ventilation.
Ensure that small objects do not fall through any ventilation grille. If this happens,
switch off immediately, disconnect from the mains supply and contact your dealer
for advice.
Positioning
Choose the installation location carefully. Avoid placing it in direct sunlight or close
to a source of heat. No naked ame sources, such as lighted candles, should be
placed on the unit. Also avoid locations subject to vibration and excessive dust,
cold or moisture. The unit can be used in a moderate climate.
This unit must be installed on a sturdy, level surface. Do not place in a sealed area
such as a bookcase or in a cabinet. Do not place the unit on an unstable surface or
shelf. The unit may fall, causing serious injury to a child or adult as well as serious
damage to the product. Do not place other equipment on top of the unit.
Due to stray magnetic elds, turntables or CRT TVs should not be located nearby
due to possible interference.
Electronic audio components have a running in period of around a week (if used
several hours per day). This will allow the new components to settle down and the
sonic properties will improve over this time.
Power sources
the marking label. If you are not sure of the type of power-supply to your home,
consult your product dealer or local power company.
This unit can be left in Standby mode when not in use and will draw <0.5W in this
state. To turn the unit off, switch off at the rear panel. If you do not intend to use
this unit for a long period of time, unplug it from the mains socket.
3

Wi-Fi information
FCC Statement
Caution: Exposure to Radio Frequency Radiation.
The device shall be used in such a manner that the potential for human contact
during normal operation is minimized.
When connecting an external antenna to the device, the antenna shall be placed
in such a manner to minimize the potential for human contact during normal
operation. This transmitter must not be co-located or operating in conjunction with
any other antenna or transmitter.
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy, and if
not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try and correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modications not expressly approved by the
party responsible for compliance could void the user’s authority to operate this
equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with a
minimum distance of 20cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
2 .4GHz operation of this product in the USA is rmware-limited to channels 1
through 11.
Modications
The FCC requires the user to be notied that any changes or modications to this
device that are not expressly approved by Cambridge Audio, may void the user’s
authority to operate the equipment.
Canada-Industry Canada (IC)
This Class B digital apparatus complies with Canadian ICES-003
This device complies with Industry Canada licence-exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.
Under Industry Canada regulations, this radio transmitter may only operate using
an antenna of a type and maximum (or lesser) gain approved for the transmitter by
Industry Canada. To reduce potential radio interference to other users, the antenna
type and its gain should be so chosen that the equivalent isotropically radiated
power (e.i.r.p.) is not more than that necessary for successful communication.
This radio transmitter 9095A-MXI01 has been approved by Industry Canada to
operate with the antenna types listed below with the maximum permissible gain
and required antenna impedance for each antenna type indicated. Antenna types
not included in this list, having a gain greater than the maximum gain indicated for
that type, are strictly prohibited for use with this device.
C059-510137-A; Antenna+RG-178 Cable+SMA Plug Reverse, 3.0dBi, 50Ω
DECLARATION OF CONFORMITY WITH FCC RULES FOR ELECTROMAGNETIC
COMPATIBILITY
We, Cambridge Audio, of Gallery Court, Hankey Place, London SE1 4BB,
declare under our sole responsibility that this device,
851N with external EW-7711UAn Wi-Fi Dongle
to which this declaration relates, complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Overloading
Do not overload wall outlets or extension cords as this can result in a risk of re
or electric shock. Overloaded AC outlets, extension cords, frayed power cords,
damaged or cracked wire insulation and broken plugs are dangerous. They may
result in a shock or re hazard.
Be sure to insert each power cord securely. To prevent hum and noise, do not
bundle the interconnect leads with the power cord or speaker leads.
Cleaning
To clean the unit, wipe its case with a dry, lint-free cloth. Do not use any cleaning
uids containing alcohol, ammonia or abrasives. Do not spray an aerosol at or
near the unit.
Battery disposal
Batteries may contain substances harmful to the environment. Please dispose
of any discharged batteries with due consideration and in accordance with local
environmental/electronic recycling guidelines.
Loudspeakers
Before making any connections to loudspeakers, make sure all power is turned off
and only use suitable interconnects.
Servicing
These units are not user serviceable. Never attempt to repair, disassemble or
reconstruct the unit if there seems to be a problem. A serious electric shock could
result if this precautionary measure is ignored. In the event of a problem or failure,
please contact your dealer.
4

851Nazur
This equipment complies with RSS-102 limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum
distance of 20cm between the radiator and your body.
Cet appareil numérique de Classe B est conforme à la norme Canadienne ICES-
003
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage
est susceptible d'en compromettre le fonctionnement.
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio
peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur)
approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les
risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut
choisir le type d'antenne et son gain de sorte que la puissance isotrope rayonnée
équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une
communication satisfaisante.
Le présent émetteur radio 9095A-MXI01 a été approuvé par Industrie Canada
pour fonctionner avec les types d'antenne énumérés ci-dessous et ayant un gain
admissible maximal et l'impédance requise pour chaque type d'antenne. Les
types d'antenne non inclus dans cette liste, ou dont le gain est supérieur au gain
maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur.
C059-510137-A; Antenna+RG-178 Cable+SMA Plug Reverse, 3.0dBi, 50Ω
Cet équipement est conforme a RSS-102 limites énoncées pour un environnement
non contrôlé. Cet équipement doit être installé et utilisé avec une distance
minimale de 20 cm entre le radiateur et votre corps.
IMPORTANT NOTE:
IC Radiation Exposure Statement:
This equipment complies with Canada radiation exposure limits set forth for
uncontrolled environments. This equipment should be installed and operated with
a minimum distance of 20cm between the radiator and your body.
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Cet appareil numérique de la classe B conforme á la norme NMB-003 du Canada.
Europe-European Union Notice
Radio products with the CE 0889 or CE alert marking comply with the R&TTE
Directive (1995/5/EC) issued by the Commission of the European Community.
Compliance with this directive implies conformity to the following European Norms.
• EN 60065 – Product Safety.
• EN 300 328 – Technical requirement for radio equipment.
• EN 301 489 – General EMC requirements for radio equipment.
To determine the type of transmitter, check the identication label on your
Cambridge Audio product.
Products with the CE marking comply with European Low Voltage (2006/95/EC),
Electromagnetic Compatibility (2004/108/EC) and Environmentally-friendly design
of Energy-related Products (2009/125/EC) Directives issued by the Commission of
the European Community. Compliance with these directives implies conformity to
the following European Norms.
• EN 55022 – Electromagnetic Interference.
• EN 55024 – Electromagnetic Immunity.
• EN 61000-3-2 – Power Line Harmonics.
• EN 61000-3-3 – Power Line Flicker.
• EN 60065 – Product Safety. Products that contain the radio transmitter are
labeled with CE 0889 or CE alert marking and may also carry the CE logo.
• EN 62301:2005 - Household electrical appliances. Measurement of standby
power.
• 1275/2008 - Implementing EuP Directive for Standby Power Consumption.
Cambridge Audio warrants this product to be free from defects in materials and
workmanship (subject to the terms set forth below). Cambridge Audio will repair
or replace (at Cambridge Audio’s option) this product or any defective parts in this
product. Warranty periods may vary from country to country. If in doubt consult your
dealer and ensure that you retain proof of purchase.
To obtain warranty service, please contact the Cambridge Audio authorised dealer
from which you purchased this product. If your dealer is not equipped to perform
the repair of your Cambridge Audio product, it can be returned by your dealer to
Cambridge Audio or an authorised Cambridge Audio service agent. You will need
to ship this product in either its original packaging or packaging affording an equal
degree of protection.
Proof of purchase in the form of a bill of sale or receipted invoice, which is evidence
that this product is within the warranty period, must be presented to obtain
warranty service.
This Warranty is invalid if (a) the factory-applied serial number has been altered or
removed from this product or (b) this product was not purchased from a Cambridge
Audio authorised dealer. You may call Cambridge Audio or your local country
Cambridge Audio distributor to conrm that you have an unaltered serial number
and/or you made a purchase from a Cambridge Audio authorised dealer.
This Warranty does not cover cosmetic damage or damage due to acts of God,
accident, misuse, abuse, negligence, commercial use, or modication of, or to
any part of, the product. This Warranty does not cover damage due to improper
operation, maintenance or installation, or attempted repair by anyone other than
Cambridge Audio or a Cambridge Audio dealer, or authorised service agent which
is authorised to do Cambridge Audio warranty work. Any unauthorised repairs will
void this Warranty. This Warranty does not cover products sold AS IS or WITH ALL
FAULTS.
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY ARE THE
EXCLUSIVE REMEDY OF THE CONSUMER. CAMBRIDGE AUDIO SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY IN THIS PRODUCT. EXCEPT TO THE EXTENT
PROHIBITED BY LAW, THIS WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER
EXPRESS AND IMPLIED WARRANTIES WHATSOEVER INCLUDING, BUT NOT LIMITED
TO, THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL
PURPOSE.
Some countries and US states do not allow the exclusion or limitation of incidental
or consequential damages or implied warranties so the above exclusions may not
apply to you. This Warranty gives you specic legal rights, and you may have other
statutory rights, which vary from state to state or country to country.
For any service, in or out of warranty, please contact your dealer.
Limited warranty
5
