AzureWave AW-GA800BT User manual

AW-GA800BT802.11b/gUSBWirelessModule
UserGuide

ii
COPYRIGHT
AzureWaveTechnologies,Inc.Allrightsreserved.Nopartofthisdocumentmaybereproduced,
transmitted,transcribed,storedinaretrievalsystem,ortranslatedintoanylanguageinany
formorbyanymeanswithout thewrittenpermissionofAzureWaveTechnologies, Inc.
DISCLAIMER
AzureWaveprovidesthisdocument asis”, without warrantyof anykind, neitherexpressed nor
implied, including, butnot limitedto,theparticularpurpose. AzureWavemaymake
improvementsand/orchangesinthisdocument orinthe productdescribed inthisdocument at
anytime.Thisdocumentcouldinclude technicalinaccuraciesortypographicalerrors.
TRADEMARKS
AzureWaveisatrademarkofAzureWaveTechnologies, Inc. Othernamesmentioned inthis
document aretrademarks/registeredtrademarksoftheirrespectiveowners.
USINGTHISDOCUMENT
ThisdocumentprovidesdetaileduserguidelinestoprovideAzureWave802.11b/gUSB WLAN
Moduleoperation andsetting-up. Thougheveryefforthasbeen madetoassurethat this
documentis currentandaccurate,moreinformationmayhavebecomeavailablesubsequent to
theproductionof thisguide. Inthat event, pleasecontact yourAzureWaverepresentativefor
additionalinformationthat mayhelpinthedevelopmentprocess.

iii
Contents
Safetystatements...........................................................................................................2-1
About thisguide..............................................................................................................2-1
AW-GA800BT802.11b/gUSBWLANModule specificationsummary..................................2-2
Chapter 1 ProductInformation.......................................................................................2-2
1.1Product overview................................................................................................2-2
1.2 Features.............................................................................................................2-2
1.3LEDandantenna port............................................................. 誤! 尚未定義書籤。
1.4Supportednetworksetup....................................................................................2-3
1.4.1Ad-Hoc mode............................................................................................2-3
1.4.2Infrastructure mode..................................................................................2-4
1.4.3Softwareaccesspoint (SoftAP).................................................................2-5
Chapter 2 Installation....................................................................................................2-1
2.1Systemrequirements..........................................................................................2-1
2.2HardwareInstallation..........................................................................................2-1
Chapter 3 Wi-SetWizard...............................................................................................3-2
3.1LaunchWi-Set Wizard.........................................................................................3-2
3.2Wi-SetupWizard Steps........................................................................................3-4
3.3StationMode Configuration.................................................................................3-4
3.3.1 Configure Infrastructure typenetwork........................................................3-5
3.3.2BuildAd-Hocnetworkingmodenetwork.....................................................3-6
3.4BuildSoftAPnetwork.........................................................................................3-8
3.4.1Normal User..............................................................................................3-8
3.4.2AdvancedUser.........................................................................................3-11
Chapter 4 RtWLAN:WirelessLANManagement GUI........................................................4-1
4.1 HowtoLaunchRtWLAN......................................................................................4-2
4.2IntroductionofMainWindow...............................................................................4-2
4.3 Stationmode......................................................................................................4-6
4.3.1InfrastructureandAd-Hoc.........................................................................4-6
4.4 APmode...........................................................................................................4-11
4.5 WindowsZeroConfiguration...............................................................................4-14
4.5.1SwapfromRtWLANtoWindowsZeroConfiguration...................................4-14
4.5.2RollbackfromWindowsZeroConfigurationtoRtWLAN...............................4-15
AppendixA: Mappingofcountryandchannelplan........................................................4-1
AppendixB: Q&A........................................................................................................4-4
AppendixC: ReleaseHistory........................................................................................4-5

2-
1
Safety statements
FCC RadiationExposureStatement:
ThisequipmentcomplieswithFCC radiation exposurelimitsset forthforan uncontrolled
environment. This transmittermust not beco-locatedoroperatingin conjunction withanyother
antenna ortransmitter.
Aboutthisguide
Theuserguide containstheinformation youneed toinstall andconfigureyourAzureWave
802.11b/gUSB WLANModule.
Guideorganization
Thisguide containsthefollowingchapters:
l Chapter1:Product Information
Thischapterdescribesthegeneralfunctionality,featuresandconfigurationmodesof
AzureWave802.11b/gUSB WLAN Module.
l Chapter2:Installation
It isrecommendedthat usersshouldread thischapterbeforeinstalling bothAzureWave
802.11 b/gUSB WLAN Modulehardwareandsoftware.Thischapterpresentsthe
systematicinstallationof AzureWave802.11b/gUSB WLAN Moduleandantenna, utilities
anddriveronthesupport CD.
l Chapter3: W-Set Wizard
Thischaptershowsyouthe setupofwirelessnetworkinyourofficeorhome. FollowThe
step-by-stepdirection,providedby Wi-Set wizard,youcan haveyourownwirelesslocal
areanetworkupand runningveryquickly.
l Chapter4:Management GUI
Thischapterteachesyoutheproperoperationsofselected modefromW-SetWizard.The
GUIdisplaynetworkstatus,connectionprofilesand networktraffictohelpyou monitorand
managethenetworkconfiguration.

2-
2
AzureWave802.11 b/g USB WLAN Modulespecificationsummary
Hostsystemconnections
Interface FullycomplieswithUSB2.0or1.1
USB datetransferrate USB highspeed (480Mbps), and full speed(12Mbps)
Chapter1ProductInformation
1.1 Productoverview
Thankyoufor choosing AzureWave802.11b/gUSB WLAN Module.
TheAzureWave802.11b/gUSB WLAN Moduleisan easy-to-usewireless localareanetwork
(WLAN)adapterwhichisdesignedforhomeorofficeuse.DirectSequenceSpreadSpectrum
(DSSS), ComplementaryCodeKeying(CCK), and OrthogonalFrequencyDivisionMultiplexing
(OFDM)basebandprocessing areimplementedtosupportall IEEE802.11b,and 802.11gdata
rates.Differentialphaseshiftkeying modulationschemes,DBPSK andDQPSK withdata
scramblingcapability,areavailable, alongwithcomplementarycodekeying toprovidedata
ratesof1, 2,5.5,and11Mbps,withlongorshort preamble.Ahigh-speedFast Fourier
Transform(FFT)/InverseFastFourierTransform(IFFT)combinedwithBPSK, QPSK, 16QAM
and64QAMmodulationof the individualsub-carriersprovidesdataratesof 6,9, 12, 18, 24,36,
48and54Mbps, withrate-compatiblepuncturedconvolutioncodingwithacodingrateof 1/2,
2/3, and 3/4.
TheAzureWave802.11b/gUSB WLAN Modulealso supportsWake-On-LAN(WOL)function
andremotewake-upgivingyou the conveniencetoremotelog infromotherplacestothis
system.
Toprovide efficientsecuritytoyourwireless communication,thehardware-basedIEEE 802.11i
encryption/decryptionengine, including 64-bit/128-bitWEP,TKIP, and AES, supportsWi-Fi
alliance WPA andWPA2security.
Withthesefeaturesand manymore, AzureWave802.11b/gUSB WLAN Moduleis readyto
connectyoutothe worldof wirelesscommunication.
1.2 Features
Systemrequirements

2-
3
TheAzureWave802.11b/gUSB WLAN Moduleisanon-boardcomponenton ASUS
motherboardrequiringmanualinstallation. Makesurethatyoursystemmeetsthe following
requirements.
l ASUSmotherboardwithAzureWave802.11b/gUSB WLANModuleon-boardsolution
l Minimum64MBsystemmemory
l Operatingsystem
Station mode:Windows®2000/XP/Server2003,WindowsXP/Server2003x64
AP/wirelessbridgemode :Windows®2000/XP/Server2003
l Opticaldriveforutilitiesanddriverinstallation
Easyhardwareinstallation
Becausethe AzureWave802.11b/gUSB WLANModulecomesembeddedinmotherboard,
nohardwareinstallationisnecessary.Justconnecttheantenna, installthe driverand utilities
fromthemotherboardsupportCD and start wireless communicationimmediately.
54Mbpsspeedwirelesstravel
TheAzureWave802.11b/gUSB WLANModuleprovidesuptofive timesmore data
transmissionthanIEEE802.11bstandards,andbreaksthe wirelesstransmissionbarrierto
speedupthe internetconnection.
Wi-SetWizard
Easy-usewirelessLANsetupwizardhelpsyoutoconnect withpresent wirelessnetwork. The
step-by-stepwizardprovidesaconvenient waytofacilitatethe complexwireless LANsetup
process.
Automaticwirelessestablishment
Theutility application ofAzureWaveRTL8187 Wireless LANUSB 2.0Adapterautomatically
searchesandreportsthehotspotsaround itandthewireless signalqualityandWEPcapability
associatedwitheachhotspot. Then youcouldconnect tothemostsuitablewirelessnode
1.3 Supportednetwork setup
Youcan useAzureWave802.11b/gUSB WLAN Moduleinvariouswirelessnetwork
configurations.Werecommend youtoselectthemostappropriateconfigurationforyourhome
orofficenetworkbeforesetting it up.
1.3.1Ad-Hoc mode

2-
4
Ad-Hocwireless networksbringtogether
workstationsandcomputerstoactas
serverstoallotherusersonthenetwork
withoutcomplexinfrastructure, setup or
administration.Usersonthenetworkcan
sharefiles,printers.Wheninadhocmode,
theAzureWave802.11 b/gUSB WLAN
Moduleconnectstoanotherwireless
devicewithinits effective rangeand
communicateswitheachotherinthesame
LAN workgroup.Selectthisconfiguration
whennoaccesspoint ispresentinyour
wirelessnetwork.
1.3.2Infrastructuremode
Thebiggestdifferencebetween
infrastructuremode and ad-hocmodeis
that it includesanaccesspoint. In
infrastructuremode, an accesspoint
establishesthenetworkthat provides
wirelesslinksinthe validatingrangefor
clientsto communicatewitheachotheror
withawired networktotheinternet. Onan
infrastructurenetwork,the access point
maymanagethebandwidthtomaximizeutilization. Infrastructurenetworking hasthefollowing
advantagesoverad-hocnetworking:
l RangeExtension
Eachwireless LANenabledcomputerwithinthe range oftheaccesspointcancommunicate
withotherwirelessLAN enabledcomputerswithinthe validrangeof signalfromtheaccess
point.
l Roaming
Awireless LANenabledcomputercanphysicallymovefromtheoperatingrangeof one
accesspoint toanotherwithout losing connection totheLAN. Aquickassociation
hand-shake”ismadebetween the newaccesspointand thewireless deviceasthe
computertraversesfromthecoverageofone accesspoint toanother.
l Wired towirelessLAN connectivity
RealTek RTL8187L
Mobil station 1
Mobil station 2
ADSLModem
RealTek RTL8187L
Access Point
ADSLModem
Mobilstation 1

2-
5
Accesspointestablishesthebridgebetween wireless LAN and otherwiredcounterparts.
1.3.3Softwareaccess point (Soft AP)
YoucouldconfigureAzureWave802.11
b/gUSB WLANModuleasasoftware
accesspoint (soft AP). Inthismode, the
AzureWave802.11b/gUSB WLAN
Moduleactsastheaccesspoint that
provideswireless linksinthe validating
range toclientstationstotheinternet.
Yoursystemshouldsatisfythefollowing
tworequirementstoapply thismode:
l The systemyou use alreadyconnects
totheinternetorintranetthroughanotheroneEthernet adapter.
l Youareusing Windows®2000, XPorServer2003 operationsystem
Notice:WindowsXP/Server2003 x64 platformsare notsupported tohave softwareaccesspoint
capability.
RealTek RTL8187L
Mobil station 2AccessPoint
ADSLModem
Mobilstation 1

2-
1
Chapter2Installation
2.1 Systemrequirements
BeforeinstallingtheAzureWave802.11b/gUSB WLAN Module, driverand utilities,makesure
yoursystemsatisfythefollowingrequirements
l ASUSmotherboardwithAzureWave802.11b/gUSB WLANModulespecificslot
l Intel®Pentium™4
l Minimum64MBsystemmemory
l Windows®Operation System
Ad-Hocandinfrastructuremode:Windows®2000, XP and Server2003
SoftwareAPand Wireless Bridge:Windows®XPandServer2003
l Opticaldrivefordriverand utilitiesinstallation
2.2 HardwareInstallation
Tocompletethehardwareinstallationof AzureWave802.11 b/gUSB WLANModule, you only
need toinstallthemoveabledipolarantennaat therearof
motherboard.
Installing theantenna:
l LocatethewirelessLAN antenna port on themotherboard
rearpanel.
l Connecttheantennatwist-onconnector(female)tothe
wireless LAN antenna port(male)
l Placethe antenna atanelevatedlocationtoenhanceyour
wireless LANvalidcoverage.

3-
2
Chapter3Wi-SetWizard
3.1 LaunchWi-SetWizard
Inthis section,you will obtaindetail instruction insettingwireless configurationbyfollowing
Wi-SetWizard. PleaserefertoChapter1.4tounderstand thenetworktypestheAzureWave
802.11b/gUSB WLANModulesupports.
Inthefirst timeinstallation,Wi-SetWizardisexecutedimmediatelyafterinstallation tohelpyou
settheproperwirelessconfiguration.
Inaddition,youcouldlaunchit fromeitherprogrammenu
orWireless LANManagement GUI.
Inthefollowingsections, werepresentthe steps,theconvenient and easywireless setup,in

3-
3
Wi-SetWizard.

3-
4
3.2 Wi-SetupWizardSteps
Whateverwhichwireless configuration
you wouldsetup, thefirstscene of
Wi-SetWizardis SelectOperation
Mode”dialogthatshowsasright picture.
Youcouldselect eitherstation orAP
modefromthefirststep.
ForAd-hocandinfrastructuretype
configuration, you shouldselect Station
mode.Thesoftwareaccess point
configurationcouldbearchivedbyselect
APmode.
l Station
Set theoperationmode tobe Station”. Followstepsinsection4.3.
l AP
Set theoperationmode tobe Access Point”.Followstepsinsection4.4.
l Next
Gotonextstep ofselectedmode.
l Cancel
Giveup Wi-Set Wizard. The default wirelessconfigurationwillbeautomatically appliedas
Infrastructure”type of Stationmodeifuserwon’tset it up here.
3.3 StationModeConfiguration
Twotypes,infrastructureandad-hoctypes,
ofstationmodeareprovidedhere.
l Infrastructure
Configurethewirelessasinfrastructure
typenetwork. Followstepsin4.3.1
BuildInfrastructuretypenetwork.
l Ad-Hoc

3-
5
ConfigurethewirelessasAd-Hoctypenetwork.Followstepsin4.3.2BuildAd-Hoc
networkingmodenetwork
l Back
Gobacktopreviousstep –SelectOperationMode.
l Next
Gotonextstepsof selected type.
l Cancel
Giveup Wi-Set Wizardand keepthelastconfiguration.
3.3.1ConfigureInfrastructuretype network
ItiseasytobuildupinfrastructuretypenetworkwithWi-Set Wizard. The nextstep afterselect
infrastructuretypenetworkistoselect thedesiredconnection.
SelecttheBSS connectionlist
Selectvalidwireless BSS,Infrastructure
BasicServiceSet,connectionnearby
yoursystemforconnecting. The listed
BSS aretouchableaccesspoint around
you.Youhavetopickonefromthelist
andgotonext.
l SSID listbox
Fourfieldsareshowninthelist box
toprovideaccess pointstatus.
n SSID: thenameofaccess point
n Security:thesecurity statusofaccesspoint.Nonemeanssecurity/passwordisnotnecessary.WEP
meanstheaccesspointacquiresecurity/passwordtologin.
n Channel:thechannelthisaccess pointapplies.
n Signal:Thesignalstrength;highermeanbetter.
l Refresh
Rescanthe IBSS list.
l Back
Gobacktopreviousstep ~SelectStationType.

3-
6
l Next
Gotonextstep of infrastructuretypeconfiguration. It isrelativethe securitystatusof
selected access point.
n None:SetupTCP/IP.
n WEP:AWEPdialogispopedupbeforeSetupTCP/IPasbelowpicture.Youhaveto inputthe
password/networkkeytojointhisaccess pointbeforesetupTCP/IP.Thepassword/networkkeyis
definedby theadministratorofaccesspoint.Theinvalidnetworkkeywill stopgoingtonextstep.
l Cancel
Giveup Wi-Set Wizardand keepthelastconfiguration.
SetupTCP/IP
Youhavetosetup theTCP/IPby
following the configuration ofconnect
accesspoint.Thefollowingsetting
shouldmatchtheconfigurationof access
pointyoujoin.Pleasecheckthesetting
ofit.
l Back
Gobacktopreviousstep ~SelecttheIBSS connectionlist
l Finish
All settingsof infrastructurearefinished.
3.3.2BuildAd-Hoc networkingmode network
Itiseasytobuildup Ad-Hoc type networkwithWi-SetWizard.Thenext stepafterselect
Ad-Hoc typenetworkis toselect thedesiredconnection.

3-
7
SelectTheIBSS ConnectionList
Inthis step, youcould selectthepresent
Ad-Hocstation tojoin. Inaddition, you
could createanotherAd-Hocstation by
press NewIBSS”button.
l SSID listbox
DisplayallpresentAd-Hocstation
around thissystem.
l NewIBSS
CreateanewAd-Hocstation bythe shown-up
dialoginsteadof joiningwithapresentAd-Hoc
node. Inthisdialog, youcouldconfigurenetwork
name, appliedchannel,authenticationand
encryptionruleonthisAd-Hocnode.After
creatinganewAd-Hocnode, the stepsofbuild
Ad-Hocnetworkconnection isfinished.
l Refresh
Rescanthe Ad-Hocstationsnearbythis system.
l Back
Gobacktopreviousstep ~SelectStationType.
l Next
The wizardwillshowupthecontentsofprofile.Youshouldset it uptomatchthesecurity
configuration withselected Ad-Hocstation.Then the stepsarefinished.
l Cancel
Giveup Wi-Set Wizardand keepthelastconfiguration.

3-
8
3.4 BuildSoftAPnetwork
SetupaWirelessNetwork
Thesettingof Soft APcouldsettledone
byeitherconvenient Normal User”or
complex AdvancedUser”operation.
l Normal User
Onlybasicsettingsareincluded infollowingsteps.Less-experienceuserscouldapply this
kindsetuptoarchiveaccesspointsetup.Fundamentalsecuritysetting isincluded.
l AdvancedUser
Youneedmoresecurityknowledgeonwireless networktohelpyou go through following
steps.Experienced usercouldselect thiskindsetup.Advanced securitysettingsare
included.
l Back
Gobacktopreviousstep ~SelectOperationMode
l Next
The next step isdependantonthe option userselect:
n NormalUser:Pleasefollowstepsin4.4.1NormalUser
n AdvancedUser:Pleasefollowstepsin4.4.2AdvancedUser
l Cancel
Giveup currentWi-SetWizardsetupandrollbacktopreviousconfiguration.
3.4.1Normal User
Fornormalusermode,thebasicsecurityfunctiononly requesttwotypesnetwork/passwordkey
toprovide WEPencryption.
WirelessNetworkProperties

3-
9
l NetworkName(SSID)
The serviceserveidentifyof this
accesspoint. Thelengthofthe
self-namingdoesnot exceed 32
characters.
l WEPEncryption
n Enable:Thejoinedwireless station
shouldhavesame
network/passwordkeywiththis
accesspoint.
n Disable:nonetwork/passwordkey
isrequiredforjoinedwirelessstation.
l Back
Backtopreviousstep~Setup aWirelessNetwork
l Next
The next step isdependantonthe decision ofWEPtobeeitherEnableorDisable.
n WEPEnable:Youshouldpreparenetwork/passwordkeyforWEP.GotoWireless NetworkSecurity.
n WEPDisable:Theaccess pointissetasanopenedhot-spot.Anyonecouldjointhisaccesspoint
andconnecttointernet.
l Cancel
Giveup currentWi-SetWizardsetupandroll backtopreviousconfiguration.
WirelessNetworkSecurity
Twotypespass key,ASCIIand
Passphrase,performsecuritywithdifferent
level.
l ASCII
Youshouldprovide either5or8ASCII
characterson Networkkey editbox.
l PASSPHRASE
Youcouldinput wordson NetworkKey
edit box.

3-
10
n 64bits:Thegeneratedpasskey is64-bitstobecompanywithdatapackets.
n 128 bits:Thegeneratedpass keyis128-bitstobecompanywithdatapackets.
l Back
Gobacktopreviousstep ~WirelessNetworkProperties
l Next
Gotonextstep ~ShowSettingInformation
l Cancel
Giveup currentWi-SetWizardsetupandroll backtopreviousconfiguration.
ShowSettingInformation
l Back
Ifyou donotsatisfywithcurrent
setting, you couldgobacktoprevious
step ~Wireless NetworkSecurity
l Next
Confirmthecurrentsetting andgo to
nextstep ~Finish.
l Cancel
Giveup currentWi-SetWizardsetupandroll backtopreviousconfiguration.
SelecttheInternetConnection List
Thissteponly showswithmultiplenetwork
connectionsystem.If thereisonly one
internetconnectionavailable,thisstep is
discarded. Inthisstep, you havetoselect
onenetworkconnection fromthelist box.
Thisnetworkconnectionshouldbe
configured toconnectinternet.
l NetworkListBox
Inthelistbox, you couldseeall

3-
11
networkconnectionthissystemprovides.Youhavetopickone fromthelist.
l Back
Gobacktopreviousstep ~ShowSetting Information.
l Next
Gotonextstep, Finish, whiletheinternetconnectionisselected.
If thestatusofselectednetworkconnectionisdisconnected, awarningdialog willpop up
toinformyou that.
l Cancel
Giveup currentWi-SetWizardsetupandroll backtopreviousconfiguration.
Finish
l Finish
PressfinishbuttontocloseWi-Set
wizard.The wireless configuration is
going to be appliedwithinfewseconds.
3.4.2Advanced User
Thestepsofadvanceduserprovide moredetailconfigurationincluding channeland
authentication
WirelessNetworkProperties
Inthis step, youcouldassignthe
channelnumberandauthentication
modeforthe access point.
Ifthe settingof WEPtobe Disable”and

3-
12
Authenticationtobe Open system”, thenthisaccesspointisopened forfree join.
l NetworkName(SSID)
The serviceserveidentifyof thisaccesspoint.The lengthof theself-namingdoesnot
exceed32characters.
l Channel select
Youcouldpickone channelfrom1to11.
l WEPEncryption
Anencryption systempreventseavesdropping onwireless networktraffic.
n Enable:Thejoinedwireless stationshouldhavesamenetwork/passwordkeywiththisaccess
point.
n Disable:nonetwork/passwordkey isrequiredfor joinedwireless station.
l Authentication
The nextgenerationofWi-Fisecurity,Wi-FiProtected Access, orWPA,willuse
authentication toverifywhetherusershaveaccess toaparticularwirelessnetwork.
n Opensystem:Thisaccesspointiswithoutauthenticationprotectionwithuser.
n Sharekey:Any stationwouldjointhisaccess pointshouldpasswithkeysameasthesettingon
accesspoint.
l Back
Gobacktopreviousstep ~SetupaWireless Network.
l Next
Gotonextstep.It dependson the settingof WEPandAuthentication.
Authentication
Encryption Open system Shared key WPA-PSK
WEP WLANSecurity
WEP(Disable) ShowNetworkSetting n/a
l Cancel
Giveup currentWi-SetWizardsetupandroll backtopreviousconfiguration.
WirelessNetworkSecurity
Twotypespass key,ASCIIandPassphrase,performsecuritywithdifferent level.
l ASCII
