AZZA Chroma 410 Series User manual

www.azzatek.comwww.azzatek.com
USER MANUALUSER MANUAL
410A 410B

RF Remote
Optional Liquid Cooling System
6.
7.
AZZA PRISMA Digital RGB Fan Installation
For Motherboard

Model
Model Name
Model Number
Specifications
Type
Color
Side Panel Window
Max CPU Cooler Height
Max Video Card Length
Power Supply
Motherboard Compatibility
External 5.25" Drive Bays
Internal 2.5" Drive Bays
Internal 3.5" Drive Bays
Expansion Slots
Top Ports
Physical Specifications
Dimensions (HxWxD)
Weight
Digital RGB Light Effects
Tempered Glass Side Window
Available Fan Ports
Dust Filters
Water Cooling
Isolated Chamber
Easy Installation Cooler
Features
Expansion
Chroma 410
CSAZ-410A
Up to 162mm
Up to 400mm Long Video Card
Not included
ATX, Micro ATX
520x205x500mm / 20.5x8.1x19.7 inches
6.82 kg / 15.0 lbs
Digital RGB light on the front. All digital RGB light devices
controlled by RF Remote (included) or motherboard.
Dustproof PVC Net x2 on bottom of Chassis
Supports radiators up to 240mm on top / 360mm in front
Power supply is housed inside its own isolated chamber,
preventing its heat from affecting other components
A pre-cut hole for easy installation of CPU Cooler,
eliminating the need to remove the motherboard
High-quality tempered glass side windows allow for clear visuals to inner
components
Up to 2
2xUSB3.0, 2xUSB2.0, HD Audio
0
Up to 6
ATX Mid Tower
Black(exterior)/Black(interior)
Tempered Glass with rubber mounts
2x120mm Fan ports on the top
3x120mm or 2x140mm Fan ports in the front
(2x120mm Black Fans included)
1x120mm Fan port in the rear
(1x120mm PRISMA-Digital RGB Fan included)
Digital RGB lighting: Also known as "addressable" RGB. Digital RGB lights offer the ability to assign colors
to each LED diode individually, whereas analog RGB lighting only allows the LED strip to display one color
along the whole strip at a time. The terms "digital" and "addressable" can be used interchangeably when
referring to RGB lighting.
7(Horizontal)+2(Vertical)

Features
Expansion
Model
Model Name Chroma 410
Model Number CSAZ-410B
Specifications
Type
Color
Side Panel Window
Max CPU Cooler Height Up to 162mm
Max Video Card Length Up to 400mm Long Video Card
Power Supply Not included
Motherboard Compatibility ATX, Micro ATX
External 5.25" Drive Bays
Internal 2.5" Drive Bays
Internal 3.5" Drive Bays
Expansion Slots
Top Ports
Physical Specifications
Dimensions (HxWxD) 520x205x500mm / 20.5x8.1x19.7 inches
Weight 6.82 kg / 15.0 lbs
Front Panel Acrylic Side Translucent modeling
Tempered Glass Side Window
Available Fan Ports
Dust Filters Dustproof PVC Net x2 on bottom of Chassis
Water Cooling
Isolated Chamber
Easy Installation Cooler
Supports radiators up to 240mm on top / 360mm in front
Power supply is housed inside its own isolated chamber,
preventing its heat from affecting other components
A pre-cut hole for easy installation of CPU Cooler,
eliminating the need to remove the motherboard
High-quality tempered glass side windows allow for clear visuals to inner
components
2x120mm Fan ports on the top
3x120mm or 2x140mm Fan ports in the front
(2x120mm PRISMA-Digital RGB Fans included)
1x120mm Fan port in the rear
(1x120mm Black Fan included)
Up to 2
7(Horizontal)+2(Vertical)
2xUSB3.0, 2xUSB2.0, HD Audio
ATX Mid Tower
Black(exterior)/Black(interior)
Tempered Glass with rubber mounts
0
Up to 6
Digital RGB light on the front. All digital RGB light devices
controlled by RF Remote (included) or motherboard.
Digital RGB Light Effects
Digital RGB lighting: Also known as "addressable" RGB. Digital RGB lights offer the ability to assign colors
to each LED diode individually, whereas analog RGB lighting only allows the LED strip to display one color
along the whole strip at a time. The terms "digital" and "addressable" can be used interchangeably when
referring to RGB lighting.

1
2
3
4
5
6
7
8
9
10
11
12
13
4
5
6
8
9
1
2
3
7
7
101112
Front panel
Panel transparent plate
Panel reflector
Power button
Transparent power button holder
USB fixed plate
Case feet x4
Top panel
PCIe cover plate
PCIe cradle
Side plate EVA crash pad x4
Left glass
Right side panel
410A
13

1
2
3
4
5
6
7
8
9
10
11
12
13
4
5
6
8
9
1
2
3
7
7
101112
Front panel
Panel transparent plate
Panel reflector
Power button
Transparent power button holder
USB fixed plate
Case feet x4
Top panel
PCIe cover plate
PCIe cradle
Side plate EVA crash pad x4
Left glass
Right side panel
410B
13

Power
USB3.0 (Blue)
USB2.0 (Black)
Mic
Audio

▪Supports up to 400mm long Video cards.
MAX 400mm Video cardMAX 400mm Video card

Optional Liquid Cooling System
Max Height of
Water Cooling
360 mm
120mm x3
120mm x2
Front
Top
Max Length of
Water Cooling
240 mm

Parallel Connection ("daisy-chaining")
Digital RGB
Digital RGB
Digital RGB
1 2
3 4
+5V
No Pin Ground
Data
RGB1
RGB2
1 2
3 4
+12V
R B
G
RGB1
All lighting modes are controlled
by motherboard software.
CAUTION
The addressable RGB fan has a 3-pin connector (4 holes). Please ensure that you are connecting the 3-pin connector
on the fan to the 3-pin RGB header on the motherboard or RF Remote connector.
Do not plug it into the 4-pin header, as the incompatible voltage will fry the fan. The 3-pin connector on the fan still has
4 holes, but the 4th hole is intentionally blocked, for this reason, so please do not try to force it!
Our digital RGB devices are WS2812B-compliant. Each fan contains 18 digital/addressable LED diodes. The WS2812B
standard supports up to 60 diodes at the maximum for a single header, so please do not daisy-chain more than 3
digital RGB fans together.
If you do not have a motherboard that is compatible with digital RGB, then you can opt to use the included
RF remote and receiver.
AZZA PRISMA Digital RGB Fan Installation For Motherboard

RF Remote
The first Digital RGB fan is to be connected to the Digital RGB LED RF remote
in the chassis, while the rest of them can be daisy chained to the first one
with their own male and female plugs.
R G
W
B
MODE
+
+
+
SPEED
DIY
DIY
MODE ADD
DIY
DEL
DIY
SPEED
-
-
-
MENU
AUTO
—
RF Wireless
R G
W
B
MODE
+
+
+
SPEED
DIY
DIY
MODE ADD
DIY
DEL
DIY
SPEED
-
-
-
MENU
AUTO
—
RF Wireless
Power on / off
Press the shutdown key
to save the parameters.
Mode + (358 modes)
Speed-/Brightness –
Custom Mode +
Custom Mode –
7 Color static
monochrome mode.
Auto play 358 Modes
To adjust the number of LED pixel
points and the RGB order: In the
off state,press Menu and hold for 5
seconds to enter the setup menu,
press MODE + and MODE - to
adjust the number of LED pixel
points.Press the RGB key to
adjust the RGB order,Press R
until the led strip shows red.
Press G until the led strip shows
green,Press B until thelled strip
shows blue,adjust the end press
the shutdown key to exit.
Speed+/Brightness+
Adds the current effect
to the custom mode.
Removes the current
effect from the custom
mode.
Delete match the remote
control ID:
Press and hold the W key for 5
seconds to cancel the remote
control ID matching (led strip white
flashing 3 times).
Remote control ID match:
long press "G" key 5 seconds,
remote control one to one match
(led strip green flash 3 times)
(Model Number: RF-DRGB-T358)
