AZZA OCTANE User manual

Octane
CSAZ-460A CSAZ-460B

Installation Instructions
1. Specifications
2. Chassis Parts
3. Control Panel Functions
4. 3.5”/2.5” HDD/SSD Installation
5. Cooling System Installation
6. ARGB Control Board
7. ARGB Control Modes Switching

Model
Model Name:
Model Number:
Specifications
Type: ATX Mid Tower
Color: Black/Black(interior), White/White(interior)
Side Panel Window: LeSide panel: Slidable tempered glass panel
Max CPU Cooler Height: UP to 165mm
Max Video Card Length: Up to 360mm long video card
Power Supply: Not Included
Motherboard Compability: <270mm E-ATX、ATX、Micro ATX、ITX
External 5.25" Drive Bays: 0
Internal 2.5" Drive Bays: Up to 4
Internal 3.5" Drive Bays: Up to 2
Expansion Slots: 7
Top Ports: Power buon, reset buon,Led buon, HD Audio, USB 3.0 x 1, USB2.0x2
Physical Specifications
470x215x443/18.5x8.5x17.4 inches
Weight:
Tempered Glass Sides Window: High-quality tempered glass side window allows for clear visuals to inner components
Addressable RGB Light Effects:
CSAZ-460A:
All ARGB light synchronize devices connect to the ARGB control board.
CSAZ-460B:
Addressable RGB light strip in the front and all ARGB light synchronize devices make
connecons.
Allowing the LED buon to directly control the ARGB lighng, or switched to be controlled
by the motherboard synchronize soware.
Available Fan Ports:
3x120mm or 3x140mm Fan ports in the front(CSAZ-460A: 3x120mm ARGB fan included)
3x120mm or 2x140mm Fan ports on the top
1x120mm Fan port in the rear(CSAZ-460B: 1x120mm black fan included)
2x 120 mm fan ports on top of the power supply shroud
Water Cooling: Supports radiators up to 280/360mm in the Front
Supports radiators up to 240mm in the Top
Dust Filters:
Power Supply Support:
Removable (magnetic) dustproof net on the top, iron net on bottom of chassis.
CSAZ-460B: LED light guide mesh on the front.
Boom mounted ATX Power Supply
Octane
Expansion
Features
CSAZ-460A/CSAZ-460B
Specifications
Case Dimension (HxWxD)
6.4kg /14.1lbs

1
6
8
2
4
3
5
7
9
1
Chassis
2
Metal side panel
3
Sliding tempered glass panel
4
2.5” SSD tray x 2
5
Hard disk cage
6
3.5” HDD/ 2.5” SSD brackets
7
Front panel
8
9
Removable magnetic mesh
Steel dust filter
CSAZ-460A
Chassis Parts

1
Chassis
2
Metal side panel
3
Sliding tempered glass panel
4
2.5” SSD tray x 2
5
Hard disk cage
6
3.5” HDD/ 2.5” SSD brackets
7
Front panel
Addressable RGB strip
Led light guide mesh
8
9
10
11
Removable magnetic mesh
Steel dust filter
Chassis Parts
CSAZ-460B
1
6
2
4
3
5
7
8
9
10
11

Control Panel Functions
USB 3.0 (Blue)
USB 2.0 (Black)
Audio
Mic
POWER
RESET
LED

▪Multifunctional hard disk bracket support
3.5” HDD or 2.5” SSD x 1 ( )
3.5 ˝/ 2.5˝ HDD/SSD Installation
3.5″3.5″
2.5″2.5″
or
▪Supports up to 360mm long video cards.
▪Supports up to 120mm fan x2 ( )
▪2.5" SSD metal tray support 2.5” SSD x 2
( )
▪Multifunctional hard disk cage support
3.5” HDD or 2.5” SSD x 1( )
A
B
CD
EF
C D
B
A
MAX 360mm video cardMAX 360mm video card
EF

Cooling System Installation
Front
120mm x3
140mm x3
or
Max Height of
Radiator
360 mm

Cooling System Installation
Rear
120mm x1

Cooling System Installation
Top
120mm x3 140mm x2
or
Max Length of
Radiator
240 mm

ARGB Control Board
CSAZ-460A

ARGB Control Modes Switching
※Press the LED button to cycle through different RGB lighting modes, controlled by the
LED button though the ARGB control board.
※Hold the LED button for 3 seconds to switch the RGB control function between
motherboard RGB software and LED button.
CSAZ-460A

CSAZ-460B
ARGB Control Modes Switching
※To synchronize all addressable RGB light devices,
it needs to be switched to be controlled only by the
motherboard.
▪SATA connector plug to Power Supply.
▪LED button(assembly already)
▪ARGB 3pin connector plug to the 5V
ARGB port of the motherboard.
▪ARGB 3pin connector plug to ARGB devices .
VDG
IN

ARGB Control Modes Switching
※Press the LED button to cycle through different RGB lighting modes, controlled by the
LED button though the ARGB control board.
※Hold the LED button for 3 seconds to switch the RGB control function between motherboard
RGB software and LED button, or turn off the light.
CSAZ-460B
Hold the LED button for 3 seconds to switch :
Swtch the RGB mode by LED button(Default)
Turn off the light
Switch the RGB
control function
to the motherboard software
3 seconds3 seconds
3 seconds
