AZZA PYRAMID MINI 806 User manual

Installation Instructions
1. Specifications
2. Chassis Parts
3. Removing The Top Glass Panel
4. ITX Motherboard Mount
5. Power Supply Installation
6. 2.5"SSD Installation
7. Fan Installation
8. Digital RGB Fan Installation For Motherboard

Specifications
Model
Model Name: PYRAMID MINI 806
Model Number: CSAZ-806
Specifications
Type:
Material:
Side Panel Window:
Max CPU Cooler Height:
Max Video Card Length: Up to 300mm long video card (Horizontal)
Power Supply: Not included
Motherboard Compability:
External 5.25" Drive Bays:
Internal 2.5" Drive Bays:
Internal 3.5" Drive Bays:
Expansion Slots:
Front Ports:
Physical Specifications
Metal Chassis Dimensions (HxWxD) 435 x 368 x 368 mm/17.1 x 14.5 x 14.5 inches
Weight: 6.3kg/13.9lbs
Tempered Glass Side Window:
Available Fan Ports:
Water Cooling: Supports radiators up to 120mm on the Top
Isolated Chamber:
Easy Installaon Cooler: A pre-cut hole for easy installaon of CPU Cooler,
eliminang the need to remove the motherboard
Accessories:
High-quality tempered glass side window allows for clear visuals to inner components
1x120mm Fan port in the Top(1x 120mm Hurricane II Digital RGB Fan included )
SFX power is on the boom
Prevent its heat from affecng other components
20cm PCI-E Extend cable for VGA card (included)
0
2
Power Buon
、
1xUSB 3.0
、
HD Audio
Features
MINI ITX Tower
1.5mm SPCC+ 2.0mm Aluminum
4 sides panel are tempered glass
Expansion
0
Up to 2
UP to 85mm
Mini ITX

Chassis Parts
2
3
4
5
6
8
9
10
11
12
TOP tempered glass panel cover
Pyramid structure
Fan bracket
12cm ARGB Fan
Power supply rack
PCIe slot
Fan cable management cover
Spring bolt screw of top panel cover
2.5" SSD bracket
Screws for 2.5" SSD bracket
Removable(magnetic) dust proof mesh
71
1
2
3
4
5
6
7
8
10 12
11
9
I/O Ports: Power button,USB 3.0 x 1 , HD Audio

Removing The Top Glass Panel
Loosen the four screws
Lift to remove top panel

ITX Motherboard Mount

* Product photos are for reference only.
Power Supply Installation
SFX Power Supply

* Product photos are for reference only.
2.5"SSD Installation
2.5" SSD

* Manage the fan cables by hiding cable cover
Fan Installation
■ Fasten the fan screws ■ Secure the fan to the top of the Pyramid.

Digital RGB Fan Installation For Motherboard
The addressable RGB fans can connect directly to the 5V addressable RGB headers of compatible motherboards,
such as those from MSI™, ASUS™, Gigabyte™ and AsRock™.
Please note: Only 5V addressable headers from compatible motherboards are supported. Please do NOT connect
the fan to a 12V non-addressable header.
Please check your motherboard’s specifications before use. Do not go past the motherboard’s allowed limits on
power rating and LED count when connecting multiple fans/LED strips.
