Installation and Operation Instructions
Original instructions
Level- and temperature sensor
Nivotemp NT M-L
BE100029
01/2019
Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen
Tel. [phone] / 49 89-0, Fax: [phone] / 49 89-20
E-Mail: [email protected]
Internet: www.buehler-technologies.com

Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen
Tel. [phone] / 49 89-0, Fax: [phone] / 49 89-20
Internet: www.buehler-technologies.com
E-Mail: [email protected]
Read this instruction carefully prior to installation and/or use. Pay at-
tention particularly to all advises and safety instructions to prevent in-
juries. Bühler Technologies can not be held responsible for misusing
the product or unreliable function due to unauthorised modifications.
All rights reserved. Bühler Technologies GmbH 2019
Document information
Document No..........................................................BE100029
Version..........................................................................01/2019

Nivotemp NT M-L
Contents
1 Introduction..................................................................................................................................................................................................................... 2
1.1 Intended Use.........................................................................................................................................................................................................2
1.2 Functionality......................................................................................................................................................................................................... 2
1.2.1 Liquid level monitoring ......................................................................................................................................................................2
1.2.2 Temperature monitor .........................................................................................................................................................................2
1.3 Model key............................................................................................................................................................................................................... 2
1.4 Scope of Delivery.................................................................................................................................................................................................. 2
2 Safety instructions......................................................................................................................................................................................................... 3
2.1 Important advice................................................................................................................................................................................................. 3
2.2 General hazard warnings ................................................................................................................................................................................. 3
3 Transport and storage .................................................................................................................................................................................................. 5
4 Setup and connection...................................................................................................................................................................................................6
4.1 Installation ............................................................................................................................................................................................................6
4.2 Electrical connections ........................................................................................................................................................................................6
5 Operation and control .................................................................................................................................................................................................. 7
6 Cleaning and Maintenance.........................................................................................................................................................................................8
7 Service and repair...........................................................................................................................................................................................................9
7.1 Spare parts and accessories .............................................................................................................................................................................9
8 Disposal........................................................................................................................................................................................................................... 10
9 Appendices...................................................................................................................................................................................................................... 11
9.1 Technical Data NT M-L ......................................................................................................................................................................................11
9.2 Standard Pin Assignment NT M-L.................................................................................................................................................................. 11
10 Attached documents....................................................................................................................................................................................................13
iBühler Technologies GmbHBE100029 ◦ 01/2019

Nivotemp NT M-L
1 Introduction
1.1 Intended Use
Level sensors are used to monitor the liquid level and temperature in fluid systems.
Level sensors must not be used in highly flammable or corrosive liquids.
The medium must not contain particles, particularly metallic particles, to prevent deposits on the float or between the float and
switching tube. If necessary, filter the medium.
Please note the technical data in the appendix for the specific intended use, existing material combinations, as well as temper-
ature limits.
WARNING
All device models are solely intended for industrial applications. They are not safety com-
ponents. The devices must not be used if failure or malfunction thereof jeopardises the
safety and health of persons.
Use in explosive areas is prohibited.
1.2 Functionality
1.2.1 Liquid level monitoring
The measuring tube is located inside the tank. The reed-contact is located inside the measuring tube.
Simply put, the reed-contact works the same as a regular resistance potentiometer. The reed-contact consists of a number of
reed switches along with resistors connected in series. The total length of the chain varies by the path being monitored.
If a magnet inside a float trips the reed switch, a resistance signal proportional to the position of the float will be output. When
the float changes positions, resistances are more or less activated and the resistance signal altered based on the position of the
float. The resistance signal is analysed by the built-in electronics and output via the IO-Link interface.
1.2.2 Temperature monitor
The temperature is monitored by a temperature sensor (Pt100) located at the bottom end of the Reed-contact. The temperature
signal is analysed by the built-in electronics and output via the IO-Link interface.
Please note the technical data in the appendix.
1.3 Model key
NT M
M12
Brass
MS
Version
200
280
370
500
600
700
800
900
1000
Model designation
Plug connection
Length (max. 1000 mm)
Measuring mode
LTD Level and temperature measurement
(IO-Link)
---- ----
-LTD ---- ---- ----
G3/4
G1
Connection
Output
1D1S
1.4 Scope of Delivery
– Level sensor
– Product Documentation
– Connection/mounting accessories (optional)
2 Bühler Technologies GmbH BE100029 ◦ 01/2019

Nivotemp NT M-L
2 Safety instructions
2.1 Important advice
Operation of the device is only valid if:
– the product is used under the conditions described in the installation- and operation instruction, the intended application
according to the type plate and the intended use. In case of unauthorized modifications done by the user Bühler Technolo-
gies GmbH can not be held responsible for any damage,
– when complying with the specifications and markings on the nameplates.
– the performance limits given in the datasheets and in the installation- and operation instruction are obeyed,
– monitoring devices and safety devices are installed properly,
– service and repair is carried out by Bühler Technologies GmbH,
– only original spare parts are used.
This manual is part of the equipment. The manufacturer keeps the right to modify specifications without advanced notice. Keep
this manual for later use.
Signal words for warnings
DANGER
Signal word for an imminent danger with high risk, resulting in severe injuries or death if not avoided.
WARNING
Signal word for a hazardous situation with medium risk, possibly resulting in severe injuries or death if not
avoided.
CAUTION
Signal word for a hazardous situation with low risk, resulting in damaged to the device or the property or
minor or medium injuries if not avoided.
NOTICE
Signal word for important information to the product.
Warning signs
These instructions use the following warning signs:
Warns of a general hazard General information
Warns not to inhale toxic gasses Wear respiratory equipment
Warns of corrosive liquids Wear a safety mask
Warns of explosive areas Wear gloves
2.2 General hazard warnings
The equipment must be installed by a professional familiar with the safety requirements and risks.
Be sure to observe the safety regulations and generally applicable rules of technology relevant for the installation site. Prevent
malfunctions and avoid personal injuries and property damage.
The operator of the system must ensure:
– Safety notices and operating instructions are available and observed,
– The respective national accident prevention regulations are observed,
– The permissible data and operational conditions are maintained,
– Safety guards are used and mandatory maintenance is performed,
– Legal regulations are observed during disposal.
3Bühler Technologies GmbHBE100029 ◦ 01/2019

Nivotemp NT M-L
Maintenance, Repair
Please note during maintenance and repairs:
– Repairs to the unit must be performed by Bühler authorised personnel.
– Only perform conversion-, maintenance or installation work described in these operating and installation instructions.
– Always use genuine spare parts.
Always observe the applicable safety and operating regulations in the respective country of use when performing any type of
maintenance.
The method for cleaning the devices must be adapted to the IP protection class of the devices. Do not use cleaners which could
damage the device materials.
DANGER Toxic, acidic gases/liquids
Protect yourself from toxic, corrosive gasses/liquids when performing any type of work.
Wear appropriate protective equipment.
4 Bühler Technologies GmbH BE100029 ◦ 01/2019

Nivotemp NT M-L
3 Transport and storage
Only transport the product inside the original packaging or a suitable alternative.
The equipment must be protected from moisture and heat when not in use. It must be stored in a covered, dry, dust-free room
at room temperature.
5Bühler Technologies GmbHBE100029 ◦ 01/2019

Nivotemp NT M-L
4 Setup and connection
DANGER Toxic, acidic gases/liquids
Protect yourself from toxic, corrosive gasses/liquids when performing any type of work.
Wear appropriate protective equipment.
4.1 Installation
The level switch comes fully assembled and can be mounted to the tank using the screw-in thread. Please be sure the float can
move freely and to leave enough space between the tank wall and add-ons.
After removing the float, where applicable, be sure the magnet inside the float is above the fluid level. This can easily be verified
with a piece of iron to determine the magnet position inside the float.
4.2 Electrical connections
Electricity is supplied via plug connectors. Please refer to the appendix for installation dimensions, nominal voltage and plug
configuration.
The switching outputs are PNP transistors.
The level- and temperature sensor is powered with 18-30V direct voltage. The sensor connects with a cable and standard M12
plug-in connectors.
6 Bühler Technologies GmbH BE100029 ◦ 01/2019

Nivotemp NT M-L
5 Operation and control
NOTICE
The device must not be operated beyond its specifications.
Version with IO-Link interface
This unit is equipped with an IO-Link interface, which require an IO-Link master.
The IO-Link interface allows direct access to process and diagnostics data, and allows configuring the unit during operation.
The IODDs required to configure the unit is available at https://ioddfinder.io-link.com/.
If the IO-Link interface is not being used (no master or only used to parametrise), the level- and temperature sensor functions as
a regular level- and temperature sensor with 2 switching outputs. The default parameters and switching function of the switch-
ing outputs, however, can be parametrised via IO-Link master.
For more information please visit: www.io-link.com
7Bühler Technologies GmbHBE100029 ◦ 01/2019

Nivotemp NT M-L
6 Cleaning and Maintenance
This device is maintenance-free.
The method for cleaning the devices must be adapted to the IP protection class of the devices. Do not use cleaners which could
damage the device materials.
8 Bühler Technologies GmbH BE100029 ◦ 01/2019

Nivotemp NT M-L
7 Service and repair
This chapter contains information on troubleshooting and correction should an error occur during operation.
Repairs to the unit must be performed by Bühler authorised personnel.
Please contact our Service Department with any questions:
Tel.: [phone] or your agent
If the equipment is not functioning properly after correcting any malfunctions and switching on the power, it must be inspected
by the manufacturer. Please send the equipment inside suitable packaging to:
Bühler Technologies GmbH
- Reparatur/Service -
Harkortstraße 29
40880 Ratingen
Germany
Please also attach the completed and signed RMA decontamination statement to the packaging. We will otherwise be unable to
process your repair order.
You will find the form in the appendix of these instructions, or simply request it by e-mail:
[email protected].
7.1 Spare parts and accessories
Accessories
Item no. Description
9144 05 0010 Connecting cable M12x1, 4-pin, 1.5 m, angular coupling and straight plug
9144 05 0046 Connecting cable M12x1, 4-pin, 3.0 m, angular coupling and straight plug
9144 05 0047 Connecting cable M12x1, 4-pin, 5.0 m, angular coupling and strands
9Bühler Technologies GmbHBE100029 ◦ 01/2019

Nivotemp NT M-L
8 Disposal
Dispose of parts so as not to endanger the health or environment. Follow the laws in the country of use for disposing of elec-
tronic components and devices during disposal.
10 Bühler Technologies GmbH BE100029 ◦ 01/2019

Nivotemp NT M-L
9 Appendices
9.1 Technical Data NT M-L
Basic unit
Version MS Dimensions
Operating pressure: max. 1 bar
63.5
L
L2
Measuring range
3.5
45
MIN.
MAX.
L1 = H
M12x1
Profile gasket
(NBR)
Ø23.5
SW
ØA
3
G3/4 (G1)
45
G3/4 G1
32.3 39.9
ØA
H16 18
SW 36 41
Medium temperature: -20 °C to +80 °C
Ambient temperature: -20 °C to +70 °C
Float: SK 161
Min. fluid density: 0.8 kg/dm³
Lengths (all versions): 200, 280, 370, 500, 600, 700, 800, 900 and 1000 mm
Material/Version
Float: NBR
Immersion tube: Brass
Flange G3/4: Brass
Flange G1: Brass
Seals: NBR/FKM
Weight at L=500mm: G3/4 = approx. 300 g, G1 = approx. 390 g
Input values Level Temperature
Measuring principle: Reed-contact Pt100 Cl. B, DIN EN 60751
Resolution: 10 mm
Tolerance: ± 0.8 °C
Operating voltage: 18 - 30 VDC
Analysis display electronics
accuracy:
± 1 % from end value ± 1 % from end value
IO-Link Revision 1.1
Baud rate: COM3 (230.4 k)
SIO Mode: Yes
min. time period: 10 ms
9.2 Standard Pin Assignment NT M-L
Plug connection
M12
Dimensions
Number of pins 4-pin
DIN EN 61076-2-101
IP rating IP67*
*With moulded plug top
11Bühler Technologies GmbHBE100029 ◦ 01/2019

Nivotemp NT M-L
Version 1D1S
Plug M12 4-pin
Connection schematic
Pin
1 +24VDC
2 S2 (PNP max. 200mA)
3 GND
4 C/Q (IO-Link)
12 Bühler Technologies GmbH BE100029 ◦ 01/2019

Nivotemp NT M-L
10 Attached documents
– Declaration of conformity: KX100033
– RMA - Decontamination Statement
13Bühler Technologies GmbHBE100029 ◦ 01/2019
