Bühler technologies GAS 222.11 Ex1 Owner's manual

Gas Analysis
Installation and Operation Instructions
Original instructions
Sample gas probes
GAS 222.11 Ex1
BE460073
04/2023
Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen
Tel. [phone] / 49 89-0, Fax: [phone] / 49 89-20
E-Mail: [email protected]
Internet: www.buehler-technologies.com

Bühler Technologies GmbH, Harkortstr. 29, D-40880 Ratingen
Tel. [phone] / 49 89-0, Fax: [phone] / 49 89-20
Internet: www.buehler-technologies.com
E-Mail: [email protected]
Read this instruction carefully prior to installation and/or use. Pay at-
tention particularly to all advises and safety instructions to prevent in-
juries. Bühler Technologies can not be held responsible for misusing
the product or unreliable function due to unauthorised modifications.
All rights reserved. Bühler Technologies GmbH 2023
Document information
Document No..........................................................BE460073
Version.........................................................................04/2023

GAS 222.11 Ex1
Table of Contents
1 Introduction.....................................................................................................................................................................................................................2
1.1 Intended Use.........................................................................................................................................................................................................2
1.2 Dust Atmosphere Requirements ....................................................................................................................................................................4
1.3 Type Plate...............................................................................................................................................................................................................4
1.4 Scope of delivery ..................................................................................................................................................................................................4
1.5 Ordering instructions......................................................................................................................................................................................... 5
1.6 Product Description............................................................................................................................................................................................6
2 Safety instructions ......................................................................................................................................................................................................... 7
2.1 Important Information...................................................................................................................................................................................... 7
2.2 General Hazard Warnings ................................................................................................................................................................................8
2.3 Ambient Temperature range of the equipment......................................................................................................................................10
2.4 Permissible gas inlet temperature............................................................................................................................................................... 10
3 Transport and storage .................................................................................................................................................................................................11
4 Installation and connection ...................................................................................................................................................................................... 12
4.1 Installation site requirements....................................................................................................................................................................... 12
4.2 Installation .......................................................................................................................................................................................................... 12
4.3 Installing the sampling tube (optional)...................................................................................................................................................... 12
4.4 Installing the downstream filter................................................................................................................................................................... 13
4.5 Installing the upstream filter (Optional).................................................................................................................................................... 13
4.6 Connecting the Gas Line.................................................................................................................................................................................. 13
4.6.1 Blowback Connection........................................................................................................................................................................ 14
4.6.2 Connecting the calibrating gas line (optional).......................................................................................................................... 14
4.7 Connecting the Blowback and Pressure Vessel (Optional).................................................................................................................... 14
4.8 Electrical Connections.......................................................................................................................................................................................15
4.8.1 Connecting the Earth Conductor/Earthing .................................................................................................................................15
4.8.2 Solenoid Valves (Optional) ...............................................................................................................................................................15
4.8.3 Limit Switch (Optional)......................................................................................................................................................................15
5 Operation and Control................................................................................................................................................................................................ 16
5.1 Before Startup .................................................................................................................................................................................................... 16
6 Maintenance...................................................................................................................................................................................................................17
6.1 Maintaining the filter element ..................................................................................................................................................................... 18
6.1.1 Replacing the downstream filter................................................................................................................................................... 18
6.1.2 Replacing the upstream filter ........................................................................................................................................................ 19
6.2 Blowback of the in-situ filter (within the process stream).................................................................................................................... 19
6.2.1 Manual Blowback (Without Blowback Control)....................................................................................................................... 20
6.2.2 Automatic Blowback (External Blowback Control).................................................................................................................. 20
6.3 Maintenance Schedule ................................................................................................................................................................................... 20
7 Service and repair......................................................................................................................................................................................................... 21
7.1 Troubleshooting ................................................................................................................................................................................................ 21
7.2 Spare Parts...........................................................................................................................................................................................................22
8 Disposal ...........................................................................................................................................................................................................................23
9 Appendices .....................................................................................................................................................................................................................24
9.1 Technical Data....................................................................................................................................................................................................24
9.2 Terminal Diagram Probe Terminal Box ......................................................................................................................................................25
9.3 Terminal Diagram Terminal Box Limit Switch .........................................................................................................................................25
9.4 Flow chart ............................................................................................................................................................................................................25
9.5 Dimensions .........................................................................................................................................................................................................26
9.6 List of chemical resistance ..............................................................................................................................................................................27
9.7 User book (Please make copies).....................................................................................................................................................................28
10 Attached Documents...................................................................................................................................................................................................29
iBühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
1 Introduction
1.1 Intended Use
The sample gas probe is intended for installation into gas analysis systems in commercial applications.
ATEX/IECEx
Used in zone 1 (explosion group IIC) and 21 (dust group IIIC) and sampling from zone 0 (explosion group IIC) and 20 (dust group
IIIC).
DANGER Explosion hazard
Gas and dust atmosphere must not be present at the same time. These so-called hybrid
mixtures can have different ignition points than the individual components and are
therefore not included in the explosion protection markings for gas and dust.
Blowing an internal explosive atmosphere back from the gas probe is prohibited due to the potential risk of explosion. Process
gases or process gas mixtures must not contain solids which produce ignitable impact sparks when combined with the probe
materials including filter and sampling tubes.
Probe marking depending on selected options:
for zone 0/1: for zone 1:
ATEX: II 1G/2G Ex db1 eb mb2 IIC T4 Ga/Gb ATEX: II 2G Ex db1 eb mb2 IIC T4 Gb
IECEx: Ex db1 eb mb2 IIC T4 Ga/Gb IECEx: Ex db1 eb mb2 IIC T4 Gb
for zone 0/21: for zone 20/1:
ATEX: II 1G/2D
Ex db1 eb mb2 llC T4 Ga
Ex tb mb2 lllC T130 °C Db
ATEX: II 1D/2G
Ex ta lllC T130 °C Da
Ex db1 eb mb2 llC T4 Gb
IECEx: Ex db1 eb mb2 llC T4 Ga
Ex tb mb2 lllC T130 °C Db
IECEx: Ex ta lllC T130 °C Da
Ex db1 eb mb2 llC T4 Gb
for zone 20/21: for zone 21:
ATEX: II 1D/2D Ex ta/tb mb2 IIIC T130°C Da/Db ATEX: II 2D Ex tb mb2 IIIC T130°C Db
IECEx: Ex ta/tb mb2 IIIC T130°C Da/Db IECEx: Ex tb mb2 IIIC T130°C Db
1 "db" only for GAS 222.11/30 versions with limit switch.
2 "mb" only for version with solenoid valve.
Please refer to the type plate for the exact probe marking.
For devices designed for sampling from zone 0 or zone 20 the areas of application are indicated in the marking with "/":
II 1G/2G Ex db eb mb IIC T5/T6 Ga/Gb
Parameters for sampling from Zone 0
Parameters for use in Zone 1
The opposite is an example of the gas marking with separate areas of applic-
ation. The same procedure applies to dust approvals.
Please note, unlike the operating zone, the temperature class for sampling zone 0 is lower. This is also indicated by the ignition
protection marking in the type plate.
Always note the explosion protection marking in the name plate of your equipment (and all add-on parts).
2 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
Sample gas probes are among the main components in a gas conditioning system.
– Therefore also note the related drawing in the data sheet in the appendix.
– Before installing the device, verify the listed technical data meet the application parameters.
– Further verify all contents are complete.
Please refer to the type plate to identify your model. In addition to the job number it also contains the item number and model
designation.
Please note the specific values of the device when connecting, and the correct versions when ordering spare parts.
Passing through gases
Flammable gases above the UEL (upper explosion limit) may only be blown back with inert gases. Flammable gases from 25% LEL
(lower explosion limit) and up to the LEL may be blown back provided the operator ensures the blown back gas is not and cannot
be explosive. For safety reasons we recommend only using inert gases in these cases as well.
Blowing back explosive atmospheres (range from LEL to UEL) with the probes is prohibited due to possible adiabatic compres-
sion (high blowback pressure against contaminated filter). The operator is responsible for compliance with these conditions tak-
ing into account his risk assessment.
Limitations categories/zones due to accessories
Please note, the accessories used may limit the approved applications of the probes.
Please note the following table:
ATEX + IECEX Only ATEX
GAS 222 types with accessories: Gas Dust Gas and dust
(separate zones)
Sampling zone/operating zone
11 Ex1, 21 Ex1, 30 Ex1,
31 Ex1, 35 Ex1, 35-U Ex1
Pressure vessel PAV 01
(item no. 46222PAV and accessories)
Zone1***/Zone 1 Zone 20/Zone 21 Zone 20/Zone 1
11 Ex1, 21 Ex1, 30 Ex1,
31 Ex1
Ceramic inlet filter*
(item no.:46222307 + 46222307F)
Zone 2/Zone 1 Zone 20/Zone 21 Zone 20/Zone 1
or
Zone 2 / Zone 21
11 Ex1, 20 Ex1, 21 Ex1 Ceramic outlet filter*
(item no. 46222026 + 46222026P)
Zone 2/Zone 1 Zone 20/Zone 21 Zone 20/Zone 1
or
Zone 2 / Zone 21
11 Ex1, 20 Ex1, 21 Ex1 Sampling tubes
(item no.: 46222001, 462220011, 46222006,
46222004, 46222016, 46222017, 46222018
Zone 0/Zone 1 No zone/Zone 21 Zone 0/Zone 21
11 Ex1, 20 Ex1, 21 Ex1 Ceramic sampling tubes**
(item no.: 4622200205, 4622200210,
4622200215)
Zone 2/Zone 1 No zone/Zone 21 Zone 2/Zone 21
* Accessories not suitable for sampling highly ignitable dusts with a minimum ignition energy (MIE) of <3mJ.
** When sampling gas from Zone 2, ceramic sampling tubes may only be used if application- and process-related intensive elec-
trostatic charges are ruled out.
*** Blowback of explosive atmosphere/gases is prohibited.
3Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
1.2 Dust Atmosphere Requirements
The sample gas probe may only be used in areas with explosive dust atmosphere if the smouldering temperatures of the dust
layers and the ignition temperatures of the dust atmosphere is higher than the following temperatures.
Probe temperature class
T80 °C T120 °C T130 °C T175 °C T226 °C T300 °C
Smouldering temper-
ature for max.
5 mm dust layer
≥ 155 °C ≥ 195 °C ≥ 205 °C ≥ 250 °C ≥ 301 °C ≥ 375 °C
Dust atmosphere ig-
nition temperature
≥ 120 °C ≥ 180 °C ≥ 195 °C ≥ 263 °C ≥ 339 °C ≥ 450 °C
The basis for safety factors is EN 1127-1.
1.3 Type Plate
Example:
0158
GAS 222.11 Ex1
000053273 462221110143411111 001
Manufacturer and address
Model designation
Order no., item no.
Electrical supply
Type examination certificate no.
230V; valve/клапан 24V UC
Bühler Technologies GmbH
Harkortstr. 29 D-40880 Ratingen
IBExU17ATEX1088X
IECEx IBE 17.0024X
Ex eb mb IIC T4 Gb
Explosion protection marking II 2G
IECEx certificate number:
Ex eb mb IIC T4 Gb
ATEX certificate number:
Explosion protection marking
1.4 Scope of delivery
– 1 x Sample gas probe
– 1 x Flange gasket and screws
– Product documentation
– Connection and mounting accessories (only optional)
4 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
1.5 Ordering instructions
The item number is a code for the configuration of your unit. Please use the following model key:
4622211 X X X X X 4 0 0 X X X X X X Product Characteristics
Terminal box
0 No
1 Yes
Flange
0 1 Flange DN65 PN6
0 2 Flange DN3"-150
x x Other
Hazardous area
Outside
4 Zone 1 (Atex/IECEx)
7 Zone 21 (Atex/IECEx)
9 none
Inside
3 Zone 0 (Atex/IECEx)
4 Zone 1 (Atex/IECEx)
6 Zone 20 (Atex/IECEx)
7 Zone 21 (Atex/IECEx)
9 none
Temperature class (inside/outside)
Ga/Gb or Gb/Gb Ga/Db or Gb/Db Da/Gb or Db/Gb Da/Db or Db/Db
4 T4/T4 T4/T130 °C T130 °C/T4 T130 °C/T130 °C
Calibration gas port
0 No
1 6 mm
2 6 mm with check valve
3 1/4"
4 1/4" with check valve
Pressure vessel *
0 No
1 Yes
Purge valve *
0 Ball valve
1 Solenoid valve 110 V (marked with "mb")
2 Solenoid valve 230 V (marked with "mb")
3 Solenoid valve 24 V (marked with "mb")
9 none
Pneumatic actuator for internal ball valve
0 No
1 Monostable pressure-free opened
2 Monostable pressure-free closed
Limit switch for pneumatic actuator
0 No
1 Yes (marked with "db" or "ta" or "tb")
Solenoid valve for pneumatic actuator
0 No
1 110 V (marked with "mb")
2 230 V (marked with "mb")
3 24 V (marked with "mb")
* Blowback of explosive atmosphere prohibited.
5Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
1.6 Product Description
Probe Description
GAS 222.11 Ex1 Probe with inlet and/or outlet filter, shut-off valve and blowback connection
Accessories Please refer to the data sheet at the end of this manual for accessories for this probe
6 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
2 Safety instructions
2.1 Important Information
This unit may only be used if:
– the product is being used under the conditions described in the operating- and installation instructions, used according to
the nameplate and for applications for which it is intended. any unauthorized modifications to the device will void the war-
ranty provided by Bühler Technologies GmbH,
– the limits in the data sheet and the instructions must be observed,
– the handle including O-ring are installed at a suitable ambient temperature range and filter (where applicable),
– monitoring equipment / protection devices must be connected correctly,
– service and repairs not described in these instructions is performed by Bühler Technologies GmbH,
– using genuine replacement parts.
– Regulation IEC/EN60079-14 must be observed when erecting electrical systems in explosive areas.
– Additional national regulations pertaining to initial operation, operation, maintenance, repairs and disposal must be ob-
served.
– These operating instructions are a part of the equipment. The manufacturer reserves the right to change performance-, spe-
cification- or technical data without prior notice. Please keep these instructions for future reference.
Signal words for warnings
DANGER
Signal word for an imminent danger with high risk, resulting in severe injuries or death if not avoided.
WARNING
Signal word for a hazardous situation with medium risk, possibly resulting in severe injuries or death if not
avoided.
CAUTION
Signal word for a hazardous situation with low risk, resulting in damaged to the device or the property or
minor or medium injuries if not avoided.
NOTICE
Signal word for important information to the product.
Warning signs
These instructions use the following warning signs:
Warns of a general hazard General notice
Warns of voltage Unplug from mains
Warns not to inhale toxic gasses Wear respiratory equipment
Warns of corrosive liquids Wear a safety mask
Warns of explosive areas Wear gloves
7Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
2.2 General Hazard Warnings
The maximum surface temperatures of the probes also vary based on operating conditions (steam temperature, sample gas in-
let temperature, ambient temperature, fluid flow rate). When used in explosive areas, also particularly note the related hazard
warnings.
The equipment must be installed by a professional familiar with the safety requirements and risks.
Be sure to observe the safety regulations and generally applicable rules of technology relevant for the installation site. Prevent
malfunctions and avoid personal injuries and property damage.
The operator of the system must ensure:
– Safety notices and operating instructions are available and observed,
– The respective national accident prevention regulations are observed,
– The permissible data and operational conditions are maintained,
– Safety guards are used and mandatory maintenance is performed,
– Legal regulations are observed during disposal,
– compliance with national installation regulations.
Maintenance, Repair
Please note during maintenance and repairs:
– Repairs to the unit must be performed by Bühler authorised personnel.
– Only perform conversion-, maintenance or installation work described in these operating and installation instructions.
– Always use genuine spare parts.
– Do not install damaged or defective spare part. If necessary, visually inspect prior to installation to determine any obvious
damage to the spare parts.
Always observe the applicable safety and operating regulations in the respective country of use when performing any type of
maintenance.
NOTICE Accessories may limit critical operating parameters of the base unit
Adding accessories may limit critical operating parameters. Ambient temperatures, zone
classifications, explosion groups, temperature classes or chemical resistances of ac-
cessories may vary from the base unit.
Always include all technical data in the operating instructions and data sheets of all
components in the safety assessment.
NOTICE When used in explosive areas
Regulation IEC/EN60079-14 must be observed when erecting electrical systems in ex-
plosive areas.
Additional national regulations pertaining to initial operation, operation, maintenance,
repairs and disposal must be observed.
DANGER Electrical voltage
Electrocution hazard.
a) Disconnect the device from power supply.
b) Make sure that the equipment cannot be reconnected to mains unintentionally.
c) The device must be opened by trained staff only.
d) Regard correct mains voltage.
8 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
DANGER Toxic, corrosive gas/condensate
Sample gas/condensate may be hazardous to health.
a) If necessary, ensure a safe gas/condensate discharge.
b) Always disconnect the gas supply when performing maintenance or repairs.
c) Protect yourself from toxic/corrosive gasses/condensate when performing mainten-
ance. Wear appropriate protective equipment.
DANGER Explosion hazard
Life and explosion risk may result from gas leakage due to improper use.
a) Use the devices only as described in this manual.
b) Regard the process conditions.
c) Check tubes and hoses for leakage.
DANGER Danger to life and explosion during installation and maintenance
The unit must not be worked on (assembly, installation, maintenance) in explosive at-
mospheres.
DANGER
Use in explosive areas
Flammable gas or dust atmospheres could ignite or explode. Avoid the following hazard
sources:
Application area!
Never operate the gas probe outside the specifications. Sampling gases or gas mixtures
which are also explosive in the absence of air is prohibited.
Electrostatic charge (sparking)!
The equipment may only be used where normal operating conditions do not frequently
produce flammable, electrostatic discharge.
Always clean plastic housing parts and decals with a damp cloth.
Sparking!
Protect the M3 connectors from external blows.
Flame propagation!
If the process holds a risk of flame propagation, install a flame arrestor.
Adiabatic compression (explosion hazard)
Adiabatic compression may cause high temperatures during blowback. Never blowback
if explosive gas or dust atmospheres are present. Only use nitrogen (inert gas) to blow-
back flammable gas.
Dust
If possible, take the electrical components which must be opened for repair to a dust-
free room. If unable to do so, prevent dust from entering the housing.
Zonal carryover when sampling from zone 20, 21, 22
If the particle size of the dusts being filter is smaller than the fineness of the filter ele-
ments used, zonal carryover from the process to the probe must be expected.
The fineness of the filter elements used must be clearly smaller than the average particle
size of dusts in the process gas.
Dust ignition
Regularly clean dust from all components. Dust layers >5mm may have lower smoulder-
ing temperatures and the dust layer could potentially ignite at a temperature below its
smouldering temperature.
Also remove dust under the thermal insulation and from the gas probe heating tape.
The ignition temperature and smouldering temperature of flammable dusts or dust lay-
ers which are present must be above the marked surface temperature plus a safety
factor (also see section "Dust atmosphere requirements").
9Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
2.3 Ambient Temperature range of the equipment
The ambient temperature range may be limited based on the version. Please note the Ambient temperature ranges under
"Technical Data".
2.4 Permissible gas inlet temperature
The permissible gas inlet temperatures between versions will vary based on the temperature class of the gas in den outer zones
(see chapter "Technical Data").
10 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
3 Transport and storage
Only transport the product inside the original packaging or a suitable alternative.
The equipment must be protected from moisture and heat when not in use. They must be stored in a covered, dry and dust-free
room at a temperature between -20°C to 50°C (-4°F to 122°F).
11Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
4 Installation and connection
NOTICE Accessories may limit critical operating parameters of the base unit
Adding accessories may limit critical operating parameters. Ambient temperatures, zone
classifications, explosion groups, temperature classes or chemical resistances of ac-
cessories may vary from the base unit.
Always include all technical data in the operating instructions and data sheets of all
components in the safety assessment.
4.1 Installation site requirements
Sample gas probes are intended for flange mounting.
– Installation site and installation position are determined based on requirements specific to the application.
– If necessary, the connection piece should be slightly tilted toward the centre of the channel.
– The installation site should be protected from the weather.
– In addition, adequate and safe access for installation and future maintenance work should be provided. Particularly follow
the uninstalled size of the probe tube!
If the probe is transported to the installation site in pieces, it will first need to be assembled.
4.2 Installation
DANGER Danger to life and explosion during installation and maintenance
The unit must not be worked on (assembly, installation, maintenance) in explosive at-
mospheres.
DANGER Explosion hazard
When used in explosive areas
Flammable gasses and dust could ignite or explode.
Never operate the gas probe outside the specifications. Extracting gases or gas mixtures
which are also explosive in the absence of air is prohibited.
DANGER Explosion hazard due to flame propagation
Severe injuries and damage to the system
If the process holds a risk of flame propagation, install a flame arrestor.
4.3 Installing the sampling tube (optional)
The sampling tube, if necessary with the fitting extension, must be screwed in. The probe is then attached to the mating flange
using the included seal and nuts.
12 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
4.4 Installing the downstream filter
NOTICE
The downstream filter and the O-ring for the handle must be inserted prior to first star-
tup.
Operating without downstream filter prohibited!
O-ring handle
Attach an O-ring suitable for the expected ambient temperature (see "Spare Parts
and Accessories").
Attach the downstream filter to the handle. Then carefully insert the handle with
filter in the gas probe and turn 90° to secure.
Verify the handle is seated correctly. When seated correctly it locks onto the filter
housing.
4.5 Installing the upstream filter (Optional)
The upstream filter, if necessary with matching extension, must be screwed in. The probe is then attached to the mating flange
using the included seals and screws.
4.6 Connecting the Gas Line
The sample gas line must be carefully and properly connected using a suitable fitting.
This table provides an overview of the sample gas probe connections:
Probe
GAS 222
Reservoir
PAV01
Ball valve/
blowback valve
(without PAV01)
Ball valve
pneumatic drive
Control valve
3/2-way solenoid
valve
Connecting flange 1) DN65/PN6/
DN3"-150
Sample gas inlet G3/4
Sample gas outlet NPT 1/4
Blowback connection G3/8 Ø12
Test gas connection 1) Tube Ø6 mm
Tube Ø1/4
Filling port NPT 1/4
Condensate G1/2
Bypass NPT 1/4
Control air G1/8 G1/4
Tab.1: Gas Probe Connections (Varies by Model)
1) Varies by version.
Please note the following items when connecting the sample gas line (NPT 1/4") on heated probes to prevent thermal bridges:
– Choose the shortest possible screw connection.
– Shorten the connection pipe for the sample gas line as much as possible. To do so, remove the insulation around the sample
gas line. This is done by loosening the fixing bolts.
CAUTION Fragile
The insulation is fragile. Handle with care, do not drop.
After connecting the sample gas line it must be braced and secured with the clamp.
13Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
Long sample gas lines may require additional support clamps along the way to the analysis system! Once all lines have been
connected and checked for leaks, carefully reinstall and secure the insulation.
WARNING Gas emanation
Sample gas can be harmful to the health!
Check the lines for leaks.
4.6.1 Blowback Connection
Without accessories installed for the blowback device, the blowback connection comes with a sealed G3/8 screw-in connection. If
you require blowback, you will need to undo this screw-in connection and ensure the blowback line is connected properly and
tight.
DANGER Toxic, corrosive gasses
Explosive or toxic gases can develop due to a leaking or open blowback connection.
4.6.2 Connecting the calibrating gas line (optional)
Connecting the calibrating gas line requires a Ø6 mm or Ø1/4” pipe fitting.
If the calibrating gas connection was ordered with check valve, a Ø6 mm or Ø1/4” pipe can be connected directly to the check
valve.
4.7 Connecting the Blowback and Pressure Vessel (Optional)
The air lines must be connected carefully and properly, using suitable fittings.
If the probe is equipped with pressure vessel for efficient blowback (optional), a manual shut-off valve (ball valve) must be in-
stalled in the air supply, immediately upstream from the pressure vessel.
On probes used to sample flammable gas, nitrogen (inert gas) must be used for blowback. Blowback of explosive gases is prohib-
ited.
NOTICE
The operating pressure of the compressed air (inert gas) required for blowback must al-
ways be higher than the process pressure.
Required pressure differential min. 3 bar (44 psi).
DANGER Broken pressure vessel
Gas leak, danger due to flying parts.
Maximum operating pressure of the pressure vessel 10 bar (145 psi)!
The operating pressure reduces based on the operating voltage (see solenoid valve type
plate).
DANGER Adiabatic compression during gas blowback (explosion hazard)!
Adiabatic compression may cause high gas temperatures and must be checked by the
user.
Gas blowback may result in high gas temperatures due to adiabatic compression. This
can cause flammable gases to ignite spontaneously.
a) Blowback of explosive atmosphere / gases is prohibited.
b) Flammable atmosphere / gases (non-explosive) may only be blown back with nitro-
gen (inert gas).
14 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
4.8 Electrical Connections
WARNING Hazardous electrical voltage
The device must be installed by trained staff only.
CAUTION Wrong mains voltage
Wrong mains voltage may damage the device.
Regard the correct mains voltage as given on the type plate.
CAUTION Equipment damage
Cables damaged
Do not damage the cable during installation. Install a strain relief for the cable connec-
tion. Secure the cable against twisting and loosening. Please note the temperature res-
istance of the cables (> 100°C/212°F).
Only use cables with a temperature resistance of >100°C (212°F) to connect to power. Make sure the connecting cable has suffi-
cient strain relief (match cable diameter to the seal on the cable fitting).
4.8.1 Connecting the Earth Conductor/Earthing
Always connect all of the designated connections on your unit to your protective conductor system. Connect the earth to the ad-
ditional equipotential bonding conductor connection on the housing.
4.8.2 Solenoid Valves (Optional)
DANGER Explosion hazard when opening the solenoid valve housing
The solenoid valve is a closed system. It must not be removed!
A fuse suitable for the rated current (max. 3 x Ib per IEC60127-2-1) or a protective motor switch with short circuit and fast
thermal response (set for rated current) must be connected upstream from each magnet to prevent short-circuits.
– For magnets with a very low rated current, a fuse of the lowest current value under the IEC standard will suffice. This fuse
must be connected separately, upstream.
– The rated fuse voltage must be equal to or greater than the specified nominal voltage (UN +10%) of the magnet. The fuse rat-
ing is specified in the type plate of the solenoid valve.
– The limiting breaking capacity of the fuse element must be equivalent to or greater than the maximum short-circuit current
expected at the installation site (typically 1500A).
DANGER Potential equalization/static charge
Static charges can result in incendive sparking.
Avoid static charges. All conductive probe parts must be earthed!
The housing has a connection for an earth/equipotential bonding conductor. Ensure the
housing is adequately earthed (minimum conductor cross-section 4 mm2).
Particularly also observe the requirements of IEC/EN 60079-14!
4.8.3 Limit Switch (Optional)
The optimal limit switch has a separate terminal box with terminals (terminal diagram see "Appendix").
15Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
5 Operation and Control
NOTICE
The device must not be operated beyond its specifications.
NOTICE
The weather hood must be closed during operation!
WARNING Housing or component damage
Never exceed the maximum working pressure and temperature range of the drive.
DANGER Explosion hazard due to electrostatic discharge
Equipment may only be used where normal operating conditions do not produce fre-
quent flammable, electrostatic discharge.
5.1 Before Startup
Before starting the device, verify:
– The hose- and electrical connections are not damaged and correct installed.
– No parts of the gas probe have been removed.
– The protection and monitoring devices are installed and functional (e.g. flame arrester).
– The gas inlet and outlet on the gas probe are open.
– Ambient parameters are met.
– Probe parts are resistant to media to be conveyed and in the surrounding area.
– The electrical connections are tight.
– The monitoring equipment is connected and set as specified.
– Precautions have been taken.
– The earth is proper and functional.
– The outlet filter and the handle with O-ring are installed (if applicable).
16 Bühler Technologies GmbH BE460073 ◦ 04/2023

GAS 222.11 Ex1
6 Maintenance
– Damaged parts must be replaced immediately.
– Regularly check the function of the electrical protection.
During maintenance, remember:
– The equipment must be maintained by a professional familiar with the safety requirements and risks.
– Only perform maintenance work described in these operating and installation instructions.
– Observe the respective safety regulations and operating specifications when performing any type of maintenance.
– Always use genuine spare parts.
DANGER Danger to life and explosion during installation and maintenance
The unit must not be worked on (assembly, installation, maintenance) in explosive at-
mospheres.
DANGER Electrical voltage
Electrocution hazard.
a) Disconnect the device from power supply.
b) Make sure that the equipment cannot be reconnected to mains unintentionally.
c) The device must be opened by trained staff only.
d) Regard correct mains voltage.
DANGER Toxic, corrosive gases
The measuring gas led through the equipment can be hazardous when breathing or
touching it.
a) Check tightness of the measuring system before putting it into operation.
b) Take care that harmful gases are exhausted to a save place.
c) Before maintenance turn off the gas supply and make sure that it cannot be turned
on unintentionally.
d) Protect yourself during maintenance against toxic / corrosive gases. Use suitable pro-
tective equipment.
DANGER Dangerous electrostatic charge (explosion hazard)
Incendive electrostatic charges may occur when cleaning plastic housing parts and
decals (e.g. with a dry cloth or compressed air). The sparks this produces could ignite
flammable, explosive atmospheres.
Always clean plastic housing parts and decals with a damp cloth!
WARNING Housing or component damage
Never exceed the maximum working pressure and temperature range of the drive.
CAUTION Hot surface
Risk of burns
Depending on the operating parameters, the housing temperature may reach over 100
°C during operation.
Allow the unit to cool down before performing maintenance.
17Bühler Technologies GmbHBE460073 ◦ 04/2023

GAS 222.11 Ex1
CAUTION Excess pressure
The unit mustn’t be pressurised or energised when opened.
If necessary, close the gas supply and ensure a safe pressure on the process end before
opening.
CAUTION Drive pressurised
Never loosen or remove the cover or any accessories with the drive pressurised.
CAUTION Never open the drive with the function “single-acting”!
This may only be done at the manufacturer’s plant.
CAUTION Do not attach levers or tools to the drive’s spindle!
Levers and tools on the spindle can flap around when switching the compressed air or
control voltage back on and cause serious injury or damage!
6.1 Maintaining the filter element
The probes feature a particle filter which needs to be changed as it becomes dirty.
To do so, disconnect the voltage supply and if applicable close the shut-off valve to the process or switch off the process.
CAUTION!Do not damage the rear filter seat.
NOTICE
Ceramic filter elements are very brittle by nature. Handle them with care, don’t let them
fall.
Filter elements made out of sintered stainless steel can be cleaned in an ultrasonic bath
and be used several times as long as both seals are still in proper conditions.
6.1.1 Replacing the downstream filter
– Unlock and lift up the weather hood.
– Turn the handle at the back end of the probe by 90° (handle must then be horizontal), pushing in slightly, and remove.
– Remove the dirty filter element and check the sealing surfaces.
– Before installing the new filter element, replace the seal on the handle plug (seal included with the filter element). When
changing the seals in low temperatures the temperature limits must particularly be observed (see “Spare Parts and Accessor-
ies”)
– Then carefully insert the handle with new filter, push in slightly and turn 90° (handle must then be vertical). Pull on the
handle to verify the filter element is firmly seated.
– With the filter removed, if necessary also need clean the inside of the sampling tube by blowing it out or using a cleaning
wand.
NOTICE
The weather hood can only be closed again when the handle is completely vertical. In or-
der to do so, loosen the hood from the locking supports by lifting slightly and then fold
down. Ensure that the hood lock clicks into place correctly.
18 Bühler Technologies GmbH BE460073 ◦ 04/2023
