Baby Jogger POD User manual

Read these instructions carefully
before use and keep them for
future reference. Your child’s
safety may be affected if you do
not follow these instructions.
www.babyjogger.com
POD
ASSEMBLY INSTRUCTIONS

2
• Avoid serious injury from falling or sliding out. Always use safety harness(es). Always
use the crotch strap(s) in combination with the waist belt(s).
• Do not install a car seat or any other seating device not approved by the manufacturer
inside this chassis.
• Make no modifications to this chassis.
• Do not allow any of the child’s body, clothing, shoe laces, or toys to come in contact
with moving parts.
• Never leave child unattended in the chassis.
• Not for use during inclement weather such as snow or ice.
• Use extra caution and slower speed when using on wet or uneven surfaces.
• Check passenger(s) frequently, during use in extreme hot or cold weather to avoid heat
exhaustion or hypothermia. Ensure the seating compartment is properly ventilated and
the child/children stay adequately hydrated.
• Recommended temperature limits are 32°F to 100°F (0°C-38°C).
• Do not use with children who exceed the weight limitations.
• Do not use cleaning solvents; clean only with mild soap and water.
• Do not use the POD on stairs. Resulting damage to the POD will not be covered
under warranty.
• This unit sits one or two passengers. When used with one passenger, the passenger
must be seated in the center position.
• Maximum weight capacity – 100lbs (45 kg) (combined passenger(s) and baggage weight.)
• Maximum baggage weight – 8lbs (3.6 kg)
• Children must be at least 12 months and able to sit upright unassisted to ride in chassis.
• Check tire pressure before each use. Your tires should be filled to a maximum of 50 psi.
For the sake of your precious cargo, please
read these warnings before using the POD.
WARNING:

1
1 Remove chassis from box and set
wheels aside.
2 Insert handlebar into handlebar attachment brackets until both
sides click into place.
3 To unfold the chassis: Lift handle up and away from the lower frame until it clicks into place.
4Turn chassis upright and attach red safety strap to snap located
just below the fold mechanism on right side of chassis.
Handlebar
Attachment Bracket
Safety
Strap Location
FRAME
Click

2
CANOPY
1 Lay chassis back so the handle is
resting on the ground. Locate the
white support rod at the top rear
of the POD seating compartment.
2 Insert support rod into black canopy brackets located
on each side of the frame.
3 Locate the white support rod
at the top center of the POD
seating compartment.
4 Insert support rod into black canopy brackets located
on each side of the frame.

3
1 To install rear wheels: Insert wheel axle into wheel
mount on chassis frame until it clicks into place.
NOTE: Ensure the wheel is properly secured
to frame, test by gently trying to pull the
wheel out after installing.
2 To remove rear wheels: Press the wheel release
button while sliding the wheel away from the
wheel mount.
Wheel Mount Release Button
2 Lift up on the brake pedal to
disengage the parking brake.
1 Push the brake pedal down to
engage the parking brake.
Warning: Engage parking brake before loading and unloading passenger(s).
Engaged Disengaged
REAR WHEELS
& PARKING BRAKE

4
For use with a single passenger:
Warning:
When used with
only one child, the
child must be seated
in the center seating
position.
3 Buckle center waist belt.2 Place child in center seating
position. Buckle harness yoke
to center crotch strap buckle.
1 Buckle shoulder straps of harness yoke into center two buckles
on back of seat.
SAFETY HARNESS
ATTACHMENT & CONFIGURATION

5
For use with two passengers:
3 Buckle the waist belt.2 Place child in right seating
position. Buckle harness yoke
to the crotch strap buckle. (The
center crotch buckle will not
have a harness yoke attached.)
1 Buckle shoulder straps of harness yoke into two right buckles
on back of seat.
4 Repeat steps 2 and 3 to
secure second child into
safety harness on the left
side of the seat.

6
2 Rethread webbing strap
through front of harness
yoke to hold in place.
1 Thread webbing strap through
plastic guide on upper buckle
to lengthen or shorten.
To adjust crotch strap:
1 Thread webbing strap through
plastic guide on lower buckle
to lengthen or shorten.
To adjust waist belt:
1 Thread webbing strap through
waist buckle to lengthen or
shorten.
SAFETY HARNESS
SAFETY HARNESS ADJUSTMENT
To adjust shoulder harness length:

7
To adjust shoulder harness height:
2 Unclip harness yoke from
seat back.
1 Pull mesh seat back down to
expose upper harness buckles.
3 Slide the buckle down
to desired height.
5 Fasten harness buckle to seat
back and repeat on other side.
4 Thread harness yoke through
lower opening on mesh seat back.

8
The handlebar on the POD has two height adjustments.
2 Flip the handlebar over and reinsert into handlebar attachment brackets until both sides click into place.
1 Press buttons on each side of the handlebar attachment brackets while
pulling the handle tubing out.
To adjust the height of the handlebar:
Handlebar
Attachment
Bracket
Highest
Position
Lowest Position
ADJUSTABLE HANDLEBAR
Click

9
1 Squeeze the hand brake to give you better
control over your stroller while jogging or
running or while strolling on uneven terrain.
2 To rotate the hand brake’s position on
the handle bar, loosen the bolt using the
supplied Allen wrench. Rotate the hand
brake assembly on the handlebar until it is
in a comfortable position. Tighten the bolt
to secure hand brake.
Adjusting the hand brake: If you do not have
good braking action, simply squeeze the brake
handle (A) five or six times. If the problem
persists, loosen the brake’s cylinder ring (B) to
adjust the small ring (C) and then move the
small ring away from the handle to tighten the
cable. (Please do not over tighten!) To lock the
rings, tighten the cylinder ring (B) against the
handle while holding the small ring (C) in place.
• The POD Chassis is equipped with a hand
brake for use with the Jogging Kit and
Stroller Kit.
C
A
B
HAND BRAKE

10
BUG CANOPY STORAGE
& FOLDING
1 Completely unzip
bug canopy.
2 Roll bug canopy up
to the top of the POD.
3 Secure bug canopy in place by using
the provided loops and barrels.
To store the bug canopy:
1 Unsnap red safety strap. Stand in front of chassis.
Pull fold handles and lift up to fold.
2 Connect storage strap to underside of chassis frame.
Safety
Strap
To fold POD:

Seat and Frame Care
• The chassis seat and frame can be wiped cleaned using a soft, damp cloth.
Windows
• Plastic windows can crack at low temperatures. If chassis is stored or left in cold weather you
will need to let it warm up before folding or unfolding.
Wheels and Axles
• Check wheels for loose spokes and axles before every use. Moisture – especially from the
beach – can rust the wheels, footbrake and parts of frame. Spraying regularly with a silicone
lubricant will keep your chassis and wheels clean and safe.
Storage
• Store your POD in a dry, well ventilated area. To avoid mildew, make sure fabric is dry before
storing. Sunshine can fade fabric and dry out tires, so storing your POD indoors will prolong
its good looks. However if you do store it outside, using a tarp will help protect against weather
wear. If using the POD as a trailer, do not store attached to your bicycle.
11
CHASSIS CARE
& MAINTENANCE

12
Trailer Kit
Jogger Kit
The POD offers three different conversion kits for Stroller, Jogger, or Trailer
mode (sold separately) allowing you to choose how you want to use your POD.
All conversion kits are easy to install with no tools necessary so you are free to
change your activity on the go. The POD Rain Canopy is also sold separately.
POD CONVERSION KITS
Stroller Kit

13
Baby Jogger's Warranty:
Baby Jogger warrants that the frame is free of manufacturer defects for 5 years from date of purchase. Manufacturer’s
defects include but are not limited to the breaking of welds and frame tube damage. Textile or soft side materials and all
other components shall be warranted for one year from the date of purchase (except for tubes and tires). Proof of purchase
is required to make a warranty claim and the warranty is only extended to the original purchaser.
THIS WARRANTY DOES NOT COVER:








fitness for a particular purpose is according to the specific warranty period for this model unit at time of purchase. Some states do not allow the


consult your local or state consumer affairs office or your state’s Attorney General.
E-MAIL: 
CALL: 
 1-804-262-6277
MAIL: THE BABY JOGGER COMPANY
8575 Magellan Parkway
Suite 1000
 
PRODUCT REGISTRATION ON-LINE AT
www.babyjogger.com/register

We wish you many happy journeys with your
new POD! Your POD is a great product, and
we are proud to manufacture it. If you have any
questions or comments, please give us a call at:
1.800.241.1848
Baby Jogger is a Division of Dynamic Brands
8575 Magellan Parkway, Suite 1000 • Richmond, VA 23227
T: 800.241.1848 • F: 804.262.6277 • www.babyjogger.com
Thank You!
