Bachmann Long Caboose User manual

BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
Body Shell Assembly
1:20.3 Large Scale
Long Caboose
G887X-IS001

BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
Roof & Cupola Assemblies
1:20.3 Large Scale
Long Caboose
G887X-IS002

Chassis Assembly
1:20.3 Large Scale
Long Caboose
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
G887X-IS001

BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
Wiring Assembly
1:20.3 Large Scale
Long Caboose
G887X-IS002
3mm 3mm
3mm
3mm
WHITE
GRAY
GRAY
BROWN
GREEN
BROWN
PURPLE
YELLOW
ORANGE
BLACK
RED
GREEN
BLUE
BLUE
MARKED LIGHT 2
MARKED LIGHT 1

Pull up the cushion cover
Remove the dummy plug from
the socket
Install 8 pin decoder (either
bachmann HO decoder or other
decoder from open market)
There are 2 switches
under the chassis
for selection of
pick up & LEDS
How to install Decoder
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
DCC
Please notice that when
using non-Bachmann decoder,
switch 2 should be located at
the marker light positon otherwise
it works improperly.
SWITCH 1 SWITCH 2
8 5
1 4
8 PIN SOCKET
G887X-IS003

Slide the seat cover horizontally
Lift up the seat cover with
cushion
Follow the battery logo position
to install two AA batteries
How to load batteries inside the car body
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
- AA +
+ AA -
Batteries not included
CAUTION!
- Do not mix old and new batteries or
different types of batteries
- Remove batteries if the product is not
in use
- Do not short-circuit the battery contacts
G887X-IS003

Unfasten 4 screws
at the long ladder
(88797 , 88798)
Slide the roof cover
backward horizontally
Pull up the roof cover
DETAIL A
DETAIL B
B
A
When assembling the
roof cover, make sure
the ladder is installed
into the brackets on
the roof end.
How to remove the roof from the body
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
G887X-IS004

Unfasten two screws on the
coupler box cover and then
remove the fine scale couplers
Install the offset shank
coupler with chain
Make sure the chain is fastened
to the uncoupling lever before
assemble the coupler.
How to change the front / rear
die-cast offset shank couplers
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
(ACCESSORY BAG)
How to exchange LEDs on markers/table lights
G887X-IS004
Remove marker lamp / chimney
Grasp bracket while
removing LED

How to separate the two sides of the interior
walls from the body shell
BACHMANN INDUSTRIES, INC.
1400 East Erie Avenue
Philadelphia, Pennsylvania 19124 USA
800-356-3910
www.bachmanntrains.com
Printed in China
G887X-IS005
Unfasten 8 screws at
the two sides of body shell
1
2Pull up two sides of interior
walls carefully to prevent
damage to the wires inside
the interior walls
