Badger Basket 97851 Quick setup guide

Metal and Bamboo Multi-Bin
Storage Cubby
Assembly and Use Instructions. Adult Assembly Required.
Read all instructions before use. This manual is part of the product
and must be saved for future reference.
VERSION CODE*:
1.0/0421/TG
* Model and Version numbers are needed
if replacement parts are requested
MODEL NUMBER*:
97851 -
Charcoal/Natural
Badger Basket®, PO Box 227, Edgar, WI 54426-0227 USA • Web: www.badgerbasket.com
U.S. Based Customer Service Toll-Free (Mon-Thurs 7:00 AM-4:00 PM CST): 1-800-236-1310
Phone: [phone] • Fax: [phone]
FOR REPLACEMENT PARTS:
http://www.badgerbasket.com/parts
•Assembly Videos available on YouTube
•

ASSEMBLY TIPS! Review the entire manual before beginning. Leave hardware slightly loose
during assembly and then go back and tighten fully at the end. If using a power screwdriver,
keep torque setting low and go slow to prevent damage to the product.
BEFORE YOU BEGIN ASSEMBLY:
Check all parts and hardware. If anything is missing
or not satisfactory, please DO NOT call the store
or return the product to them. Please go online to:
http://www.badgerbasket.com/parts
Most problems are resolved
without you needing to leave home.
When emailing or calling us, please have this
instruction manual, your product model number,
and your Version Code ready.
Your Model Number is: 97851
Your Version Code is: 1.0/0421/TG
CARE INSTRUCTIONS:
Metal pieces can be wiped clean with a damp cloth and mild soap and dry thoroughly.
Periodically inspect the product to ensure all the parts remain tight.
WARNING
ADULT ASSEMBLY REQUIRED
DUE TO THE PRESENCE OF SMALL PARTS AND SHARP
POINTS DURING ASSEMBLY, KEEP OUT OF REACH OF
CHILDREN UNTIL ASSEMBLY IS COMPLETE.
READ ALL INSTRUCTIONS before use of this product.
Keep instructions for future use. Use only the parts and hardware
provided by Badger Basket®. Do not use the product if it is damaged, broken, or
missing parts. DO NOT allow anyone to climb, sit on, stand on, or play on or inside of this
product. It is not a seat, step stool, or ladder. Periodically check to make sure all the
hardware remains tight. No product is a replacement for adult supervision.
WARNING - FAILURE TO FOLLOW THESE
WARNINGS AND THE INSTRUCTIONS COULD
RESULT IN SERIOUS INJURY OR DEATH

A
C D
E F
G H
I×16 J K×2
L×2 M N
B
LEFT METAL SECTION RIGHT METAL SECTION
METAL MIDDLE SHELF METAL TOP
METAL BOTTOM METAL MIDDLE DIVIDER
METAL TOP DIVIDER METAL FRONT
BOLT
ALLEN WRENCH
6×25mm 6×30mm
TOOL REQUIRED
(NOT INCLUDED)

1
2
I×4
I×6
D
I
I
I
I
A
CB
I
I
For Steps 1 – 3, we suggest leaving the bolts slightly loose. Bolts should be
tightened completely as noted in Step 4.
Open PART A – LEFT METAL SECTION and PART B – RIGHT METAL
SECTION and push together, slide in PART C – METAL
MIDDLE SHELF and fasten bolts
Set the unit onto PART D – METAL TOP and fasten bolts

E
F
G
I
I
I
I
3
4
I×6
Turn the unit over and set onto PART E – METAL BOTTOM and fasten bolts
Slide in PART G – METAL TOP DIVIDER and PART F – METAL MIDDLE DIVIDER
then tighten all bolts completely with PART J – ALLEN WRENCH

H
5
6
7
Slide in PART H – METAL FRONT
WALL
1
WALL
LL
2
WALL
K
K
3
WALL
M
4
N
