Baker Hughes Masoneilan 71000 Series User manual
71000 Series
Heavy Duty, Streamlined
Angle Control Valve
Instruction Manual (Rev.D)
Copyright 2023 Baker Hughes Company. All rights reserved.
THESE INSTRUCTIONS PROVIDE THE CUSTOMER/OPERATOR WITH IMPORTANT PROJECT-
SPECIFIC REFERENCE INFORMATION IN ADDITION TO THE CUSTOMER/OPERATOR’S
NORMAL OPERATION AND MAINTENANCE PROCEDURES. SINCE OPERATION AND
MAINTENANCE PHILOSOPHIES VARY, BAKER HUGHES COMPANY (AND ITS SUBSIDIARIES
AND AFFILIATES) DOES NOT ATTEMPT TO DICTATE SPECIFIC PROCEDURES, BUT TO
PROVIDE BASIC LIMITATIONS AND REQUIREMENTS CREATED BY THE TYPE OF EQUIPMENT
PROVIDED.
THESE INSTRUCTIONS ASSUME THAT OPERATORS ALREADY HAVE A GENERAL
UNDERSTANDING OF THE REQUIREMENTS FOR SAFE OPERATION OF MECHANICAL AND
ELECTRICAL EQUIPMENT IN POTENTIALLY HAZARDOUS ENVIRONMENTS. THEREFORE,
THESE INSTRUCTIONS SHOULD BE INTERPRETED AND APPLIED IN CONJUNCTION WITH
THE SAFETY RULES AND REGULATIONS APPLICABLE AT THE SITE AND THE PARTICULAR
REQUIREMENTS FOR OPERATION OF OTHER EQUIPMENT AT THE SITE.
THESE INSTRUCTIONS DO NOT PURPORT TO COVER ALL DETAILS OR VARIATIONS IN
EQUIPMENT NOR TO PROVIDE FOR EVERY POSSIBLE CONTINGENCY TO BE MET IN
CONNECTION WITH INSTALLATION, OPERATION OR MAINTENANCE. SHOULD FURTHER
INFORMATION BE DESIRED OR SHOULD PARTICULAR PROBLEMS ARISE WHICH ARE NOT
COVERED SUFFICIENTLY FOR THE CUSTOMER/OPERATOR’S PURPOSES THE MATTER
SHOULD BE REFERRED TO BAKER HUGHES.
THE RIGHTS, OBLIGATIONS AND LIABILITIES OF BAKER HUGHES AND THE CUSTOMER/
OPERATOR ARE STRICTLY LIMITED TO THOSE EXPRESSLY PROVIDED IN THE CONTRACT
RELATING TO THE SUPPLY OF THE EQUIPMENT. NO ADDITIONAL REPRESENTATIONS OR
WARRANTIES BY BAKER HUGHES REGARDING THE EQUIPMENT OR ITS USE ARE GIVEN
OR IMPLIED BY THE ISSUE OF THESE INSTRUCTIONS.
THESE INSTRUCTIONS ARE FURNISHED TO THE CUSTOMER/OPERATOR SOLELY TO
ASSIST IN THE INSTALLATION, TESTING, OPERATION, AND/OR MAINTENANCE OF THE
EQUIPMENT DESCRIBED. THIS DOCUMENT SHALL NOT BE REPRODUCED IN WHOLE OR IN
PART WITHOUT THE WRITTEN APPROVAL OF BAKER HUGHES.
Copyright 2023 Baker Hughes Company. All rights reserved.
Table of Contents
Safety Information.....................................................................................................................1
Numbering System....................................................................................................................2
1. Introduction............................................................................................................................3
1.1 Field of Application ....................................................................................................................... 3
................................................................................................................................... 3
1.3 Actuator and Other Accessories ................................................................................................... 3
2. Unpacking ..............................................................................................................................3
3. Installation..............................................................................................................................3
........................................................................................................................ 3
3.2 Isolation Bypass Valve.................................................................................................................. 3
3.3 Flow Direction............................................................................................................................... 3
4. Maintenance...........................................................................................................................4
................................................................................................................................. 4
5. Maintenance & Repair...........................................................................................................4
5.1 Threaded Seat Ring Removal ...................................................................................................... 4
..................................................................................................................... 4
5.3 Lapping Seats............................................................................................................................... 5
5.3.1 Threaded Trim .................................................................................................................... 5
........................................................................................................................ 5
.................................................................................................... 5
5.4.2 Replacing Existing Stem Only ............................................................................................. 6
.................................................................................................................................. 7
...................................................... 7
....................................................................................................... 7
........................................................................................................................... 7
............................................................................................................. 7
5.5.3.1.1 Stem .................................................................................................................... 7
........................................................................................................ 8
................................................................................................................ 8
5.5.3.1.4 Spring Loaded Follower ...................................................................................... 8
................................................................................................ 8
........................................................................................................ 9
.................................................................................................................................. 10
Tightening Torque .....................................................................................................................11
Parts Reference Diagram..........................................................................................................12
Parts List ....................................................................................................................................12
Copyright 2023 Baker Hughes Company. All rights reserved.
Safety Information
Important - Please read before installation
These instructions contain DANGER, WARNING, and CAUTION
installing and maintaining your control valve. DANGER and
WARNING hazards are related to personal injury. CAUTION
hazards involve equipment or property damage. Operation
of damaged equipment can, under certain operational
conditions, result in degraded process system performance
that can lead to injury or death. Total compliance with all
DANGER, WARNING, and CAUTION notices is required for
safe operation.
CAUTION
CAUTION
WARNING
DANGER
CAUTION
CAUTION
WARNING
DANGER
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
CAUTION
WARNING
DANGER
Indicates a potentially hazardous situation which, if not avoided,
could result in serious injury.
CAUTION
CAUTION
WARNING
DANGER
Indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury.
CAUTION
CAUTION
WARNING
DANGER
hazardous situation which, if not avoided, could result in property
damage.
Note: Indicates important facts and conditions.
About this Manual
•
prior notice.
• The information contained in this manual, in whole or part,
written permission.
•
in this manual to your local supplier.
• These instructions are written specifically for the
Masoneilan™ 71000 Series Streamlined Angle Valves,
and do not apply for other valves outside of this product
line.
Useful Life Period
The current estimated useful life period for the 71000 Series
a certified technician. To maximize the useful life of the product, it
is essential to conduct annual inspections, routine maintenance
and ensure proper installation to avoid any unintended stresses
on the product. The specific operating conditions will also impact
the useful life of the product. Consult the factory for guidance on
specific applications if required prior to installation.
Warranty
in materials and workmanship for a period of one year from the
date of shipment provided said items are used according to
Baker Hughes recommended usages. Baker Hughes reserves
the right to discontinue manufacture of any product or change
product materials, design or specifications without notice.
Note: Prior to installation
•
•
system.
• Under certain operating conditions, the use of damaged
equipment could cause a degradation of the performance
of the system which may lead to personal injury or death.
• Changes to specifications, structure, and components
used may not lead to the revision of this manual unless
such changes affect the function and performance of the
product.
Copyright 2023 Baker Hughes Company. All rights reserved.
Numbering System
Body Series Bonnet Type
7 Angle
5 Heavy Duty
2nd 3rd 4th 5th
2nd
1
1st
7
1st
Actuator Type
Spring Diaphragm
87 Spring-Diaphragm
Direct, Air to Close
(fail to open action)
88 Spring-Diaphragm
Reverse, Air to Open
(fail to close action)
Piston Actuator
spring. Air to Open or
Air to Close action
Spring return,
Direct, Air to Close,
single acting
(fail open action)
Spring return,
Reverse, Air to Open,
single acting
(fail close action)
2 Equal %
Contoured
1 Single Seat
Down
Seating
Notes:
Copyright 2023 Baker Hughes Company. All rights reserved.
1. Introduction
1.1 Field of Application
The following instructions are designed to guide the user during
the installation and maintenance of 71000 Series Streamlined
Angle Valves.
and understood prior to installing, operating or performing
maintenance on this equipment. Throughout the text, safety
otherwise, serious injury or equipment malfunction could result.
Baker Hughes has a highly skilled After Sales Department
component parts.
performing maintenance use only Masoneilan replacement
spare parts department. When ordering parts, always include
1.2 Serial Plate
This plate is usually fixed on the side of the actuator yoke. It
class, pressure shell material, actuator pressure supply, and
other necessary information.
1.3 Actuator and Other Accessories
The valve is normally equipped with an actuator. There is a
particular instruction manual for each actuator, as well as for all
actuator instruction manual for electrical and air connections. The
71000 Series most commonly uses the 51/52/53 Series piston
cylinder actuators, or the 87/88 spring diaphragm actuators.
Note: This manual describes all standard options of the
71000 Series valves. In order to meet the particular
requirements of your application, Baker Hughes may have
developed a special option covered by an Appendix to the
present manual. If this is the case, the instructions of this
Appendix always prevail over the general manual
instructions.
WARNING
applied regulations, standards and criterion.
2. Unpacking
damage to the accessories and component parts. Contact the
local Baker Hughes Sales office or Service Center with any
3. Installation
3.1 Piping Cleanliness
Before installing the valve in the line, clean piping and valve of all
foreign material such as welding chips, scale, oil, grease or dirt.
proof joints.
3.2 Isolation Bypass Valve
To allow for in-line inspection, maintenance or removal of the
valve without service interruption, provide a manually operated
stop valve on each side of the 71000 Series valve with a manually
in Figure 1).
Figure 1 - Typical Installation with isolation valves
to allow for in-line inspection.
3.3 Flow Direction
installed actuator, unless otherwise noted.
Copyright 2023 Baker Hughes Company. All rights reserved.
4. Maintenance
maintenance or replacement of a damaged part, proceed as
Prior to performing maintenance on the valve,
isolate the valve and vent the process pressure.
Shutoff the supply air line and the pneumatic or
electric signal.
4.1 Disassembly
•
supply, positioner signal pressure, and from the volume tank
•
installation.
•
and outlet while slightly pulling upward to relieve the weight
•
instruction manual for the specific actuator model.
• If the valve is installed in a horizontal position, also run a
applied against the piping system, while disconnecting and
removing the valve.
• Unscrew the packing stud nuts (B028) in order to reduce the
packing adhesion to the plug stem.
• Disconnect the plug stem (B008) from the actuator stem.
• Remove the yoke nut (B013) and separate the actuator with
•
plug stem (B008).
Care must be given to avoid damage to the plug
and plug guiding surfaces
CAUTION
•
situated one pair opposite the other, then leaning on a flat
on the plug stem in order to “unstick” the plug and the guide
(B006), then lift them off slowly either together or separately.
•
as the plug guide (B006) and separate them if necessary.
Remove the gasket (B009); pull out the packing (B011).
• Unscrew the seat ring retainer (B001) and remove the
5. Maintenance & Repair
Note: Spiral wound gaskets (B009 and B010) should not be
reused, and it is imperative that new gaskets be installed
each time the valve is disassembled.
The purpose of this section is to provide recommended
maintenance and repair procedures. These procedures assume
5.1 Threaded Seat Ring Removal
remove.
engage the seat ring lugs and adapted to a standard wrench. If
the seat ring is exceptionally resistant to removal, the application
CAUTION
CAUTION
WARNING
DANGER
When using heating devices, ensure that proper
safety practices are observed. Flammability and
toxicity of the process uid must be considered and
proper precautions taken.
5.2 Plug Guide Removal
The plug guide (B006) is a slide fit over the valve plug (B005). It
Masoneilan repair shop upon request.
Copyright 2023 Baker Hughes Company. All rights reserved.
5.3 Lapping Seats
Lapping is the process of working the valve plug against the
seating surface angle of the plug is 30 degrees and the seat ring
is 40 degrees (relative to the centerline axis). A good grade of fine
grinding compound is required for the lapping operation.
such as graphite. This will slow the cutting rate and prevent
tearing of the seating surfaces. The amount of lapping required
depends on the materials, condition of seating surfaces, and
improve seating, there is usually no advantage in continuing as
excessive lapping may result in rough seats. The only remedy is
finish with a finer grade (600 grit).
Note: Lapping should produce a line contact area, not the
entire surface, due to the difference in seat angles.
CAUTION
CAUTION
WARNING
DANGER
Before lapping, the plug and stem sub-assembly
must be concentric. (See pinning operation, section
5.4).
5.3.1 Threaded Trim
1.
2.
cleaned.
Note: A sealant compatible with the process should be
applied sparingly to the seat ring threads and sealing
shoulder.
3.
for removal. If the seat ring is exceptionally resistant to
helpful.
CAUTION
CAUTION
WARNING
DANGER
Ensure proper safety practices are observed when
using heating devices. Flammability and toxicity of
the process uid must be considered, and proper
precautions must be taken.
Do not over-tighten. Do not strike seat ring lugs
directly. This could distort the seat ring resulting in
seat leakage.
4. Apply lapping compound on the plug at several spots equally
spaced around the seating area.
5.
6.
Apply slight pressure and tighten evenly.
7. Insert two or three pieces of packing rings (B011) into the packing
8. Screw a drilled and tapped rod with a T-handle onto the plug
stem and secure with a locknut.
Note: As an alternative, drill a hole through a flat steel
plate and fasten to the plug stem using two locknuts.
9. Apply slight pressure on the stem, and rotate the stem in
short oscillating strokes (around 8 to 10 times). Repeat this
step as necessary.
Note: The plug should be lifted and turned 90° each
time before repeating Step (9). This intermittent lifting is
required to keep the plug and seat ring concentric during
lapping.
CAUTION
CAUTION
WARNING
DANGER
Avoid over-lapping as this can cause damage to
the seating surface rather than improve leakage
performance.
10.
and plug. The seating area of the seat ring and the plug
Do not remove seat ring.
CAUTION
CAUTION
WARNING
DANGER
Maintenance of the plug should be limited to
cleaning of the ports and the procedures dened
under Sections 5.3 (Lapping) and 5.4 (Pinning) as
required.
5.4 Plug Stem Pinning
- Replacing existing plug and stem, or
- Replacing existing stem only
Note: If it is necessary to replace the plug, then the plug stem
must be replaced at the same time. The original pin hole in
an existing stem will not provide the necessary fit, and might
seriously impair the strength of the assembly.
5.4.1 Replacing Plug and Stem
CAUTION
CAUTION
WARNING
DANGER
Do not tighten nuts to nal torque specications at
this time. The bonnet is used temporarily for guiding
purposes only.
CAUTION
CAUTION
WARNING
DANGER
Use care to avoid damage to the guiding surfaces of
the valve plug during disassembly, assembly, and
pinning operations.
Copyright 2023 Baker Hughes Company. All rights reserved.
A. Reference Marking on the Plug Stem
Measure the depth of the pilot recess in the plug (B005)
(Dimension X as shown in Figure 2), and make a reference
mark on the plug stem (B008) at the same distance from the
thread.
B. Screwing Stem to Plug
• Hold the plug (B005) in a vise using soft jaws to prevent
surface damage.
•
Lock two nuts against each other on the end of the new
plug stem (B008), and screw the stem solidly into the plug
(B005) using a wrench on the upper nut.
guide.
C. Drilling the New Parts
• If the plug (B005) is already fully drilled, then drill the
stem (B008) to the same diameter (see Figure 2) as the
plug (B005) shank hole.
• If the plug guide area has a center mark,
- Match the hole size in the plug, or
- Match Diameter C (see Figure 2)
If the plug (B005) area does not have any hole or any center
mark,
and plug stem (B008) diameter (see Figure 2).
mark on the plug (B005) area using a center punch.
In all cases after drilling:
While pinning is being performed, care must be taken
not to damage the seating surface or plug guide. Always
use a soft metal or plastic vice jaws with cylindrical
features to hold the plug guide area (see Figure 2).
CAUTION
Figure 2 - Plug Stem Pinning
==
Soft metal
or plastic
vise jaws
Cylindrical machining
diameter of the jaws =
plug guide diameter “A”
C Dia.
D
X
X
AB
Reference Mark
==
Soft metal
or plastic
vise jaws
Cylindrical machining
diameter of the jaws =
plug guide diameter “A”
C Dia.
D
X
X
AB
Reference Mark
==
Soft metal
or plastic
vise jaws
Cylindrical machining
diameter of the jaws =
plug guide diameter “A”
C Dia.
D
X
X
AB
Reference Mark
Trim
Size
Pressure
Class Capacity
Plug diameter
A
Inches
Stem Diameter
B
Inches
Pin hole Diameter
C
Inches
D
Inches
X
Inches
1Up to 2500 Reduced 0.98 0.38 0.100 0.94 0.37
Full
1.5 Up to 2500 Reduced 0.98 0.50 0.138 1.25 0.50
Full 1.38
2Up to 2500 Reduced 1.61 0.75 0.197 1.88 0.75
Full 1.97
3
Up to 1500 Reduced 1.97 0.75 0.197 1.88 0.75
2500 1.00 2.00 0.98
Up to 1500 Full 2.72 0.75 0.197 1.88 0.75
2500 1.00 2.00 0.98
4
Up to 1500 Reduced 2.72 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
Up to 1500 Full 3.58 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
6
Up to 1500 Reduced 3.98 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
Up to 1500 Full 5.47 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
8
Up to 1500 Reduced 5.47 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
Up to 1500 Full 6.30 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
10
Up to 1500 Reduced 6.30 1.00 0.197 2.00 0.98
2500 1.25 0.315 3.13 1.25
Up to 1500 Full 4.37 1.25 0.315 3.13 1.25
2500 1.50 0.394 3.50 1.50
12 Up to 1500 Full 4.37 1.25 0.315 3.13 1.25
Copyright 2023 Baker Hughes Company. All rights reserved.
D. Pinning the Plug-Stem Assembly
1.
plug (B005) diameter and plug stem (B008) diameter (
see
Figure 2
). Apply a small amount of grease on the pin and
2.
hammer while the plug is held is a vise. (see Figure 2).
3.
placed in a lathe to ensure it is concentric with the stem.
mallet.
5.4.2 Replacing Existing Stem Only
A. Removing Existing Pin and Stem
1.
to drive out the old plug stem pin (B007).
Note: If it is necessary to drill out the pin, use a drill
bit slightly smaller than the pin diameter.
2. Hold the plug (B005) in a vise (Follow previous CAUTION
alerts to protect parts).
3. Lock one nut against another at the end of the plug stem
(B008). Using a wrench on the lower nut, unscrew the stem
counter-clockwise.
B. Screwing Stem to Plug
C. Drilling the New Stem
as a guide).
D. Pinning
previous section, taking care not to damage the plug guide
area.
5.5 Packing Box
packing flange nuts (B028) against the packing flange (B014). Care
operation of the valve. If all compression is used up and the valve
leaks, then new packing is required.
CAUTION
CAUTION
WARNING
DANGER
Valve must be isolated and the pressure vented be-
fore performing packing box maintenance.
5.5.1 Braided PTFE with Carbon or Aramid Core (Standard)
Note: The Braided PTFE/Carbon or Aramid packing rings
have a skive cut allowing packing replacement without
disconnecting the plug stem from the actuator connector or
actuator stem.
A. Loosen and remove packing flange nuts (B028).
B. Lift the packing flange (B014) and packing follower (B030) up
the valve stem.
Note: They may be taped in place to keep them out of
the way before proceeding.
C. By means of a hooked instrument, remove packing rings
(B011) ensuring not to damage the sealing surfaces of the
Note: On valves equipped with an optional lubricator
connection, the lantern ring must also be removed to
gain access to lower packing rings.
D. Replace packing rings (B011).
Note: Assemble and compress rings one at a time into
packing box. The skive cut of each packing ring must be
placed about 120 degrees apart.
Note: On valves equipped with an optional lubricator
connection, see Figure 4 for correct amount of rings to
place under the lantern ring .
E. Replace packing follower (B030) and packing flange (B014).
F. Replace and tighten packing stud nuts (B028).
CAUTION
CAUTION
WARNING
DANGER
Do not over tighten.
G.
necessary to stop external leakage.
Note: In an emergency, string packing may be used as
a temporary repair only. It must be replaced with the
correct packing as soon as possible.
5.5.2 Flexible Graphite Rings
Note: Flexible graphite packing rings replacement may require
disconnecting the plug stem from the actuator stem and removal
of the actuator if rings are not skive cut.
A. Loosen and remove packing flange nuts (B028).
B. Remove packing flange (B014) and packing follower (B030)
from the plug stem.
C. By means of a hooked instrument, remove packing (B011)
ensuring not to damage the sealing surfaces of the packing
Note: On valves equipped with an optional lubricator
connection, the lantern ring must also be removed to
gain access to lower packing rings.
D.
ring (Graphite Filament Yarn braided ring),
graphite rings (smooth rings),
Note: Assemble and compress rings one at a time into
packing box.
Note: On valves equipped with an optional lubricator
connection, see Figure 4 for correct arrangement
according to valve size.
E.
F.
Copyright 2023 Baker Hughes Company. All rights reserved.
CAUTION
CAUTION
WARNING
DANGER
Do not over-tighten.
G.
H.
necessary to stop external leakage.
5.5.3 LE Packing
configuration if required.
The packing is provided as a set of rings consisting of middle
rings. All of our Low-E solutions come with Live Loading which
is imperative to maintain a constant load on the packing and is
necessary for thermal cycling applications.
Consequently, it can effectively prevent fugitive emissions leaks
from a control valve. The Low-E packing system can directly
replace conventional packing, requiring no modification to the
control valve or actuator.
The packing material could vary depending on the specifications
and timing when the valve was ordered. It is important to
5.5.3.1 Preparation
5.5.3.1.1 Stem
Inspect stem for any nicks or scratches on the surface
finish. Reject the stem for any of these reasons as they may
damage packing.
Note: A properly etched part number on the stem in
the packing area will have no adverse effect on the
performance of the packing.
5.5.3.1.2 Packing Box
Note: Bonnets that have a lube hole or leak detection port
are unacceptable for use with the packing arrangement.
CAUTION
CAUTION
WARNING
DANGER
Packing box should be clean and free of burrs, rust,
and any foreign matter. Parts can be cleaned with
denatured alcohol.
Note: Packing box finish should be 125 AARH (Ra 3,2) or
better.
Packing box must be finished to the bottom of the bore.
5.5.3.1.3 Packing
Inspect packing rings. DO NOT use packing if any nicks or
to ensure that it is in proper arrangement (different packing
materials contain arrangements specific to the design).
5.5.3.2 Packing Installation
a. Refer to the packing instructions that were provided
with the packing for proper installation.
b
an additional aid while completing the packing
installation.
c
Note: All exposed surfaces of the packing set must be
covered with the lubricant.
d
cycled approximately 500 times. Adjust if necessary.
periodically inspect valves to spot leakage. Adjust if
necessary and per OEM recommendations. If leak is
not resolved, packing and any non-confirming hardware
Valve
Size
Total
6
7
200 88
Quantity of Packing Rings (6)
Packing box with Kevlar
/
PTFE
packing rings
Lantern
Ring
(7)
Packing box with
Flexible Graphite packing rings
and Back-up rings
Braided
Back-up Rings
Flexible
Graphite Rings
Lantern
Ring
(7)
Total
6
7
8
in.
3/4 to4
6 to8
mm
20 to 100
150 to 200
Figure 3 - Packing Ring Arrangements with Optional Lubricator Connection
Copyright 2023 Baker Hughes Company. All rights reserved.
5.5.4 Packing Box Efficiency
routing operations of the maintenance service. In order to
provide a correct functioning of the valve, the packing should
necessary only to remove the packing follower and flange and
introduce one or two split rings.
Note: In case of urgency, the braided packing of suitable
section can be inserted without removal of the worn rings.
Before this operation, the valve must be put out of service. If
the packing is made up of non-split rings, it may be necessary
to disassemble the valve and remove the worn packing. To
repack the stuffing box, see paragraph “Reassembling”.
Copyright 2023 Baker Hughes Company. All rights reserved.
6.0 Reassembly
the corrosion, erosion or wear. It is also necessary to replace the
• Clean all gasket mating surfaces
•
amount of sealant to the seat ring retainer (B001) threads
and sealing shoulder, and screw and lock the seat ring
Note: A sealant compatible with the process should be
applied sparingly on the retainer thread.
•
Center the guide gasket (B010) on the top of the guide (B006),
centered on the upper part of the guide.
•
size.
•
one. If packing rings have a radial cut, stagger the cut of
• Slip the packing follower and flange over the plug stem.
Tighten the nuts (B028) manually. Verify if the plug
nuts (B028) to another full turn with the wrench.
•
(B013).
• Be sure that the plug sits normally on the seat ring and
connect the actuator to airline or to electrical circuit.
• Connect the actuator stem to the valve stem in accordance
with the appropriate actuator instruction manual. The 71000
Series most commonly uses the 51/52/53 Series piston
cylinder actuators, or the 87/88 spring diaphragm actuators.
• Replace the valve on the piping, carry out the connections
and start it up again.
CAUTION
CAUTION
WARNING
DANGER
Do not over-tighten or strike seat ring (B002) or seat
ring retainer (B001) directly. This could distort the
seating area resulting in unwarranted seat leakage.
CAUTION
CAUTION
WARNING
DANGER
Care must be taken during assembly to ensure proper
alignment of the trim, and that the plug and plug guid-
ing surfaces do not get damaged.
CAUTION
CAUTION
WARNING
DANGER
For bonnet with purge or injection connection: NPT or
ange. Before achieving metal to metal contact with
the body, rotate the bonnet to orient this connection
in front of the existing piping.
Copyright 2023 Baker Hughes Company. All rights reserved.
Valve Size
ANSI Class
Max.
Body Studs
Required Torque
Carbon Steel
Body Studs Retainer Seat Ring
mm in. Size Qty Ft. Lbs daN.m Ft. Lbs daN.m
25
1
600 1/2 - 13 UNC
4
52
7
148 20
40 600 3/4 - 10 UNC
4
118 16 148 20
50
2
600 5/8 - 11 UNC
8
96 13 221 30
80
3
600 3/4 - 10 UNC
8
170 23 1475 200
100
4
600 7/8 - 9 UNC
8
295 40 3690 500
150
6
600 1 - 8 UN 12 288 39 4425 600
200
8
600 ¹ ³ 12 605 82 4425 600
250 10 600 16 443 60 11065 1500
300 12 600 16 443 60 1106 5 1500
Tightening Torque
Copyright 2023 Baker Hughes Company. All rights reserved.
Parts Reference Diagram
Item Designation Item Designation
B001 Seat ring retainer B011
B002 Seat ring B013 Yoke nut
B004 B014
B005 Valve plug B028
B006 B029
B007 B030
B008 B032 Bonnet stud nut
B009 B033 Bonnet stud
B010
(8, 10 and 12 sizes only) B034 Bonnet
Parts List
Copyright 2023 Baker Hughes Company. All rights reserved. Baker Hughes provides this information on an
Contact your Baker Hughes representative for the most current information. The Baker Hughes logo and
Masoneilan are trademarks of Baker Hughes Company. Other company names and product names used in
this document are the registered trademarks or trademarks of their respective owners.
BHMN-71000-IOM-33420D-0923 09/2023
Tech Field Support & Warranty:
Find the nearest local Channel Partner in your area:
valves.bakerhughes.com
bakerhughes.com
Other manuals for Masoneilan 71000 Series
1
Table of contents
Other Baker Hughes Control Unit manuals
Baker Hughes
Baker Hughes Masoneilan 41005 Series User manual
Baker Hughes
Baker Hughes Masoneilan 72000 Series User manual
Baker Hughes
Baker Hughes Masoneilan 78-80S User manual
Baker Hughes
Baker Hughes Masoneilan 39004 Series User manual
Baker Hughes
Baker Hughes Consolidated 1982 Series User manual
Baker Hughes
Baker Hughes Consolidated 1811 Series User manual
Baker Hughes
Baker Hughes Masoneilan LincolnLog 78400/18400 Series User manual
Baker Hughes
Baker Hughes Masoneilan VariPak 28000 Series User manual
Baker Hughes
Baker Hughes Mooney Flowgrid Slam Shut User manual
Baker Hughes
Baker Hughes Consolidated 2900-40 Series User manual
Baker Hughes
Baker Hughes Consolidated 1900/P Series User manual
Baker Hughes
Baker Hughes Masoneilan DSH Series User manual
Baker Hughes
Baker Hughes 13900 Series User manual
Baker Hughes
Baker Hughes Masoneilan V-Max 36005 Series User manual
Baker Hughes
Baker Hughes Masoneilan 78-80H User manual
Baker Hughes
Baker Hughes Masoneilan SteamForm 84003 Series User manual
Baker Hughes
Baker Hughes Masoneilan 49000 Series User manual
Baker Hughes
Baker Hughes Masoneilan 77000 Series User manual
Baker Hughes
Baker Hughes Masoneilan 73000 Series User manual
Baker Hughes
Baker Hughes Consolidated 2900 series User manual
Popular Control Unit manuals by other brands
Ducati
Ducati CTR31 instruction manual
LOGOMAT
LOGOMAT HSL CPU installation guide
S&S Northern
S&S Northern Merlin 1000S Installation, operating and maintenance guide
Texas Instruments
Texas Instruments TPSM84424EVM user guide
Allen-Bradley
Allen-Bradley MicroLogix 1762-IF4 installation instructions
ABB
ABB ACQ810 Hardware manual
Hydro Instruments
Hydro Instruments PRV-71H Series Operation and maintenance manual
Efka
Efka AB600A5010 operating manual
Atlas Copco
Atlas Copco Power Focus 3000 Original product instructions
Clack Valve
Clack Valve WS1 CD Matrix Operation and instruction manual
Anybus
Anybus CompactCom 40 Modbus-TCP Network guide
Metel
Metel IPLOG-DELTA-1 installation manual
