Bakfiets Q-3 User manual

Bakfiets
Q-3
Two-wheel cargo bike assembly manual

1
2
3
4
5
6
7
8
10
9
11
12
13
14
15
16
17
18
19
21
23
22
20
24

1
2
3
4
5
6
7
8
10
9
11
12
13
14
15
16
17
18
19
21
23
22
20
24

1.Handle bar & brake lever 2.gear shift 3.brake lever 4.box5.corner iron
6.front light
7.Front wheel 8.front brake 9.fork 10. turning rod 11.park frame12.frame
13.Chain cover & chain 14.chainwheel and crank 15.pedal 16.rear wheel
17.rear fender
18.rear reflector 19.seat post lock 20.seat post 21.saddle 22.rubber band
23. carrier
24. front fender
1. Assemble the front wheel set
a. When front brake is Drum brake
Assembly the fender onto the fork as shown in figure bellow, and then
put the front wheel with drum brake between fork two legs, and fix the
wheel with drum brake leg and lock it with nut. Adjust the brake cable
and fix it.

b.When the front brake is V brake
Assemble the fender onto the fork as shown in figure below,and then put the
wheel set between fork legs and lock it as figure 2. Adjust the V brake and
brake cable length and lock it.
figure3
frame
Wheel with
drum brake
nut
fork
fender

c. .When front brake is roller brake
Assemble the fender onto the fork as shown in figure below, and then put the
front wheel wth drum brake between fork two legs, and fix the roller brake and
lock it with nut. Adjust the brake cable and fix it.
fork
Frame
V
brake
Figure 2
Lock nut
fender
Front wheel set

2.Assemble the parking stand
Assemble the parking stand on to the frame and lock it. And then pull on the
spring as shown in figure 4.
Figure1
Frame
Front fender
Front wheel set
Roller brake
Lock nut
Lock nut
adjuster
Fork

3.Assembly the handle bar
Assemble the handle bar as shown in figure below, adjust the height and
frame
Parking stand
Mandrel axel
spring
Figure 4

4.Assemble the box and safety belt
Assemble the box as shown in figure 6 and fix it with bolt, fix the safety belt
on the box.
lock it.
Figure 5
box
Gear shift
Brake lever
Brake lever
Brake cable
Gear cable
Handle bar

5.Assemble saddle and pedal
Insert seat post into the seat and lock it with nut as show
in figure 9.
figure6
Figure 7
figure8
Corner iron
Cover
type nut
Bolt with
wisher
Safety belt
Safety belt
Corner iron
9015
box
9016
box

Put another end of post into the frame seat tube and
lock the post lock. （Note：Safety line must be under
the seat post lock ）
Figure9
Saddle
Seat post
Seat post lock
Frame seat tube
