BALDR 330 User manual

MULTI-PURPOSE POWER STATION
RECOMMENDED TO FULLY CHARGE BALDR 330 BEFORE USE
www.zestpowers.com
BALDR 330

GENERAL SPECIFICATIONS
The BALDR 330 is a portable battery pack with the ability to supply 330W of pure sine wave
AC power via the onboard AC output. Additionally, The BALDR 330 is able to support USB
quick charging via the onboard 1 x USB-C port and 3 x USB-A ports. Overall storage capacity
is 297Wh of energy.
1
Capacity
Cell Type
297Wh (82500mAh / 3.6V)
18650
Lithium-ion
L8"xW 6"xH6.5"(L204 x W154 x H164mm)Dimensions
Cell Chemistry
Weight 7.6 lbs (3.46 kg)
Fully charged 5 to 7 hoursCharging Time
Shelf Life Charge every 3 months (fully charged before storage)
Input, 8mm Charging Port
Output USB-A ( x 3 )
12-24V, up to 4A (Max 52W)
110V+/-10%, 60Hz (330W Rated, 700W Surge)
5V,9V,12V, up to 3A, (Max 54W total,with QC3.0 protocol)
Output AC(Output, pure
sine wave)
Output USB-C ( x 1 ) 5V,9V,12V, up to 3A, (Max 18W, without USB-PD protocol)
Output DC ( x 2 ) 5521 type, 12V/5A
Output Cigarette lighter 12V/10A
Wireless Charger 5W
LED Light Power 2W
Operating / Storage Altitude up to 6562 ft. (2000m)
Operating / Storage
Maximum Humidity up to 75% non-condensing
Operating Temp 14 to 104°F (-10 to 40°C)
Charging Temp 32 to 113°F (0 to 45°C)
Storage Temp -4 to 113°F (-20 to 45°C)
500 cycles to 85% capacity typical (depending on use
and care)
Life Expectancy

WARNINGS
To ensure safe operation and service of the meter, follow these instructions. Failure to
observe these warnings can result in severe injury or death.
• DO NOT use BALDR 330 in excess of its output rating. Overload outputs above rating
may result in a risk of fire or injury to persons, even though we have built-in overload
protection.
• DO NOT use BALDR 330 or AC Wall plug power adapter, if it is damaged or has been
modified. Damaged or modified batteries may exhibit unpredictable behavior resulting in
fire, explosion, or risk of injury.
• DO NOT subject to vibration, impacts, or drops. Secure BALDR 330 during transport.
The housing may not show signs of damage, but internal components may have been
compromised. It is adviseable to replace it if any such severe events occur.
• DO NOT expose BALDR 330 to moisture, rain, or snow.
• DO NOT charge, use or store BALDR 330 in a bathroom or in an area exposed to rain
or moisture.
• DO NOT leave children or the persons, who with reduced physical/sensory or mental
capabilities/or lack of experience and knowledge, along with BALDR 330 unless they have
been given supervision or instruction concerning use of it by a person responsible for
their safety.
• DO NOT attempt to repair BALDR 330 or AC Wall plug power adapt er. There are no
user-serviceable components inside.
• DO NOT handle BALDR 330 with wet hands.
• DO NOT place BALDR 330 on its side or upside down while in use or in storage.
• If rust, odor, overheating, or other abnormal circumstance are observed, stop using and
contact BALDR customer service.
• Children should be supervised to ensure that they DO NOT play with the BALDR 330 alone.
• The BALDR 330 is only used for emergency power station, it cannot replace the standard
AC or DC power of household appliances or digital products.
• Keep away from high voltage electrical fields.
• Risk of fire and burns, DO NOT open, crush, heat above 113°F (45°C) or incinerate. Follow
all instructions.
• Use of a power supply, charger, or cable not recommended or sold by portable battery
manufacturer may result in a risk of fire or injury to persons.
• Should fluid from inside of BALDR 330 come in contact with your skin or clothing, wash
the affected areas with tap water.
• The accessories included in the box should only be used with the BALDR 330.
• KEEP THIS PRODUCT AWAY FROM PETS.
2

FEATURE DETAILS
BUTTON FEATURE
LCD Screen Display
DC Output
Cigarette Lighter Output
USB-C Output
USB-A Output
330W Rated AC Output
Anti-collision Strip
DC Input
A: BALDR 330 Power ON/OFF Button
B: SOS mode & LED light Button
C: DC Output Power ON/OFF Button
D: USB Output Power ON/OFF Button
E: AC Output Power ON/OFF Button
SOS MODE & LED light
Wireless Charger
Folding Handle
Air Intake Vent with Cooling Fan
Note: No user-serviceable parts inside.
Recommended to fully charge the BALDR 330 before use.
1
3
4
2
5
7
8
6
9
10
11
12
3
10
12
1
3
24 5 6
7
8
9
11
A
C
B
E
D

LCD FEATURES
HOW TO CHARGE
WHAT IT POWERS
DO NOT CONNECT DEVICE VIA AC OUTPUT PORT WHILE CHARGE THE BALDR 330.
RECOMMEND TO DISCONNECT THE BALDR 330 WHEN FULLY CHARGED.
H
I
H: Battery Level Indicator
I: Input Status
J: DC Output Status
K: AC Output Status
J
K
From Solar Charger
100W 5-7 hours
From Car Port 12V
7-9 hours when car running
From Wall Charger 110V
5-7 hours
depending on solar conditions
Around
6 Recharges
Around
4 hours
Around 6 hours Around 3 Recharges
Around
42 Recharges
Around 2 nights
Laptops (41.4Wh) 32" TV(60W)
DJ Drone(89.2Wh)
Gopro (5.9Wh)
CPAP without heated
humidifier (15W)
Mini Fridge(40W)
Around
27 Recharges
Smartphone(10Wh) Switch(16Wh)
Around
15Recharges
Around
70 hours
Floodlight(4W)
4

WIRELESS CHARGER
Press ON/OFF Button A before charging. Press ON/OFF Button to shut down the output(s)
When not in use.
COOLING FAN
BALDR 330 utilizes an internal cooling fan to ensure the product is operating within the
appropriate temperature range. BALDR 330, when it experiences a higher output load, will
automatically turn on the fan. During discharge, and possibly charging, the fan may operate
intermittently to keep internal temperature within operating range. The fan will likely start when
the AC circuit is activated to ensure proper operation.
FUNCTION BUTTONS
5
USB-C OUTPUT
The USB-C output port will NOT function until the appropriate Button A & D are both pressed
to activate.
The USB-C cable of different devices need different endorsements of corresponding protocols,
if the USB-C port didn't work, try to use the AC output port.
4
10
12
BALDR 330 POWER ON/OFF A
Button A is the master switch. Press Button A to activate the button B/C/D.
Press Button A to shut down the output(s) When not in use. 10 seconds after you turn off the
Button A, BALDR 330 will have a BEEP sound indication.
SOS MODE & LED LIGHT B
Function available no matter the Button A activate or not.
First, press Button B to turn on the LED light;
Second, DOUBLE-Press to turn on the SOS mode;
Third, press Button B back to LED light, one more time again, will turn off the light.
10 seconds after you turn off the Button B, BALDR 330 will have a BEEP sound indication.
DC OUTPUT POWER ON/OFF C
The DC output port will NOT function until the appropriate Button A & Care both pressed to
activate. Press Button C to shut down the output(s) When not in use.
USB OUTPUT POWER ON/OFF D
The USB output port will NOT function until the appropriate Button A & Dare both pressed to
activate.
Press Button D to shut down the output(s) When not in use.
AC OUTPUT POWER ON/OFF E
The AC output port will NOT function until the appropriate Button A & Eare both pressed to
activate.
Press Button E to shut down the output(s) When not in use.

Connect the provided AC Wall power adapter to Input , and allow BALDR 330 to fully charge
prior to use, approx. 5-7 hours. When charging, the LCD Screen will be illuminated, and the
LCD display will provide Battery level Indicator H, BALDR 330 is fully charged when the level
is 100%. It is recommended to fully charge BALDR 330 every 3 months to maintain the health
of the battery pack.
BATTERY LEVEL INDICATOR H : The battery level is provided by percentage of battery
charge corresponding to the number of bars and percentage displayed. The segments in the
battery level correspond to the current state of charge, 0-5% empty, 6-20% one segment,
21-40% two segments, 41-60% three segments, 61-80% four segments, and all five are lit
when charge level is above 81%.
Provides the user live telemetry data on time to completely charge, or deplete the battery based
upon the energy entering or leaving the battery.
Highly recommend to fully charge BALDR 330 when first use. Higher battery level indicator
show, more precise the data will indicate.
PLEASE BE AWARE that this value can adjust multiple times as the energy draw changes from
the connected devices. This is evident during initial activation of ports with a connected device.
RECOMMENDED back to charge the BALDR 330 when battery indicate less than 20%.
Note that when you first plug in a power source, whether it's a solar panel or a wall charger, the
BALDR 330 may take a minute to detect and adjust its charge circuitry before it starts drawing
power from the source.
INPUT Status I: The BALDR 330 is capable of providing input energy in watts.
BALDR 330 charge process is normal when the input watts is 20-60 which show on the battery
level indicator.
DC Output Status J: The display will provide output watts of the DC port .
AC Output Status K: The display will provide output watts of the AC port .
The output watts of USB port will NOT display on the LCD Screen .
LCD Screen will enter sleep mode after 120 seconds of inactivity (no new output load
detected), and will "wake up" when inputting a charging cord or when any button is pressed.
DETAILS DISPLAYED ON LCD
OPERATING INSTRUCTIONS
6
2 3
1
8
1
1
6
CHARGING BALDR 330

Select the type of outlet required by pressing the Output ON/OFF Button C/D/E. The output
port will NOT function until the appropriate button is pressed to activate the port. When
activated, the indicator on the button will illuminate green, indicating that the output(s) are
active, and the LCD display will turn on and provide details on the charging output. The
LCD Screen will automatically shut down when no outputs are activated.
BALDR 330 ACCESSORY LIST
PASS-THROUGH CHARGING
The advanced battery management system of the BALDR 330 allows it to charge a connected
device via DC output & USB output while charge the BALDR 330.
DO NOT CONNECTED DEVICE VIA AC OUTPUT WHILE CHARGE THE BALDR 330.
Do following:
• Check the input charge cable. The port will be efficient when the input charge cable meets
the specification outlined in the GENERAL SPECIFICATIONS section.
• Only charge BALDR 330 with provided AC wall power adapter.
OVERLOAD CONDITION
If an overload condition occurs on the OUTPUT port, BALDR 330 will:
• Automatically turn off AC Output power.
• The blue indicator light of LCD Screen still illuminated.
• DC OUTPUT Status J still the same status as usual.
• 110V AC wall plug
power adapter
• 18V with MC4
connector cable
Recommend to use 100W Solar panel (not included).
• 12V Car Charger
cable
7
1
6
POWERING / CHARGING DEVICES WITH BALDR 330
BALDR 330 will enter sleep mode after120 seconds of inactivity (no new output load detected),
and will "wake up" when inputting a charging cord or when any button is pressed.
Press the ON/OFF button(s) to shut down the output(s) when not in use.
• User Manual

STORAGE
ATTENTION
CLEANING
Transportation:BALDR 330 complies with all legal requirements for transport of dangerous
goods. The capacity of the lithium battery pack exceeds 100Wh. Based on international
standards, if BALDR 330 is transported by airplane, it must be transported in accordance with
IATA standard packaging. IATA instructions and labeling requirements and the relevant
declarations must be completed.
If storing for more than 1 month, charge completely before storage and recharge approximately
every 3 months to avoid full discharge and possible damage.
Store indoors, in cool temperatures, mild humidity, and away from direct sunlight (See GENERAL
SPECIFICATIONS section). Leaving in a vehicle or other confined spaces in extreme hot
temperatures can lead to decreased service life, overheating, and fire. Extreme cold conditions
below specific storage range can also harm BALDR 330 performance and service life.
Keep away from corrosion chemicals and gases.
After taking out of storage, visually inspect to make sure BALDR 330 and all accessories look
satisfactory. This increase review the intake and exhaust side vents to ensure they are clear of
debris. Allow BALDR 330 to return to ambient conditions before recharging, or charging other
Be sure that BALDR 330 is disconnected from all input power sources and output devices.
Use a clean, dry, soft-lint-free cloth to wipe down it. Remove any debris, dirt, or other
blockages on both side vents. When cleaning debris from the side vents, do not allow the
debris, dirt, or other blockages to enter the body of BALDR 330.
DO NOT use abrasive cleaners or solvents.
DO NOT use compressed air to clean side cooling vents, as this will force foreign
particles into the internal circuitry.
To avoid the risk of electrical shock, DO NOT use metal objects to clean ports.
8
devices.

BALDR 330 WILL NOT CHARGE OR OPERATE connected devices:
• Ensure that the DC/USB/AC output ports / / / / are activated by pressing the
Button(s) A & C/D/E for the port(s) in use.
• Confirm the connected device is suitable for the BALDR 330 by reviewing the output
specifications provided in the GENERAL SPECIFICATIONS section.
• Confirm BALDR 330 is charged by reviewing the Battery Level Indicator H.
• Verify the watt data displayed on the Status Indicator I/J/K of LCD Screen for overload
condition.
TROUBLESHOOTING
MAINTENANCE
DISPOSAL/RECYCLE
BALDR 330 WILL NOT CHARGE:
• Confirm that the wall plug power adapter's cord is inserted fully into the DC Input .
• Confirm that the AC wall plug power adapter is the charger provided with BALDR 330.
• If the input does not comply with the requirements located in the GENERAL
SPECIFICATIONS section, the Low Watt range 0 to 10 may be displayed on
INPUT STATUS I of LCD screen .
Recharge as needed. There are no pre-designated intervals at which to recharge as long as the
BALDR 330 is being used regularly. Avoid discharging completed on a regular basis, as this can
impact overall life.
Regularly inspect all ports and wall charger for any debris, dirt, damage and corrosion.
DO NOT attempt to fix.
DO NOT cover the BALDR 330 with towels, clothing or other items.
Regularly observe if the side vents are collecting dirt or dust, and clean following cleaning
procedures noted in manual.
Do not place equipment and its accessories in the trash. Items must be properly disposed
of in accordance with local regulations. See www.epa.gov for additional information.
9
STATEMENT
Copyright BALDR. All rights reserved. All trademarks cited herein are the property of their
respective owners.
The information contained herein is subject to change without notice. The only warranties for
BALDR products and services are set forth in the warranty statements accompanying such
products and services. BALDR shall not be liable for technical or editorial errors or omissions
contained herein.
Second Edition: Mar 2020. This user guide describes features that are common to most models.
C
2
1
1
8
3 4 5 6

WARRANTY
10
Limited Warranty
BALDR Warrants to the original consumer purchaser that the BALDR will be free from defects
in workmanship and material under normal consumer use during the applicable warranty period
identified in the 'Warranty Period' section below, subject to the exclusions set forth below. This
warranty statement sets forth BALDR's total and exclusive warranty obligation. We will not
assume, nor authorize any person to assume for us, any other liability in connection with the
sale of our products.
Warranty Period
The warranty period is 12 months. In each case, the warranty period is measured starting on
the date of purchase by the original consumer purchaser. The sales receipt from the first
consumer purchase, or other reasonable documentary proof, is required in order to establish
the start date of the warranty period.
The warranty can be extended to TWO TOTAL years if you registered via
www.togopower.com or contact [email protected].
Remedy
BALDR will repair or replace( at BALDR's option) any BALDR product that fails to operate
during the applicable warranty period due to defect in workmanship or material. If a valid claim
is made during the applicable period, BALDR, at its option, will either (1) replace the product,
or (2) exchange the product with a product that is of equal value. A replacement product
assumes the remaining warranty of the original product or ninety (90) days from the date of
replacement, whichever is greater. Customer is responsible for the return shipping costs.
Limited to Original Consumer Buyer
The warranty on BALDR's product is limited to the original consumer purchaser and to any
subsequent owner.
Exclusions
BALDR's warranty does not apply to (i) any product that is misused, abused, modified,
damaged by accident, or used for anything other than normal consumer use as authorized in
BALDR's current product literature, or (ii) any product purchased through an online auction
house. BALDR's warranty does not apply to the battery cell unless the battery cell is fully
charged by you within seven days after you purchase the product and at least every 3 months
thereafter.
How to Receive Service
To obtain warranty service, contact our customer service team at [email protected].

NOTES
322 Paseo Tesoro, Walnut, CA 91789
1-855-801-0798
[email protected]
www.zestpowers.com
