BALDR B0359WST4H4PR User manual

WIRELESS COLOR WEATHER STATION
WITH 3 REMOTE SENSORS
MODEL:B0359WST4H4PR (US VERSION)
Thank you for your order. BALDR weather
station is functional product, no matter what
problems you have met while using the
weather station, please feel free to contact
us to get support.
Email：
[e-mail]
Phone：
1-833-381-5659
USER MANUAL

Contents
PRODUCT OVERVIEW 3
3
4
6
7
7
8
9
9
10
12
12
12
12
13
15
15
15
16
16
17
17
17
18
18
20
21
1.1 Package List
1.2 Appearance Description
1.3 Button Function Explanation
INITIAL OPERATION
2.1 Quick Setup
2.2 Barometer Setting
2.3 RF Signal Receiving
2.4 WWVB Signal Receiving
MANUAL SETTINGS
ALARM FUNCTION
3.1 Alarm Time Setting
3.2 Alarm ON/OFF Setting
3.3 Snooze Function
HOW TO GET MORE ACCURATE VALUE
MAX AND MIN RECORDS
TEMPERATURE,HUMIDITY AND COMFORT DISPLAY
4.1 Temperature Display
4.2 Humidity Display
4.3 Comfort Display
WEATHER FORECAST
ADJUSTABLE BACKLIGHT
LOW BATTERY INDICATORS
PRECAUTIONS
TROUBLESHOOTING
FACTORY RESTART
WARRANTY

PRODUCT OVERVIEW
3
1.1Package List
Following contents are included in the package:
1 x Weather Station Main Unit
3 x Remote Sensors（not include 6x AA batteries)
1 x AC Adaptor
1 x CR2032 Cell Battery
1 x User Manual
Product Size：
Main unit : 115*160*19mm (4.52*6.3*0.75in)
Sensor：99*36*18mm (3.9*1.4*0.7in)
6.3in(160mm)
1.4in(36mm)
0.7in(18mm)
0.75in(19mm)
4.52in(115mm)
3.9in(99mm)

4

Main unit
(1). Temperature and humidity of Channel 1/2/3
(2). Max/min record of Channel 1/2/3
(3). Indoor temperature and humidity
(4). Max/min record of indoor temperature and humidity
(5).Trend of temperature/humidity
(6). Three comfort level indication
(7). Weather forecast
Weather forecast for next 12-24 hours
(8).Barometric Pressure
Barometer display in mmHg,inHg or hPa/mb
(9).Calendar display
Weekdays in 7 languages
(10).Current time
12/24 hour format selectable
(11).Alarm clock and snooze function
(12).Low battery indication
(13).RCC signal icon
inHg
mmHg
hPa mb
1
2
7
84
101312
5
3
6
9
11

1. “ ” button 6. “ ▼ ” button
2. “ SET ” button 7. “ ” button
3. “ MEM ” button 8. Stand bracket
4. “ CH ” button 9. Hanging hole
5. “ ▲/RCC ” button 10. Battery compartment
5
Outdoor Sensor
SET
CH
MEM
RCC
/
1
9
10
8
1
2
3
4
2
3
4
5
6
7
1.Signal light 3. Battery compartment
2.Hanging hole 4. Channel 1-2-3 switch
Notes:For optimum 433MHz transmission, place the outdoor
sensor no more than 100 meters (330 feet , open air) from the
weather station.

6
1.3 Button Function Explanation
Button
Function
Normal
Mode
Time
Setting
Alarm
Setting
Alarm
Goes
Off Press
Press
Press
Hold
Press
Hold
Hold
▲/RCC
Turn Off
Alarm
Increase
Select
°C/℉
Turn
ON/OFF
RCC
Receiving
Mode
Increase
Adjust
Quickly
Adjust
Quickly
▼
Turn Off
Alarm
Decrease
12/24H
Switch
/
Decrease
Adjust
Quickly
Adjust
Quickly
MEM
Turn Off
Alarm
/
Check
MAX/MIN
Records
Clear All
Records
/
/
/
SET
Turn Off
Alarm
/
/
Enter
Manual
Setting
Confirm
/Go To
Next
Step
/
/
CH
Turn Off
Alarm
/
/
Re-
connect
to
Sensors
/
/
/
Turn Off
Alarm
Confirm
/Go To
Next Step
Check Alarm
Time,Turn
ON/OFF
Alarm
Function
Set
Alarm
Time
/
/
/
Snooze
Mode
Exit/Back
to Normal
Mode
Select
Backlight
Level
/
Exit/Back
to Normal
Mode
/
/

7
INITIAL OPERATION
2.1 Quick Setup
(1).Set 3 sensors channel from CH1/CH2/CH3 in order. (the channel
of each sensor should be different from others.)
(2).Peel off the protecting mask of main unit.
(3).Remove the CR2032 cell battery of main unit.
(4).Plug the AC adapter to a powered outlet.
(5).Load all sensors with 2xAA batteries matching the polarity (+and-)
within 3 minutes.
Notes:
a.Use new and high quality alkaline batteries for better product
performance.
b.Do not mix new and old batteries or batteries of different types.
c.Do not mix alkaline, standard or rechargeable batteries with this
product.
(6).Install the CR2032 cell battery after data received for memory
function.
Notes:
a. The main unit will receive the sensors’ data in 3 minutes after
power on,please set up according to above steps. If missed, press
and hold “CH” button 5-6 seconds to re-connect to sensor.
b. The CR2032 cell battery for memory function (included), please
do not used as power supply. If you need to replace the cell battery,
please take out the part device as shown in the figure below, load
new battery matching the polarity（+and-).

2.2 Barometer Setting
8
Pick out
Positive
pole
 THIS PRODUCT CONTAINS A BUTTON-CELL BATTERY.
IF SWALLOWED, IT COULD CAUSE SEVERE INJURY OR DEATH IN
JUST 2 HOURS.SEEK MEDICAL ATTENTION IMMEDIATELY IF
INGESTED.
(1) .After power on, the pressure reading will be flashing for 10 seconds.
If there is no need for calibration, touch the top button to exit setting.
If calibration is required, you can press “▲/RCC ” or “▼” button to
adjust data; press and hold “▲/ RCC” or “▼” button will quickly adjust
the value. Default setting : hPa/mb.
(2). If no operation within 10 seconds, it will automatically save and
exit setting.
(3). Barometer range: 800-1100hPa/mb
(600-825 mmHg, 23.62 -29.53inHg ).
Notes: The data is relative pressure value.
After the barometer setting, It will start receiving 3 outdoor sensors’
signals for 3 minutes. If all 3 channels' signals are received within 3
minutes or receiving window ends, it will enter into the WWVB signal
receiving window.

9
2.3 RF Signal Receiving
(1). After the barometer setting, the main unit will start receiving 3
outdoor sensors’ signals for 3 minutes. If all 3 channels' signals are
received within 3 minutes or receiving window ends, it will enter into
the WWVB signal receiving window.
(2). If disconnect, please press and hold the "CH" button to
re-connect the sensors.
2.4 WWVB Signal Receiving
(1). After RF signal receiving, it will start searching radio signal for 7
minutes with the antenna symbol displaying on screen. Meanwhile, the
backlight brightness will automatically adjust to 3%
(default brightness: 100%).
Notes:When receiving RCC signal, please keep the weather
station close to the window or receive RCC signal outdoors to
enhance the signal reception.
(2). Once signal received, the main unit will display the received time/
month/date/weekday.
(3). Daily RCC signal receiving: there are regular radio signals receiving
at UTC 7:00, 8:00, 9:00, 10:00, 11:00 each day. It starts receiving
signals at 7:00 every day. For each day, once the signal is received at
any one receiving time, it will stop receiving a signal that day.
(4). During receiving, all buttons except “▲/RCC ” button are
unresponsive. Press and hold “▲/RCC ” button to exit RCC receiving.
(5). Manual receiving: press and hold “▲/RCC ” button to enter RCC
signal receiving.
RCC symbol display:
a. When receiving signal, RCC icon will be flashing.
b. When signal successfully received, LCD will display complete
RCC icon and exit RCC receiving.
c. If no signal is received, the RCC icon will disappear.

10
MANUAL SETTINGS
After RCC signal received, if there is no need for other settings,
you can just finish reading here. If there is other setting requirements
such as set the time zone , or if there is no signal received, you can
follow bellow steps for manual setting.
(1). Press and hold “ SET ” button to enter into setting, press “ SET ”
button to skip setting steps or go to the next setting option.
(2). Press “ SET ” to select Weekday Language. Default setting:
English. Press the“▲/RCC” or “ ▼ ” button to select languages:
English、German、Italian、French、Dutch、Spanish、Danish optional.
(3). Press “ SET ” to select Hours. Press “▲/RCC” or “ ▼ ” button to
adjust the value.
(4). Press “ SET ” to select Minutes. Press “▲/RCC” or “ ▼ ” button to
adjust the value.
(5). Press “ SET ” to select Year. Press “▲/RCC” or “ ▼ ” button to
adjust the value.
Notes: The default year is 2020, if the weekday display is
incorrect. Please confirm year was set correctly.
(for manual setting only)
(6). Press “ SET ” to select Month & Date display format. Default
setting: M/D. Press the“▲/RCC” or “ ▼ ” button to select M/D or
D/M format. (M: Month, D: Date)
(7). Press “ SET ” to select Month. Press “▲/RCC” or “ ▼ ” button
to adjust the value.
(8).
Press “ SET ” to select the Date. Press “▲/RCC” or “ ▼ ” button
to adjust the value.
(9). Press “ SET ” to select the Barometric Unit. Default setting: inHg.
Press “▲/RCC” or “ ▼ ” button to select unit: mmHg, inHg or hPa/mb
optional.
(10). Press “ SET ” to select the RCC. Default setting : ON. Press
“▲/RCC” or “ ▼ ” button to select OFF or ON.

11
Time
Zone
AST EST CST MST PST AKT HAT
Atlantic Eastern Central Mountain Pacific Alaskan Hawaiian
(12).
Press “ SET ” to select DST ON/OFF. Default setting : ON. Press
“▲/RCC” or “ ▼ ” button to select DST ON if you do observe Daylight
Saving Time.
DST symbol display:
a.Select “DST ALWAYS” ,means DST function is always on all the
year round.
b.Select “DST ”,means DST function will be on during daylight
saving time.
c.Select “DST OFF”, means DST function is off.
(13). Press “ SET ” to select Weather. Press “▲/RCC ” or “ ▼ ”
button to select weather : Sunny, Partly Cloudy, Cloudy, Rainy or
Snow optional.
(14). Press “SET” to confirm and exit.
*Tips:
a. Press and hold “▲/RCC” or “ ▼ ” button will quickly change the
value.
b. During setting, touch top button to save and exit setting.
c. During setting, if no operation for 10 seconds, it will automatically
save and exit setting.
(11). Press “ SET ” to select Time Zone. Default setting : -5. Press
“▲/RCC” or “ ▼ ” button to select time zone: AST(-4),EST(-5),
CST(-6),MST(-7),PST(-8),AKT(-9),HAT(-10) optional.

(1).When in time display mode, press “ ” button to check alarm time.
(2).When in alarm time display mode, press “ ” button to turn on/
turnoff the alarm by the ON/OFF of symbol.
(1).Press and hold “ ” button to enter into alarm time setting.
(2).Press “▲/RCC ” or “ ▼ ” button to adjust data;(press and hold
“▲/RCC ” or “ ▼ ” button will quickly change the value.
(3).The setting order is: Hour → Minute→ Exit.
(4).During setting, touch top button to save and exit setting.
(5).During setting, if no operation for 10 seconds, it will automatically
save and exit setting.
(6).The alarm is default ON after setting the alarm time. Alarm symbol
will display on screen.
12
ALARM FUNCTION


3.3 Snooze Function
(1). When the alarm is ringing, press any other button except top button
to stop the alarm. And the alarm will restart next day.
(2).When alarm is ringing, press the top button to activate snooze
function. The alarm will ring again in 5 minutes snooze interval. And
the “” symbol will be flashing on screen to indicate the snooze mode.
Press any other button except top button to exit the snooze mode.
And the alarm will restart next day.
(3).When alarm rings, the ascending “Bibi” alarm sound will last for 2
minutes if no operation.

13
HOW TO GET MORE ACCURATE VALUE
For the more accurate reading and weather forecast, please place the
sensor at a proper place:
(1).When the sensor is first used or relocated, please place the whole
set device atthesamepositionforhalfanhouror more afterpower
on before having accurate measuring of temperature and humidity.
(2).Place the sensorvertically, meanwhile, pleaseplacethesensorat
aheightabout 1.2-2.5meters/3.93-8.20 feet.
≥5ft
(3).Make sure there ain't a thick wall or strong interference source
using same signal frequency (433Ghz) between the weather station
and sensor. (suchasTVs,microwaves,computers,etc).
(4).Avoid exposing to direct rain, sunlight or other heat/cold source.

14
(5).Leave certain space of gap between the sensor and the wall to
avoid blocking the vent of the sensor for well-ventilated.
(6).Mount the sensor in multi ways,no matter whatever way, make
sure at least one side of the back’s vent is not blocked.
Check the Setting Video by: https://youtu.be/H5yKehuueI4
Place on a
stable surface
hang from the back
hole using a nail Lift with a rope

15
(1)After power on, the indoor temperature will display automatically,
it will update reading each 30 seconds and start to receive outdoor
signal which lasts for max 3 minutes.
(2)Indoor temperature display range: -10℃~ +50.0℃ (14℉~ 122℉),
for temperature lower than -10℃, the reading will be :”LL.L”; for
temperature higher than +50.0℃,the reading will be :”HH.H”.
(3)Outdoor temperature display range: -40℃~+ 60℃ (-40℉~140℉),
for temperature lower than -40℃, the reading will be :”LL.L”; for
temperature higher than +60℃, the reading will be:”HH.H”.
(4)Arrow indication for temperature changes:
The temperature changes less than 1℃/1.8℉ within one hour
or compared with last reading.
The reading increase by 1℃/1.8℉ within one hour or compared
with last reading.
The reading decrease by 1℃/1.8℉ within one hour or compared
with last reading.
(5)Accuracy: ±1℃. Temperature resolution is 0.1 ℃(0.1 ℉).
(6)Press “▲/RCC ” button to switch from ℃ to ℉.
4.1Temperature Display
(1). Press “MEM” button to check maximum temperature and humidity,
the value will display for 5 seconds.
(2). Press “MEM” button second time to check the minimum temperature
and humidity, the value will display for 5 seconds.
(3). Press “MEM” button third time will return to standard mode.
(4). Press and hold “MEM” button will clear the max and min record and
reactivate the memory.
(5). Normally, the Max and Min record will update every 24 hours at 0:00.
MAX AND MIN RECORDS
TEMPERATURE,
HUMIDITY AND COMFORT DISPLAY

16
(1) After power on, the indoor humidity will display automatically, it will
update reading each 30 seconds and start to receive outdoor signal
which lasts for max 3 minutes.
(2)Humidity display range: 1%-99%,for humidity lower than 1%, the
reading will be “1%”; for humidity higher than 99%, the reading will
be “99%”.
(3)
Accuracy: when the temperature is between 20℃~26℃(68 ℉~ 78.8℉)
and the humidity is between 40-80%, the accuracy is ±5%, if out of
this range the accuracy will be ±8%.
(4)Arrow indication for humidity changes:
The humidity changes less than 3% RH within one hour or
compared with last reading.
The reading increase by 3% RH within one hour or compared
with last reading.
The reading decrease by 3% RH within one hour or compared
with last reading.
(5)Humidity resolution: 1%.
4.2Humidity Display

Notes: The data is relative humidity value.
Display
Humidity
DRY 1%- 39% COMFORT 40%-70% WET 71%-99%
(1). The temperature and humidity is dry when the humidity is below 40%.
(2).The temperature and humidity is comfort when the temperature is
20℃~28℃(68℉~82.4℉) and the humidity is 40%-77%.
(3). The temperature and humidity is wet. (When the humidity is above 70%)
(4). When the temperature is not 20℃-28℃(68℉~82.4℉) and the humidity
is 40%-77%, the comfort level icon will not be displayed.

17
Notes:
a.As weather conditions cannot be 100% correctly forecasted we
are not responsible for any loss caused by an incorrect forecast.
b.The icons forecast the weather in terms of getting better or
worse and not necessarily sunny or rainy, as each icon indicates.
The weather icon are based on the hourly calculation of indoor/outdoor
temperature and humidityandbarometerdata for next 12 hours forecast
with 70%-75% accuracy.
There are 5 kinds of weather modes:
Sunny, Partly Cloudy, Cloudy, Rainy, Snow.
After powering on, touch “ ” button to adjust the brightness
of the backlight.
Backlight brightness can be selected from 3%, 50%, 100% and off.
WEATHER FORECAST
ADJUSTABLE BACKLIGHT
About Outdoor Sensor: When battery signal shows next to the outdoor
temperature, batteries in your outdoor sensor should be replaced soon.
About Cell Battery in Main Unit: The CR2032 cell battery is only for
memorizing the setting during sudden power outage. When battery
signal shows next to indoor temperature, CR2032 battery should be
replaced soon.
LOW BATTERY INDICATORS
Sunny Partly Cloudy Cloudy Rainy Snow

18
Do not clean any part of the product with benzene, thinner or other
solvent chemicals. When necessary, clean it with a soft cloth.
Never immerse the product in water. This can cause electrical shock
and damage the product.
Do not subject the product to extreme force, shock, or fluctuations
in temperature or humidity.
Do not tamper With the internal components.
Do not mix new and old batteries or batteries of different types.
Do not mix alkaline, standard or rechargeable batteries with this product.
Remove the batteries if storing this product for a long period of time.
Do not dispose of this product as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
PRECAUTIONS
TROUBLESHOOTING
Problem Possible Solution
Outdoor
temperature
is flashing or
showing
dashes
If the wireless signal indicator shows"--", which means
connection loss or wireless interference. Press and hold the
"CH" button to re-connect the sensors, if doesn’t work,
please try the FACTORY RESTART.
Note: Distance/Resistance can cause loss of outdoor
sensors signal, please move the outdoor sensors to a closer
location if disconnected again.
Time is
inaccurate
*Check to see if the RCC Tower icon appears on the
forecast station. If not, the forecast station has not
received a WWVB/DCF time signal in the past 24-hours.
*Check that the Time Zone selected correctly reflects your
location. Adjust the time zone in the MANUAL SETTINGS
(Refer to this part of the manual).
* FOR US MARKET:Check that the DST indicator is correct
for your location (most areas observe DST so this should
be ON). Adjust the DST indicator in the Manual
Settings(Refer to this part of the manual).

19
Inaccurate
temperature
or humidity
When the indoor temperature/humidity is inaccurate, it is
often due to the location of the display or overpow-
ered/under powered batteries. You can test the accuracy
at you home.
Side-by-side test: Bring the outdoor sensor in the house
and place it next to the weather station for 2 hours.
(1).Temperature:Compare indoor and outdoor temperature.
The temperature should be within 2℃(4 ℉) to be within
tolerance.
Humidity:Compare indoor and outdoor humidity. The
temperature should be within 10%RH to be within
tolerance.
(2).Look for heat sources such as sunlight, door or window
frames or reflected heat or cold near the weather station.
Inaccurate
weather
forecast
This Weather station has 5 forecast icons that predict the
weather condition of the next 12 hours based on the
change of temperature, humidity and barometer. The
weather forecast is about 70-75% correct. As weather
conditions cannot be 100% correctly forecasted we are
not responsible for any loss caused by an incorrect
forecast.
Outdoor
sensor drains
batteries
quickly
*Test a new set of alkaline batteries. Write down the date
of installation and the voltage of the batteries.When the
batteries fail, please note the date and voltage again.
*Check the distance and resistance between the outdoor
sensor and weather station. Outdoor sensors at the end of
the range may work while batteries are fresh but not after
they drain a bit.
*Check for leaking batteries, which may damage the
outdoor sensor.
*Battery life is over 24 months when using reputable
battery brands for Alkaline batteries.

20
The buttons
doesn't
workable
suddenly
Within 7 minutes of receiving RCC signal, the other
buttons have no response except "▲/RCC" button. You
can press and hold the "▲/RCC" button to exit RCC
receiving.
The backlight
suddenly went
out and turned
on in the early
morning
There are regular RCC radio signal receiving at early
morning each day. Once signal received at any one
receiving time, it will stop receiving signal that day. During
receiving, the backlight brightness will automatically adjust
to 3%, and return to previous brightness after receiving.
If your BALDR weather station still can't be worked well after trying the
troubleshooting steps, please visit ourof f icialwebsite:
https://www.baldr.com or email us by [email protected] for help.
Note: Allow the outdoor sensor and weather station to sit
together for 30 minutes to establish a strong connection before
move the sensors.
FACTORY RESTART
The factory restart returns the weather station and outdoor sensor to
and “out-of-the-box” default state and often resolves an issue.
1) Unplug the adapter of the weather station.
2) Take out the CR3023 battery.
3) Remove three sensors batteries.
4) Install the weather station adapter after 1 minute.
5) Install three sensors batteries respectively. (Note: the channels of
the three sensors are CH1, CH2 and CH3 respectively.)
6) Insert the CR2032 battery into the weather station after the outdoor
data results are available.
