BALDR B0389WST2H2-V1 User manual

WIRELESS COLOR
WEATHER STATION
USER MANUAL
MODEL:B0389WST2H2-V1
English Deutsche Français Italiano Español

English
Deutsche
Français
Italiano
Per l'avvio di questo dispositivo è necessario:
Unità principale di 3 batterie AA
Sensore da 2 batterie AA
For the start-up of this device:
Main unit by AC adapter (included) or 3 x AAA batteries(not included)
Sensor by 2xAA batteries (not included)
Español
English ------------------------------------------03 ~ 20
Deutsche ------------------------------------------21 ~ 38
Français ------------------------------------------39 ~ 56
Italiano ------------------------------------------57 ~ 74
Español ------------------------------------------75 ~ 92
CONTENTS
Für die Inbetriebnahme dieses Gerätes benötigen Sie:
Hauptgerät durch 3xAAABatterien
Sensor mit 2xAA Batterien
Pour la mise en service de cet appareil, vous avez besoin de :
Unité principale par 3 piles AAA
Capteur par 2xAA Batteries
Para la puesta en marcha de este dispositivo necesita:
Unidad principal por baterías 3xAAA
Sensor por 2xAA Baterias

USER MANUAL
MODEL:B0389WST2H2-V1
WIRELESS COLOR
WEATHER STATION
3
We thank you for your purchase of Baldr wireless color weather station .It
has been designed and constructed using innovative components and
techniques to enable the perfect display. Please read the instructions
carefully to become familiar with the properties and functions before you
use the unit.If your BALDR product does not operate properly after trying
the troubleshooting steps, please contact the seller on your order page or
shoot an email to: [email protected].
For the start-up of this device:
Main unit by AC adapter (included) or 3 x AAA batteries(not included)
Sensor by 2 x AA batteries (not included)
ENEN

4
PRODUCT OVERVIEW
MAIN UNIT
FRONT VIEW
1.Weather forecast
2.Sensor signal indication
EN
Weather forecast for next 12-24
hours
Switch channel from CH1--CH2--
CH3--Channel scan
12.Max/min records for indoor
temperature and humidity
3.Outdoor sensor channel
Max/min temperature &
humidity records will update
each 24 hour and recorded from
midnight
37 2
1
14
4
6
13
5
12
8
11
9181615 20 10
17
19

9.Current indoor temperature
10.Current indoor humidity
11.Low battery indicator of main
unit
Battery power is lower than3.6V
or only connect AC adaptor
5
12/24 hour format selectable
Only can automatically adjust the
brightness of backlight under AC
adapter supply
Arrow icon indicates the direction
temperature is trending
Arrow icon indicates the direction
humidity is trending
16.Calendar display
5.Current outdoor humidity
17.Current time
Battery power is lower than 2.5V
13.Low battery indicator of
sensor
Max/min temperature & humidity
records will update each 24 hour
and recorded from midnight
14.Max/min records for outdoor
temperature and humidity
Weekdays in 7 languages
15.Weekday display
18.Snooze indicator
19.Alarm indicator
20.Auto dim indicator
Outdoor high/low temperature
alert symbol
Arrow icon indicates the direction
temperature is trending
Arrow icon indicates the direction
humidity is trending
6.Outdoor temperature alert
7.Frosting point icon
8.Comfort level indicator
ENEN
4.Current outdoor temperature

6
EN
1.“SET/MEM” button
Back View
Short press to check max/min
records
Long press to enter into settings
( In normal display format)
Long press to clear current max/
min records (In MEM display format)
Short press to turn on /off the Auto
dim function (In auto dim mode)
or decrease the value (In time and
alarm setting mode)
3. “-/AUTO DIM” button
2.“+/CH ” button
Short press to switch channel or
increase the data
Long press to enter into signal re
-registration mode
4. “ALARM” button
Short press to check the alarm
time and turn on/off the alarm in
normal display format
Long press to enter into alarm
setting in normal display format
1 2 3 6 4 5
8
11
7
9
10
SET/MEM /CH /AUTODIM ALARM A LERTS

Top View
“ ”button
Press to turn on the the backlight in battery power supply mode.
Press to switch backlight brightness among 100%,3%, off in AC
adapter power supply mode
Press to return to current time display in setting mode
Press to activate snooze function when alarm is ringing
OUTDOOR SENSOR
12
3
4
7
ENEN
5. “ALERTS” button
Short press to check alerts value
with the “HI/LO”symbol displaying
on the screen
Long press to enter into HI/LO
temperature alert setting ( In alert
checking mode)
6.“ ”button
7.Hanging Hole
8.Sensitive vents
9.Battery Compartment
10. Angle adjustable stand
bracket
11.DC Hole

8
1. Signal light
3. Battery compartment 4. Channel 1-2-3 switch
2. Hanging hole
FEATURES
1.Measures indoor and outdoor temperature(C/F) and humidity
2.Indoor temperature range:-10℃~50℃（14℉~122℉）
3.Outdoor temperature range:-40℃~60℃（-40℉~140℉)
4.Indoor and outdoor humidity range:1%-99%
5.Max/min record of temperature & humidity(in and out)
6.Weather forecast for next 12-24 hours
7.White backlight in dimmer and auto-dim function
8.Calendar function
10.Time display in 12/24H
11.Alarm and snooze function
12.Comfort level indication(GOOD;DRY;HUMID)
13.Up to 3 RF channels(channel scan or fixed to one channel)for
outdoor sensors (only one sensor included in the package)
14.Frosting point warning function
15.Outdoor high/low temperature alert
16.Low battery reminder for main unit and outdoor sensors
17.Key tone ON/OFF selectable
18.Angel adjustable bracket for better view
9.Weekdays in 7 languages: GER (German), ENG (English), FRE
(French),ITA(Italian), SPA(Spanish),DUT(Dutch),DRN(Denmark)
EN
PACKAGE CONTENT
Following contents are included in the package:
1 x Weather Station Main Unit
1 x Remote Sensor
1 x AC Adapter
1 x User Manual

9
ENEN
GETTING STARTED
BALDR recommends high quality alkaline or lithium batteries
for the best product performance. Heavy duty or rechargeable
batteries are not recommended.
MAIN UNIT INSTALLATION
Powered by AC Adaptor:
Powered by batteries:
SENSOR INSTALLATION
SENSOR SETUP
Connect the power adaptor with DC hole on side of the main unit and
plug the adaptor to a powered outlet.
1. Remove the battery compartment cover.
2. Insert 3x AAA battery matching the polarity(+and-).
3. Replace the battery cover
1. Remove the battery compartment cover.
2. Insert 2 x AA batteries in each sensor matching the polarity (-+and-).
3. Replace the battery cover.
● Power the main unit prior to load the batteries of sensor.
● Switch the button of 3 sensors to CH1 , CH2 and CH3. For example,
you can set to Channel 1 for the sensor. But please ensure the main
unit are set to the same channel before synchronization. (Special
note: Press.“ ’’ button on the main unit to set the channel. The
setting order is CH1--CH2--CH3--Channel scan（from CH1 to CH2 to
CH3,Channel scan with 5 seconds intervals）,you must select the
same number choices for both the sensor and the main unit in order to
synchronize).
/CH

10
EN
● Auto synchronization: after power on both units, the receiving status
will last for max 3 minutes, the receiving antenna signal will flash, if
no signal received in 3 minutes, the antenna signal will disappear
and stop receiving outdoor signal.
●If the main unit is out of 3 minutes’ signal receiving window, you need
to press and hold the “ ’’ button to enter signal receiving again.
MAIN UNIT SETUP
When power on or reset, LCD will full display for 3 seconds with “BI”
sound.
Time
Display
(EU
version)
24hr
Time
Display
(US
version)
12hr
Date
Format
(EU
version)
D/M
Date
Format
(US
version)
M/D
Weather
Forecast
Sunny to
cloudy
Langu
age
ENG(US
version)
/GER(EU
version)
Key
Tone
ON
Temper
ature
Unit
℃(EU
version)
/℉（US
version)
Date
Display
2021
.01.01
Manual Settings
RF Signal receiving
After power on, it will start receiving outdoor sensor’s signal for 3
minutes. If all 3 channels signal received within 3 minutes or receiving
window ends, you can start manual settings.
After signal received, please follow bellow steps for manual setting.
Press and hold “ ” button to enter into setting, press “ ”button to
skip setting steps or go to the next setting option.
*Tips: press and hold “ ” or “ ” button will quickly change the
value by 8 steps.
1. Press “ ” to select time display mode. Press “ ” or “ ” button
to select 12hr or 24hr.
2. Press “ ”to select Hours. Press “ ” or “ ” button to adjust the
value.
/CH
SET/MEM
SET/MEM
SET/MEM
SET/MEM
/AU TODIM
/CH /AU TODIM
/CH /AU TODIM
3. Press “ ” to select Minutes. Press “ ” or “ ” button to adjust
the value.
SET/MEM /CH /AU TODIM
/CH /AU TODIM
4. Press “ ”to select Year. Press “ ” or “ ” button to adjust the
value.
SET/MEM
/CH

ENEN
11
REMARK: There are 7 languages selectable for weekday display: ENG、
ITA、FRE、DUT、SPA、DAN、GER (English/ Italian/ French/ Dutch/
Spanish/ Danish/ German)
Language German
GER
Sunday
English
ENG
French
FRE
Italian
ITA
Spanish
SPA
Dutch
DUT
Denmark
SON SUN DIM DOM DOM ZON
Monday MON MON LUN LUN LUN MRR
Tuesday DIE TUE MAR MAR MAR DIN
Wednesday MIT WED MER MER MIE WOE
Thursday DON THU JEU GIO JUE DON
Friday FRE FRI VEN VEN VIE VRI
Saturday SAM SAT SAT SAB SAB ZRT
DRN
ZON
MRN
TIR
ONS
TOR
FRE
LOR
5. Press “ ” to select Month&Date display format. Press “ ” or
“ ” button to adjust the value.
6. Press “ ” to select Month. Press “ ” or “ ” button to adjust the
value.
7. Press “ ” to select Date. Press “ ” or “ ” button to adjust the
value.
8. Press “ ” to select Weekday Language. Press the “ ” or “ ”
button to select languages: ENG、ITA、FRE、DUT、SPA、DAN、
GER optional.
9. Press “ ” to select temperature unit display format. Press “ ” or
“ ” button to adjust the value.
10. Press “ ” to select Beep. Press “ ” or “ ” button to turn
ON/OFF.
11. Press “ ” to confirm and exit.
12. During setting, touch top button to save and exit setting.
13. During setting, if no operation for 20 seconds, it will automatically save
and exit setting.
SET/MEM
SET/MEM
SET/MEM
SET/MEM
SET/MEM
SET/MEM
SET/MEM
/CH /AU TODIM
/CH /AU TODIM
/CH /AU TODIM
/CH
/AU TODIM
/CH /AU TODIM
/CH
/AU TODIM

EN
12
ALARM FUNCTION
Alarm Time Setting
1.Press and hold “ ” button to enter into alarm time setting.
2.Press “ ” or “ ” button to adjust data; press and hold “ ” or
“ ” button will quickly change the value by 8 steps.
3.The setting order is: Hour → Minute→ Exit.
4.Press “ ” button to skip setting steps or go to the next setting option.
5.During setting, touch top button to save and exit setting.
6.During setting, if no operation for 20 seconds, it will automatically save
and exit setting.
7.The alarm is default ON after setting the alarm time. Alarm symbol
will display on screen.
Alarm ON/OFF Setting
1. When in time display mode, press “ ” button to check alarm time.
Press “ ” button twice to turn ON/OFF alarm by the ON/OFF of
symbol .
2. When in alarm time display mode, press “ ” button to turn on/off the
alarm by the ON/OFF of symbol .
3.If no operation for 5 seconds, it will automatically save and exit setting.
SNOOZE FUNCTION
1. When the alarm is ringing, press any other button except top button
to stop the alarm. And the alarm will restart next day.
2. Or when alarm is ringing, press the top button to activate “ ”
function. The alarm will ring again in 5 minutes snooze interval. And
the symbol will be flashing on screen to indicate the snooze mode.
Press any other button except top button to exit the snooze mode. And
the alarm will restart next day.
3. When alarm rings, the ascending “Bibi” alarm sound will last for 2
minutes if no operation.
ALARM
ALARM
ALARM
ALARM
ALARM
/CH /CH
/AU TODIM
/AU TODIM

13
ENEN
OPERATION GUIDELINE
MAX AND MIN RECORD
TEMPERATURE
1.Press “ ” to check maximum and minimum temperature and
humidity, the value will display for 5 seconds.
2.Press “ ” button second time to check the minimum temperature
and humidity, the value will display for 15 seconds.
3.Press “ ” button third time will return to standard mode
4.When in max record or min record display mode,press and hold the
“ ” button to clear the max and min record
5. Normally, the Max and Min record will update every 24 hours at 0:00.
1. After power on ,the indoor temperature will display automatically, it will
update reading each 30 seconds and start to receive outdoor signal
which lasts for max 3 minutes.
2. Indoor temperature display range:-10℃~ 50.0℃(14℉~122℉); for
temperature lower than -10℃(14℉),the reading will be :“LL.L”; for
temperature higher than +50℃(122℉),the reading will be :“HH.H”.
3. Outdoor temperature display range :-40℃~60℃(40℉~140℉); for
temperature lower than-40℃(40℉),the reading will be :“LL.L”; for
temperature higher than +60℃(140℉),the reading will be :“HH.H”.
4. Arrow indication for temperature changes:
5.Accuracy: For temperature between 0℃~50℃(32℉~122℉),the
accuracy is ±1℃,if out of this range the accuracy will be ±2℃.
Temperature resolution is 0.1 ℃(0.1℉).
Remark: The reading will be more accurate standing still for half an hour
after power on
will display when the reading increase by 1℃within one hour or
compared with last reading
will display when the reading decrease by 1℃within one hour or
compared with last reading.
SET/MEM
SET/MEM
SET/MEM
SET/MEM

EN
14
1. After power on ,the indoor humidity will display automatically, it will
update reading each 30 seconds and start to receive outdoor signal
which lasts for max 3 minutes.
2. Humidity display range: 1%-99%;for humidity lower than 1%,the
reading will be “1%”;for humidity higher than 99%, the reading will
be “99%”.
3. Accuracy: For humidity between 40%-80%, the accuracy is ±5%, if
out of this range the accuracy will be ±8%.
4. Arrow indication for humidity changes:
5.Humidity resolution:1% .
DISPLAY
HUMIDITY DRY
1%- 39%
COMFORT
40%-70%
WET
71%-99%
TEMPERATURE NA 20℃-28℃NA
Remark: The reading will be more accurate standing still for half an hour
after power on
COMFORT LEVEL INDICATOR
Humidity
RF RE-REGISTRATION
TEMPERATURE ALERT FUNCTION
SET OUTDOOR TEMPERATURE ALERT
Press and hold the " " button to clear all sensors data and start
receiving signal again.
1.In alert checking mode, press and hold “ ” button to enter into
outdoor temperature alert value ; the setting data will be flashing in
1Hz.
will display when the reading increase by 3% RH within one hour
or compared with last reading.
will display when the reading decrease by 3% RH within one hour
or compared with last reading.
ALARM
/CH

15
ENEN
2.The setting order is: High temperature alert value→Low temperature
alert value→ Exit.
3.Press “ ” or “ ” button to adjust data; press and hold “ ” or
“ ” button will quickly change the data by 8 steps.
1.Press “ ” button to check the HI/ LO outdoor temperature.
2.In alert checking mode, press “ ” or “ ” button to turn on/off the
alert.
3.In alert checking mode, press and hold “ ” button to enter into alert
temperature value settings.
4.Press “ ”or “ ” button to adjust the high temperature alert value
with on of the symbol , then press “ ” button to set the low
temperature alert.
5.Press “ ”or “ ” button to adjust the low temperature alert value
with on of the symbol , then press “ ” button or top button to save
settings and exit.
6.Default setting : The alert is off; High temperature alert value 35℃;Low
temperature alert value 10℃.
7.The ascending “Bibi” alarm will ring per minute with the symbol flashing
when the outdoor temperature reaches the alert value and will stop
ringing when out of alert range.
The weather forecast icon will show after power on. There are 7 kinds of
weather modes: sunny in daytime, sunny at night,sunny to cloudy in
daytime, sunny to cloudy at night, cloudy, rainy, snow. The weather icon
displays are based on the hourly calculation of indoor/ outdoor
temperature and humidity. The forecast is for next 12 hours with
70%-75% accuracy .
4.If no operation for 20 seconds, it will automatically save and exit setting.
TURN ON/OFF TEMPERATURE ALERT
WEATHER FORECAST
/CH /CH
/AU TODIM
/CH /AU TODIM
/CH /AU TODIM
/CH /AU TODIM
/AU TODIM
ALERTS
ALERTS
ALERTS
ALERTS

FROSTING POINT WARNING FUNCTION
BACKLIGHT FUNCTION
LOW BATTERY INDICATORS
Daytime weather mode:
● When outdoor temperature reading is between 0℃~2.9℃,the icon
will be flashing to indicate the frosting point.
● When outdoor temperature reading is lower than 0℃, the icon will
always display.
● When powered by batteries, press " " button to turn on the
backlight. The backlight will last 20 seconds.
● About Outdoor Sensor: When battery indicator shows next to the
outdoor temperature, replace batteries in your outdoor sensor.
● For continuous backlight, please connect the power adapter.
● Press" "button to switch backlight brightness among 100%, 3%
and off.
● Press" "to enter into auto dim mode, the backlight brightness will be
automatically adjusted To 3% level from 10:00pm to 8:00am.
Night weather mode (from PM6:00 to AM7:00):
Cloudy Rainy Snow
Sunny at
night Sunny to cloudy at night
Sunny in
daytime Sunny to cloudy in daytime
Cloudy Rainy Snow
16
EN
/AU TODIM

● About Main Unit: The AAA battery is only for power supply. When
battery indicator shows next to your indoor temperature, replace
battery.
17
ENEN
TROUBLE SHOOTING
Flashing of the outdoor reading is generally an
indication of wireless interference.
1. Bring both the sensor and display indoors,
side by side and remove batteries from
each.
2. Make sure the 1-2-3 switch on both units
match.
3. Reload batteries in main unit.
4. Reload batteries in outdoor sensor.
5. Let both units sit within a couple feet of each
other for a few minutes to gain a strong
connection before taking sensor to outdoor
area.
• Reload the batteries of both outdoor sensor
and main unit. Please refer to the SENSOR
SETUP section.
• Relocate the main unit and/or the outdoor
sensor. The units must be within 328 ft (100
m) of each other.
• Make sure both units are placed at least 3
No outdoor sensor
reception
Problem Possible Solution
Outdoor reading is
flashing or showing
dashes

Place main unit in a dry area free of dirt and dust. To help ensure an
accurate indoor temperature measurement, be sure to place the Main
unit away from heat sources or vents.
BALDR sensors are sensitive to surrounding environmental
conditions. Proper placement of both the main unit and outdoor
sensor are critical to the accuracy and performance of this
product.
Main Unit Placement
PLACEMENT INSTRUCTION
If your BALDR product does not operate properly after trying the
troubleshooting steps, contact the seller on your order page or
shoot an email to: [email protected].
feet (0.9 m) away from electronics that may
interfere with the wireless communication
(such as TVs, microwaves, computers, etc).
• Use standard alkaline batteries. Do not use
heavy duty or rechargeable batteries. NOTE:
It may take a few minutes for main unit and
sensor to synchronize after batteries are
reloaded.
Make sure both the main unit and sensor are
placed out of direct sunlight and away from
any heat sources or vents.
If the temperature is higher than the detection
range, HH will display on screen for indication;
if lower than the detection range, LL will
display on screen for indication.
Inaccurate
temperature/
humidity
“HH/LL” display in
indoor and/or
outdoor
temperature
18
EN

Outdoor Sensor Placement
Important Placement Guidelines
PRECAUTIONS
ENEN
Sensor must be placed outside to observe outdoor conditions. Sensor
is water resistant for water splashes and is designed for general outdoor
use, however, to extend its life place the sensor in an area protected
from direct weather elements. The best location is 1.2 to 2.4 meters
(4 to 8 feet) above the ground with permanent shade and plenty of
fresh air to circulate around the sensor.When placed by hanging hole,
the best distance from the wall is more than 1cm for better ventilation.
● The distance between main unit and transmitter should be at least
1.5~2 meters (5~6.5 feet) away from any interfering sources such as
computer monitors or TV sets.
● To maximize wireless range, place units away from large metallic
items, thick walls, metal surfaces, or other objects that may limit
wireless communication. Please do not use other electrical products
such as headphones or speakers operating on the same signal
frequency.
● Neighbors using electrical devices operating on the same signal
frequency can also cause interference.
● Place the main unit more than 1.2 meters away from the power source
for better usage.(including the power source of the product itself or any
other electrical appliances)
● Do not clean any part of the product with benzene, thinner or other
solvent chemicals. When necessary, clean it with a soft cloth.
● Never immerse the product in water. This can cause electrical shock
and damage the product.
● Do not subject the product to extreme force, shock, or fluctuations in
temperature or humidity.
● Do not tamper With the internal components.
● Do not mix new and old batteries or batteries of different types.
● Do not mix alkaline, standard or rechargeable batteries with this
product. Remove the batteries if storing this product for a long period
of time.
19

EN
WARRANTY
● Do not dispose of this product as unsorted municipal waste.
Collection of such waste separately for special treatment is
necessary.
BALDR provides a 1-year limited warranty on this product against
manufacturing defects in materials and workmanship. Warranty
service can only be performed by our authorized service center. The
original dated bill of sale must be presented upon request as proof of
purchase to us, or our authorized service center.
The warranty covers all defects in material and workmanship with the
following specified exceptions:(1) damage caused by accident, unreasonable
use or neglect (including the lack or reasonable and necessary maintenance);
(2) damage occurring during shipment (claims must be presented to the c
arrier); (3) damage to, or deterioration of any accessory or decorative surface;
(4) damage resulting from failure to follow instructions contained in your
owner’s manual.
This warranty covers only actual defects within the product itself, and does not
cover the cost of installation or removal from a fixed installation, normal set-up
or adjustments, claims based on misrepresentation by the seller or
performance variations resulting from installation-related circumstances.
To receive warranty service, the purchaser must contact with BALDR
nominated service center for the problem determination and service procedure.
Thank you for your choice of BALDR products!
20
[e-mail]
