BALDR B0360WST2H2PR-V1 User manual

RADIO-CONTROLLED
WEATHER STATION
USER MANUAL
MODEL:B0360WST2H2PR-V1
English Deutsche Français Italiano Español

For the start-up of this device you require:
Main unit by AC Adaptor(included)or 3xAAA batteries(not included)
Sensor by 2xAA batteries(not included)
English
Deutsche
Français
Italiano
Español
English ------------------------------------------03 ~ 22
Deutsche ------------------------------------------23 ~ 42
Français ------------------------------------------43 ~ 62
Italiano ------------------------------------------63 ~ 82
Español ------------------------------------------83 ~ 102
CONTENTS
Für die Inbetriebnahme dieses Gerätes benötigen Sie:
Hauptgerät mit Netzadapter (im Lieferumfang enthalten) oder
3xAAA-Batterien (nicht enthalten)
Sensor mit 2xAA-Batterien (nicht enthalten)
Pour la mise en service de cet appareil, vous avez besoin :
Unité principale avec adaptateur secteur (inclus) ou 3 piles AAA
(non incluses)
Capteur par 2xAA batteries (non incluses)
Per l'avvio di questo dispositivo: Unità principale con
adattatore CA (incluso) o 3 batterie AAA (non incluse) e un sensore
con 2 batteries AA (non incluse).
Para la puesta en marcha de este dispositivo necesitas: Unidad
principal con adaptador CA (incluido) o 3 pilas AAA (no
incluidas) y un sensor con 2 pilas AA (no incluidas).

USER MANUAL
MODEL:B0360WST2H2PR-V1
RADIO-CONTROLLED
WEATHER STATION
3
We hereby thank you for purchasing Baldr Color radio-controlled Weather
Station.We design and manufacture the item using innovative components
and techniques to enable the perfect display of temperature and
humidity by this device. It is also equipped with weather forecast
functions. Please read the instructions carefully to become familiar with
the properties and functions properly before usage.
For the start-up of this device you require:
Main unit by AC Adaptor(included)or 3xAAA batteries
(not included)
Sensor by 2xAA batteries(not included)
ENEN

4
Product Overview
Front View
1. Sensor signal indication
EN
1
6
7
2
3
20
16
17
4
18
9
10
1112
19
13
8
5
14
15
2. Outdoor sensor channel
12.Alarm indicator
13.Snooze indicator
Switch channel from CH1--CH2
--CH3--Channel scan

11.RCC indicator
Arrow icon indicates the
direction humidity is trending
14.Current indoor humidity
Max/min temperature &
humidity records will update
each 24 hour and recorded
from midnight
3. Current outdoor temperature
15.Max/min records for indoor
temperature and humidity
Arrow icon indicates the direction
temperature is trending
5
Battery power is lower than
3.6V or only connect AC
adaptor
Arrow icon indicates the
direction temperature is
trending
Max/min temperature & humidity
records will update each 24 hour
and recorded from midnight
16.Current indoor temperature
17.Low battery indicator of
main unit
Battery power is lower than
2.5V
18.Low battery indicator of
sensor
Arrow icon indicates the direction
humidity is trending
Outdoor high/low temperature
alert with the symbol
5. Current outdoor humidity
19.Comfort level indicator
20.Outdoor temperature alert
Weather forecast for next 12-24
hours
6. Weather forecast
Barometer display in hPa/mb
Weekdays in 7 languages
12/24 hour format selectable
7. Barometric pressure
8. Calendar display
9. Weekday display
10.Current time
ENEN
4. Max/min records for outdoor
temperature and humidity

6
EN
5
2
3
4
1
1. Hanging Hole 2. Sensitive vents
3. Battery Compartment 4. Stand Bracket
5. DC Hole
Back View
Top View
Backlight/Snooze touch button
Press to switch backlight brightness among 100%, 50% ,10%,3%
and off

7
ENEN
1. “SET ’’ button
Long press to enter into time setting
Short press to exit the RCC signal
receiving
Long press to receive RCC signal
3. “▼/RCC’’ button
2. “▲/CH ’’button
Short press to switch channel
Long press to enter into signal receiving
Short press to check alarm time, turn
on/off alarm
Long press to enter into alarm setting
4. “ ’’ button
Short press to check Max/min record
Long press to clear the max/min record
6. “MEM ’’ button
5. “ALERTS ’’ button
Short press to check the temperature
alert value
Long press to enter into temperature
alert value setting
Note:
The default year is 2020, if the weekday display is incorrect . Please
confirm year was set correctly. (for manual setting only)
1
2
3
4
5
6
SET
/CH
ALERTS
MEM
/RCC
Side View

8
1. Signal light（Working:Red light flashing）2. Hanging hole
3. Battery compartment 4. Channel 1-2-3 switch
OUTDOOR SENSOR
12
3
4
Features
1. Measures indoor and outdoor temperature(C/F) and humidity
2. Indoor temperature range:-10℃~50℃（14℉~122℉）
3. Outdoor temperature range:-40℃~60℃（-40℉~140℉）
4. Indoor and outdoor humidity range:1%-99%
5. Max/min record of temperature & humidity(in and out)
6. Weather forecast for next 12-24 hours with barometer
7. Temperature/Humidity tendency display in arrows
8. Time, alarm and snooze function
9. Time display in 12/24H
11. Up to 3 RF channels(channel scan or fixed to one channel)for
outdoor sensors (only one sensor included in the package)
10. Weekdays in 7 languages: GER (German), ENG (English), FRE
(French),ITA(Italian), SPA(Spanish),DUT(Dutch),DRN(Denmark)
EN

9
ENEN
Package Content
Getting Started
12. Outdoor high/low temperature alert
13. Indoor temperature, humidity and barometer data can be
calibrated manually
14. Calendar function
15. Comfort level indication(GOOD;DRY;HUMID)
16. White backlight with dimmer
17. Key tone ON/OFF selectable
Following contents are included in the package：：
1xDigital Weather Station
1xRemote Sensor
1xAc Adaptor
1xUser Manual
Connect the power adaptor with DC hole on side of the main unit
and plug the adaptor to a powered outlet
BALDR recommends high quality alkaline or lithium batteries
for the best product performance. Heavy duty or rechargeable
batteries are not recommended.
MAIN UNIT INSTALLATION
Powered by AC Adaptor:

10
EN
Powered by batteries:
SENSOR INSTALLATION
SENSOR SETUP
1. Remove the battery compartment cover.
2. Insert 3x AAA batteries matching the polarity(+and-)
3. Replace the battery cover
1. Remove the battery compartment cover
2. Insert 2xAA batteries matching the polarity（+and-)
3. Replace the battery cover
● Power the main unit prior to load the battery of sensor
● Switch the Channel 1 -2- 3 of the senor to any channel you want.
For example, you can set to Channel 1 for the sensor. But please
ensure the main unit are set to the same channel before
synchronization. (Special note: Press.“▲/CH’’ button on the main
unit to set the channel.The setting order is CH1--CH2--CH3--
Channel scan（from CH1 to CH2 to CH3,8 seconds intervals）,
you must select the same number choices for both the sensor and
the main unit in order to synchronize)
●Auto synchronization: after power on both units, the receiving
status will last for max 3 minutes,the receiving antenna signal will
flash, if no signal received in 3 minutes, the antenna signal will
disappear and stop receiving outdoor signal.
● If the main unit is out of 3 minutes’signal receiving window, you
need to press and hold the “▲/CH’’button to enter into signal
receiving again.

ENEN
11
Pressure Unit
(DCF/MSF)
Pressure Unit
(WWVB)
Weekday
Language
(DCF)
Weekday
Language
(WWVB/MSF)
hPa/mb inHg GER ENG 0:00
(24H format)
12:00
(12H format)
Display Time
(DCF)
Display Time
(WWVB/MSF)
Temperature Unit
（DCF/MSF)
Temperature Unit
（WWVB)
℃ ℉ 0hr -5EST
Time zone
(DCF)
Time zone
(WWVB)
MAIN UNIT SETUP
RF SIGNAL RECEIVING
RCC RECEIVING
1. After RF signal receiving, it will start searching radio signal for 7
minutes with the antenna symbol “ ”displaying on screen.
2. There are daily automatic DCF/WWVB/MSF receiving at 1:00AM,2:00
AM, 3:00 AM, 4:00AM, 5:00AM. It will first start receiving DCF/WWVB/
MSF time at 1:00 AM, 2:00AM, 3:00AM each day. If DCF time is not
received till 3:00AM, it will start receiving again at 4:00AM and 5:00AM.
If the time is not successfully received at 5:00AM, there will be no
receiving the day, It will start searching for signal at 1:00AM the next
day
When power on or reset, LCD will full display for 3 seconds with
“ BI”sound
The default value is :
● After barometer setting, it will start receiving outdoor sensor’ s signal
for 3 minutes.If all 3 channels signal received within 3 minutes or
receiving window ends, it will enter into DCF/WWVB/MSF signal
receiving window
● RF signal will not receive during the RCC reception,please exit the
RCC receiving first by pressing the “▼/RCC’ ”Button

EN
12
MANUAL SETTINGS
1. After signal received, if there is no need for other settings, you
can just finish reading here. If there is other setting requirements.
Please check the following steps. Or if there is no signal received,
you can follow bellow steps for manual setting.
2. Press and hold “SET” button to enter into setting, press “SET”
button to skip setting steps or go to the next setting option, the
setting data will be flashing in 1Hz.
3. Press “SET” to select Weekday Language. Press the“▲/ CH” or
“▼/RCC” button to select languages: GER(German),ENG(English),
ITA(Italian),FRE(French),DUT(Dutch),SPA(Spanish),DRN(Denmark),
Default setting :GER(DCF),ENG(WWVB/MSF)
3. On normal time mode, Long press “▼/RCC’’ button to enter DCF
/WWVB/MSF signal receiving.
4. During DCF reception, press “▼/RCC’’ button to exit RCC
receiving.
5. The time will be converted to the current time of corresponding
time zone after receiving the RCC .(Except 0 time zone)
Remark: It will exit RCC receiving automatically when the alarm is
activated during DCF/WWVB/MSF reception , you can repeat step
3 to enter into DCF/WWVB/MSF signal receiving after turning off
the alarm.
RCC symbol display:
a. When receiving signal , RCC icon“ ’’will be flashing by“1HZ”
b. When signal successfully received, LCD will display complete RCC
icon“ ’’and exit RCC receiving.
c. If no signal is received, the RCC icon will disappear.

13
ENEN
4. Press “SET” to select key tone ON/OFF. Press “▲/CH”or “▼/RCC”
button to select.Default setting : key tone ON
*Tips: press and hold “▲/CH’’ or “▼/RCC’’ button will quickly
change the value by 8 steps
5. Press “SET’’to select Barometric Unit.Press “▲/CH’’ or “▼/RCC’’
button to select unit: mmHg, inHg or hPa mb optional. Default
setting:hPa mb（DCF/MSF). imHg（WWVB)
6. Press “SET’’ to select temperature unit. Press “▲/CH’’ or“▼/RCC’’
button to select ℃or ℉.Default setting : ℃(DCF/MSF) ℉（WWVB)
7. Press “SET’’ to select the RCC. Press “▲/CH’’ or “▼/RCC’’ button
to select OFF or ON. Default setting : RCC ON.
8. Press “SET’’ to select Time Zone. Press “▲/CH’’ or “▼/RCC’’ button
to select time zone from -12 H to + 12 H.Default setting : 0 hr(DCF)
-5EST(WWVB)
9. Press“SET’’to select Year. Press “▲/CH’’ or “▼/RCC’’
button to adjust the value
Remark:If RCC is set off , there is no Time zone option.
10. Press “SET’’ to select Month. Press“▲/CH’’ or “▼/RCC’’ button to
adjust the value
Remark: There are 7 languages selectable for weekday display:
FRE、SPA、ENG、GER、ITA、DUT、DRN
Language German
GER
Sunday
English
ENG
French
FRE
Italian
ITA
Spanish
SPA
Dutch
DUT
Denmark
SON SUN DIM DOM DOM ZON
Monday MON MON LUN LUN LUN MRR
Tuesday DIE TUE MAR MAR MAR DIN
Wednesday MIT WED MER MER MIE WOE
Thursday DON THU JEU GIO JUE DON
Friday FRE FRI VEN VEN VIE VRI
Saturday SAM SAT SAT SAB SAB ZRT
DRN
ZON
MRN
TIR
ONS
TOR
FRE
LOR

EN
14
11. Press “SET’’ to select Date. Press “▲/CH’’ or “▼/RCC’’ button
to adjust the value
12. Press “SET’’ to select time display mode. Press “▲/CH’’ or
“▼/RCC’’button to select 12hr or 24hr.Default setting : 24hr format
(DCF) 12hr format(MSF/WWVB)
13. Press “SET’’ to select Hours. Press“▲/CH’’ or “▼/RCC” button
to adjust the value.
14. Press “SET’’ to select Minutes. Press“▲/CH’’ or“▼/RCC’’ button
to adjust the value.
15. Press “SET’’ to select weather. Press “▲/CH’’ or“▼/RCC’’button
to select weather: Sunny, Sunny To Cloudy, Cloudy, Rainy optional
16. Press “SET”to confirm and exit.
17. During the setting, if no operation for 20 seconds, it will
automatically save and exit setting.
ALARM FUNCTION
SET ALARM TIME:
1. Press and hold “ALARM” button to enter into alarm time setting mode.
2. Press “▲/CH”or “▼/RCC”button to adjust data; press and hold
“▲/CH”or“▼/RCC”button will quickly change the data by 8
steps
3. The setting order is: Hour → Minute→Exit.
4. During setting, touch top button to save and exit setting
5. During setting, if no operation for 20 seconds, it will automatically
save and exit setting.
6. The alarm is default ON after setting the alarm time. Alarm symbol
will display on screen.
TURN ON/OFF ALARM:
1. When in time display mode, press “ALARM button once to check alarm
time. Press “ALARM”button second time to turn on/off alarm by the ON/OFF
of symbol . If on operation for 20 seconds, it will automatically return to
current time display.

15
ENEN
2. OR when alarm is ringing, press “ ” button to activate snooze
function. And the alarm will repeat in 5 minutes. The “ ”symbol will
be flashing on screen to indicate the snooze mode. Press any other
button except top button to exit the snooze mode. And the alarm will
restart next day.
2. When in alarm display mode, press the “ALARM”button to turn on/off
the alarm by the ON/OFF of symbol If on operation for 20 seconds, it
will automatically return to current time display.
SNOOZE FUNCTION
1. When the alarm is ringing, press any other button except top button
to stop the alarm. And the alarm will restart next day.
3. When alarm rings, the ascending “Bibi”alarm sound will last for 2
minutes if no operation.
PLACEMENT INSTRUCTION
BALDR sensors are sensitive to surrounding environmental conditions.
Proper placement of both the main unit and outdoor sensor are critical
to the accuracy and performance of this product.
Main Unit Placement
Place main unit in a dry area free of dirt and dust. To help ensure an
accurate indoor temperature measurement, be sure to place the Main
unit away from heat sources or vents.
Outdoor Sensor Placement
Sensor must be placed outside to observe outdoor conditions. Sensor
must be placed outside to observe outdoor conditions. Sensor is water
resistant for water splashes and is designed for general outdoor use,
however, to extend its life place the sensor in an area protected from
direct weather elements. The best location is 4 to 8 feet(1.2 to 2.4
meters) above the ground with permanent shade and plenty of fresh
air to circulate around the sensor.When placed by hanging hole ,the
best distance from the wall is more than 1cm for better ventilation.

EN
16
Operation Guideline
Important placement guidelines
●The distance between main unit and transmitter should be at least
5~6.5 feet (1.5~2 meters) away from any interfering sources such
as computer monitors or TV sets.
●To maximize wireless range, place units away from large metallic
items, thick walls, metal surfaces, or other objects that may limit
wireless communication
● Neighbors using electrical devices operating on the same signal
frequency can also cause
● Place the main unit more than 1.2 meters away from the power
source for better usage.(including the power source of the product
itself or any other electrical appliances)
TEMPERATURE&HUMIDITY
● Indoor temperature display range :-10°C~50°C (14°F ~122°F).
Outdoor temperature range:-40℃~60℃（-40℉~140℉),LL.L or
HH.H will display when out of range
● Indoor and outdoor humidity range:1%-99%
●Accuracy: For temperature between 10℃~30℃,the accuracy is± 1
℃,if out of this range the accuracy will be±1.5℃; For humidity between
40-70%RH,the accuracy is±5%RH,if out of this range,the accuracy will
be±8%RH.
●Arrow indication for temperature changes:
will display when temperature changes less than 1℃within one
hour or compared with last reading
will display when the reading increase by 1℃within one hour or
compared with last reading.
will display when the reading decrease by 1℃within one hour or
compared with last reading.

17
ENEN
●Arrow indication for humidity changes:
will display when humidity changes less than 3%RH within one
hour or compared with last reading.
will display when the reading increase by 3%RH within one hour
or compared with last reading.
will display when the reading decrease by 3%RH within one hour
or compared with last reading.
Remark: The reading will be more accurate standing still for half an
hour after power on.
TEMPERATURE ALERT FUNCTION
SET OUTDOOR TEMPERATURE ALERT
1. Press and hold “ALERTS”button to enter into outdoor temperature
alert value ; the setting data will be flashing in 1Hz.
2. The setting order is: High temperature alert value→Low
temperature alert value→ Exit.
3. Press “▼/RCC’’ or “▲/CH’’ button to adjust data; press and hold
“▼/RCC’’ or “▲/CH’’ button will quickly change the data by 8
steps.
4. If no operation for 20 seconds, it will automatically save and exit
setting
TURN ON/OFF TEMPERATURE ALERT
1. The temperature alert function will be ON after setting the alert
values.
2. Press“ALERTS”button to check the high temperature alert value.
3. Press“▼/RCC’’ or “▲/CH’’button to turn on/off the high temperature
alert function with on/off of the symbol /
4. Press “ALERTS”button again to check the low temperature alert
value.

EN
18
5. Press“▼/RCC’’or “▲/CH’’button to turn on/off the low temperature
alert function with on/off of the symbol / .
6. Default setting : High temperature alert value 35℃;Low temperature
alert value 10℃.
7. The ascending “Bibi”alarm will ring for 5 seconds per minute with
the symbol flashing when the outdoor temperature reaches the alert
value and will stop ringing when out of alert range.
MAX AND MIN RECORD
1. Press “MEM’’to have maximum temperature and humidity (within 24
hours), the value will display for 5 seconds.
2. Press “MEM’’ second time to have the minimum temperature and
humidity(within 24 hours), the value will display for 5 seconds.
3. Press “MEM’’ third time will return to standard mode.
4. Press and hold “MEM’’will clear the max and min record and
reactivate the memory.
5. Normally, the Max and Min record will update every 24 hours at
0:00.
BAROMETER&WEATHER FORECAST
COMFORT LEVEL INDICATION
1 2 3 4 5
1. Humidity 84-99%RH (Too Wet)
2. Humidity 76-83%RH(Wet)
3. Humidity 40-75%RH(Comfortable)
4. Humidity 26-39%RH(Dry)
5. Humidity 1-25%RH(Too dry)

19
ENEN
●When powered by batteries, press " "button to turn on the
backlight. The backlight will last 15 seconds.
●For continuous backlight, please connect the power adaptor.
●Press" " button to switch backlight brightness among 100%,
50% , 10%,3% and off
Baldr weather stations were calibrated precisely at our
manufacturing facility, but if you desire the reading of this weather
station to keep consistent with the equipment you trust, you can
manually calibrate the indoor temperature /humidity and the
barometer values following below steps:
1. In normal display mode, press and hold the “MEM”and
“ALERTS”buttons simultaneously to enter into indoor
temperature and humidity/barometer value calibration mode.
BACKLIGHT FUNCTION
CALIBRATION
●The weather forecast icon will show after power on. There are 5 kinds
of weather modes: Sunny, Sunny To Cloudy, Cloudy, Rainy, Snow. The
weather icon displays are based on the hourly calculation of indoor/
outdoor temperature, humidity and barometer data. The forecast is for
next 12 hours with 70%-75% accuracy .
●Barometer range: 800hpa~1100hpa
●Pressure Unit: hPa/mb (DCF/MSF) inHg(WWVB)
Sunny Sunny to Cloudy Cloudy Rainy Snow
5 Weather Modes

2. Press “SET ’’button to select the order, press “▲/CH” or “ ▼/RCC”
button to adjust the value.
3. Press and hold “ ” button before powering the weather station to
clear the calibration values.
20
EN
TROUBLE SHOOTING
Flashing of the outdoor reading is generally an
indication of wireless interference.
1. Bring both the sensor and display indoors,
side by side and remove batteries from
each.
2. Make sure the 1-2-3 switch on both units
match.
3. Reload batteries in main unit.
4. Reload batteries in outdoor sensor.
5. Let both units sit within a couple feet of each
other for a few minutes to gain a strong
connection before taking sensor to outdoor
area.
• Reload the batteries of both outdoor sensor
and main unit. Please refer to the SENSOR
SETUP section.
• Relocate the main unit and/or the outdoor
sensor. The units must be within 328 ft (100
m) of each other.
• Make sure both units are placed at least 3
No outdoor sensor
reception
Problem Possible Solution
Outdoor reading is
flashing or showing
dashes
