Balt 91113 User manual

123456789012345678901234567890121234567890123456789012345678901212345678901234

Assembly Instructions

Up-Rite Desk Mounted

Sit/Stand Workstation

Single Monitor

Part Drawing Description Qty Part Drawing Description Qty

WOW 91113

Hardware List

BAllen Wrench 1 EA

Screw M6*13mm 8 EA

P1 Keyboard Top 1 EA

P2 Support Post 1 EA

P3 Keyboard Support 1 EA

P4 Monitor Mount 1 EA

P5 Mount Bar 1 EA

C Wire Wrap 1 EA

D Tension Plate 2 EA

E Screw M8*70mm 2 EA

F Screw M8*12mm 2 EA

1.)

EAD

HROUGH

NSTRUCTIONS

FROM

BEGINNING

END

BEFORE

STARTING

ASSEMBLE

UNIT

Assembly Instructions

Illustration # 2

2.)

IdentifyandSeperate alltheparts toyournew Workstation.

Loosenthe twoAllenRecess Screws inthe rearsection of theSupport Post’s (P2) table

clamp. Next,loosen thetwoAllen RecessScrews inthe topsection . Slidethe Support

Post(P2) ontothe backof the tableyouwill beusing. Tighten thetwo top Screws (E)

usingAllenWrench(C)untillthe SupportPost isfirmlyin place. Tightenthe twoScrews (F)

inthe rearof theclamp tolock the unitin place. Seeillustration #2.

Your

Table

Top

Screws

Rear

Screws

3.)

Illustration # 1

Slidethe MountBar (P5)under theclamp sectionof theSupport Post(P2). Loosely attach

usingtwo Screws(F) andtwo Screws(E) asshown inillustration #1.

5.)

Illustration # 4

AttachtheKeyboardTop(P1)to the KeyboardSupport usingsix Screws(A) asshown in

illustration#4. TightenScrews usingAllenWrench.

Illustration # 3

4.)

Attachthe KeyboardSupport (P3)to theplate onthe frontof theSupport Post(P2) using

twoScrews (A). TightenScrews withAllenWrenchasshown inillustration #3.

Use Wire Wrap (D) to manage electrical cables after your equipment is installed.

7.)

Illustration # 6 91113_09-24-15

6.)

Illustration # 5

Clamp

Lever

Loosen the clamp lever on the Monitor Mount (P4) and insert two Tension Plates (D) on the sides. Slide the

Monitor Mount down the vertical post of the Support Post (P3). Clamp the lever down to secure at your height

setting. See illustration # 5.

P2 Clamp

Lever
