Quick Start Guide
Elinx Managed Ethernet Switch
EIR618 Series
Items Included
1
2
3
LED Chart Hardware Installation
Log into the Switch
5
4
oEthernet Switch
oConsole Cable (RS-232 RJ-45 to DB-9)
oCD with Support Manual
oThis Quick Start Guide
oPanel Mount Bracket
oIP Address: 192.168.16.1
oSubnet Mask: 255.255.255.0
oGateway: 192.168.16.254
oUser Name: root, Password: root
LED Status Meaning
Green The Switch is powered on
PWR Off The Switch is powered off
Green Power Source 1 is available
PWR1 Off Power Source 1 is unavailable
Green Power Source 2 is available
PWR2 Off Power source 2 is unavailable
Red Power or Port failure
Fault Off Normal Operation
Green The Switch is the master of a redundant
ring (X-Ring)
R.M Off The Switch is not the master of a
redundant ring.
Green SFP Port is linked
Blinking Data is being transmitted or received
LINK/ACT
Port 17/18*
SFP Off Not connected to the network
T
Green Port is linked
T
Blinking Data is being transmitted or received
T
Off Not connected to the network
B
Green Operating at 1000M
Port
17/18*
RJ-45 B
Off Disconnected or below 1000M
T
Green Connected to the network
T
Blinking Data is being transmitted or received
T
Off Not connected to the network
B
Yellow Operating in full-duplex
B
Blinking Data collision
P
1-16*
B
Off Half-duplex or not connected
*Note Ports 1 through 16 are 10/100 RJ-45, Ports 16 & 17 are
100/1000 RJ-45 or SFP.
oRecord the switch’s MAC Address in the space
provided. The MAC Address is printed on the product
label. NOTE: Provide the MAC Address to your
Network Administrator. The Network Administrator
should provide an IP Address, Subnet Mask, and
Gateway.
oSelect a mounting location and install with the attached
DIN rail clip or included panel mount kit.
oConnect power to the switch
o12 to 48 VDC
oRedundant inputs are available with fault
contacts.
NOTE: The installation of an SFP Module disables
the associated RJ-45 Port.
oThese instructions are for Web based management.
Refer to the User’s Manual for instructions concerning
console management.
oConnect a switch port to a stand alone PC. Change the
PC’s network IP Address to allow it to connect to the
switch (ex: 192.168.16.2). Use the default subnet mask
and gateway.
oLaunch the PC’s web browser and navigate to the
switch by typing the switch’s IP Address in the browser
address window.
oNavigate the web page by expanding the folders on the
left side of the web page.
Default Settings

EIR618 Series-5107qsg
International Headquarters: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA
815-433-5100 Fax [phone] www.bb-elec.com [email protected] [email protected]
European Headquarters: Westlink Commercial Park Oranmore Co. Galway Ireland
[phone] Fax [phone] www.bb-europe.com [email protected] [email protected]
IP Configuration
User Name and Password
76
oExpand the “system tree” and select IP configuration.
oEnter the IP Address, Subnet Mask, and Gateway
provided by your Network Administrator.
oSave changes.
oDisconnect the stand alone PC and connect the switch
to the network.
oInform your Network Administrator that the IP Address
has been changed.
oNOTE: The User Manual contains instructions for
assigning the IP Address from a DHCP Server and
allowing the switch to be a DHCP Server.
oThis step should be accomplished by the Network
Administrator.
oLog onto the switch from a Network PC.
oExpand the “System Tree” and select user
authentication..
oEnter the new User Name and Password. Record this
information in the space provided below. File this
document for future reference.
oClick the Apply button.
USER NAME: ______________________________________
PASSWORD:_______________________________________
MAC ADDRESS: ____________________________________
IP ADDRESS: _______________________________________
Basic Configuration is complete. A
comprehensive Manual is contained on the CD
ROM. Refer to this manual to configure the
advanced features of this switch.
