B&B Electronics Elinx EIR508 Series User manual

EIR508 Series-5107qsg
International Headquarters: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA
815-433-5100 Fax [phone] www.bb-elec.com [email protected] [email protected]
European Headquarters: Westlink Commercial Park Oranmore Co. Galway Ireland
[phone] Fax [phone] www.bb-europe.com [email protected] [email protected]
1
2
34
5
oEthernet Switch
oCD with Support Manual
oThis Quick Start Guide
oPanel Mount Bracket
oIP Address: 192.168.16.1
oSubnet Mask: 255.255.255.0
oGateway: 192.168.16.254
oUser Name: root, Password: root
oRecord the switch’s MAC Address in the space
provided. The MAC Address is printed on the product
label. Provide the MAC Address to your Network
Administrator. The Network Administrator should
provide an IP Address, Subnet Mask, and Gateway.
oSelect a mounting location and install with the attached
DIN rail clip or included panel mount kit.
oConnect power to the switch
o12 to 48 VDC
oRedundant DC input is available with fault
contacts.
Pos Status
Description
OFF Disable port 1 Alarm
1 ON Enable port 1 Alarm
(If port 1 link fails, the fault LED will light)
OFF Disable port 2 Alarm
2 ON Enable port 2 Alarm
(If port 2 link fails, the fault LED will light)
OFF Disable port 3 Alarm
3 ON Enable port 3 Alarm
(If port 3 link fails, the fault LED will light)
OFF Disable port 4 Alarm
4 ON Enable port 4 Alarm
(If port 4 link fails, the fault LED will light)
OFF Disable port 5 Alarm
5 ON Enable port 5 Alarm
(If port 5 link fails, the fault LED will light)
OFF Disable port 6 Alarm
6 ON Enable port 6 Alarm
(If port 6 link fails, the fault LED will light)
OFF Disable port 7 Alarm
7 ON Enable port 7 Alarm.
(If port 7 link fails, the fault LED will light)
OFF Disable port 8 Alarm
8 ON Enable port 8 Alarm
(If port 8 link fails, the fault LED will light)
OFF Disable the ring master function.
9 ON Enable the switch as the ring master
in the redundant ring group.
LED Status Meaning
Green The Switch is powered on
Power Off The Switch is powered off
Green Power Source 1 is available
Power 1 Off Power Source 1 is unavailable
Green Power Source 1 is available
Power 2 Off Power Source 2 is unavailable
Yellow Power Source failure or Port Failure
Fault Off Normal Operation
Green Ring Master (Master of a redundant ring)
R.M. Off The switch is not a Ring Master
Green The port is linked
Blinking The port is receiving or transmitting packets
LNK/ACT
Ports 7 & 8 Off No device attached
Yellow Full Duplex Mode
Blinking Data Collision
FDX/COL
Ports 7 & 8 Off Half Duplex Mode
Green
10/100 Ports
Yellow
Quick Start Guide
Elinx Managed Ethernet Switch
EIR508 Series
Items Included
Default Settings
DIP Switch Settings
LED Chart
Hardware Installation

EIR508 Series-5107qsg
International Headquarters: 707 Dayton Road PO Box 1040 Ottawa, IL 61350 USA
815-433-5100 Fax [phone] www.bb-elec.com [email protected] [email protected]
European Headquarters: Westlink Commercial Park Oranmore Co. Galway Ireland
[phone] Fax [phone] www.bb-europe.com [email protected] [e-mail]
6
7
8
oConnect a stand alone PC to a port on the switch.
Change the PC’s network IP Address to allow it to
connect to the switch (ex: 192.168.16.2). Use the
default subnet mask and gateway.
oLaunch the PC’s web browser and navigate to the
switch by typing the switch’s IP address in the browser
address window.
oNavigate the web page by clicking on the links located
on the top of the web page.
oClick on the IP Configuration link at the top of the web
page.
oEnter the IP Address, Subnet Mask, and Gateway
provided by your Network Administrator.
oSave changes
oDisconnect the stand alone PC and connect the switch
to the Network.
oInform your Network Administrator that the IP Address
has been changed.
oNOTE: The User Manual contains instructions for
assigning the IP Address from a DHCP Server.
oThis step should be accomplished by your Network
Administrator.
oLog onto the switch from a network PC.
oClick on the Security Manager link on the top of the web
page.
oEnter the new User Name and Password. Record this
information in the space provided below. File this
document for future reference.
oClick the Apply button.
oClick the “Save Configuration” link at the top of the web
page.
USER NAME: ______________________________________
PASSWORD:_______________________________________
MAC ADDRESS: ____________________________________
IP ADDRESS:_______________________________________
Basic Configuration is complete. A
comprehensive Manual is contained on the CD
ROM. Refer to this manual to configure the
advanced features of this switch.
Log into the Switch
IP Configuration
User Name and Password
