B&D 86957 User manual

These instructions are intended for professional garage door
installers.All references are taken from inside looking out.
Smart Phone Control Kit
Doc # 161056_00
Part # 86958
Released 16/07/19
Smart Hub Installation Instructions
NETWORK SMART HUB KIT - ORDER NO. 86957
ITEM DESCRIPTION QTY
1 WIRELESS HUB100 WT B&D 1
2 POWER SUPPLY AU 240V 1
3 WALL BRACKET HUB100 1
4 PLASTIC WALL PLUG 6.9 X 25 2
5 SELF TAPPING SCREW 6 X 25 2
6NETWORK TRANSCEIVER MODULE 1
7 HARNESS 4 CORE 275 ASSY 1
Garage Door Openers
Important Safety Instructions
WARNING! • DO NOT attempt to disassemble, repair or modify the product. This will
invalidate the warranty.
• DO NOT install product on openers that control J-Type or Single Piece Doors.
• Do not allow children to play with the Smart Hub or your smart phone if the
ATA phone app has been installed.
ELECTROCUTION! • Keep the device away from water and other liquids. In the event that water
or other liquids enter the device, power off he product immediately and
clean the device.
• To reduce the risk of re or electric shock,do not expose this device to rain or
moisture.The device should not be exposed to dripping or splashing.
• DO NOT remove the cover as there are no user-serviceable parts inside.
CAUTION:
Fall from ladder • Ensure ladder is the correct type for job.
• Ensure ladder is on at ground.
• Ensure user has 3 points of contact while on ladder.
Burns • DO NOT handle damaged or leaking batteries
This device allows for operation of the door when not in line-of-sight of the door and
opener.
The door may operate unexpectedly, therefore do not allow anything to stay in or near the
path of the door. When the door is not operating automatically, watch the door when it is
moving and keep people away until the door is completely opened or closed. Contact with
the moving door can cause serious personal injury or damage to property.
It is our strong recommendation that your opener be tted with SAFETY BEAMS.Safety
Beams detect any obstructions in the doors path and override automatic operation if
one presents. These must be installed as in accordance with AS/NZS 60335-2-95:2012.
This is in addition to regular professional servicing, and monthly obstruction tests as detailed
in your opener’s Home Owners Manual.
This device must be connected to power at all times.
DO NOT disconnect power after setup.

b&d group ofce locations
Head Ofce 6-8 Fiveways Blvd, Keysborough 3173 Phone [phone]
New South Wales 34 Marigold St, Revesby 2212 Phone [phone]
Queensland 17 Oasis Court, Clontarf 4019 Phone [phone]
Victoria 147-153 Canterbury Rd, Kilsyth 3137 Phone [phone]
South Australia 23 Frederick Rd, Royal Park 5014 Phone [phone]
Western Australia 96 Mulgul Rd, Malaga 6090 Phone [phone]
International/Export 34 Marigold St, Revesby 2212 Phone [phone]
www.bnd.com.au
Prefixed trademarks are the property of B&D Australia Pty Ltd. B&D Doors & Openers
is a division of B&D Australia Pty Ltd.ABN 25 010 473 971. © 2016 B&D Australia Pty Ltd.
2
Auto-Lock Kit - Installation instructions
your representative is
Smart Hub Set Up
Mounting the Hub
a. Determine whether you are going to wall mount
the hub.
i. If hub is to be placed on bench, simply connect
to power supply 2, turn on and proceed to
installing the Transceiver.
ii. If hub is to be wall mounted follow steps below.
b. To wall mount - Use wall bracket 3as template to
mark where to drill holes. Pre-drill holes.
i. For plaster walls - insert (2) two Plastic wall plugs
4into holes, place wall bracket over holes and
afx with (2) two self tapping screws 5.
ii. For brick walls - place wall bracket 3over holes
and afx with (2) two self tapping screws 5.
c. Slide the hub over the bracket.
d. Connect the power supply 2and turn on.
1
3
5
This device must be connected to power at all times. DO NOT disconnect power after setup.
Warranty
This warranty is to be read in conjunction with the owner’s
copy of the opener installation instruction.
WARRANTY
ACCESSORIES 1 year
Mounting the Transceiver to the Opener
a. Disconnect the power supply to the opener.
b. Remove the left hand side pocket from the opener.
c. Reach inside the opener and pull out the 5 pin
harness and connect to the wireless basestation
module 6.
d. Place the module into the pocket and ret the
cover.
e. Download the B&D App and follow the instructions
in the App to setup new smart hub.
f. Use a programmed remote and run the door
through a few cycles which will update the unit
with the details of the transceiver module.
6
