Specifications
Radio 3General
Radio Range
900 MHz: Up to 9.6 km (6 miles)
2.4 GHz: Up to 3.2 km (2 miles)
Minimum Separation Distance
900 MHz (1Watt): 4.57 m (15 ft)
2.4 GHz (65 mW): 0.3 m (1 ft)
Radio Transmit Power
900 MHz: 30 dBm (1 W) conducted (up to 36 dBm
EIRP)
2.4 GHz: 18 dBm (65 mW) conducted, less than or
equal to 20 dBm (100 mW) EIRP
900 MHz Compliance (1 Watt)
FCC ID UE3RM1809: This device complies with FCC
Part 15, Subpart C, 15.247
IC: 7044A-RM1809
2.4 GHz Compliance
FCC ID UE300DX80-2400 - This device complies with
FCC Part 15, Subpart C, 15.247
ETSI/EN: In accordance with EN 300 328: V1.7.1
(2006-05)
IC: 7044A-DX8024
Spread Spectrum Technology
FHSS (Frequency Hopping Spread Spectrum)
Antenna Connection
Ext. Reverse Polarity SMA, 50 Ohms
Max Tightening Torque: 0.45 N·m (4 lbf·in)
Notice: This equipment must be professionally installed.
The output power must be limited, through the use of
firmware or a hardware attenuator, when using high-gain
antennas such that the +36 dBm EIRP limit is not
exceeded.
Power
FlexPower models: 10 to 30 V dc (Outside the USA:
12 to 24 V dc, ±10%) on the brown wire, or 3.6 to
5.5 V dc low power option on the gray wire 4
Integrated battery models: 3.6 V dc low power option
from an internal battery or 10 to 30 V dc
Master radio consumption (900 MHz): Maximum
current draw is < 100 mA and typical current draw is
< 30 mA at 24 V dc. (2.4 GHz consumption is less.)
Repeater/slave radio consumption (900 MHz):
Maximum current draw is < 40 mA and typical current
draw is < 20 mA at 24 V dc. (2.4 GHz consumption is
less.)
Housing
Polycarbonate housing and rotary dial cover; polyester
labels; EDPM rubber cover gasket; nitrile rubber, non-
sulphur cured button covers
Weight: 0.26 kg (0.57 lbs)
M-Hx and M-HxC models: Mounting: #10 or M5 (SS
M5 hardware included)
M-HxE models: Mounting: 1/4-inch or M7 (SS M7
hardware included)
Max. Tightening Torque: 0.56 N·m (5 lbf·in)
Interface
Indicators: Two bi-color LEDs
Buttons: Two
Display: Six character LCD
Wiring Access
M-Hx models: Four PG-7, One 1/2-inch NPT, One 5-
pin Euro-style male connector
M-HxC models: External terminals
M-HxE models: Two 1/2-inch NPT ports
Inputs and Outputs
Discrete Inputs
Rating: 3 mA max current at 30 V dc
Sample Rate: 40 milliseconds
ON Condition (NPN): Less than 0.7 V
OFF Condition (NPN): Greater than 2 V or open
Counter Inputs
Event Counter: Input rating 1 Hz – 10 kHz (For
battery powered devices, the recommended input
rating is less than 1 kHz)
Rate (Frequency) Counter: 1 Hz – 25 kHz
Threshold: 1.7 V
Analog Inputs
Rating: 24 mA
Impedance: Approx. 22 Ohms 5
Sample Rate: 1 second
Accuracy: 0.1% of full scale +0.01% per °C
Resolution: 12-bit
Thermistor Input (MultiHop)
Model: Omega’s 44006 or 44031 families of 10 kOhm
Sample: 1 second
Accuracy: 0.4 °C (10 to 50 °C); Up to 0.8 °C (−40 to
85 °C)
Discrete Output Rating (MultiHop NMOS)
Less than 1 A max current at 30 V dc
ON-State Saturation: Less than 0.7 V at 20 mA
Discrete Output ON Condition
Less than 0.7 V
Discrete Output OFF Condition
Open
3Radio range is with the 2 dB antenna that ships with the product. High-gain antennas are available, but the range depends on the environment and line of
sight. To determine the range of your wireless network, perform a Site Survey.
4For European applications, power the DX80 from a Limited Power Source as defined in EN 60950-1.
5To verify the analog input's impedance, use an Ohm meter to measure the resistance between the analog input terminal (AIx) and the ground (GND)
terminal.
