5. When desired stirring is completed, press the power switch to OFF
position. Remove container from the top plate.
•If you need to stir a high viscosity liquid, we recommend to set a
slower stirring speed.
•If the stir bar is not running smoothly, try moving the container
slightly, the stir bar should be in the center of the container.
Stirring Time
The MS400C magnetic stirrer has a built-in clock chip, which allows for
time management during stirring and heating.
1. Press the Time key, the display shows 000 min.
2. Press the / key to set a desired stirring time.
3. Press the Enter key, the timer begins countdown until it reaches
zero, the stirrer will stop running.
To exit the setup without saving changes, press the Exit key.
Heating
1. Insert the plug of the temperature probe into the jack socket on the
rear panel of stirrer.
2. Place the temperature probe into the liquid.
3. Press the ° C key, the display shows 000°C.
4. Press the / key to set a desired temperature.
5. Press the Enter key to begin the heating.
•The hot plate will not heat if the temperature probe is not attached.
•While heating a liquid, the temperature probe must be immersed.
Otherwise, the hot plate will heat continuously and will go into a
fault condition.
•During the heating process, the Heating icon will show in sequence
as follows:
•When the liquid reached the target temperature, the Heating icon
will continuously flash.
•Press the ° C key, then press the Exit key, the hot plate will stop
working.
Temperature Calibration
During the heating, if the temperature reading displayed differs from
that of an accurate thermometer, please follow the steps below to
calibrate the temperature probe.
1. Turn off the stirrer.
2. Press and hold the and keys for 5 seconds, then turn on the
stirrer.
3. Press the / key to modify the temperature value.
4. Press the Enter key to save.
