Barbeques Galore BVDA18M User manual

WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result caus-
ing property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s in-
structions.
• If you cannot reach your gas supplier, call the
fire department.
— Installation and service must be performed by a
qualified installer, service agency, or the gas
supplier.
WARNING: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Refer to this
manual for correct installation and
operational procedures. For assis-
tanceoradditionalinformationcon-
sult a qualified installer, service
agency, or the gas supplier.
WARNING: This appliance is for
installationonlyinasolid-fuelburn-
ingmasonryorUL127factory-built
fireplace, constructed of noncom-
bustiblematerial,andconnectedto
aworkingflue.(Seepage4formini-
mum flue opening.)
WARNING: This is a gas-fired appliance. It uses air (oxygen) from the room in which it is
installed. Provisions for adequate combustion and ventilation air must be provided. Refer to
NationalFuelGasCode,ANSIZ233.1/NFPA54 , Section5.3,AirforCombustionandVentilation .
Convertible from Natural Gas to Propane/LP Gas
Models BVDA18M, BVDA24M,
and BVDA30M
For Use with Log Sets
Mossy Maple
Models BMM18, BMM24 and BMM30
Twisted Pine
Models BTP18 and BTP24
Premium Pear
Models BPP18 and BPP24
Black Walnut
Models BBW18 and BBW24
Aspen Birch
Models BWB18 and BWB24
ANSI Z21.60a-2000
CSA 2.26a-2000
APPROVED
NATURAL GAS LOG
VENTED DECORATIVE APPLIANCE
OWNER’S MANUAL
Save this manual for future reference.
Save this manual for future reference.

109220-01C
2
1. This appliance, as supplied, is only for use with the type of gas
indicated on the rating plate. This appliance is convertible for
use with propane/LP.
2. If you smell gas
• shut off gas supply
• do not try to light any appliance
• do not touch any electrical switch; do not use any phone in
your building
• immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions
• if you cannot reach your gas supplier, call the fire department
3. Never install the log set
• in a recreational vehicle
• where curtains, furniture, clothing, or other flammable objects
areless than 42inchesfrom thefront,top, orsidesof the logset
• in high traffic areas
• in windy or drafty areas
4. Before installing in a solid fuel burning fireplace, the chimney
flue and firebox must be cleaned of soot, creosote, ashes and
loose paint by a qualified chimney cleaner. Creosote will ig-
nite if highly heated. Inspect chimney flue for damage.
5. You must operate this log set with fireplace doors or screens in
place and fully closed. Unless provided by other means, fire-
place doors or screens must have openings for introduction of
combustion air.
6. This log set is designed to be smokeless. If logs ever appear to
smoke, turn off appliance and call a qualified service person.
Note: During initial operation, slight smoking could occur due
to log curing and the burning of manufacturing residues. You
may wish to add more ventilation by opening a window.
7. To reduce the creation of soot, follow the instructions inClean-
ing and Maintenance, page 10.
8. Do not allow fans to blow directly into the fireplace. Avoid
any drafts that alter burner flame patterns. Ceiling fans can
create drafts that alter burner flame patterns. Altered burner
patterns can increase sooting.
SAFETY INFORMATION
Carbon Monoxide Poisoning: Early signs of carbon monoxide
poisoningresemblethe flu, with headaches, dizziness, or nausea. If
you have these signs, the log set may not be working properly. Get
fresh air at once! Have log set serviced. Some people are more
affected by carbon monoxide than others. These include pregnant
women,peoplewithheartorlungdiseaseoranemia,thoseunderthe
influence of alcohol, and those at high altitudes.
Natural Gas: Natural gas is odorless. An odor-making agent is
addedtothegas.The odorhelpsyoudetectagasleak. However,the
odor added to the gas can fade. Gas may be present even though no
odor exists.
Make certain you read and understand all Warnings. Keep this
manual for reference. It is your guide to safe and proper operation
of this log set.
WARNING ICON G 001
WARNINGS
IMPORTANT: Read this owner’s manual carefully and
completely before trying to assemble, operate, or ser-
vicethislogset.Improperuseofthislogsetcancause
serious injury or death from burns, fire, explosion,
electrical shock, and carbon monoxide poisoning.
DANGER: Carbon monoxide poisoning may lead
to death!
WARNING: Any change to this log set or its
controls can be dangerous.
WARNING: Keep flue open when operating unit.
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................ 2
LOCAL CODES........................................................................... 3
PRODUCT IDENTIFICATION ..................................................... 3
UNPACKING ............................................................................... 3
PRODUCT FEATURE................................................................. 3
INSTALLATION ........................................................................... 4
OPERATING APPLIANCE .......................................................... 9
INSPECTING BURNERS.......................................................... 10
CLEANING AND MAINTENANCE ............................................ 10
TROUBLESHOOTING ...............................................................11
ILLUSTRATED PARTS BREAKDOWNAND PARTS LIST ....... 14
REPLACEMENT PARTS .......................................................... 19
ACCESSORIES ........................................................................ 19
WARRANTY INFORMATION ...................................... Back Cover
TABLE OF CONTENTS
SAFETY INFORMATION
WARNING:Thisproductcontainsand/orgenerates
chemicals known to the State of California to cause
cancer or birth defects, or other reproductive harm.

109220-01C
3
3
UNPACKING
CAUTION:Donotremovethedataplatesfromthe
burner pan. The data plates contain important prod-
uct information.
1. Remove logs, hearth kit, pan materials, and hardware fromcarton.
2. Remove all protective packaging applied to logs and base for
shipment.
3. Check all items for any shipping damage. If damaged, promptly
inform dealer where you bought the product.
PRODUCT FEATURE
ON/OFF SAFETY VALVE/PILOT
Unit is tested and approved to ANSI Z21.60a-2000 and CSA 2.26a-
2000 as a vented decorative appliance. It is supplied with the parts
and instructions to convert to propane/LP gas use.
SAFETY INFORMATION
Continued
SAFETY INFORMATION
LOCAL CODES
PRODUCT IDENTIFICATION
UNPACKING
PRODUCT FEATURE
9. Do not use a blower insert, heat exchanger insert or other ac-
cessory not approved for use with this log set.
10. The installation and provisions for combustion and ventilation
airmust conformwiththeNationalFuelGasCode,ANSI Z233.1/
NFPA 54, Section 5.3, Air for Combustion and Ventilation.
11. Do not run log set
• where flammable liquids or vapors are used or stored
• under dusty conditions
12. Do not burn solid fuel in the fireplace after installing the log set.
Donotusethis log set to cook food orburnpaperorotherobjects.
13. Log set becomes very hot when in use. Keep children and adults
away from hot surface to avoid burns or clothing ignition. Log
set will remain hot for a time after shut-down. Allow surface
to cool before touching.
14. Carefully supervise young children when they are in the room
with log set.
15. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect the
appliance and to replace any part of the control system and
any gas control which has been under water.
16. To help prevent breakage, new logs must be broken-in (see
Curing logs page 9).
17. Turn log set off and let cool before servicing, installing, or
repairing. Only a qualified service person should install, ser-
vice, or repair log set.
18. Keep the appliance area clear and free from combustible ma-
terials, gasoline, and other flammable vapors and liquids.
PRODUCT IDENTIFICATION
Figure 1 - Product Identification (BVDA24M Shown)
Grate
Burner
Pan
Burner
Manifold
Burner
Clamp
Grate Steps
Hearth Kit Model ________________________
Serial Number __________________________
Log Set Model __________________________
Pilot Adjustment
Screw Access
LOCAL CODES
Installanduselogsetwithcare.Followalllocalcodes.Intheabsence
of local codes, use the latest edition of The National Fuel Gas Code
ANSI Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269

109220-01C
4
INSTALLATION
WARNING: Before installing in a solid fuel burn-
ing fireplace, the chimney flue and firebox must be
cleaned of soot, creosote, ashes and loose paint by
a qualified chimney cleaner. Creosote will ignite if
highly heated. A dirty chimney flue may create and
distribute soot within the house. Inspect chimney
flue for damage.
NOTICE: Installation, service, and repair of this appli-
ance must be performed by a qualified installer, ser-
vice agency, company or gas supplier experienced
with this type of gas appliance. Only factory autho-
rized components listed in these instructions may be
used in accordance with the manufacturer’s instruc-
tions and all codes and requirements of the authority
having jurisdiction. Any modifications to this kit, or
use of unauthorized components or accessory items
will void the manufacturer’s warranty, and may result
in a hazardous condition.
CAUTION: Do not remove the data plates at-
tached to the burner pan. The data plates contain
important warranty information.
FLUE OPENING SPECIFICATIONS
Note: This vented appliance must be installed only in a solid-fuel
burning fireplace with a working flue and constructed of noncom-
bustible material.
The charts in Figure 2 indicate technical information regarding the
installation of your gas log set. Please make sure that all of the
specificationsshownareapplicablebeforeinstallationisattempted.
The fireplace must include a working flue and venting system with
the minimum openings shown in the Figure 2. The minimum flue
sizesshowninFigure2arebasedona6'chimneyheightusinground
pipe. Your minimum flue size will vary based on input rate and
chimneyheight.Refertothe NationalFuelGasCodeANSIZ233.1/
NFPA 54, Section 6.6, for details
MODEL DESCRIPTION
BVDA18M 18" Dual Burner 55,000 45,000 .116 32 .082 45
BVDA24M 24" Dual Burner 65,000 55,000 .138 29 .086 44
BVDA30M 30" Dual Burner 70,000 60,000 .1405 28 .089 43
Btu Input
Natural
Gas
Btu Input
Propane/
LP Gas
MINIMUM FIREBOX SIZES
LOG FRONT BACK MINIMUM
SIZE WIDTH WIDTH* DEPTH HEIGHT
FLUE SIZE
18" 34" 16" 14" 18" 8" diam.
24" 35 3/4" 17" 15 1/2" 18" 8" diam.
30" 42" 27" 18" 18" 9" diam.
*At depth indicated
SPECIFICATIONS (W.C.)
Min. Max.
NG 7 10.5 6
LP 11 14 10
Figure 2 - Technical Information Charts
Burner Orifice
Natural
Propane/LP
In. Num. In. Num.
CHECK GAS TYPE
Use only natural gas. If your gas supply is not natural gas, you must
convert the appliance to Propane/LP. Follow the instructions on
page 7.
If the fireplace does not have a gas supply shut-off valve, one must
be installed.
FUEL INLET PRESSURE MANIFOLD PRESSURE
INSTALLATION
Flue Opening Specifications
Check Gas Type
WARNING: The Massachusetts State Board re-
quires all installations be performed by a Licensed
Plumber or Gas Fitter. Massachusetts state code re-
quires all vent dampers be welded open or removed.

109220-01C
5
5
INSTALLATION
Continued
VENTING SPECIFICATIONS FOR
INSTALLATION
Thefireplace chimney flueandvent mustbedraftingproperly. To
checktheventforproperdrafting:Lightatightlyrollednewspaper
on one end and place it at the inside front edge of the fireplace.
Observe the smoke and be sure the vent is properly drawing it up
the chimney. If the smoke spills out into the room, extinguish the
flameandremoveanyobstructionuntilproperventingisachieved.
The chimney flue damper must be fixed open to provide a minimum
of81sq.in.offreeairopeningduringoperationofthislogset.Amulti-
purpose damper clamp is provided to fix the damper in position.
INSTALLING DAMPER CLAMP
Secure the damper stop clamp provided to the leading edge of the
damper as shown in Figure 3. If for any reason this clamp doesn't
work on your fireplace, another suitable clamp or permanent stop
must be installed, or the damper blade must be cut or removed.
Damper
Clamp
Damper
Clamp
Damper
Manufactured Fireplace
Masonry Fireplace
Figure 3 - Attaching Damper Clamp
Damper Damper
INSTALLATION
Venting Specifications for Installation
Installing Damper Clamp
Connecting to Gas Supply
Installation Items Needed
Beforeinstallinglogset,makesureyouhavetheitemslistedbelow.
• piping (check local codes)
• sealant (resistant to LP gas)
• equipment shutoff valve
• test gauge connection
• adjustable (crescent) wrench or pliers
• sediment trap
• tee joint
• pipe wrench
CONNECTING TO GAS SUPPLY
WARNING: A qualified service person must con-
nect log set to gas supply. Follow all local codes.
CAUTION: Use only new, black iron or steel pipe.
Internally-tinnedcoppertubingmaybeusedincertain
areas. Check your local codes. Use pipe of 1/2" diam-
eteror greater toallowproper gasvolumeto log set.If
pipe is too small, undue loss of volume will occur.
Installation must include an equipment shutoff valve, union, and
plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge
hook up. NPT tap must be upstream from log set (see Figure 4).
IMPORTANT: Install equipment shutoff valve in an accessible
location. The equipment shutoff valve is for turning on or shutting
off the gas to the appliance.
Figure 4 - Gas Connection
* Purchase the optional CSA design-certified equipment shutoff
valve from your dealer.
**Minimum inlet pressure for purpose of input adjustment.
3" Minimum
Sediment Trap
From Gas Meter
(5" W.C.** to
10.5" W.C.
Pressure)
CSA Design-Certified
Equipment Shutoff Valve
With 1/8" NPT Tap*
Approved Flexible Gas Hose (no longer
than 36" if required by local codes)
Tee Joint
Pipe Nipple
Cap

109220-01C
6
INSTALLATION
Continued
We recommend that you install a sediment trap in supply line as
shown in Figure 4, page 5. Locate sediment trap where it is within
reachfor cleaning. Installinpiping system betweenfuelsupply and
heater. Locate sediment trap where trapped matter is not likely to
freeze.Asedimenttraptrapsmoistureandcontaminants.Thiskeeps
them from going into log set controls. If sediment trap is not
installed or is installed wrong, log set may not run properly.
WARNING: Use pipejointsealant thatisresistant
to liquid petroleum (LP) gas.
Figure 5 - Checking Gas Joints
Gas Meter
Equipment Shutoff Valve
WARNING: Test all gas piping and connections
for leaks after installing or servicing. Correct all
leaks at once.
WARNING: Neveruse anopen flame tocheck for
aleak. Applyamixture ofliquidsoap and waterto all
joints.Bubblesformingshowaleak.Correctallleaks
at once.
CHECKING GAS CONNECTIONS
Pressure Testing Gas Supply Piping System
Test Pressures In Excess Of 1/2 PSIG (3.5 kPa)
1. Disconnect log set and its individual equipment shutoff valve
from gas supply piping system.
2. Cap off open end of gas pipe where equipment shutoff valve
was connected.
3. Pressurize supply piping system by either using compressed air or
opening main gas valve located on or near gas meter.
4. Check all joints of gas supply piping system. Apply mixture of
liquid soap and water to gas joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect log set and equipment shutoff valve to gas supply.
Check reconnected fittings for leaks.
Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Figure 5).
2. Pressurize supply piping system by either using compressed air or
opening main gas valve located on or near gas meter.
3. Check all joints from gas meter to equipment shutoff valve (see
Figure 5). Apply mixture of liquid soap and water to gas joints.
Bubbles forming show a leak.
4. Correct all leaks at once.
HEARTH PAN INSTALLATION
If using propane/LP gas, see Propane/LP Gas Conversion before
installing hearth pan.
1. Place the burner pan assembly in the center of the fireplace
floor. Make sure the front of pan faces forward.
2. Thread the gas supply fitting to the fireplace gas supply pipe.
Adjust to most convenient position.
3. Install the gas connector tube to the gas supply fitting. Carefully
shape tube to attach to inlet fitting. Be careful not to cause
kinks in tube.
4. Test for leaks following instructions under Testing Burner for
Leaks, page 10.
5. Retighten and adjust the location of the gas control as neces-
sary. The gas control should be level, with the control rod to
the front.
Figure6-InstallingInletFittingand GasConnector Tube(Valve
Cover Removed for Clarity)
Gas Connector Tube
Regulator
Gas Control
Valve
INSTALLATION
Connecting to Gas Supply (Cont.)
Checking Gas Connections
Hearth Pan Installation
Apply pipe joint sealant lightly to male NPT threads. This will
prevent excess sealant from going into pipe. Excess sealant in pipe
could result in a clogged burner injector.

109220-01C
7
7
INSTALLATION
Continued
Propane/LP Gas Conversion
To convert to propane/LP gas, the burner inlet fitting and pilot orifice
must be replaced and the regulator pressure must be reset. The
propane/LP burner inlet fitting is supplied with the orifice installed.
Thepropane/LPpilotorificeforconvertingthe pilot is supplied and
is marked with a red stripe.
1. Remove control rod extension and piezo ignitor by pulling gently.
2. Remove screws that attach pilot assembly to valve cover and
valve cover to burner pan (see Figure 7).
3. Remove valve cover.
4. Using a wrench, remove gas control valve by turning counter-
clockwise (see Figure 8).
5. Remove the burner inlet fitting from the gas control assembly
(see Figure 8). DO NOT remove the orifice from this fitting.
The propane/LP burner inlet fitting is included in the hardware
kit (see Figure 9).
6. Be sure to use the correct orifice for your appliance. The orifice
kit included with this appliance contains an orifice installed in
an air mixer fitting.
7. Using thread sealant(resistant to the actionof propane/LP gas) on
smaller end of fitting, screw the burner inlet fitting into the outlet
side of the gas control (see Figure 8). Tighten using a wrench.
Piezo Ignitor
Control Rod
Extension
Screw
Valve Cover
Control
Knob
Figure 7 - Removing/Installing Cover, Control Knob, and Piezo
Ignitor
Thermocouple
Ignitor
Pilot
INSTALLATION
Hearth Pan Installation (Cont.)
8. Thread gas control valve and burner inlet fitting into burner
manifold (see Figure 8). Use thread sealant on male threads of
burner inlet fitting. Secure with a wrench. Make sure control
rod is facing the front (see Figure 8).
9. To adjust regulator pressure, remove the brass hex plug from
regulator (see Figure 10).
10. Remove the plastic pressure button from the brass plug (see
Figure 10).
11. Reverse the plastic pressure button and replace it into the brass
plug (see Figure 10).
12. Replace brass plug into regulator.
13. Using two screws removed in step 2, replace valve cover.
14. Gently loosen and remove the pilot line connection from the
pilot bracket (see Figure 11).
15. Replace injector with propane/LP injector with red stripe.
16. Replace and tighten pilot line to bracket.
17. Using screws removed in step 2, reattach pilot bracket to
valve cover.
18. Continue with step 1 under Hearth Pan Installation, page 6.
Burner Inlet Fitting
Gas Control
Valve
Burner Pan
Assembly
Figure 8 - Removing/Installing Gas Control Valve
Control Rod
Figure 9 - Burner Inlet Fittings with Injectors
NATURAL
GAS FITTING PROPANE/LP
GAS FITTING
Injector for
Natural Gas
Injector for
Propane/LP
Gas
Burner Inlet
Fitting for
Natural Gas
Figure 10 - Adjusting Regulator Pressure for Conversion
Reversed Plastic
Pressure Button
for Propane/LP
Conversion
Plastic Pressure
Button Positioned
for Natural Gas
Regulator
Brass Plug
Figure 11 - Installing Propane/LP Pilot Orifice
Pilot Injector
Pilot Adjustment Screw
Pilot Bracket

109220-01C
8
INSTALLATION
Continued
TESTING BURNER FOR LEAKS
1. Generously apply soapy solution to all connections.
WARNING: Never check for gas leaks with
open flame.
Figure 12 - Installing Grate (Pan Material Not Shown)
Grate
Grate Steps
2. Light the burner with the shut-off valve no more than half open
and holding a match slightly in front of the pan (see Lighting
Instructions, page 9).
3. Inspect all connections for bubbles, raw gas odor, or flame
from any area other than the burner (leaks). If leaks are de-
tected, shut off the gas valve immediately. Tighten, or reas-
semblethe loose connection(s) using pipe joint compound until
burner system is leak free.
4. When the burner is tested and leak free, observe the individual
tongues of flame on the burner.
Note: The burner design in-
cludes more ports on the outside of the bar. Make sure that all
ports are clear and producing flame evenly across the burner. If
any ports appear blocked, clear them by removing the burner
manifold and reaming the ports with a modified paper clip or
other suitable tool.
5. When finished testing, turn the gas shut-off valve OFF to extin-
guish all flames.
ADDING PAN MATERIAL
1. Open thebagofashbed material(vermiculite)andspreadit evenly
across the burner pan to the top. You may overflow the front and
sides of the pan to cover the entire pan. Do not cover valve.
2. Open the glowing embers and evenly cover the ash bed mate-
rial (vermiculite) in the burner pan.
INSTALLING THE GRATE AND LOGS
1. Place the grate over the burner pan where the two outer hori-
zontal supports on the grate fit into the two pan positioning
notches in the rear vertical edge of the pan.
2. Slide the two rear log grate steps over the two outer horizontal
supports on the grate as shown in Figure 12.
3. Place the back log on the grate onto the grate steps (see
Figure 13).
4. Place the front log(s) on the grate and slide forward against
the front bars on the grate (see Figure 13).
5. Place the smaller top logs onto the bottom logs (see Figure 14).
Leave as much open space between logs as possible to mini-
mize flame impingement and sooting. Note: Logs may chip if
they are handled roughly or if hit together while being placed.
INSTALLATION
Testing Burner for Leaks
Adding Pan Material
Installing the Grate and Logs
Figure 13 - Installing Front and Back Logs (Number and style of
your logs may vary)
Figure 14 - Placement of Top Logs (Aspen Birch Shown)
Twisted Pine LogsMossy Maple Logs

109220-01C
9
9
OPERATING APPLIANCE
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING:Ifyoudo not followtheseinstructions
exactly, a fire or explosion may result causing prop-
erty damage, personal injury or loss of life.
BEFORE LIGHTING smell all around the appliance area for
gas.Besuretosmellnexttothefloorbecausesomegasisheavier
than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in
your building.
• Immediatelycallyourgas supplier from a neighbor’sphone.
Follow the gas supplier’s instructions.
• Ifyoucannotreachyourgassupplier,callthefiredepartment.
During the 2-3 hour appliance break-in period, you may detect
an odor from the appliance as the various paints and com-
pounds used in the manufacturing of this log set cure. This is a
normal and temporary situation that is not cause for alarm.
However,youmaywanttoprovideextraventilationtotheroom
during this time.
To ensure proper curing of the logs:
• Ignite a 2" flame and maintain it for 1 hour.
• Burnthe logsinconsecutive1hourperiods raising theflame
anadditional2"tofullflame height foratotal of threehours.
CURING
LOGS
1. STOP! Read the safety information, above.
2. Make sure equipment shutoff valve is fully open.
3. Press in and turn control knob clockwise to the
OFF position.
4. Waitfive (5) minutesto clear outany gas.Thensmellforgas
around log set and near floor. If you smell gas, STOP! See
Safety Information, page 2. If you don’t smell gas, go to the
next step.
5. Turn control knob counterclockwise to the PILOT
position and press in. Keep control knob pressed in for five
(5) seconds.
Note: You may be running this log set for the first time
after hooking up to gas supply. If so, the control knob may
need to be pressed in for 30 seconds. This will allow air to
bleed from the gas system.
• If control knob does not pop up when released, contact a
qualified service person or gas supplier for repairs.
6. With control knob pressed in, push down and release igni-
tor button. This will light pilot.Visually locate the pilot on
the control valve cover by the edge of the burner pan to
look for flame. If needed, keep pressing ignitor button un-
til pilot lights.
Note: If pilot does not stay lit after several tries, turn the
gas control knob to OFF and call your service technician
or gas supplier.
7. Keep control knob pressed in for 30 seconds after lighting
pilot. After 30 seconds, release control knob.
Note: If pilot goes out, repeat steps 3 through 7.
8. Turn control knob counterclockwise to the ON
position. Burner should light. If burner does not light, call
a qualified service person.
Ignitor
Control Knob
Pilot
FROM "PILOT" POSITION
SLIGHT PUSH TO
TURN OFF
PULL PUSH
ON
ON
FROM "PILOT" POSITION
SLIGHT PUSH TO
TURN OFF
PULL PUSH
FROM "PILOT" POSITION
SLIGHT PUSH TO
TURN OFF
PULL PUSH
OFF
On Off
OFF
OFF
Figure 15 - Ignitor and Control Knob
Figure 16 - Thermocouple and Pilot
WARNING: Keep flue open when operating unit.
LIGHTING
INSTRUCTIONS Pilot
Burner
Thermocouple
OPERATING APPLIANCE
For Your Safety Read Before Lighting
Curing Logs
Lighting Instructions
ON

109220-01C
10
Pilot
Thermocouple
TO TURN OFF GAS
TO APPLIANCE
Shutting Off Appliance
1. Turn controlknobclockwise tothePILOTposition.
2. Press in and turn control clockwise to the OFF
position.
Shutting Off Burner Only (pilot stays lit)
Turn control knob clockwise to the PILOT position.
INSPECTING BURNERS
Check pilot flame pattern and burner flame patterns often.
PILOT ASSEMBLY
The pilot assembly is factory preset for the proper flame height.
Alterations may have occurred during shipping and handling. The
pilot is located on the back right hand side of the burner.
Thethermocoupleshouldbefullyenvelopedintheflame.Theflame
should not be lifting off of the thermocouple element.
If your pilot assembly does not meet these requirements:
• Access the pilot adjustment screw through slot in valve cover.
Turn adjustment screw clockwise to decrease or counterclock-
wise to increase the flame to proper size (see Figure 11, page 7).
Do not remove the adjustment screw.
• see Troubleshooting, pages 11 through 13
Figure 17 - Correct Pilot Flame Pattern
BURNER FLAME PATTERN
Burner flames will be steady; not lifting or floating. Flames should
go up through the middle of logset. Flames should not "spill" to the
edges of the pan or sides of the logset.
Figure 18 shows atypical flame pattern.If burner flamepattern differs
from that described:
• turn appliance off (see To Turn Off Gas to Appliance)
• see Troubleshooting, pages 11 through 13
Figure 18 - Typical Flame Pattern
OPERATING APPLIANCE
Continued
CLEANINGANDMAINTENANCE
• Keep the area around the log set clean and clear of debris.
• Occasionally, you may use a soft bristle brush to clean logs.
• Periodically inspect air mixer and burner tube for foreign matter
blocking air inlet and flame holes.
• Once every year a qualified agency or certified chimney sweep
should examine and clean the venting system of the fireplace.
OPERATING APPLIANCE
To Turn Off Gas to Appliance
INSPECTING BURNERS
Pilot Assembly
Burner Flame Pattern
CLEANING AND MAINTENANCE

109220-01C
11
11
TROUBLESHOOTING
WARNING: Turn off log set and let cool before
servicing. Only a qualified service person should
service and repair log set.
POSSIBLE CAUSE REMEDY
OBSERVED PROBLEM
Note: All troubleshooting items are listed in order of operation.
1. Poor fuel quality
2. Fireplace venting system not drafting
properly
3. Excessive flame impingement or
blockage
4. Improper fuel/air mixture
5. Excessive gas supply/pressure
1. Passage of air/gas across irregular sur-
faces
2. Excessivegaspressureonnaturalgasunits
1. Incorrect gas supply or pressure
2. Blocked burner orifice or burner mani-
fold ports
3. Improper burner orifice size
1. Ignitor electrode not connected to igni-
tor cable
2. Ignitor cable pinched or wet
3. Bad ground on piezo ignitor
4. Broken ignitor cable
5. Bad piezo ignitor
6. Ignitor electrode broken
7. Ignitor electrode positioned wrong
Log set is smoking/sooting excessively
( Note: It is natural and unavoidable for
vented gas log sets to produce moderate
levels of carbon (soot) where flames
contact the logs. This is especially true
with propane/LP gas.)
Burner is excessively noisy
( Note: The movement and combustion of
gas will create low, unavoidable levels of
noise.)
Burner flame is too low or too high
When ignitor button is pressed, there is no
spark at pilot
1. Contact local natural or propane/LPgas
company
2. Adjust damper wide open and/or have
fireplace and venting professionally
cleaned and checked
3. Separate the logs to allow more flame
passage
4. Remove any foreign items from the
flame pattern and/or check for proper
orifice sizing
5. Preheat flue in very cold weather
1. Relieve any tight bends or kinks in gas
supply line
2. Check/reset gas regulator pressure (see
Propane/LP Gas Conversion, page 7)
1. Check for proper gas supply pressure
2. Free burner orifice and manifold ports
of any burrs, paint, or other blockage
3. Verify proper burner orifice sizing (see
Figure 2, page 4)
1. Reconnect ignitor cable
2. Free ignitor cable if pinched by any
metal or tubing. Keep ignitor cable dry
3. Scrape away paint on bracket for better
contact with ground on piezo ignitor
4. Replace ignitor cable
5. Replace piezo ignitor
6. Replace electrode
7. Reposition electrode
TROUBLESHOOTING

109220-01C
12
OBSERVED PROBLEM
When ignitor button is pressed, there is
spark at pilot but no ignition
Pilotlights but flame goes out when control
knob is released
Burner does not light after pilot is lit
Delayed ignition burner
REMEDY
1. Turn on gas supply or open equipment
shutoff valve
2. Turn control knob to PILOT position
3. Press in control knob while in PILOT
position
4. Continue holding down control knob.
Repeat igniting operation until air is re-
moved
5. Adjust pilot flame for approximately
2" blue flame
6. Clean pilot (see Cleaning and Mainte-
nance, page 10) or replace pilot assembly
7. Replace gas control
1. Press in control knob fully
2. After pilot lights, keep control knob
pressed in 30 seconds
3. Fully open equipment shutoff valve
4. A) Contact local natural gas company
B) Clean pilot (see Cleaning and Mainte-
nance, page 10) or replace pilot assembly
5. Hand tighten until snug, then tighten
1/4 turn more
6. Replace thermocouple
7. Replace control valve
1. Clean burner orifice
2. Contact local natural or propane/LPgas
company
3. Replace burner orifice
4. Reconnect leads
1. Adjust pilot flame for approximately
2" blue flame
2. Replace pilot orifice set
TROUBLESHOOTING
Continued
POSSIBLE CAUSE
1. Gas supply turned off or equipment
shutoff valve closed
2. Control knob not in PILOT position
3. Control knob not pressed in while in
PILOT position
4. Air in gas lines when installed
5. Pilot adjustment screw closed
6. Pilot is clogged
7. Low gas pressure
1. Control knob not fully pressed in
2. Control knob not pressed in long enough
3. Equipment shutoff valve not fully open
4. Pilot flame not touching thermocouple,
which allows thermocouple to cool,
causing pilot flame to go out. This prob-
lem could be caused by one or both of
the following:
A) Low gas pressure
B) Dirty or partially clogged pilot
5. Thermocouple connection loose at con-
trol valve
6. Thermocouple damaged
7. Control valve damaged
1. Burner orifice clogged
2. Inlet gas pressure is too low
3. Burner orifice diameter is too small
4. Thermocouple leads disconnected or im-
properly connected
1. Pilot flame needs adjusting
2. Wrong pilot orifice
TROUBLESHOOTING

109220-01C
13
13
WARNING: If you smell gas
•Shut off gas supply.
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in
your building.
•Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
•Ifyoucannotreachyourgassupplier,callthefiredepartment.
POSSIBLE CAUSE
1. Metal expanding while heating or con-
tracting while cooling
1. Log Set burning vapors from paint, hair
spray, glues, cleaners, chemicals, new
carpet, etc. (See IMPORTANT state-
ment above)
2. Gas leak. SeeWarning statement at
top of page
1. Gas leak. SeeWarning statement at
top of page
2. Control valve defective
1. Gas leak. SeeWarning statement at
top of page
OBSERVED PROBLEM
Log Set produces a clicking/ticking noise
just after burner is lit or shut off
Log Set produces unwanted odors
Gas odor even when control knob is in OFF
position
Gas odor during combustion
REMEDY
1. This is common with most log sets. If
noise is excessive, contact qualified ser-
vice person
1. Open flue to maximum. Stop using odor
causingproductswhilelogsetis running
2. Locate and correct all leaks (see Check-
ing Gas Connections, page 6)
1. Locate and correct all leaks (see Check-
ing Gas Connections, page 6)
2. Replace control valve
1. Locate and correct all leaks (see Check-
ing Gas Connections, page 6)
IMPORTANT: Operating log setwhereimpurities in airexistmay create odors.
Cleaning supplies, paint, paint remover, cigarette smoke, cements and glues,
newcarpetortextiles,etc.,createfumes.Thesefumesmaymixwithcombustion
air and create odors. These odors will disappear over time.
TROUBLESHOOTING
Continued
TROUBLESHOOTING

109220-01C
14
ILLUSTRATED PARTS
BREAKDOWN
MODELS BVDA18M, BVDA24M
AND BVDA30M
Propane/LP
Natural Gas
3
2
14
8
26
25
15
4
13
20
21
18
24
19
6
4
17
22
23
10
7
5
9
9
11
12
1
16
ILLUSTRATED PARTS BREAKDOWN
Models BVDA18M, BVDA24M and BVDA30M

109220-01C
15
15
PARTS LIST
This list contains replaceable parts used in your log set. When
ordering parts, follow the instructions listed under Replacement
Parts on page 19 of this manual.
PARTS LIST
Models BVDA18M, BVDA24M and BVDA30M
KEY PART NUMBER FOR
NO. BVDA18M BVDA24M BVDA30M DESCRIPTION QTY.
1 901063-01 901063-01 901063-01 Brass 3/8 FLR x 1/2 FPT Elbow 1
2 901056-01 901056-01 901056-01 Brass 3/8 FLR x 3/8 MPT Elbow 1
3 901066-01 901066-01 901066-01 Brass Air Mixer - Natural Gas 1
4 901064-07 901064-08 901064-04 Natural Gas Injector 1
901065-05 901065-03 901065-04 Propane/LP Gas Injector 1
5 901209-01 901209-02 901209-03 Burner Manifold 1
6 901137-01 901137-02 901137-03 Burner Pan 1
7 901242-01 901242-01 901242-01 Damper Clamp - Std. Assembly 1
8 901232-01 901232-01 901232-01 Gas Line - 12" Aluminum 1
9 901431-01 901431-01 901431-01 Grate Steps 2
10 901246-01 901246-02 901246-03 Log Grate 1
11 901681-01 901681-01 901681-01 Burner Strap 1
12 901078-01 901078-01 901078-01 Nut #8/32 1
13 901076-01 901076-01 901076-01 Screw #8/32 x 3/8 1
14 901082-01 901082-01 901082-01 Regulator 1
15 901066-02 901066-02 901066-02 Propane/LP Brass Air Mixer 1
16 901070-01 901070-01 901070-01 Propane/LP Pilot Orifice 1
17 901075-01 901075-01 901075-01 Screw 1/4" #8 “B” pt 4
18 901079-01 901079-01 901079-01 Pilot Valve Control Dial 1
19 901080-01 901080-01 901080-01 Pilot Valve Dial Extension 3" 1
20 097159-04 097159-04 097159-04 Piezo Igniter 1
21 901068-02 901068-02 901068-02 Manual Valve 1
22 901069-01 901069-01 901069-01 Pilot Burner (with natural gas orifice) 1
23 901072-01 901072-01 901072-01 Piezo Igniter Electrode 1
24 901140-01 901140-01 901140-01 Steel Shroud 1
25 901042-01 901042-01 901042-01 Control Dial Instructions 1
26 901056-01 901056-01 901056-01 Brass 3/8 FLR x 3/8 MPT Elbow 1
PARTS AVAILABLE —NOT SHOWN
901156-01 901156-01 901156-01 .125# Bag Embers 1
901155-01 901155-01 901155-01 1.5# Bag Ash Bed Material
(Vermiculite) 1

109220-01C
16
KEY PART NUMBER FOR
NO. BMM18 BMM24 BMM30 DESCRIPTION QTY.
1 901565-04 901566-04 901567-04 Bottom Split Rear Log 1
2 901735-01 901735-02 901735-02 Bottom Split Front Log 1
3 901734-01 901734-02 901734-03 Bottom Split Front Log 1
4 — — 901580-03 VR-11 Top Round Log 1
5 901588-02 901588-02 901588-02 VS-12 Top Split Log 1
6 — 901592-02 901592-02 VCR-12 Top Round Log 1
7 901591-05 901591-05 901591-05 VCR-11 Top Round Log 1
8 901551-04 901551-04 901551-04 CHR-13 Top Round Log 1
9 901587-02 901587-02 901587-02 VCR-9 Top Round Log 1
ILLUSTRATED PARTS
BREAKDOWN
LOG SETS
Mossy Maple
This list contains replaceable parts used in your log set. When
ordering parts, follow the instructions listed under Replacement
Parts on page 19 of this manual.
4
2
7
8
5
6
9
3
1
ILLUSTRATED PARTS BREAKDOWN
Log Set Models BMM18, BMM24,and BMM30

109220-01C
17
17
ILLUSTRATED PARTS
BREAKDOWN
LOG SETS
Twisted Pine
This list contains replaceable parts used in your log set. When
ordering parts, follow the instructions listed under Replacement
Parts on page 19 of this manual.
Premium Pear
KEY PART NUMBER FOR
NO. BTP18 BTP24 DESCRIPTION QTY.
1 901737-01 901737-01 Bottom Split Front Log 1
2 901565-06 901566-06 Bottom Split Rear Log 1
3 901591-07 901591-07 VCR-11 Top Round Log 1
4 901619-02 901619-02 FS-12Y Top Split Log 1
5 901617-02 901617-02 FS-16 Top Split Log 1
6 901612-02 901612-02 FS-17 Top Split Log 1
7 —901588-03 VS-12 Top Split Log 1
3
4
2
1
7
6
5
2
7
1
3
6
4
5
KEY PART NUMBER FOR
NO. BPP18 BPP24 DESCRIPTION QTY.
1 901565-05 901566-05 Bottom Split Rear Log 1
2 901736-01 901736-02 Bottom Split Front Log 1
3 901551-05 901551-05 CHR-13 Top Round Log 1
4 901591-06 901591-06 VCR-11 Top Round Log 1
5 901592-03 901592-03 VCR-12 Top Round Log 1
6 901566-02 901556-02 CHR-13Y Top Round Log 1
7 —901580-05 VR-11 Top Round Log 1
ILLUSTRATED PARTS BREAKDOWN
Log Set Models BTP18, BTP24, BPP18 and BPP24

109220-01C
18
KEY PART NUMBER FOR
NO. BWB18 BWB24 DESCRIPTION QTY.
1 109274-01 109282-01 Bottom Front Log 1
2 109273-01 109281-01 Bottom Rear Log 1
3 109278-01 109278-01 13" Top Log 1
4 109277-01 109277-01 12" Top Log 1
5 109276-01 109276-01 11" Top Log 1
6 109279-01 109279-01 13" Top Log "Y" 1
7 —109284-01 14" Top Log (Left) 1
2
1
3
5
4
6
7
Aspen Birch
ILLUSTRATED PARTS
BREAKDOWN
LOG SETS
4
1
2
6
5
3
7
Black Walnut
KEY PART NUMBER FOR
NO. BBW18 BBW24 DESCRIPTION QTY.
1 109287-01 109294-01 Bottom Front Log 1
2 109286-01 109295-01 Bottom Rear Log 1
3 109292-01 109292-01 14" Top Log 1
4 109290-01 109290-01 13" Top Log 1
5 109291-01 109291-01 12" Top Log "Y" 1
6 109289-01 109289-01 12" Top Log 1
7 —109297-01 13" Top Log (Left) 1
This list contains replaceable parts used in your log set. When
ordering parts, follow the instructions listed under Replacement
Parts on page 19 of this manual.
ILLUSTRATED PARTS BREAKDOWN
Log Set Models BBW18, BBW24, BWB18, and BWB24

109220-01C
19
19
ACCESSORIES
Purchase these logset accessories from your local dealer. If they
cannotsupplytheseaccessories,callContactBarbequesGaloreat
1-800-673-5206. You can also write to the address listed on the
back page of this manual.
ASH BED MATERIAL (Vermiculite) - GA9750A
For all models. Carton of 6.
GLOWING EMBERS - GA9950A
For all models. Use for firebox decoration only.
SILICA SAND - GA9850A
For all models. Use for firebox decoration only. Carton of 6.
LAVA ROCK - GA6067A
For all models. Use for firebox decoration only.
DECORATIVE ASH BED CONTROL COVER
CDABKA
Forall models.An attractive way to cover control knoband piezo
ignitor.
18" ORNAMENTAL GRATE ENHANCER
GA9350A
For 18" models only. Additional decoration for front grate.
24" ORNAMENTAL GRATE ENHANCER
GA9360A
For 24" models only. Additional decoration for front grate.
30" ORNAMENTAL GRATE ENHANCER
GA9370A
For 30" models only. Additional decoration for front grate.
FIRE CRACKLE - CF6A
For all models. Creates the sound of a real burning fire.
REPLACEMENT PARTS
Note: Use only original replacement parts. This will protect your
warranty coverage for parts replaced under warranty.
PARTS UNDER WARRANTY
Contact Barbeques Galore at 1-800-673-5206. When calling
Barbeques Galore, have ready
• your name and address
• model and serial numbers of your log set
• how log set was malfunctioning
• type of gas used (propane or natural gas)
• purchase date
Usually, we will ask you to return the part to the factory.
PARTS NOT UNDER WARRANTY
Contact Barbeques Galore at 1-800-673-5206. When calling
Barbeques Galore, have ready
• model number of your log set
• the replacement part number
REPLACEMENT PARTS
ACCESSORIES

109220-01C
20
KEEP THIS WARRANTY
WARRANTY INFORMATION
Model
Serial No.
Date Purchased
Always specify model and serial numbers when communicating with the factory.
We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty. We make
no other warranty, expressed or implied.
109220-01
Rev. C
03/03
NOT A UPC
109220 01
LIMITED WARRANTY
BARBEQUES GALORE VENTED GAS LOGS
Barbeques Galore warrants this product to be free from defects on burner system for four (4) years and logs for a lifetime from the date of first
purchase, provided that the product has been properly installed, operated and maintained in accordance with all applicable instructions. To make
a claim under this warranty the Bill of Sale or cancelled check must be presented.
This warranty is extended only to the original retail purchaser. This warranty covers the cost of part(s) required to restore this log set to proper
operatingconditionandanallowanceforlaborwhenprovidedbyaBarbequesGaloreAuthorizedServiceStores.Warrantypart(s)MUSTbeobtained
throughauthorizeddealersofthisproductand/orBarbequesGalorewhowillprovideoriginalfactoryreplacementparts.Failuretouseoriginalfactory
replacement parts voids this warranty. The log set MUST be installed by a qualified installer in accordance with all local codes and instructions
furnished with the unit.
This warranty does not apply to parts that are not in original condition because of normal wear and tear, or parts that fail or become damaged as a
result of misuse, accidents, lack of proper maintenance or defects caused by improper installation. Travel, diagnostic cost, labor, transportation and
any and all such other costs related to repairing a defective log set will be the responsibility of the owner.
TO THE FULL EXTENT ALLOWED BY THE LAW OF THE JURISDICTION THAT GOVERNS THE SALE OF THE PRODUCT; THIS
EXPRESSWARRANTYEXCLUDESANYANDALLOTHEREXPRESSEDWARRANTIESANDLIMITSTHEDURATION OF ANY AND
ALL IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE
TOFOUR (4) YEARS ON BURNERSYSTEM AND ALIFETIME ONLOGS FROM THEDATE OF FIRSTPURCHASE; ANDBARBEQUES
GALORE’SLIABILITYISHEREBYLIMITEDTOTHEPURCHASEPRICEOFTHEPRODUCTANDBARBEQUESGALORESHALLNOT
BE LIABLE FOR ANY OTHER DAMAGES WHATSOEVER INCLUDING INDIRECT, INCIDENTAL OR CONSEQUENTIAL DAMAGES.
Some states do not allow a limitation on how long an implied warranty lasts or an exclusion or limitation of incidental or consequential damages,
so the above limitation on implied warranties, or exclusion or limitation on damages may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from state to state.
For information about this warranty write:
15041 Bake Parkway
Suite A
Irvine, California 92618
