Barco TF-20 Manual

Superior visual performance in all outdoor conditions
With TF-20, Barco has done it again—a superior LED tile that exceeds industry
expectations in all essential categories, featuring:
TF-20
All conditions, outdoor 20mm LED tile
• Revolutionary LED innovation
• World-class image processing
• Environmental responsibility
• Countless applications
An industry leader in high-tech electronics for 75 years, Barco maintains its
commitment to the LED market by investing 10% of revenue annually back into
R&D, delivering advanced features and robust solutions.
Key features
7,600 NIT brightness
4,000:1 contrast ratio
16-bit color processing
System Color Signature
100,000-hour lifetime
Field-replaceable shaders
Tilted LED configuration
PFC, RoHS and EMC
Wide operating temp.

Revolutionary LED innovation
Four revolutionary LED advancements give TF-20 a significant advantage over its
competitors. Each of these features alone means you’re dealing with a world-class
product. The combination of them catapults TF-20 into a class of its own.
16-bit processing generates 281 trillion colors for true color in all
ambient conditions. Extra grayscale processing delivers stunning
detail in high or low NIT settings.
7,600 NIT brightness makes TF-20 ideal in any outdoor setting.
Superior components ensure the screen stays brighter longer,
providing 100,000 hours of continuous use.
4,000:1 contrast tempers brightness into sharp, focused images
and easily readable text. “Light trap” shaders protect LEDs from
harm and are field-replaceable if damaged.
Tilted LED configuration directs 26% more light downward for more efficient use
of available brightness, resulting in more targeted light beneath the screen and
improved vertical viewing angles.
World-class image processing
Barco’s world-renowned image processing produces sharp, brilliant images unmatched
by competitors. System Color Signature monitors LED color signature, temperature
thresholds and overall runtime, while component selection and layout minimizes heat
distribution and operating temperature—a holistic approach to visual performance.
DX-700 and D320 digitizers are compatible will all resolutions and aspect ratios,
require no external frame rate conversion and accept both analog and digital inputs.
True Color Reproduction ensures accurate color rendering
and self-adjusting image uniformity during the lifetime of
the tile.
True Motion Reproduction delivers smooth, flicker-free video by enhancing image
signals, minimizing the "smearing" effect inherent in large image magnification.
Typical vertical viewing angle TF-20 tilted LED configuration
DX-700
D320

Environmental responsibility
When it comes to the environment, TF-20 meets or exceeds the latest international
regulations. Green products contain safe components and produce less power,
creating strong community support and sustainable markets.
Power Factor Correction
Found only in high-end LED tiles, PFC reduces mains
harmonics, mitigates electrical impact on power networks
and conserves energy.
Restriction of Hazardous Substances
Meets international RoHS standards, meaning all product
components contain no lead, mercury, cadmium, Cr6, PBB or
PBDE.
Electromagnetic Compatibility
Operates in a self-contained field, unaffected by electrical
devices and causing no harm to other devices like cell phones
or medical equipment.
Low power consumption, maximum ROI
Efficient components last longer, produce less heat and require no HVAC, resulting in
considerably less power consumption—significantly reducing cost.
NIT
8K
7K
6K
5K
4K
3K
2K
1K
Hours 50,000 100,000 Heat Power
TF-20
Typical
TF-20
Typical
Countless applications
With half-sizes available for curved or creative displays, TF-20 is perfect for use
in countless outdoor applications, including sports stadiums, branding, outdoor
advertising and architectural integration. By selecting TF-20 for your outdoor LED
installation, you are acquiring what is considered the most reliable and cost-effective
20mm-range LED tile available in today’s market.
Sports Out-of-Home Media Architectural integration
Efficient components Less heat, low power
Wembley Stadium, London Mega Park, Mallorca Crown Fountain, Chicago

TF-20 specifications
960mm
960mm
250mm
480mm
TF-20 (full) TF-20 (half)
Pixel pitch 20mm 20mm
Typical brightness (calibrated) 7,600 NIT 7,600 NIT
LED configuration 1R, 1G, 1B 1R, 1G, 1B
Pixel density 2,304/tile (48x48) 1,152/tile (48x24)
Viewing angle (horizontal)
Viewing angle (vertical)
+60°/- 60°
+15°/-45°
+60°/- 60°
+15°/-45°
Contrast ratio 4,000:1 4,000:1
Power consumption/m2
. max
. average
400 watts
120 watts
400 watts
120 watts
Color processing 16-bit/color 16-bit/color
Colors 281 trillion 281 trillion
Refresh rate 800 Hz 800 Hz
Temperature
. operating
.
storage
-35° C to 50° C
(-31° F to 122° F)
-35° C to 50° C
(-31° F to 122° F)
-35° C to 50° C
(-31° F to 122° F)
-35° C to 50° C
(-31° F to 122° F)
Humidity
. operating
. storage
10 to 99%
10 to 99%
10 to 99%
10 to 99%
Weight/tile 54 kg (119 lbs) 30 kg (66 lbs)
Lifetime 100,000 hours 100,000 hours
Dimensions (HxMxD) 960mm x 960mm x
250mm
960mm x 480mm x
250mm
Serviceability Front/back access*Front/back access*
Ruggedness
. front
. back
IP65
IP54
IP65
IP54
Reference number
. front access
. back access
R9004816
R9004817
R9004814
R9004815
Certification UL/ETL, CE, FCC Class A, RoHS, CCC, CETL
*
Front or back, to be specified at order
960mm
References: Cover, SLite; London, SLite; Mallorca,
SLite; Chicago, SLite. Tilt image simulated.
