Barco R9001309 User manual

OWNER'S MANUAL
RETRO DATA
2100LC
R9001309

BARCO PROJECTION SYSTEMS
Date : 260898 Rev 02
OWNER'S MANUAL
R9001309
RETRO DATA
2100LC
Art. No : R5975948A

BARCO nv/Projection Systems
Noordlaan 5
B-8520 Kuurne
Belgium
Tel : [phone]
Fax : [phone]
E-mail : [email protected]
Visit Barco at the web : http://www.barco.com
Printed in Belgium
Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, August 1998.
All rights reserved.
Trademarks are the rights of their respective owners.

i -1
Table of contents
5975948A RETRODATA 2100LC 210198
TABLE OF CONTENTS
i
SAFETY INSTRUCTIONS ......................................................................................................................................1
Owner's record ..........................................................................................................................................................................1-1
On safety ....................................................................................................................................................................................1-1
On installation ..............................................................................................................................................................................1-2
On servicing ................................................................................................................................................................................ 1-2
On cleaning .................................................................................................................................................................................1-2
On repacking ...............................................................................................................................................................................1-2
On illumination .............................................................................................................................................................................. 1-2
LOCATION AND FUNCTION OF CONTROLS .......................................................................................................2
Front Control Panel Description & Function ...................................................................................................................................................2-1
Gaining access to the front control panel ..................................................................................................................................2-1
Front Control Panel Description & function, key diagram : ......................................................................................................... 2-1
Rear Input Panel Description & Function ........................................................................................................................................................2-2
Gaining access to the rear input panel ...................................................................................................................................... 2-2
Rear input panel description & function, key diagram : ............................................................................................................. 2-3
RCU Control Panel Description & Function..................................................................................................................................................... 2-4
RCU control panel access and housing .....................................................................................................................................2-4
RCU panel description & function, key diagram : ....................................................................................................................... 2-4
POWER CONNECTIONS .......................................................................................................................................3
AC Power (mains) Cord Connection ............................................................................................................................................................. 3-1
Power (mains) cord connection .................................................................................................................................................................... 3-1
Fuses ..............................................................................................................................................................................................3-1
Projector status LED ....................................................................................................................................................................................... 3-2
Switching on ..............................................................................................................................................................................................3-2
Switching to stand-by ....................................................................................................................................................................................3-2
Switching off ..............................................................................................................................................................................................3-2
Lamp life ..............................................................................................................................................................................................3-2
INPUT CONNECTIONS ..........................................................................................................................................4
Front Input Connections .................................................................................................................................................................................4-1
Signal input connection to the projector .....................................................................................................................................4-1
Connecting a Video source to the Video in 2 input ....................................................................................................................4-1
Connecting a Audio source to the Audio in B input ....................................................................................................................4-1
Connecting a RGB source to the RGB in 4 input ........................................................................................................................4-2
Rear Input connections ..................................................................................................................................................................................4-2
Signal input connection to the projector .....................................................................................................................................4-2
Connecting a Video source to the BNC input (port 1) ...............................................................................................................4-3
Connecting a S-Video source to the 4-mini DIN input (port 3) ...................................................................................................4-3
Connecting a RGB3S analogue source to port 5 ....................................................................................................................... 4-4
Connecting a RGB analogue source to port 5 ...........................................................................................................................4-4
Peripheral Equipment Input Connections ........................................................................................................................................................ 4-5
Connecting a computer ............................................................................................................................................................... 4-5
Connecting a RCVDS 05 to the Retro Projector .........................................................................................................................4-5
Connecting a VS05 to the Retro Projector ................................................................................................................................. 4-6
Connecting an IR Remote Receiver 800 to the Retro Projector ................................................................................................. 4-6
CONTROLLING .....................................................................................................................................................5
Battery installation in the RCU ........................................................................................................................................................................5-1
How to use your RCU ....................................................................................................................................................................................5-1
Projector Address .......................................................................................................................................................................................... 5-2
How to display a projector address ........................................................................................................................................... 5-2
How to program an address into the RCU? ...............................................................................................................................5-3
Controlling Chained Projectors .................................................................................................................................................... 5-3
Picture Controls with Direct Access .............................................................................................................................................................. 5-3
Brightness Control ...................................................................................................................................................................... 5-3
Contrast Control ..........................................................................................................................................................................5-3
Color Saturation Control ..............................................................................................................................................................5-4
Sharpness Control ...................................................................................................................................................................... 5-4
Tint Control ..................................................................................................................................................................................5-4
The Pause Key ............................................................................................................................................................................5-4
SOUND CONTROL ................................................................................................................................................6
Sound control with direct accessing .............................................................................................................................................................6-1

i -2
Table of contents
5975948A RETRODATA 2100LC 210198
Volume control............................................................................................................................................................................. 6-1
Bass control ................................................................................................................................................................................ 6-1
Treble control .............................................................................................................................................................................. 6-1
Balance control ........................................................................................................................................................................... 6-2
The Mute Key .............................................................................................................................................................................................. 6-2
Mono/Stereo Key ............................................................................................................................................................................................ 6-2
START UP OF THE ADJUSTMENT MODE ........................................................................................................... 7
Adjustment Mode ........................................................................................................................................................................................... 7-1
Random Access .......................................................................................................................................................................... 7-1
Installation .................................................................................................................................................................................... 7-1
Service ........................................................................................................................................................................................ 7-1
Guided Adjustment Mode ............................................................................................................................................................................... 7-2
RANDOM ACCESS ADJUSTMENT MODE ............................................................................................................8
Starting up the Random Access Adjustment Mode........................................................................................................................................ 8-1
File Service .............................................................................................................................................................................................. 8-2
Load file ....................................................................................................................................................................................... 8-2
Edit file ......................................................................................................................................................................................... 8-3
Rename ....................................................................................................................................................................................... 8-5
Copy ............................................................................................................................................................................................ 8-5
Delete .......................................................................................................................................................................................... 8-6
Options ........................................................................................................................................................................................ 8-6
Picture Tuning .............................................................................................................................................................................................. 8-6
Sync slow/fast ........................................................................................................................................................................... 8-7
Still Video ..................................................................................................................................................................................... 8-7
Color Balance .............................................................................................................................................................................. 8-7
Gamma ........................................................................................................................................................................................ 8-7
Audio Tuning .............................................................................................................................................................................................. 8-8
Volume, Balance, Bass and Treble ............................................................................................................................................ 8-8
Mute ............................................................................................................................................................................................. 8-8
Lock [OFF/AUDIO A/AUDIO B/AUDIO C] ..................................................................................................................................... 8-8
Fade ............................................................................................................................................................................................. 8-9
Geometry .............................................................................................................................................................................................. 8-9
Shift ............................................................................................................................................................................................. 8-9
Size........................................................................................................................................................................................... 8-10
Zoom ......................................................................................................................................................................................... 8-10
Blanking ..................................................................................................................................................................................... 8-11
Scale......................................................................................................................................................................................... 8-12
INSTALLATION MODE .......................................................................................................................................... 9
Starting up the Installation Mode ..................................................................................................................................................................... 9-1
Configuration ............................................................................................................................................................................... 9-1
Internal Patterns .......................................................................................................................................................................... 9-2
SERVICE MODE .................................................................................................................................................. 10
Starting up the Service Mode ...................................................................................................................................................................... 10-1
Identification ............................................................................................................................................................................. 10-3
Change Password ................................................................................................................................................................... 10-3
Change Projector Address ...................................................................................................................................................... 10-4
Change Baud rate PC............................................................................................................................................................... 10-4
Reset Lamp Run Time .............................................................................................................................................................. 10-4
Lamp Run Time History ............................................................................................................................................................ 10-5
Preset Input Balance ................................................................................................................................................................ 10-5
Change Language .................................................................................................................................................................... 10-5
75 ΩTermination ...................................................................................................................................................................... 10-6
Dimming .................................................................................................................................................................................... 10-6
Lamp Drive Mode ..................................................................................................................................................................... 10-6
I²C Diagnosis ............................................................................................................................................................................ 10-7
OPTIONAL EQUIPMENT ..................................................................................................................................... 11
IR Remote Receiver 800 ............................................................................................................................................................................... 11-1
Hardwired RCU ............................................................................................................................................................................................ 11-1
RCVDS 05 ............................................................................................................................................................................................ 11-1
VS05 Switcher ............................................................................................................................................................................................ 11-1
LCD Projection Control Software for Windows .......................................................................................................................................... 11-2
Adapter and Communication Cables ............................................................................................................................................................ 11-2
STANDARD SOURCE SET UP FILES ................................................................................................................................................................................................................... APPENDIX A-1
SOURCE NUMBER 90 - 99 ................................................................................................................................................................................................................................... APPENDIX A-2
FOCUSING THE LENS .......................................................................................................................................................................................................................................... APPENDIX B-1
LENS CLEANING PROCEDURE ........................................................................................................................................................................................................................... APPENDIX B-2
RCU SOURCE INSERT SLIPS .............................................................................................................................................................................................................................. APPENDIX C-1

1-1
Safety Instructions
5975948A RETRODATA 2100LC 210198
1SAFETY INSTRUCTIONS
WARNING
TO PREVENT FIRE OR ELECTRICAL SHOCK
HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO
RAIN OR MOISTURE
FEDERAL COMMUNICATION COMMISSION (FCC STATEMENT)
This equipment has been tested and found to comply with the limits
of a class A digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial
environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is
likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Note :
The use of shielded cables is required to comply within the limits of
Part 15 of FCC rules and EN55022.
* All the safety and operating instructions should be read before using
this unit.
* The safety and operating instructions manual should be retained for
future reference.
* All warnings on the equipment and in the documentation manuals
should be adhered to.
* All instructions for operating and use of this equipment must be
followed precisely.
On safety
1. This product should be operated from an AC power source.
This projector may be connected to an IT-power system.
Operating AC power voltage of the projector:
Notice on Safety
This equipment is built in accordance with the requirements of the
international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology
equipment including electrical business equipment.
These safety standards impose important requirements on the use
of safety critical components, materials and isolation, in order to
protect the user or operator against risk of electric shock and energy
hazard, and having access to live parts.
Safety standards also impose limits to the internal and external
temperature rises, radiation levels, mechanical stability and strength,
enclosure construction and protection against the risk of fire.
Simulated single fault condition testing ensures the safety of the
equipment to the user even when the equipment's normal operation
fails.
INSTALLATION INSTRUCTIONS
Before operating this equipment please read this manual
thoroughly, and retain it for future reference.
Installation and preliminary adjustments should be
performed by qualified BARCO personnel or by
authorized BARCO service dealers.
OWNERSRECORD
The part number and serial number are located at the back side of the
projector. Record these numbers in the spaces provided below.
Refer to them whenever you call upon your BARCO dealer regarding
this product.
PART NUMBER :
SER. NUMBER :
DEALER :
The lightning flash with an arrowhead within a
triangle is intended to tell the user that parts
inside this product may cause a risk of electrical
shock to persons.
The exclamation point within a triangle is in-
tended to tell the user that important operating
and/or servicing instructions are included in the
technical documentation for this equipment.
2. This product is equipped with a 3-wire grounding plug, a plug
having a third (grounding) pin. This plug will only fit into a grounding-
type power outlet. This is a safety feature. If you are unable to insert
the plug into the outlet, contact your electrician to replace your
obsolete outlet. Do not defeat the purpose of the grounding-type plug.
WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE
GROUNDED (EARTHED) via the supplied 3 conductor AC power
cable.
(If the supplied power cable is not the correct one, consult your
dealer.)
BARCO RETRO DATA 2100LC
Art.No. R9001309 (120V AC)
If you are not sure of the type of AC power available, consult your
dealer or local power company.

1-2
Safety Instructions
5975948A RETRODATA 2100LC 210198
A. Mains lead (Power cord) with CEE 7 plug:
The wires of the mains lead are coloured in
accordance with the following code.
Green and yellow: earth (safety earth)
Blue: neutral
Brown: line (live)
B. Power cord with ANSI 73.11 plug:
The wires of the power cord are coloured in
accordance with the following code.
Green/yellow:ground
White: neutral
Black: line (live)
3. Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.
To disconnect the cord, pull it out by the plug. Never pull the cord itself.
4. If an extension cord is used with this product, make sure that the
total of the ampere ratings on the products plugged into the extension
cord does not exceed the extension cord ampere rating. Also make
sure that the total of all products plugged into the wall outlet does not
exceed 15 amperes.
5. Never push objects of any kind into this product through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in a risk of fire or electrical shock.
Never spill liquid of any kind on the product. Should any liquid or solid
object fall into the cabinet, unplug the set and have it checked by
qualified service personnel before resuming operations.
6. Lightning - For added protection for this video product during a
lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent damage
to the projector due to lightning and AC power-line surges.
On installation
1. Do not place this equipment on an unstable cart, stand, or table.
The product may fall, causing serious damage to it.
2. Do not use this equipment near water.
3. Slots and openings in the cabinet and the back or bottom are
provided for ventilation; to ensure reliable operation of the product
and to protect it from overheating, these openings must not be blocked
or covered. The openings should never be blocked by placing the
product on a bed, sofa, rug, or other similar surface. This product
should never be placed near or over a radiator or heat register.
The projector should not be placed in a built-in installation or enclosure
unless proper ventilation is provided.
4. Do not block the projector cooling fans or free air movement under
and around the projector. Loose papers or other objects may not be
nearer to the projector than 4" on any side.
On servicing
Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage potential and
risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing
to qualified service personnel under the following
conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the equipment.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating
instructions are followed.
Note : Adjust only those controls that are covered by the operating
instructions since improper adjustment of the other controls may
result in damage and will often require extensive work by a qualified
technician to restore the product to normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating
a need for service.
Replacement parts - When replacement parts are required, be
sure the service technician has used original BARCO replacement
parts or authorized replacement parts which have the same char-
acteristics as the BARCO original part. Unauthorized substitutions
may result in degraded performance and reliability, fire, electric shock
or other hazards. Unauthorized substitutions may void warranty.
Safety check - Upon completion of any service or repairs to this
projector, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
On cleaning
Unplug this product from the wall outlet before cleaning. Do
not use liquid cleaners or aerosol cleaners. Use a damp cloth
for cleaning.
- To keep the cabinet looking brand-new, periodically clean it with a
soft cloth. Stubborn stains may be removed with a cloth lightly
dampened with mild detergent solution. Never use strong solvents,
such as thinner or benzine, or abrasive cleaners, since these will
damage the cabinet.
- To ensure the highest optical performance and resolution, the
projection lenses are specially treated with an anti-reflective
coating, therefore, avoid touching the lens. To remove dust on the
lens, use a soft dry cloth. Do not use a damp cloth, detergent
solution, or thinner.
On repacking
Save the original shipping carton and packing material; they will come
in handy if you ever have to ship your equipment. For maximum
protection, repack your set as it was originally packed at the factory.
On illumination
In order to obtain the best quality for the projected image, it is essential
that the ambient light which is allowed to fall on the screen be kept
to an absolute minimum.
When installing the projector and screen, care must be taken to avoid
exposure to ambient light directly on the screen. Avoid adverse
illumination on the screen from direct sunlight or fluorescent lighting
fixtures.
The use of controlled ambient lighting, such as incandescent spot light
or a dimmer, is recommended for proper room illumination. Where
possible, care should also be taken to ensure that the floors and walls
of the room in which the projector is to be installed are non-reflecting,
dark surfaces. Brighter surfaces will tend to reflect and diffuse the
ambient light and hence reduce the contrast of the projected image
on the screen.

2-1
Location and Function of Control
5975948A RETRODATA 2100LC 210198
2
9,'(2,1 $8',2,1%
5*%,1
/5




      

 


     
PRESS HERE
TO OPEN
LOCATION AND FUNCTION OF CONTROLS
Front Control Panel Description and Function
Rear Input Panel Description and Function
RCU Control Panel Description and Function
Gaining access to the front control panel
To reveal the keyboard in the front portion of the retro projector,
push with one finger on the indicated place of the keyboard door.
The door will pivot to the front and the local keyboard and the RCU
will be accessible
Front Control Panel Description & Function
stand-by
pause/park
sharpness
tint
color
brightness
contrast
Front Control Panel Description & function, key diagram :

2-2
Location and Function of Control
5975948A RETRO DATA 2100LC 210198
Rear Input Panel Description & Function
01 Power switch :Main power switch for 'on and off' control..
02 Stby : Stand by button :
- To initiate remote power up operation.
- To stop projection without main power off.
03 Projector Pilot Lamp : indicates the status of the projector.
- Unlit : mains (power) switch is not pressed.
- Lit : mains (power) switch is pressed and the indicated color
shows the projector mode :
Green color : operational mode of the projector.
Red color : stand-by mode of the projector.
04 Digit buttons : Direct input selection.
05 Pause : To blank the image, press PAUSE. The image disap-
pears but full power is retained for immediate restarting.
06 Mute : Press this key to temporarily turn off the sound. To
return to its previous level, press the key once again.
07 Help button : Not active.
08 Text : When adjusting one of the image controls during a
meeting, the displayed bar scale can be removed by pressing 'TEXT'
key first. To re-display the bar scale on the screen, press 'TEXT'
key again. 'TEXT' key is only active in operational mode. When 'TEXT'
is off, no warning message will be displayed.
09 Enter : To start up the adjustment mode or to confirm an
adjustment or selection in the adjustment mode.
10 ADJ. : Adjust key, to enter or exit the adjustment mode.
11 Exit : To leave the adjustment mode or to scroll upwards when
in the adjustment mode.
12 Control disc : To make menu selections when in the adjustment
mode. Also allows to increment or decrement an adjustment in the
adjustment mode.
Control disc up = up arrow in the menus
Control disc down = down arrow in the menus
Control disc to the right = arrow to the right on the menus
Control disc to the left = arrow to the left on the menus
13 Freez : To freeze the projected image at any point.
14 Phase : Used to remove instability of the image.
15 Picture controls : Use these buttons to obtain the desired level
(see also 'Controlling') for each picture function.
16 Sound controls : Use these buttons to obtain the desired
sound level.
17 Mono/Stereo : Not active.
18 Video in 2 : Video input on Cinch (RCA) connector. Allows a
video tape recorder, video camera, color receiver/monitor, etc.
having a video line output to be connected to the projector.
Connected via Port 2 (permanent connection) on the rear panel.
19 Audio in B :audio inputs on 2 Cinch (RCA) connectors for audio
(L-R). Connected via the Audio in B (permanent connection), on the
rear panel of the projector.
20 RGB In 4 : VGA(Sub-D-15) input with standard sync. Con-
nected via 5 BNC connectors to Port 4 (permanent connection) on
the rear panel of projector. The sync can be sync on green,
composite sync or separate sync (H & V.)
21 Remote home : Housing for the IR remote control.
Gaining access to the rear input panel
The rear input panel is accessible only from the rear of the retro
projector. It is contained in the lower portion of the cabinet as
indicated in the following pictures.

2-3
Location and Function of Control
5975948A RETRODATA 2100LC 210198
Rear input panel description & function, key diagram :
$8',2287
$8',2,1& $8',2,1% $8',2,1$
9,'(2
9,'(2
69,'(2
5*%+&9
5*%+&9
/5 /5
/5 /5
,5
55
**
%%
+& +&
99
72/2&$/&21752/21/<
3257
3257
3257
3257
3257
56,1 56287 &2003257 &75/
hard wire remote
2KP:
/5



   



  

   
01 A/C Power Switch : '1' = on, '0' = off. To remain in the '1'
= on position permanently
10 Port 5 : RGB H/C V input : RGB analog input with standard
sync on 5 BNC connectors. The sync can be sync on green,
composite sync, separate sync (H & V) or 3 level sync.
11 Local Control Interface : Input from the front control panel
only. Fixed wire input not to be interchanged.
12 Internal Loud speakers : Connection for the internal loud
speakers left and right side. Fixed wire input not to be interchanged.
13 RS232 IN : To allow communication with external computer,
e.g. IBM PC or compatible, Macintosh ...
14 RS232 OUT : Used to connect to next projector, RS232IN plug
(communication link for PC or MAC to the next projector).
15 Communication port : allows communication with the 800
series peripherals.
16 CTRL : remote input for hard wired remote control.
17 Audio Out : 2 x Cinch (RCA) stereo audio output.
18 Audio select LED's : lit up (next to each audio input) when
AUDIO IN A/B/C or AUDIO OUT are selected.
19 Audio In : 3 audio inputs on 2 Cinch (RCA) connectors for
audio (L-R). Audio 'B' is a fixed wire input not to be interchanged.
20 Lens Mounting : Projected picture output.
21 IR Receiver : IR receiving sensor.
03 IR-Acknowledged : (green LED) IR signals are recognized.
IR-Received : (red LED) IR signals are received without
knowing for which projector.
04 Diagnostics code : a) source number
b) error code : a two digit error code
is displayed when there is a malfunction inside the projector.
05 IR receiver : receiver for control signals transmitted from the
RCU.
06 Port 1 : Video input (composite video) on BNC connector.
Allows a video tape recorder, video camera, color receiver /
monitor, etc. having a video line output to be connected to the
projector.
07 Port 2 : Video input on Cinch (RCA) connector. Allows a
video tape recorder, video camera, color receiver/monitor, etc.
having a video line output to be connected to the projector. Fixed wire
input not to be interchanged.
08 Port 3 : S-Video on 4-pin mini-DIN connector. Separate Y/
C (luma-chroma) signal inputs for higher quality playback of Super
VHS signals.
09 Port 4 : RGB H/C V input : RGB analog input with standard
sync on 5 BNC connectors. The sync can be sync on green,
composite sync or separate sync (H & V.) Fixed wire input not to be
interchanged.
02 A/C Power input : is fixed on 120V A/C
