BARCOPROJECTIONSYSTEMS
Date :
08022000
OWNER'S MANUAL
Rev. :
01
Ciné
7
R9002380-R9002381-R9002382
R9002387-R9002388-R9002389
Art. No. :
R5976066

Due to constant research, the information in this manual is subject to change without notice.
Produced by BARCO NV, February 2000.
All rights reserved.
Trademarks are the rights of their respective owners.
BARCOn.v./ProjectionSystems
Noordlaan5
B-8520Kuurne
Belgium
Tel:[phone]
Fax:[phone]
E-mail : [email protected]
Visite Barco at the web : http://www.barco.com
Printedin Belgium
R9002380 : Ciné 7 230V
R9002381 : Ciné 7 + LIDO 230V
R9002382 : Ciné 7 + LIMO 230V
R9002387 : Ciné 7 + LIMO 120V
R9002388 : Ciné 7 + LIDO 120V
R9002389 : Ciné 7 120V

Tableof Contents
i-1
5976066 BARCOCINE 7 07022000
iTABLE OF CONTENTS
TABLE OF CONTENTS ......................................................................................................I-1
SAFETY INSTRUCTIONS..................................................................................................1-1
Safety Instructions ........................................................................................................................................ 1-1
Notice on Safety............................................................................................................................................ 1-1
installationINSTRUCTIONS.......................................................................................................................... 1-1
OWNER’SRECORD ..................................................................................................................................... 1-1
Safety indication on the product.................................................................................................................... 1-1
SafetyWarning .............................................................................................................................................. 1-2
FEDERALCOMMUNICATIONCOMMISSION(FCCSTATEMENT).............................................................. 1-2
On Safety...................................................................................................................................................... 1-2
Oninstallation ............................................................................................................................................... 1-3
Onservicing .................................................................................................................................................. 1-3
Oncleaning ................................................................................................................................................... 1-3
On repacking ................................................................................................................................................. 1-3
Onillumination............................................................................................................................................... 1-3
CONNECTIONS..................................................................................................................2-1
PowerConnectiontoProjector ...................................................................................................................... 2-1
ACPower (mains) cordconnection ............................................................................................................... 2-1
Switching on/off............................................................................................................................................. 2-1
InputSourceConnection ............................................................................................................................... 2-1
Input facilities................................................................................................................................................ 2-1
Which source to which input.......................................................................................................................... 2-2
Connectinga CompositeVideo source.......................................................................................................... 2-2
Connecting a S-Video or Video source to port 2. .......................................................................................... 2-3
Connecting a RGB Analog source with composite sync. .............................................................................. 2-4
Connecting a RGBAnalog source with Tri-level sync. ................................................................................... 2-5
Connectinga Component source. ................................................................................................................. 2-6
Connectinga ComponentsourcewithTri-levelsync. .................................................................................... 2-7
RS232Connection......................................................................................................................................... 2-7
RS232input andRS232 output of the projector............................................................................................. 2-7
Communicationportforcommunicationwithperipherals .............................................................................. 2-8
Connecting a RCVDS 05 switcher to the projector. ....................................................................................... 2-8
Connecting a VS05 switcher to the projector. ................................................................................................ 2-8
Connectingan IRRemote Receiverto theprojector...................................................................................... 2-8
GETTING STARTED ..........................................................................................................3-1
RemoteControl &LocalKeypad ................................................................................................................... 3-1
Battery Installation in the RCU ...................................................................................................................... 3-1
How to replace the batteries in the RCU ?..................................................................................................... 3-1
GainingAccess to the Local Keypad ............................................................................................................ 3-2
Overview of Functions................................................................................................................................... 3-2
OperatingtheProjector ................................................................................................................................. 3-3
Switchingon.................................................................................................................................................. 3-3
Start up in Operational Mode ........................................................................................................................ 3-4
Start up in Stand by Mode ............................................................................................................................ 3-4
Warning ......................................................................................................................................................... 3-4
RCUCommandsto the Projector .................................................................................................................. 3-4
Pointing the RCU to the reflective screen...................................................................................................... 3-4
Pointing the RCU directly to the IR Sensors.................................................................................................. 3-5
HardwiredRemoteInput ................................................................................................................................ 3-5

Tableof Contents
i-2 5976066 BARCOCINE 7 07022000
Projectoraddress .......................................................................................................................................... 3-5
Why a projector address ?............................................................................................................................. 3-5
Set up an Individual Projector Address ......................................................................................................... 3-5
How to control the projector or projectors ? ................................................................................................... 3-5
Beforeusing theRCU.................................................................................................................................... 3-6
CommonAddress.......................................................................................................................................... 3-6
Display the Projector Address on the Screen................................................................................................ 3-6
Howto programan address intothe RCU? ................................................................................................... 3-6
ControlingtheProjector ................................................................................................................................. 3-6
Input selection modes ................................................................................................................................... 3-6
When the source is selected ......................................................................................................................... 3-7
Picture controls ............................................................................................................................................. 3-7
The Pause key. ............................................................................................................................................. 3-8
TheFreeze key(onlywith line doubler). ........................................................................................................ 3-8
START UP OF THE ADJUSTMENT MODE ......................................................................4-1
AdjustmentMode .......................................................................................................................................... 4-1
Start Up......................................................................................................................................................... 4-1
PossiblePaths............................................................................................................................................... 4-2
MAIN MENU ........................................................................................................................5-1
MainMenu..................................................................................................................................................... 5-1
OverviewFlowchart....................................................................................................................................... 5-1
ImageControl................................................................................................................................................ 5-2
Starting Up .................................................................................................................................................... 5-2
LineDoubler(ifavailable) ..............................................................................................................................5-2
Whyline doubling .......................................................................................................................................... 5-2
Howto enable/disable theLineDoubler......................................................................................................... 5-2
LineMultiplier (ifavailable) ............................................................................................................................5-2
WhyLine Multiplying ..................................................................................................................................... 5-2
How to change the Multiplier Setting ............................................................................................................. 5-3
LineMultiplier ON/OFF.................................................................................................................................. 5-3
MultiplierMode ..............................................................................................................................................5-3
What can be selected within the multiplier mode ? ....................................................................................... 5-3
How to start up the Multiplier Mode menu ?.................................................................................................. 5-3
How to change the scan rate ?...................................................................................................................... 5-4
MotionProcessing.........................................................................................................................................5-4
Why Motion Processing ? ............................................................................................................................. 5-4
How to activate ? .......................................................................................................................................... 5-4
VideoEqualizing............................................................................................................................................5-4
What can be done ? ...................................................................................................................................... 5-4
How to select Video Equalizing ? .................................................................................................................. 5-4
How to adjust the Video Equalizing ? ............................................................................................................ 5-5
NoiseReduction ............................................................................................................................................5-5
What can be done ? ...................................................................................................................................... 5-5
How to select and adjust the Noise Reduction ? ........................................................................................... 5-5
ContrastEnhancement..................................................................................................................................5-5
What can be done ? ...................................................................................................................................... 5-5
How to select and adjust the contrast enhancement ?.................................................................................. 5-5
ColorAdjust................................................................................................................................................... 5-6
What can be done ? ...................................................................................................................................... 5-6
How to select 'Color Adjust' and to select a new color temperature? ........................................................... 5-6
Format Select................................................................................................................................................ 5-6
What can be done ? ...................................................................................................................................... 5-6
How to select a 'Format' ? ............................................................................................................................. 5-6
How to add a name to a 'Format' ? ................................................................................................................ 5-7
How to store the settings to a new 'Format' ?................................................................................................ 5-7
IRIS control ................................................................................................................................................... 5-7
Start Up......................................................................................................................................................... 5-7

Tableof Contents
i-3
5976066 BARCOCINE 7 07022000
Note............................................................................................................................................................... 5-7
IRIS Touch Up...............................................................................................................................................5-7
What can be done ? ...................................................................................................................................... 5-7
How to start up the IRIS Touch Up ? ............................................................................................................. 5-8
IRISAutoConverge ......................................................................................................................................5-8
What can be done ? ...................................................................................................................................... 5-8
How to start up the IRISAuto Converge ? .................................................................................................... 5-8
IRIS Full Alignment .......................................................................................................................................5-8
What can be done ? ...................................................................................................................................... 5-8
How to start up the IRIS Full Alignment ?..................................................................................................... 5-8
SoundControl................................................................................................................................................ 5-9
What can be done ? ...................................................................................................................................... 5-9
How to start up and to select the Sound Control ?........................................................................................ 5-9
Function Keys ............................................................................................................................................... 5-9
What can be done ? ...................................................................................................................................... 5-9
How to get an overview of the programmed keys ?....................................................................................... 5-9
ServiceMenus .............................................................................................................................................. 5-9
What can be done ? ...................................................................................................................................... 5-9
How to enter the Service Menu ? ................................................................................................................ 5-10
ENTERING THE SERVICE MENUS ..................................................................................6-1
Servicemenus .............................................................................................................................................. 6-1
What is available in the Service menus ? ..................................................................................................... 6-1
How to enter the Service Menus ? ................................................................................................................ 6-1
PasswordProtection...................................................................................................................................... 6-1
Enteringthe password................................................................................................................................... 6-2
RANDOM ACCESS ADJUSTMENT MODE......................................................................7-1
Random access adjustment mode. ............................................................................................................... 7-1
Starting Up .................................................................................................................................................... 7-1
OverviewFlowchart....................................................................................................................................... 7-1
Selecting Setup Pattern ................................................................................................................................ 7-2
Set up of the Selected Setup Pattern ? ......................................................................................................... 7-2
Note:.............................................................................................................................................................. 7-2
Internal Cross Hatch Pattern ......................................................................................................................... 7-2
When using the Internal Cross Hatch Pattern ? ............................................................................................ 7-2
FactoryPresetFrequencies........................................................................................................................... 7-2
Random access adjustment mode selection menu....................................................................................... 7-3
What is possible ?......................................................................................................................................... 7-3
PictureTuning ............................................................................................................................................... 7-3
Start up the Picture Tuning ............................................................................................................................ 7-3
ColorBalance................................................................................................................................................7-3
What can be done ? ......................................................................................................................................7-3
How to select the Color Balance ? ................................................................................................................ 7-4
FixedColor Balance ...................................................................................................................................... 7-4
CustomColor Balance. ................................................................................................................................. 7-4
Sync Fast/Slow Adjustment (only inputs 3,4,5,6) .........................................................................................7-5
What can be done ? ...................................................................................................................................... 7-5
How to setup the sync function ?.................................................................................................................. 7-5
Note............................................................................................................................................................... 7-5
Decoding .......................................................................................................................................................7-5
What can be done ? ...................................................................................................................................... 7-5
How to set up ? ............................................................................................................................................. 7-5
Port 2 : Video or S-Video ..............................................................................................................................7-5
What can be done ? ...................................................................................................................................... 7-5
How to configure port 2 ? .............................................................................................................................. 7-5
SwitchingPeaking ON/OFF........................................................................................................................... 7-6
LineDoubler/LineMultiplier ...........................................................................................................................7-6
What can be done ? ...................................................................................................................................... 7-6

Tableof Contents
i-4 5976066 BARCOCINE 7 07022000
How to select when a line doubler is built in ?............................................................................................... 7-6
How to select when a line multiplier is built in ? ............................................................................................ 7-6
Switching themultiplier ON/OFF ................................................................................................................... 7-6
MotionProcessing.........................................................................................................................................7-7
Why Motion Processing ? ............................................................................................................................. 7-7
How to activate ? .......................................................................................................................................... 7-7
OutputMode..................................................................................................................................................7-7
What can be done ? ...................................................................................................................................... 7-7
How to select a new scan rate ? ................................................................................................................... 7-7
VideoEqualizing............................................................................................................................................7-8
What can be done ? ...................................................................................................................................... 7-8
How to select Video Equalizing ? .................................................................................................................. 7-8
How to adjust the Video Equalizing ? ............................................................................................................ 7-8
NoiseReduction ............................................................................................................................................7-8
What can be done ? ...................................................................................................................................... 7-8
How to select and adjust the Noise Reduction ? ........................................................................................... 7-8
ContrastEnhancement..................................................................................................................................7-9
What can be done ? ...................................................................................................................................... 7-9
How to select and adjust the contrast enhancement ?.................................................................................. 7-9
Advanced Settings ........................................................................................................................................7-9
How to select the Advanced Settings ? ........................................................................................................ 7-9
WhyTime Base Correction ?......................................................................................................................... 7-9
How to activate ? .......................................................................................................................................... 7-9
ClampGating .............................................................................................................................................. 7-10
LuminaceDelay........................................................................................................................................... 7-10
Vertical Sync Reference.............................................................................................................................. 7-10
FactoryPreset............................................................................................................................................. 7-11
GeometryAdjustments ............................................................................................................................... 7-11
What can be done ? .................................................................................................................................... 7-11
Start Up....................................................................................................................................................... 7-11
Important..................................................................................................................................................... 7-11
HorizontalPhase Adjustment ...................................................................................................................... 7-12
Start Up....................................................................................................................................................... 7-12
Note............................................................................................................................................................. 7-12
How to adjust ? ........................................................................................................................................... 7-12
Raster Shift Adjustment .............................................................................................................................. 7-12
What has to be done ? ................................................................................................................................ 7-12
CAUTION .................................................................................................................................................... 7-12
Start up ....................................................................................................................................................... 7-12
Note............................................................................................................................................................. 7-13
Warning ....................................................................................................................................................... 7-13
Left-Right(east-west)Adjustments ............................................................................................................. 7-13
What can be adjusted ?............................................................................................................................... 7-13
Start up ....................................................................................................................................................... 7-13
Note............................................................................................................................................................. 7-13
Which adjustment can be executed ? ......................................................................................................... 7-13
How to enter an alignment ?........................................................................................................................ 7-14
Seagullcorrection........................................................................................................................................ 7-15
Top-Bottom(north-south)Adjustments ....................................................................................................... 7-15
What can be adjusted ?............................................................................................................................... 7-15
Start Up....................................................................................................................................................... 7-15
Note............................................................................................................................................................. 7-15
Which adjustment can be executed ? ......................................................................................................... 7-15
How to enter an alignment ?........................................................................................................................ 7-16
Seagullcorrection........................................................................................................................................ 7-16
Size Adjustment.......................................................................................................................................... 7-17
What can be done ? .................................................................................................................................... 7-17
Start up ....................................................................................................................................................... 7-17
Hint.............................................................................................................................................................. 7-17
Blanking Adjustments ................................................................................................................................. 7-18

Tableof Contents
i-5
5976066 BARCOCINE 7 07022000
What can be done ? .................................................................................................................................... 7-18
Start Up....................................................................................................................................................... 7-18
Vertical Linearity Adjustment ...................................................................................................................... 7-18
What can be done ? .................................................................................................................................... 7-18
Start Up....................................................................................................................................................... 7-18
How to adjust the Blanking ?....................................................................................................................... 7-19
ConvergenceAdjustment ............................................................................................................................ 7-20
What has to be done ? ................................................................................................................................ 7-20
Note............................................................................................................................................................. 7-20
Adjustment order ......................................................................................................................................... 7-20
Start up ....................................................................................................................................................... 7-20
How to adjust ? ........................................................................................................................................... 7-20
SERVICE MODE .................................................................................................................8-1
Servicemode. ............................................................................................................................................... 8-1
Start Up......................................................................................................................................................... 8-1
Overviewflowchart........................................................................................................................................ 8-1
ProjectorSet-up ............................................................................................................................................ 8-2
What can be done ? ...................................................................................................................................... 8-2
Start up the Projector Set-Up........................................................................................................................ 8-2
Identification..................................................................................................................................................8-2
What can be seen ? ...................................................................................................................................... 8-2
How to start up ?........................................................................................................................................... 8-3
TotalRun Time..............................................................................................................................................8-3
What can be displayed ? ............................................................................................................................... 8-3
Note............................................................................................................................................................... 8-3
How to start up ?........................................................................................................................................... 8-3
Changepassword ..........................................................................................................................................8-3
What can be done ? ...................................................................................................................................... 8-3
Note............................................................................................................................................................... 8-3
How to select ? ............................................................................................................................................. 8-4
How to enter a new password ?..................................................................................................................... 8-4
ChangeLanguage..........................................................................................................................................8-4
What can be done ? ...................................................................................................................................... 8-4
Howto changethelanguage ? ...................................................................................................................... 8-4
ChangeProjectorAddress.............................................................................................................................8-4
What can be done ? ...................................................................................................................................... 8-4
How to change that address ?....................................................................................................................... 8-5
ChangeBaudrate...........................................................................................................................................8-5
What can be set up ? .................................................................................................................................... 8-5
How to set up ? ............................................................................................................................................. 8-5
Powerupmode .............................................................................................................................................8-5
What can be done ? ...................................................................................................................................... 8-5
How to change the mode ?............................................................................................................................ 8-6
CommonnAddress........................................................................................................................................8-6
What can be done ? ...................................................................................................................................... 8-6
BARCO_logo .................................................................................................................................................8-6
What can be done ? ...................................................................................................................................... 8-6
WARNING ..................................................................................................................................................... 8-6
How to add the BARCO logo ? ...................................................................................................................... 8-6
Memorymanagement.................................................................................................................................... 8-7
What can be done ? ...................................................................................................................................... 8-7
How to select ? ............................................................................................................................................. 8-7
Copy a block .................................................................................................................................................8-7
What can be done ? ...................................................................................................................................... 8-7
How to copy ? ............................................................................................................................................... 8-8
Deletion of blocks.......................................................................................................................................... 8-8
What can be done ? ...................................................................................................................................... 8-8
Deleting block by block .................................................................................................................................8-8

Tableof Contents
i-6 5976066 BARCOCINE 7 07022000
What can be done ? ...................................................................................................................................... 8-8
How to delete a Block ? ................................................................................................................................ 8-8
Deletion of all blocks .....................................................................................................................................8-9
What can be done ? ...................................................................................................................................... 8-9
How to delete all blocks ? ............................................................................................................................. 8-9
All settings to midposition .............................................................................................................................8-9
What can be done ? ...................................................................................................................................... 8-9
How to set to midposition ? ........................................................................................................................... 8-9
Undo all settings to midpos ...........................................................................................................................8-9
What can be done ? ...................................................................................................................................... 8-9
How to cancel 'Set to midposition' ?............................................................................................................ 8-10
R & B convergence mid ..............................................................................................................................8-10
What can be done ? .................................................................................................................................... 8-10
How to set convergence to midposition : .................................................................................................... 8-10
Undo R & B convergence mid .....................................................................................................................8-10
What can be done ? .................................................................................................................................... 8-10
Howto Undo?............................................................................................................................................. 8-10
Undogreenconvergencemid ......................................................................................................................8-11
What can be done ? .................................................................................................................................... 8-11
Howto undo? ............................................................................................................................................. 8-11
Greenconvergencemid ..............................................................................................................................8-11
What can be done ? .................................................................................................................................... 8-11
How to set Green settings to midposition ?................................................................................................. 8-11
CommonSettings........................................................................................................................................ 8-11
What can be done ? .................................................................................................................................... 8-11
How to select ? ........................................................................................................................................... 8-12
G2Adjustment ............................................................................................................................................8-12
CRT run in cycle..........................................................................................................................................8-12
What can be done ? .................................................................................................................................... 8-12
How to select CRT run in cycle ?................................................................................................................ 8-12
Projectorwarmup .......................................................................................................................................8-13
What can be done ? .................................................................................................................................... 8-13
How to select ? ........................................................................................................................................... 8-13
Memorybanks............................................................................................................................................. 8-13
What can be done ? .................................................................................................................................... 8-13
How to select Memory Banks ? .................................................................................................................. 8-13
How to create a new memory bank ? .......................................................................................................... 8-13
How to recall a specific memorybank for the actual source ? ..................................................................... 8-14
I2C Diagnostics ........................................................................................................................................... 8-14
What can be seen ? .................................................................................................................................... 8-14
How to select ? ........................................................................................................................................... 8-14
PROGRAMMABLE FUNCTION KEYS..............................................................................9-1
ProgrammableFunctionKeys ....................................................................................................................... 9-1
What can be done with these keys ............................................................................................................... 9-1
How can a FunctionKey be programmed ? ................................................................................................... 9-1
Which Functions areAvailable ? ................................................................................................................... 9-1
FactoryPredefined Functions........................................................................................................................ 9-2
MESSAGES, WARNINGS AND FAILURES ...................................................................10-1
ADJUSTMENT BLOCKS AND SOURCE NUMBERS 90 - 99 ........................................ A-1
Adjustment Blocks (memory blocks) ............................................................................................................A-1
What are adjustment block ?.........................................................................................................................A-1
Built up of block ............................................................................................................................................A-1
Sourcenumbers 90- 99 ................................................................................................................................A-1
Why used ? ...................................................................................................................................................A-1
How to create a second block ? ....................................................................................................................A-1

Safety Instructions
1-1
5976066 BARCOCINE 7 011299
1SAFETY INSTRUCTIONS
SafetyInstructions
Notice on Safety
This equipment is built in accordance with the requirements of the international safety standards EN60950, UL 1950 and CSA C22.2
No.950, which are the safety standards of information technology equipment including electrical business equipment.
These safety standards impose important requirements on the use of safety critical components, materials and isolation, in order
to protect the user or operator against risk of electric shock and energy hazard, and having access to live parts.
Safety standards also impose limits to the internal and external temperature rises, radiation levels, mechanical stability and strength,
enclosure construction and protection against the risk of fire.
Simulated single fault condition testing ensures the safety of the equipment to the user even when the equipment's normal operation
fails.
INSTALLATION INSTRUCTIONS
Before operating this equipment please read this manual thoroughly, and retain it for future reference.
InstallationandpreliminaryadjustmentsshouldbeperformedbyqualifiedBARCOpersonnelorbyauthorizedBARCOservicedealers.
OWNERS RECORD
The part number and serial number are located at the back side of the projector. Record these numbers in the spaces provided below.
Refer to them whenever you call upon your BARCO dealer regarding this product.
PART NUMBER :
SER. NUMBER :
DEALER :
Safety indication on the product
The lightning flash with an arrowhead within a triangle is intended to tell the user that parts inside this product may
cause a risk of electrical shock to persons.
Theexclamationpointwithinatriangleisintendedtotelltheuserthatimportantoperatingand/orservicinginstructions
are included in the technical documentation for this equipment.

Safety Instructions
1-2 5976066 BARCOCINE 7 011299
Safety Warning
TO PREVENT FIRE OR ELECTRICAL SHOCK HAZARD, DO NOT EXPOSE THIS EQUIPMENT TO RAIN OR MOISTURE
FEDERAL CO UNICATION CO ISSION (FCC STATE ENT)
This equipment has been tested and found to comply with the limits of a class A digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his
own expense.
Note :
The use of shielded cables is required to comply within the limits of Part 15 of FCC rules and EN55022.
* All the safety and operating instructions should be read before using this unit.
* The safety and operating instructions manual should be retained for future reference.
* All warnings on the equipment and in the documentation manuals should be adhered to.
* All instructions for operating and use of this equipment must be followed precisely.
On Safety
1. This product should be operated from an AC power source.
This projector may be connected to an IT-power system.
Operating AC power voltage of the projector:
BARCOCINE 7 Art. No. R9002380/81/82 (
230V AC )
BARCOCINE 7 Art. No. R9002387/88/89 (120V AC)
Consult your dealer to switch over from 230Vac to 120 Vac or from 120Vac to 230 Vac.
If you are not sure of the type of AC power available, consult your dealer or local power company.
2. This product is equipped with a 3-wire grounding plug, a plug having a third (grounding) pin. This plug will only fit into a grounding-
type power outlet. This is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to replace
your obsolete outlet. Do not defeat the purpose of the grounding-type plug.
WARNING FOR THE CUSTOMERS: THIS APPARATUS MUST BE GROUNDED (EARTHED) via the supplied 3 conductor AC
power cable. (If the supplied power cable is not the correct one, consult your dealer.)
A. Mains lead (Power cord) with CEE 7 plug:
The wires of the mains lead are colored in accordance with the following code.
Green and yellow: earth (safety earth)
Blue: neutral
Brown: line (live)
B. Power cord with ANSI 73.11 plug:
The wires of the power cord are colored in accordance with the following code.
Green/yellow: ground
White: neutral
Black: line (live)
3. Do not allow anything to rest on the power cord. Do not locate this product where persons will walk on the cord.
To disconnect the cord, pull it out by the plug. Never pull the cord itself.
4. If an extension cord is used with this product, make sure that the total of the ampere ratings on the products plugged into the
extension cord does not exceed the extension cord ampere rating. Also make sure that the total of all products plugged into the
wall outlet does not exceed 15 amperes.
5. Never push objects of any kind into this product through cabinet slots as they may touch dangerous voltage points or short out
parts that could result in a risk of fire or electrical shock.

Safety Instructions
1-3
5976066 BARCOCINE 7 011299
Neverspillliquid ofany kindon theproduct.Shouldanyliquidorsolidobjectfall intothe cabinet,unplug thesetandhaveitchecked
by qualified service personnel before resuming operations.
6. Lightning - For added protection for this video product during a lightning storm, or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet. This will prevent damage to the projector due to lightning and AC power-line surges.
On installation
1. Do not place this equipment on an unstable cart, stand, or table. The product may fall, causing serious damage to it.
2. Do not use this equipment near water.
3. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure reliable operation of the product
and to protect it from overheating, these openings must not be blocked or covered. The openings should never be blocked by
placing the product on a bed, sofa, rug, or other similar surface. This product should never be placed near or over a radiator
or heat register.
The projector should not be placed in a built-in installation or enclosure unless proper ventilation is provided.
4. Do not block the projector cooling fans or free air movement under and around the projector. Loose papers or other objects
may not be nearer to the projector than 4" on any side.
On servicing
Do not attempt to service this product yourself, as opening or removing covers may expose you to dangerous voltage potentials
and risk of electric shock!
Refer all servicing to qualified service personnel.
Unplug this product from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the equipment.
c.If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating instructions are followed.
Note : Adjust only those controls that are covered by the operating instructions since improper adjustment of the other controls
may result in damage and will often require extensive work by a qualified technician to restore the product to normal operation.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
Replacement parts - When replacement parts are required, be sure the service technician has used original BARCO replacement
parts or authorized replacement parts which have the same characteristics as the BARCO original part. Unauthorized substitutions
may result in degraded performance and reliability, fire, electric shock or other hazards. Unauthorized substitutions may void
warranty.
Safety check - Upon completion of any service or repairs to this projector, ask the service technician to perform safety checks to
determine that the product is in proper operating condition.
On cleaning
Unplugthis product from the wall outlet before cleaning. Do not use liquid cleaners or aerosolcleaners. Use a damp cloth for cleaning.
-To keep the cabinet looking brand-new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth lightly
dampened with mild detergent solution. Never use strong solvents, such as thinner or benzine, or abrasive cleaners, since these
will damage the cabinet.
- Toensurethehighestopticalperformanceandresolution,theprojectionlensesarespeciallytreatedwithananti-reflectivecoating,
therefore, avoid touching the lens. To remove dust on the lens, use a soft dry cloth. Do not use a damp cloth, detergent solution,
or thinner.
On repacking
Savethe original shipping carton and packing material; they will come in handy if you everhave to ship your equipment. For maximum
protection, repack your set as it was originally packed at the factory.
On illumination
In order to obtain the best quality for the projected image, it is essential that the ambient light which is allowed to fall on the screen
be kept to an absolute minimum.
When installing the projector and screen, care must be taken to avoid exposure to ambient light directly on the screen. Avoid adverse
illumination on the screen from direct sunlight or fluorescent lighting fixtures.

Safety Instructions
1-4 5976066 BARCOCINE 7 011299
The use of controlled ambient lighting, such as incandescent spot light or a dimmer, is recommended for proper room illumination.
Where possible, care should also be taken to ensure that the floors and walls of the room in which the projector is to be installed are
non-reflecting, dark surfaces. Brighter surfaces will tend to reflect and diffuse the ambient light and hence reduce the contrast of
the projected image on the screen.

Connections
2-1
5976066 BARCOCINE 7 011299
2CONNECTIONS
Power Connection to Projector
AC Power (mains) cord connection
Use the supplied power cord to connect your projector to the wall outlet. Plug the female power connector into the male connector
at the front of the projector.
Leds on the front pl te of the projector
Switching on/off
The projector is switched ON and OFF using the power (mains) switch ON/OFF.
Pressed : ON
Not pressed : OFF
The projector can start now in the 'operational mode' (image displayed) or in the 'stand by mode', depending on the software setup.
Stand by indication lamp :
no light up : projector in operational mode
red : projector is in stand by.
Input Source Connection
Input facilities
- Composite Video (*)
- S-Video (*)
- RGBS or RGsB (*)
- RGB3S or RG3sB
- (R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) [component input] (**)
- (R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) [component input] (**)
(*) If the line double or line multiplier feature is built in, this feature is available via a software on/off toggle.
(**) If the line double or line multiplier feature is built in, this feature is available for component video signals on standard frequency via software on/off toggle.
OFF ON
Seeinstallation instructions before
connectingtothesupply V NOM 120/230 Volt
I MAX 5/2.5 AMP
FREQ 60/50 Hz
OFF ON
See installat ion instruc tions befor e
connectingto the supply
VN OM 120 /230 Volt
I MAX 5/2.5 AMP
FREQ 60/ 50 Hz
-9V
HOLD DOWN HD
COINC
SF
HOLD DOWN EHT
STANDBY
-CONV
-17V
+17V
+HTHD
+CONV
+9V
+210V
+30V

Connections
2-2 5976066 BARCOCINE 7 011299
Source No Projector input Press digit button
1 Comp. Video 1
2 S-Video* 2
3 RGBS or RGsB** 3
3 RGB3S or RG3sB*** 4
3 (R-Y)Y(B-Y)S or
(R-Y)Ys(B-Y)**** 5
3 (R-Y)Y(B-Y)3S or
(R-Y)Y3s(B-Y)***** 6
Connecting a Composite Video source.
Composite video signals from a VCR, OFF air signal decoder, etc..
Note :
If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active). The video input
signal will be displayed as a non interlaced image (= improved image stability).
To enable or to disable this function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see chapter
'Random access' adjustment mode).
TVtuner, e.g. MARCOPOLO
VCR
Audio amplifier
Composite
video
COMM PORT
(800peripherals) REMOTE RG(S)B SVIDEO S-VIDEO
R-Y Y(S) B-Y
RS232OUTRS232 IN
COMM PORT
(800 peripherals)
REMOTE RG(S)B
S
VIDEO
S-VIDEO
R-Y Y (S) B-Y
RS232 OUTRS232 IN
Which source to which input
* Input signal Y/C (luma/chroma)
** Input signal : R, G and B with composite sync on G or separate composite sync
*** Input signal : R, G and B with Tri level sync on G or separate Tri level sync.
**** Input signal : R-Y, Y and B-Y with composite sync on Y or separate composite sync
***** Input signal : R-Y, Y and B-Y with Tri level sync on Y or separate Tri level sync.

Connections
2-3
5976066 BARCOCINE 7 011299
Input selection
a. with the RCU : press digit button 2 or
b. with the local keypad.
(for access to the local keypad, see 'Local keypad' in chapter 'getting Started'.)
1 press ADJUST key, the General access menu is displayed on the screen (menu 1).
2 use the cursor keys to highlight
2 .
3 press ENTER to display the source.
GENERAL ACCESS
Select with ,
or
then <ENTER>.
<EXIT> to return
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5 6
3 4
1 2
Enter ADJUST
COMMPORT
(800peripherals) REMOTE SVIDEO S-VIDEO
VCR S-VHS Audio amplifier
Luma/Chroma
RG(S) B
R-Y Y(S) B-Y
RS232OUTRS232IN
Video input selection :
a. with the RCU : press digit button 1 or
b. with the local keypad.
(for access to the local keypad, see 'Local keypad' in chapter 'getting Started'.)
1 press ADJUST key, the General access menu is displayed on the screen (menu 1).
2. use the cursor keys to highlight
1 .
3. press ENTER to select the highlighted source.
menu 1
Connecting a S-Video or Video source to port 2.
Separate Y-luma/C-chroma signals for higher quality playback of Super VHS signals.
Note :
If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active). The video input
signal will be displayed as a non interlaced image (= improved image stability).
To enable or to disable this function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see chapter
'Random access' adjustment mode).
GENERAL ACCESS
Select with ,
or
then <ENTER>.
<EXIT> to return
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5 6
3 4
1 2
Enter ADJUST
menu 1

Connections
2-4 5976066 BARCOCINE 7 011299
Connecting a RGB Analog source with composite sync.
RGBanaloginputterminalswithcompositesyncinputorwithsyncongreen. Theprojectordetectsautomaticallywherethesyncsignal
is located.
Note :
If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active). The video input
signal will be displayed as a non interlaced image (= improved image stability).
To enable or to disable this function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see chapter
'Random access' adjustment mode).
Always use an interface when a computer and local monitor have to be connected to the projector.
BARCO's Interface units.
Universal analog interface R9826100
RGB 120 MHz Analog Interface R9826570 (230V)
Multifunctional Analog Interface Kit R9828120 (230V)
(MAGIK) R9828129 (120V)
VGA interface R9828070 (230V)
R9828079 (120V)
MAC interface R9828050 (230V)
R9828059 (120V)
Input Priority setting
Depending on the priority setting in the 'Picture Tuning menu', Video or S-Video can be displayed.
If the setting is not correct, handle as follow :
1 Press ADJUST key to start up the adjustment mode. The main menu will be displayed (menu 1).
2 Select 'Service Menus'.
3 Press ENTER to select.
A warning menu, 'risk of incorrect adjustment', will be displayed (menu 2).
4 Press ENTER to continue if you are qualified, or EXIT if not.
When ENTER is pressed, the 'Adjustment main menu' will be displayed (menu 3).
5 Select 'Random Access'.
6 Press ENTER to select.
The 'Choose a setup pattern menu' will be displayed (menu 4).
7 Select 'Selected source'.
8 Press ENTER to display the 'Random Access' menu (menu 5).
9 Select 'Picture Tuning'.
10 Press ENTER to display the picture tuning menu (menu 6).
11 Select 'Port2 : Video'.
12 Press ENTER to toggle between VIDEO or S-VIDEO.
13 Press ADJUST to return to operational mode.
menu 3
menu 1 menu 4
menu 5
menu 2
menu 6
Select with éor ê
then <ENTER>
<EXIT> to return.
Choose a setup pattern
from below :
SELECTED SOURCE
GENLOCKED PATTERN
INTERNAL # PATTERN
Source 01
WARNING
Risk of incorrect
adjustment of the projector
The following
SERVICE menus
are reserved to,
and to be performed only
by qualified personnel !
If qualified, press
<ENTER> to continue, or
if not, <EXIT> to return.
Select with éor ê
then <ENTER>
<EXIT> to return.
ADJUSTMENTMODE
Select a path from below :
GUIDED
RANDOMACCESS
INSTALLATION
SERVICE
Source 01
Select with éor ê
then <ENTER>
<EXIT> to return.
MAIN MENU
Image Control
IRIS Control
Sound Control
Function keys
Service Menus
Select with éor ê
then <ENTER>
<EXIT> to return.
RANDOMACCESS
ADJUSTMENTMODE
PICTURETUNING
GEOMETRY
CONVERGENCE
COLOR SELECT
Select with éor ê
<ENTER> to accept
<EXIT> to return.
PICTURETUNING
COLOR BALANCE
SYNC : FAST
DECODING : EBU
PORT2 : VIDEO
LINE DOUBLER : ON

Connections
2-5
5976066 BARCOCINE 7 011299
COMM PORT
(800 peripherals) RE MOTE SVIDEO S-VIDEO
5
*
%6
$1$/2*287
,138 7
RG(S) B
R-Y Y(S) B-Y
RS232OUTRS232 IN
menu 1
RGBS or RGsB input selection
a. Press digit button 3 on the RCU or
b. With the local keypad :
(to gain access to the local keypad, see 'Local keypad' in chapter 'getting Started'.)
1. Press ADJUST key, the General access menu is displayed on the screen (menu 1).
2. Use the cursor keys to highlight
3.
3. Press ENTER to display the source.
Connecting a RGB Analog source with Tri-level sync.
RGB analog input terminals with Tri level sync input or with Tri-level sync on green. The projector detects automatically where the
sync signal is located.
COMM PORT
(800 peripherals) RE MOTE SVIDEO S-VIDEO
VCR HDTV player Audio amplifier
RG(S) B
R-Y Y(S) B-Y
RS232OUTRS232 IN
GENERAL ACCESS
Select with ,
or
then <ENTER>.
<EXIT> to return
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5 6
3 4
1 2
Enter ADJUST

Connections
2-6 5976066 BARCOCINE 7 011299
COMM P OR T
(8 00 per iph eral s) REMOTE SVIDEO S-VIDEO
Professional VCR Audio amplifier
RG(S) B
R-Y Y(S) B-Y
RS232 OUT
RS232 IN
RGB3S or RG3sB input selection
a. Press digit button 4 on the RCU or
b. With the local keypad :
(to gain access to the local keypad, see 'Local keypad' in chapter 'getting Started'.)
1. Press ADJUST key, the General access menu is displayed on the screen (menu 1).
2. Use the cursor keys to highlight
4.
3. Press ENTER to display the source.
menu 1
GENERAL ACCESS
Select with ,
or
then <ENTER>.
<EXIT> to return
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5 6
3 4
1 2
Enter ADJUST
Connecting a Component source.
(R-Y)Y(B-Y)analog input terminals with sync input or with sync on the luminance (Y) input. The projector detects automatically where
the sync signal is located.
Line doubling or multipling is possible for component video input sources on standard line frequency.
Note :
If a line doubler or line multiplier is built in, the default position of this line doubler (multiplier) soft option is ON (active). The video input
signal will be displayed as a non interlaced image (= improved image stability).
To enable or to disable this function, enter the adjustment mode and change the position of the ON/OFF toggle switch (see chapter
'Random access' adjustment mode).
(R-Y)Y(B-Y)S or (R-Y)Ys(B-Y) input selection
a. Press digit button 5 on the RCU or
b. With the local keypad :
(to gain access to the local keypad, see 'Local keypad' in chapter 'getting Started'.)
1. Press ADJUST key, the General access menu is displayed on the screen (menu 1).
2. Use the cursor keys to highlight
5.
3. Press ENTER to select the highlighted source.
GENERAL ACCESS
Select with ,
or
then <ENTER>.
<EXIT> to return
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5 6
3 4
1 2
Enter ADJUST

Connections
2-7
5976066 BARCOCINE 7 011299
COMM PORT
(800 peripherals) REMOTE SVIDEO S-VIDEO
Professional VCR
with Tri-level sync Audio amplifier
RG(S) B
R-Y Y(S) B-Y
RS232OUT
RS2 32 IN
Connecting a Component source with Tri-level sync.
(R-Y)Y(B-Y) analog input terminals with Tri-level sync input or with Tri-level sync on the luminance input.
GENERAL ACCESS
Select with ,
or
then <ENTER>.
<EXIT> to return
SHARPNESS
TINT
COLOR
BRIGHTNESS
CONTRAST
5 6
3 4
1 2
Enter ADJUST
(R-Y)Y(B-Y)3S or (R-Y)Y3s(B-Y) input selection
a. Press digit button 6 on the RCU or
b. With the local keypad :
(to gain access to the local keypad, see 'Local keypad' in chapter 'getting Started'.)
1. Press ADJUST key, the General access menu is displayed on the screen (menu 1).
2. Use the control disk to highlight
6.
3. Press ENTER to select the highlighted source.
menu 1
RS232 Connection
RS232 input and RS232 output of the projector.
The projector is equipped with a RS232 port that allows it to communicate with a computer.
56
FRQQHFWLRQ
COMM PORT
(800 pe riph eral s) REMOTE SVIDEO S-V ID EO
RG(S) B
R-Y Y(S) B-Y
RS23 2 OUT
RS232 IN

Connections
2-8 5976066 BARCOCINE 7 011299
Applications
a) remote control:
- easy adjustment of the projector via IBM PC (or compatible) or MAC connection.
- allow storage of multiple projector configurations and set ups.
- wide range of control possibilities.
- address range from 0 to 255.
b) data communications:
- sending data to the projector or copying the data from the projector to a hard memory device.
Set up of the Baud Rate for Communication with a Computer.
See 'Change Baudrate PC' in chapter 'Service mode'
Communication port for communication with peripherals
Connecting a RCVDS 05 switcher to the projector.
- Up to 10 inputs (20 inputs when video and S-video) with the RCVDS 05 switcher and up to 90 inputs when 10 RCVDS switchers
are linked via the expansion modules.
- Serial communication with the projector.
- Remote control buttons on the RCVDS to control the projector (source selection and analog settings)
- The selected source number will be displayed on a 2 digit display and the selected input modules will be indicated with a LED on
the rear.
For more information about the use of the RCVDS 05, consult the Owner's Manual.
Connecting a VS05 switcher to the projector.
The VS05 can switch up to 5 Composite Video sources, 3 S-Video Sources and 1 RGB analog or component Video source to the
projector. In addition, the audio signal proper to the source, can be switched to an audio amplifier.
Order number : R9827890.
For more information about the use of the VS05, consult the Owner's Manual.
Connecting an IR Remote Receiver to the projector.
This infrared receiver unit makes it possible to control the projector from another room.
There is a communication line cable between the IR receiver and the projector or the RCVDS. The control information from the RCU
can now be sent to the IR Remote Receiver.
The IR Remote Receiver displays the selected source on a 7-segment display.
