barfield 1811GA Series Operator's manual

1811HA (SERIES)
PITOT-STATIC TEST SET
1811GA (SERIES) PITOT-STATIC TEST SET
USER INSTRUCTION MANUAL
M/N: 1811HA, P/N: 101-00184-SERIES
M/N: 1811GA, P/N: 101-00185-SERIES
Doc. P/N: 56-101-00184 / 00185
Revision I
September 24, 2014
____________________________________
BARFIELD, INC.
Corporate Headquarters
4101 Northwest 29thStreet
Miami, Florida 33142
www.barfieldinc.com
Email: [email protected]
Copyright © 2014 Barfield Inc. All Rights Reserved.

56-101-00184/00185 Rev. I Safety
September 24, 2014 Page iii
SAFETY INFORMATION
The manufacturer has designed this equipment to be safe when operated using the
procedures detailed in this manual. Do not use this equipment for any other purpose
than that stated.
INPUT POWER (1811HA MODEL ONLY)
100 - 240VAC / 50 - 60 Hz / 60W
FUSE PROTECTION
Operating at 120VAC: 2 fuses (5mm x 20mm), 1A
Operating at 240VAC: 2 fuses (5mm x 20mm), 0.5A
Note: The 1811HA Test Set is shipped with 2 fuses (5mm x 20mm), 1A, installed.
Caution: Always replace blown fuses with properly rated fuses.
OPERATING TEMPERATURE RANGE
0° to 50° C (32° to 122° F)

56-101-00184/00185 Rev. I Contact
September 24, 2014 Page iv
CONTACT INFORMATION
Users are requested to notify the manufacturer of any discrepancy, omission, or error found in
this manual. Inquiries should include specific questions and reference the publication title,
number, chapter, page, figure, paragraph, and effective date.
Please send comments to:
TECHNICAL CUSTOMER SUPPORT - GSTE
BARFIELD, INC.
P.O. BOX 025367
MIAMI, FL 33102-5367
USA
Telephone [phone]
[phone]
Fax [phone]
Email [email protected]

56-101-00184/00185 Rev. I Attention
September 24, 2014 Page v
ATTENTION
Although every effort has been made to provide the end user of this equipment with the most
current and accurate information, it may be necessary to revise this manual in the future. Please
be sure to complete and return the enclosed OWNER WARRANTY REGISTRATION CARD to
Barfield in order to validate the warranty and to ensure that you will receive updated information
when published. You MUST have your name and address on file at Barfield as a registered
user of this equipment, to be able to obtain the service covered by the warranty.
Visit the company website, http://barfieldinc.com/, for publication updates.
Please send the Registration Card to:
Barfield, Inc.
P.O. Box 025367
Miami, FL 33102-5367
USA

56-101-00184/00185 Rev. I Rev.
September 24, 2014 Page vi
REVISION RECORD
REV. ECO # REV. DATE DESCRIPTION OF CHANGE
- N/A August 1, 1997 Initial Release
A N/A January 30, 1998 N/A
B 260-00453 June 4, 1999 Manual revised to show new 1811HA wiring diagram
as per ECO
C
N/A September 2, 2003 Revised to newest format; added section 4 (Valve Leak Test); also, included temporary revision
changes as follows:
- Section 1-1: Part Number Variations DAS650 &
DALT55 indicator descriptions in Table 2
- Part Number for power entry module: 17752
revised to refer to Barfield Sales.
D
260-00698
May 17, 2007
Manual revised to show an additional step in the
Static Pretest procedures (Section 1-3, Page 5):
- (1) Open Crossbleed Valve (#8) fully.
E 260-00746 December 17, 2008
A
numeric code was added at the end of the former
P/Ns, to identify the instruments configuration
supplied with a particular unit. Updated Logo, page
numbering, and format.
F 260-00773 March 26, 2010 Added Safety page to front of manual.
Changed Input power to 100 - 240VAC / 50 - 60Hz /
60W, 400Hz operational but not UL certified, added
Figure 5 for Power Entry Module switch operation, re-
titled Appendix, updated Chapter 5 Inspection
Recommendations, updated chapter 2 specifications.
G 260-00828 March 25, 2011 Updated warranty information; added 12 month
required inspection steps to Table 5.
H 260-00968 April 19, 2013 Updated Inspection Recommendations
I 260-01031 Sept 24, 2014 Updated Barfield logo & warranty information

56-101-00184/00185 Rev. I Info.
September 24, 2014 Page vii
1811 SERIES
PITOT-STATIC TEST SET
INFORMATIONAL LETTER
The Barfield 1811 series Pitot-Static Testers are not advertised for use to comply with
FAR 91.411. The Test Sets do fully meet the requirements of DOT Advisory Circular 43-203B
for performing Altimeter and Static System Tests and Inspections. However, the personnel
requirements and some of the technical aspects of actual testing put a sizeable burden on the
person or persons performing the test.
Barfield advertises its 1811 series Test Sets as general-purpose trouble-shooting testers. With
respect to compliance with FAR 91.411, we feel that the customer should first be aware of all
requirements for performing test tests in the field. With this in mind, Barfield stands ready to
offer advice and assistance to its customers for accomplishing the required tests.
In conclusion, the Barfield 1811 Series Pitot-Static Testers meet the requirements for
compliance with FAR 91.411, but it is important that the customer be sure that the use of the
test set will be in compliance with the regulations.
Please note that a Barfield Altimeter and Static Test Procedure (Document number 60-101-
00150) is available to use in compliance with FAR 91.411.

56-101-00184/00185 Rev. I Maint.
September 24, 2014 Page viii
MAINTENANCE AND REPAIR INFORMATION
The manufacturer of this equipment does not recommend the user to attempt any maintenance
or repair. In case of malfunction, contact the manufacturer, to obtain the list of approved repair
facilities worldwide, ensuring that this equipment will be serviced using proper procedures and
certified instruments. A Return Maintenance Authorization (RMA) number will be assigned
during this call, to keep track of the shipment and the service.
BARFIELD PRODUCT SUPPORT
DIVISION Shipping Address:
Telephone [phone]
[phone]
Fax [phone]
Barfield, Inc.
4101 NW 29th Street
Miami, Florida 33142
USA
Mailing Address:
Barfield, Inc.
P.O. Box 025367
Miami, FL 33102-5367
USA

56-101-00184/00185 Rev. I TOC
September 24, 2014 Page ix
TABLE OF CONTENTS
Safety Information
Contact Information
Attention Page
Revision Record
Informational Letter
Maintenance and Repair Information
Table of Contents
List of Figures and Tables
Page
INTRODUCTION
1. PUBLICATION BREAKDOWN ....................................................................... 1
2. INFORMATION PROVIDED WITH THE UNIT............................................... 1
3. RECERTIFICATION........................................................................................ 3
CHAPTER 1: GENERAL INFORMATION
1. TEST SETS DESCRIPTION........................................................................... 5
2. PHYSICAL DESCRIPTION
A. Carrying Case.......................................................................................... 6
B. Part Number Variations ........................................................................... 6
C. Front Panel............................................................................................... 7
D. Power Information for 1811HA................................................................ 9
CHAPTER 2: SPECIFICATIONS AND CAPABILITIES
1. PHYSICAL DATA......................................................................................11
2. SPECIFICATIONS.....................................................................................11
3. ACCURACY ..............................................................................................11
4. OPERATING TEMPERATURE RANGE ...................................................11
5. PRESSURE/VACUUM SOURCES...........................................................11
6. PNEUMATIC CONNECTIONS..................................................................11
7. INPUT POWER FOR 1811HA...................................................................12
8. FUSE PROTECTION ................................................................................12

56-101-00184/00185 Rev. I TOC
September 24, 2014 Page x
TABLE OF CONTENTS (Continued)
Page
CHAPTER 3: OPERATION
1. THEORY OF OPERATION
A. Pressure/Vacuum Requirements ...........................................................13
B. Control Valve Operation ..........................................................................13
C. Power Supply Circuits..............................................................................14
2. 1811GA PNEUMATIC SCHEMATIC.........................................................14
3. 1811HA PNEUMATIC SCHEMATIC.........................................................15
4. PRELIMINARY
A. General.....................................................................................................16
B. Operation .................................................................................................16
C. Performing the Tests ...............................................................................16
D. Internal Pressure Vacuum Source..........................................................16
5. PRETESTS
A. Pitot Pretest..............................................................................................17
B. Static Pretest............................................................................................17
C. Applying Leak Correction.........................................................................18
D. Instrument Calibration Correction............................................................18
6. PITOT SYSTEM TEST
A. Pitot System Connection .........................................................................18
B. Pitot Leak Test.........................................................................................18
7. STATIC SYSTEM TEST
A. Static System Connection .......................................................................19
B. Static Leak Test for Non-Pressurized Aircraft.........................................20
C. Static Leak Test for Pressurized Aircraft.................................................20
D. Negative Altitude Tests............................................................................21
E. Leak Test .................................................................................................21
F. Vertical Speed Indicator (VSI) Operation................................................22
8. COMBINED PITOT/STATIC TEST
A. Combined Pitot/Static System Connection ............................................23
B. Below Field Elevation Test......................................................................23
C. Above Field Elevation Tests....................................................................24
D. Returning the Pitot/Static Test Set to Ambient.......................................25
9. MACHMETER TEST.................................................................................26
10. ENGINE PRESSURE RATIO (EPR) TEST...............................................27
11. MANIFOLD PRESSURE GAUGE TEST...................................................28
12. LOW PRESSURE TESTS.........................................................................29
13. VACUUM TESTS ......................................................................................30

56-101-00184/00185 Rev. I TOC
September 24, 2014 Page xi
TABLE OF CONTENTS (Continued)
Page
CHAPTER 4: VALVE LEAK TEST
1. METERING VALVE ADJUSTMENT PROCEDURE
A. Valve Leak Test.......................................................................................31
B. Pressure Valve Test ................................................................................31
C. Pressure Vent and Crossbleed Valve Test.............................................31
D. Vacuum Vent Test...................................................................................32
E. Vertical Speed Valve Test.......................................................................32
F. Vacuum Vent Valve Test.........................................................................32
2. RESETTING NEEDLE VALVE POSITIVE STOP......................................33
CHAPTER 5: INSPECTION RECOMMENDATIONS .........................................35
CHAPTER 6: SHIPPING.....................................................................................36
CHAPTER 7: STORAGE....................................................................................37
APPENDIX: ANALOG INSTRUMENTS SPECIFICATIONS ..............................39
Section 1: Altimeter.......................................................................................40
Section 2 Airspeed.......................................................................................46
Section 3: Vertical Speed Indicator...............................................................52

56-101-00184/00185 Rev. I LOFT
September 24, 2014 Page xii
LIST OF FIGURES AND TABLES
Page
Figure 1. Identification Label...............................................................................1
Figure 2. Limited One Year Warranty ................................................................ 3
Figure 3. Overview of 1811GA and 1811HA Test Sets ......................................5
Figure 4. 1811HA/GA Front Panel.....................................................................7
Figure 5. Power Entry Module ............................................................................ 9
Figure 6. 1811GA Pneumatic Schematic Diagram...........................................14
Figure 7. 1811HA Pneumatic Schematic Diagram ........................................... 15
Table 1. Code Numbers for Available Indicators...............................................6
Table 2. 1811GA/HA Front Panel Items........................................................... 7
Table 3. Airspeed vs. Mach number Test Table................................................26
Table 4. Engine Pressure Ratio Test Table.......................................................27
Table 5. Altitude vs. Manifold Pressure.............................................................28
Table 6. Airspeed Equivalent for Differential Pressure/Vacuum.......................29
Table 7. Recommended Inspections.................................................................35

56-101-00184/00185 Rev. I INTRO
September 24, 2014 Page 1 of 56
INTRODUCTION
1. PUBLICATION BREAKDOWN
This instruction manual establishes the operation standards for the 1811HA/GA Pitot-Static
Test Set.
Its purpose is to provide sufficient information for the personnel unfamiliar with this unit to
understand this equipment, identify its parts, and operate it in accordance with proper
procedures, operating techniques, precautions and limitations.
2. INFORMATION PROVIDED WITH THE UNIT
Besides this User Instruction Manual, the 1811HA/GA Test Set is provided with the items
described below.
A. An identification label similar to Figure 1 and located on the front bulkhead of the Test
Set, provides the following information:
Manufacturer Name
Designation of Equipment
Equipment Part Number
Equipment Model Number Equipment Serial Number
Equipment Modification (if applicable) Equipment Options (if applicable)
BF
M/N
ABC
M
L
D
OMN
P/N
H
S
EDFG
OP RQ
OAJ
S/N
TT
E
PCD
H
G
THE USA
MADE IN
K
UJKM
L
459-00024 rev. F
a Sabena technics company
PITOT-STATIC TEST SET
101-00184-635
1811HA
Figure 1 IDENTIFICATION LABEL

56-101-00184/00185 Rev. I INTRO
September 24, 2014 Page 2 of 56
B. Each new or re-certified unit is delivered with a Certificate that shows the date when the
unit was tested by the manufacturer, its serial number, and when the next certification is
due. This certificate confirms that the unit performed according to its design
specifications.
C. The one year limited warranty for this unit (Figure 2).
3. RECERTIFICATION
The Test Sets P/N 101-00184 and P/N 101-00185 have a 6-month recertification period
when analog instruments are installed. However, when digital instruments are installed the
recertification period is typically one year. For complete specifications on digital
instruments, refer to documents 61-101-02184 and 61-101-02194.
It is strongly recommended that the manufacturer, Barfield Inc., service the Test Set. This
will ensure that all applicable engineering change orders are incorporated during the
required maintenance or recertification procedure. Additionally, at this time only Barfield
technicians are qualified to service the digital instruments.
Note: It is important that the customer ensures the Test Set is in compliance with the
Recertification requirement.
Note: If the Test Set is to be used in compliance with F.A.R. 91.170 and Part 43, Appendix
E, "Altimeter System Tests and Inspections," refer to FAA Advisory Circular AC43-6B
(or subsequent) for approved inspection intervals and procedures.

56-101-00184/00185 Rev. I INTRO
September 24, 2014 Page 3 of 56
Figure 2 LIMITED ONE YEAR WARRANTY

56-101-00184/00185 Rev. I Blank
September 24, 2014 Page 4 of 56
THIS PAGE INTENTIONALLY LEFT BLANK

56-101-00184/00185 Rev. I CH. 1
September 24, 2014 Page 5 of 56
CHAPTER 1: GENERAL INFORMATION
1. TEST SETS DESCRIPTION
The BARFIELD INC. 1811HA /GA (Figure 3) is a Pitot-Static Test Set, intended to test
aircraft Pitot and Static Systems for leaks and to test the operation and calibration of
airspeed, altimeter, rate of climb, and other vacuum or low pressure units. The Test Set is a
portable unit enclosed in a fiberglass carrying case.
Note: The pitot and static port adapters fit many aircraft universally but, in some cases, these
adapters are not recommended or are inadequate. Barfield Inc. distributes high quality
custom-made pitot and static adapters for use on all general aviation, airline, helicopter
and military aircraft. Visit our web site at www.barfieldinc.com or contact the Barfield
GSTE – Sales Department at [phone] for more information.
1811HA Test Set (P/N 101-00184-SERIES) 1811GA Test Set (P/N 101-00185-SERIES)
Figure 3 Overview of the Test Sets
The 1811HA
/ GA Test Set is equipped with reference master instruments with
appropriate correction cards. (See Appendixes). Panel mounted hand pumps are
equipped with reservoir tanks to supply pressure and vacuum. Metering valves are
provided for control of all pneumatic functions. Ports are provided for external
connections. The 1811HA model also contains an integral electric pressure / vacuum
pump.

56-101-00184/00185 Rev. I CH. 1
September 24, 2014 Page 6 of 56
2. PHYSICAL DESCRIPTION
A. Carrying Case
The Tester comes with a fiberglass carrying case that contains upper and lower
sections: The lower section supports the panel assembly. The upper section has sliding
pin hinges for easy removal and is fitted with a shelf suitable for storing the manual,
hoses and the power cable.
B. Part Number Variations
There are two basic model numbers: 1811GA which has manually operated pumps, and
the 1811HA, which has all the features of the 1811GA in addition to an internal electrical
pump to supply vacuum or pressure. The three-character code at the end of the part
number identifies the various indicator combinations which are available. The three-
character code at the end of 101-00184-635, for example, specifies the Airspeed
indicator range, Vertical Speed indicator range, and the Altimeter range. The “6”
indicates an Airspeed indicator with a 20-250 knot range. The “3” indicates a Vertical
Speed indicator with a 3000 ft / min range. The “5” indicates an altimeter with a 3
pointer, 35,000 ft, in-Hg / mb Baro Scale. Refer to Table 1 for available indicator
combinations.
Table 1 Code Numbers for Available Indicators
101-00184- 635
AIRSPEED VERTICAL SPEED (CLIMB) ALTIMETER
Code Range Code Range Code Range
1 650 Knots (50 - 650 kts ) 2 2000 ft / min (max.) 2
Precision, Dual
Diaphragm, 3 ptr, 80K ft.
range cal to 55K, in-Hg
baro scale.
4 420 Knots (60 - 420 kts) 3 3000 ft / min (max.) 3 Sensitive, 3 ptr, 50K ft,
in-Hg / mb Baro scale
6 250 Knots (20 - 250 kts) 4 4000 ft / min (max.) 5 Sensitive, 3 ptr, 35K ft,
in-Hg / mb Baro scale
9 Special 6 6000 ft / min (max.) 9 Special
A DAS650, Digital 650 kts 9 Special A DALT55, Digital 55k ft
0 Vert. Speed Indicator
included in DALT55

56-101-00184/00185 Rev. I CH. 1
September 24, 2014 Page 7 of 56
C. Front Panel
Figure 5 identifies the components of the Test Set Front Panel, as listed in Table 2.
Figure 4 1811GA/HA Front Panel
Table 2 1811GA/HA Front Panel Items
ITEM DESIGNATION DESCRIPTION FUNCTION
1 PITOT PORT
1/8-27 NPT Female
Bulkhead Fitting Port for connection to aircraft Pitot
System or other application.
2 - - - - - Airspeed Indicator Monitor differential pressure in terms
of airspeed between pitot and static.
3 VERTICAL SPEED Isolation Needle Valve To isolate and / or control connection
of the vertical speed indicator with the
static side of T/S.
4 - - - - - Vertical Speed
Indicator Monitor rate of change of vacuum
static side of T/S.






  

   

 








 




 
1
2345
6
7
8
9
10
111213
141516
23
25
17
18
19 22
20 21
24

 
a Sabena technics company
aSabena technics company

56-101-00184/00185 Rev. I CH. 1
September 24, 2014 Page 8 of 56
Table 2 1811GA/HA Front Panel Items (Continuation)
ITEM DESIGNATION DESCRIPTION FUNCTION
5 - - - - - Altimeter Monitor pressure altitude at vacuum-
static side of T/S.
6 STATIC PORT
1/8-27 NPT Female
Bulkhead Fitting Port for connection to aircraft Static System or other application
7 STATIC CONTROL Vacuum Source
Needle Valve To control vacuum source.
8 CROSSBLEED
CONTROL Crossbleed Needle Valve To control pressure difference between pitot and static.
9 VACUUM
0-30 Inches of Mercury
Vacuum Gauge Monitor vacuum available in vacuum reservoir tank.
10 STATIC VENT Vacuum Vent
Needle Valve To release vacuum to ambient atmosphere.
11 VACUUM PUMP Hand Operated
Piston Pump Integral vacuum source for all tests.
12 (ALTIMETER) Calibration Card Provides altimeter calibration cor-
rection (Only for Analog Indicators).
13 (HYSTERESIS) Calibration Card Lists altimeter hysteresis (Only for
Analog Indicators)
14 (VERTICAL SPEED) Calibration Card Provides vertical speed calibration
correction (Only for Analog Indicators).
15 (AIRSPEED) Calibration Card Provides airspeed calibration cor-
rection (Only for Analog Indicators).
16 PRESSURE PUMP Hand Operated
Piston Pump Integral pressure source for all tests.
17 PITOT VENT Pressure Vent
Needle Valve To release pressure to ambient atmosphere.
18 PRESSURE 0-30 PSI Pressure
Gauge Monitor pressure available from pressure reservoir tank.
19 PITOT CONTROL Pressure Source
Needle valve To control pressure source
20 ZERO SET Adjusting screw Adjust zero settings
21 BARO WINDOW In-Hg scale Baro reading
22 BARO SET Baro set knob Adjust Baro setting
1811HA ONLY
23 POWER ENTRY
MODULE
IEC Power Line
Connector Provides electrical connection to a
100 – 240VAC, 50 - 60Hz source.
24 Electric Pump Switch Turns pump ON () or OFF (O)
25 Fuses Holder Holds fuses for electrical protection.
