RIDGID seesnake compact2 User manual

WARNING!
Read this manual careful-
ly before using this tool.
Failure to understand and
follow the contents of this
manual may result in elec-
trical shock, fire, and/or se-
rious injury.
Operator’s Manual
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

2 – English
Table of Contents
Introduction
Regulatory Statements ...............................................................................................................................................3
Safety Symbols...........................................................................................................................................................3
General Safety Rules
Work Area Safety........................................................................................................................................................4
Electrical Safety..........................................................................................................................................................4
Personal Safety ..........................................................................................................................................................4
Equipment Use and Care ...........................................................................................................................................5
Pre-Operation Inspection
Specific Safety Information
SeeSnake Compact2 Safety ......................................................................................................................................6
Product Overview
Description .................................................................................................................................................................7
Specifications .............................................................................................................................................................8
Standard Equipment...................................................................................................................................................8
System Components ..................................................................................................................................................8
Operating Instructions
Placement ................................................................................................................................................................ 10
Routing the Camera ................................................................................................................................................. 10
Connecting to a SeeSnake Monitor.......................................................................................................................... 11
Inspection Overview ................................................................................................................................................. 12
Best Practices........................................................................................................................................................... 13
Pipe Guides.............................................................................................................................................................. 14
Locating the Sonde .................................................................................................................................................. 15
Line Tracing the Push Cable ..................................................................................................................................... 16
Retrieving the Camera.............................................................................................................................................. 16
Individual Components
Self-Leveling Camera ............................................................................................................................................... 17
System Cable Assembly ........................................................................................................................................... 17
Docking System........................................................................................................................................................ 18
Maintenance and Support
Maintaining Components..........................................................................................................................................20
Cleaning ...................................................................................................................................................................21
Accessories ..............................................................................................................................................................22
Transport and Storage..............................................................................................................................................22
Service and Repair................................................................................................................................................... 22
Disposal....................................................................................................................................................................22
Troubleshooting ........................................................................................................................................................23
Appendices
Appendix A: Docking Fin Removal............................................................................................................................24
Appendix B: Camera Fault Isolation .........................................................................................................................24
Appendix C: Camera Removal .................................................................................................................................25
Appendix D: Camera Installation ..............................................................................................................................26
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 3
Introduction
The warnings, cautions, and instructions dis-
cussed in this manual cannot cover all possi-
ble conditions and situations that may occur. It
must be understood by the operator that com-
mon sense and caution are factors which cannot
be built into this product, but must be supplied
by the operator.
Regulatory Statements
The EC Declaration of Conformity (890-011-
320.10) will accompany this manual as a sepa-
rate booklet when required.
This device complies with Part 15 of FCC rules.
Operation is subject to the following two condi-
tions: (1) This device may not cause harmful in-
terference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
Safety Symbols
In this manual and on the product, safety symbols and
signal words are used to communicate important safety
information. This section is provided to improve under-
standing of these signal words and symbols.
This is the safety alert symbol. It is used to alert
you to potential injury hazards. Obey all safety
messages that follow this symbol to avoid possi-
ble injury or death.
DANGER
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE
NOTICE indicates information that relates
to the protection of property.
This symbol means read the operator’s manual
carefully before using the equipment. The manu-
al contains important information on the safe
and proper operation of the equipment.
This symbol means always wear safety glasses
with side shields or goggles when handling or
using this equipment to reduce the risk of eye in-
jury.
This symbol indicates the risk of electrical shock.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

4 – English
Personal Safety
• Stay alert, watch what you are doing, and use com-
mon sense when operating equipment. Do not use
equipment while you are tired or under the influence of
drugs, alcohol, or medication. A moment of inattention
while operating equipment may result in serious injury.
• Dress properly. Do not wear loose clothing or jewelry.
Loose clothes, jewelry, and long hair can be caught in
moving parts.
• Practice good hygiene. Use hot, soapy water to wash
hands and other body parts exposed to drain contents
after handling or using drain inspection equipment. To
prevent contamination from toxic or infectious mate-
rial, do not eat or smoke while operating or handling
drain inspection equipment.
• Always use appropriate personal protective equip-
ment when handling and using equipment in
drains. Drains may contain chemicals, bacteria, and
other substances that may be toxic, infectious, and
cause burns or other issues.Appropriate personal pro-
tective equipment always includes safety glasses and
may include a dust mask, hard hat, hearing protection,
drain cleaning gloves or mitts, latex or rubber gloves,
face shields, goggles, protective clothing, respirators,
and steel toed, non-skid footwear.
• If using drain cleaning equipment and drain in-
spection equipment at the same time, wear RIDGID
drain cleaning gloves. Never grasp the rotating drain
cleaning cable with anything else, including other
gloves or a rag which can become wrapped around
the cable and cause hand injuries. Only wear latex
or rubber gloves underneath RIDGID drain cleaner
gloves. Do not use damaged drain cleaning gloves.
General Safety Rules
WARNING
Read all safety warnings and instructions. Failure to
follow the warnings and instructions may result in
electrical shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS!
Work Area Safety
• Keep your work area clean and well lit. Cluttered or
dark areas invite accidents.
• Do not operate equipment in explosive atmo-
spheres, such as in the presence of flammable liq-
uids, gases, or dust. Equipment can create sparks
which may ignite the dust or fumes.
• Keep children and bystanders away while operat-
ing equipment. Distractions can cause you to lose
control.
• Avoid traffic. Pay attention to moving vehicles when
using on or near roadways. Wear high-visibility cloth-
ing or reflector vests.
Electrical Safety
• Avoid body contact with earthed or grounded sur-
faces such as pipes, radiators, ranges, and refrig-
erators. There is an increased risk of electrical shock
if your body is earthed or grounded.
• Do not expose equipment to rain or wet condi-
tions. Water entering equipment will increase the risk
of electrical shock.
• Keep all electrical connections dry and off the
ground. Touching equipment or plugs with wet hands
can increase the risk of electrical shock.
• Do not abuse the cord. Never use the cord for car-
rying, pulling, or unplugging the power tool. Keep cord
away from heat, oil, sharp edges, and moving parts.
Damaged or entangled cords increase the risk of elec-
trical shock.
• If operating equipment that is powered by an AC
adapter in a damp location is unavoidable, use a
ground fault circuit interrupter (GFCI) protected
supply. Use of a GFCI with an AC adapter reduces
the risk of electrical shock.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 5
Equipment Use and Care
• Do not force equipment. Use the correct equipment
for your application. The correct equipment does the
job better and more safely.
• Do not use equipment if the power switch does not
turn it on and off. Any equipment that cannot be con-
trolled with the power switch is dangerous and must
be repaired.
• Disconnect the plug from the power source and/or
the battery pack from the equipment before mak-
ing adjustments, changing accessories, or storing.
Preventive safety measures reduce the risk of injury.
• Store idle equipment out of the reach of children
and do not allow persons unfamiliar with the equip-
ment or these instructions to operate the equip-
ment. Equipment can be dangerous in the hands of
untrained users.
• Maintain equipment. Check for misalignment or bind-
ing of moving parts, missing parts, breakage of parts,
and any other condition that may affect the equip-
ment’s operation. If damaged, have the equipment
repaired before use. Many accidents are caused by
poorly maintained equipment.
• Do not overreach. Keep proper footing and balance
at all times. This enables better control of the equip-
ment in unexpected situations.
• Use the equipment and accessories in accordance
with these instructions; taking into account the
working conditions and the work to be performed.
Use of the equipment for operations different from
those intended can result in hazardous situations.
• Use only accessories that are recommended by
the manufacturer for your equipment. Accessories
that may be suitable for one piece of equipment may
become hazardous when used with other equipment.
• Keep handles dry, clean, and free from oil and
grease. Clean handles give better control of the equip-
ment.
Pre-Operation Inspection
WARNING
To reduce the risk of serious injury from electrical
shock or other causes, and to prevent damage to
your equipment, inspect all equipment and correct
any problems before each use.
To inspect all equipment, follow these steps:
1. Power off your equipment.
2. Disconnect and inspect all cords, cables, and con-
nectors for damage or modification.
3. Clean any dirt, oil, or other contamination from your
equipment to ease inspection and to prevent it from
slipping from your grip during transport or use.
4. Inspect your equipment for any broken, worn, miss-
ing, misaligned, or binding parts, or any other con-
dition which might prevent safe, normal operation.
5. Refer to the instructions for all other equipment to in-
spect and make sure it is in good, usable condition.
6. Check your work area for the following:
• Adequate lighting.
• The presence of flammable liquids, vapors, or
dust that may ignite. If present, do not work in
area until sources have been identified and cor-
rected. The equipment is not explosion proof.
Electrical connections can cause sparks.
• A clear, level, stable, and dry place for the oper-
ator. Do not use the equipment while standing
in water.
7. Examine the job to be done and determine the cor-
rect equipment for the task.
8. Observe the work area and erect barriers as neces-
sary to keep bystanders away.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

6 – English
Specic Safety Information
WARNING
This section contains important safety information
that is specific to the SeeSnake Compact2. Read
these precautions carefully before using the equip-
ment to reduce the risk of electrical shock, fire, and/
or serious injury.
SAVE ALL WARNINGS AND INSTRUCTIONS
FOR FUTURE REFERENCE!
SeeSnake Compact2 Safety
• Read and understand this manual, the digital re-
porting monitor’s manual, and the instructions for
any other equipment you are using before oper-
ating the equipment. Failure to follow all instruction
may result in property damage and/or serious injury.
Keep this manual with the equipment for future use.
• Operating the equipment while in water increas-
es the risk of electrical shock. Do not operate the
Compact2 if operator or equipment are standing in
water.
• The digital reporting monitor’s battery and other
electrical equipment and connections are not wa-
terproof. Do not expose the equipment to wet loca-
tions.
• The equipment is not designed to provide high
voltage protection and isolation. Do not use where
a danger of high voltage contact is present.
• To prevent damage to the Compact2 and to de-
crease the risk of injury, do not expose the
Compact2 to mechanical shocks. Exposure to me-
chanical shocks can damage equipment and increase
the risk of serious injury.
• Do not carry the Compact2 by the monitor’s dock-
ing handle or its front handle when transporting
the system long distances or under conditions
where disengagement of the docking system
would be hazardous. An unexpected disengagement
of the docking system may result in property damage
and/or injury.
• Placing the Compact2 where the drum cannot spin
freely may result in the push cable over-winding
inside the drum. Over-winding the push cable may re-
sult in property damage and/or serious injury. During
operation, place the Compact2 on a stable surface
and make sure the drum can spin freely.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 7
Product Overview
Description
The SeeSnake Compact2 camera reel offers fast, easy
setup and can take on the most diverse and demanding
inspection conditions. The Compact2 features a self-lev-
eling camera at the end of a push cable stiff enough to
give you the power to push through small or restricted
pipes, yet flexible enough to make multiple tight turns.
The Compact2 has a 30m [100ft] long, friction-reducing
push cable and a 25mm [1in] self-leveling camera de-
signed to inspect pipes ranging from 38mm to 152mm
[1.5in to 6in] in diameter, depending on pipe conditions.
Once a point of interest has been found in the pipe, use
the integrated 512Hz sonde and a receiver to locate its
position.
All SeeSnake monitors can connect to the Compact2 with
the SeeSnake system cable. The SeeSnake CS6Pak is
specifically designed to mount on the Compact2’s dock-
ing system for viewing ease, quick setup, and effort-
less transport. You can retrofit the SeeSnake MiniPak to
mount on the docking system with the Docking Handle
Kit, sold separately.
The Compact2’s unique docking system gives you ul-
tra-fast setup. Tilt the CS6Pak to the desired viewing
angle while docked or easily remove it from the dock for
convenient placement in your work area.
The CS6Pak is a compact, portable digital reporting mon-
itor that you can use to capture audio, video, and photos
of your pipe inspections. When you use the CS6Pak with
the Compact2, you can deliver a USB drive containing
an automatically generated professional report of the in-
spection to your customer before leaving the premises.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

8 – English
Specifications
Weight 8kg [17lb]
Overall Dimensions
Length 625mm [25in]
Height 432mm [17in]
Width 360mm [14in]
Drum Diameter 432mm [17in]
Camera
Type Self-leveling
Length 38mm [1.5in]
Diameter 25mm [1in]
Light source 6 LEDs
Sonde 512Hz
Resolution
NTSC 656 × 492 pixels
PA L 768 × 576 pixels
Spring Assembly
Type Single
Length including camera 325mm [12.8in]
Push Cable
Length 30m [100ft]
Diameter 6mm [0.26in]
Fiberglass core diameter 3mm [0.14in]
Minimum bend radius 63mm [2.5in]
Pipe Capacity
§
38mm to 152mm
[1.5in to 6in]
System Cable Length 3m [10ft]
Operating Environment
Temperature ‡ -10°C to 50°C
[14°F to 122°F]
Storage temperature -10°C to 70°C
[14°F to 158°F]
Ingress protection
without monitor IP×5
Relative humidity 5 to 95 percent
Altitude 4,000m [13,120ft]
§ Actual pipe capacity depends on pipe conditions.
‡ While the camera can function in extreme temperatures,
some image quality changes may occur.
Standard Equipment
• SeeSnake Compact2
• Docking System
• Operator’s Manual
•Product Video
• Pipe Guide Kit
•Spanner Wrench
System Components
Cable Wraps
SeeSnake System Cable
Frame
Docking System
SeeSnake System Connector
Frame Handle Drum
Rubber Feet
Serial Number Label
Frame
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 9
Spring Clip
On the outermost push cable guide, press the tab to-
ward the outer edge of the push guide to lock open the
clip and free the camera spring. After the camera spring
is released, return the spring clip to the operation posi-
tion. In the operation position, the spring clip helps guide
the push cable and secures the camera spring when it is
pushed back through the cable guides preventing it from
retracting back into the drum. The spring clip must be
in the operation position during transport to prevent the
camera spring from retracting back into the drum.
Operation Position
Locked Open
Only lock open the spring clip when you are routing the
camera. Keep the spring clip in the operation position
during normal use.
Push Cable Guides
There are three push cable guides on the frame, one
inner guide and two outer guides. When using the
Compact2, the camera, spring, and push cable should
be threaded through all three guides.
Inner Push Cable Guide
Camera Head
Outer Push Cable Guides
Spring Clip
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

10 – English
Operating Instructions
WARNING
Wear appropriate protective equipment such as
latex or rubber gloves, goggles, face shields, and
respirators when inspecting drains that might con-
tain hazardous chemicals or bacteria. Always wear
eye protection to protect against dirt and other for-
eign objects.
Do not operate equipment if operator or equipment
are standing in water. Operating the equipment
while in water increases the risk of electrical shock.
Rubber-soled, non-slip shoes can help prevent slip-
ping and electrical shock on wet surfaces.
Placement
Place the SeeSnake Compact2 and the CS6Pak near
the pipe entrance so you can manipulate the push cable
while viewing the display.
Placing the Compact2 where the drum cannot spin free-
ly may result in the push cable over-winding inside the
drum. Over-winding the push cable may result in proper-
ty damage and/or serious injury. During operation, place
the Compact2 in a stable location and make sure the
drum can spin freely. Do not pull the push cable out of
the drum unless the drum can spin freely.
Routing the Camera
If the camera is inside the drum, you must route the
camera through the push cable guides. The push cable
and camera head should be threaded through all three
guides.
1. Lock open the spring clip.
2. Reach inside the drum and find the camera.
3. Insert the camera through the inner push cable guide
and then through the two outer push cable guides.
4. Return the spring clip to the operation position to se-
cure the spring and prevent the push cable from re-
tracting back into the drum.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 11
Docking System
The Compact2 comes with a docking system assembly
installed so that a compatible monitor can be mounted
onto the reel for easy transport. Tilt the docked monitor
to the desired viewing angle or easily remove it from the
dock for convenient placement in your work area. The
docking system assembly is removable.
Note: Refer to the Docking System section for instruc-
tions on how to mount and remove a compatible monitor.
Docking Fins
Joint Sockets
Quick-Release Knob
Connecting to a SeeSnake Monitor
The Compact2 can connect to any SeeSnake monitor
with the SeeSnake system cable.
1. Unwrap the system cable from the cable wraps.
2. Pull back the outer locking sleeve on the system
cable connector.
3. Align the connector ridge and plastic guide pin with
the socket and push the connector straight in.
4. Tighten the outer locking sleeve.
NOTICE
Only twist the outer locking sleeve. To
prevent damage to the pins, never bend
or twist the connector.
Guide Pin
Connector Ridge
Outer Locking Sleeve
Socket
5. Power on the system:
• Press the Power key to power on the system.
• On a digital reporting monitor, press the Autolog
key to quick-start an inspection.
Note: For some digital reporting monitors, a USB drive
must be inserted to capture media. Refer to the moni-
tor’s manual for more information about the benefits of
Autolog video recordings.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

12 – English
Inspection Overview
The SeeSnake Compact2 can be used for basic
or advanced pipe inspections. To perform a basic
inspection, connect any SeeSnake monitor to the
Compact2, power on the system, push the push
cable through the pipe, and observe the display. An
advanced inspection requires a SeeSnake digital
reporting monitor and additionally involves captur-
ing media and delivering reports to your customer.
1. Place the Compact2 near the pipe entrance.
Make sure the system is stable and the drum
can spin freely.
2. Connect the system cable to the digital report-
ing monitor.
3. Press the Power key to power on the system.
Alternatively, insert a USB drive into the moni-
tor’s USB port and press the Autolog key to
quick-start the inspection.
4. Release the spring clip and, if desired, install a
pipe guide or camera head guide to keep the
camera centered in the pipe. Make sure the
camera lens is clean.
5. Carefully put the camera into the pipe. Protect
the push cable from sharp edges at the pipe
entrance.
6. Push the camera through the pipe and observe
the display.
7. Advanced Options:
• Set the system zero point, or take a tempo-
rary segment distance measurement.
• Capture media.
• Create on-screen custom overlay.
• Locate an inspection point or path.
• Create and deliver an inspection report to
your customer on a USB drive.
8. When the inspection is complete, retrieve the
camera and secure the spring in the spring clip.
Advanced Options
Both basic and advanced pipe inspections can include
taking pipe segment distance measurements, adjusting
the camera’s LED brightness, or activating the sonde.
Depending on your digital reporting monitor’s features,
you may also want to capture media and create reports.
Note: Refer to your digital reporting monitor manual for
instructions on capturing media and creating reports.
• Press the Brightness key to turn up the brightness
of the camera LEDs so you can see further down
the pipe.
• Capture media of the inspection by pressing the
Video key , Autolog key , or Photo key . If you
are using a CS6Pak, you must insert a USB drive
prior to capturing media.
• Press and hold the Zero key for three seconds
to set the system zero point wherever you want to
begin counting from.
• Use a RIDGID SeekTech locating receiver to locate
a point of interest with the integrated 512Hz sonde.
• Use a RIDGID SeekTech locating receiver with a
transmitter to find the path of a pipe by line tracing
the push cable.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 13
Best Practices
Refer to the following tips and recommendations to
perform the pipe inspection with efficiency and ease.
Following these tips can increase the longevity and ef-
fectiveness of your equipment and prevent damage.
• Run water through the pipe during the inspec-
tion to keep the camera system clean, make
pushing the push cable easier, and allow longer
pushes. Place a hose down the pipe or turn on
a fixture. Shut off the water flow as needed for a
clear view.
• Apply a thin film of liquid detergent or soap on the
camera to help keep the lens clear.
• Be careful when inspecting porcelain appliances.
The camera may scratch the surface finish.
• Sharp edges at the pipe entrance can cut, kink,
snag, or damage the push cable. Use extreme care
and always keep one hand near the pipe entrance
when pushing into the pipe to avoid damaging the
push cable.
• Use rubber gripper-type gloves to manipulate the
push cable, improve grip, and keep hands clean.
Use a quick push to pop the camera around a bend
such as a p-trap, tee, Y, or elbow. To pop around a
bend, pull the camera back approximately 200mm
[8in] and thrust it through in one motion. Do not use
more force than is necessary.
• The video image is most stable and clear when mov-
ing the push cable backward in the pipe. When you
have found an area of interest in the pipe, push the
camera beyond it and then pull back.
• Dragging the push cable over sharp edges can dam-
age the push cable. Do not drag the push cable over
sharp edges and do not pull or bend the push cable
at sharp angles at the pipe entrance.
• Some inspection conditions can cause the spring to
fold back so that the camera faces the wrong way.
If the push cable is visible on the display, the spring
has folded over on itself. Pull the push cable back. If
necessary, pull the push cable all the way out of the
pipe and attempt the inspection again.
• To keep the push cable from folding over on itself,
only push short sections through the pipe at a time.
If the push cable folds over on itself, it can snap or
kink.
• Obstructions or excessive build up in the pipe can
damage or prevent retrieval of the camera. Do not
use the camera to clear obstructions.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

14 – English
Pipe Guides
Pipe guides center the camera in the pipe, improve
picture quality, and help keep the lens clear. Use pipe
guides when possible to reduce wear and tear on the
camera system.
Pipe guides can easily be installed, adjusted, and re-
moved to provide better camera and push cable move-
ment in the pipe. For small pipes, tubes, or voids, the
camera head guide helps push the camera through stub-
born fittings. For larger pipes, ball guides center the cam-
era for better visibility and light illumination.
Without Pipe Guide
With Pipe Guide
Camera Head Guide Installation
The 36mm [1.4in] camera head guide can be used in
smaller pipes to push the camera through stubborn fit-
tings.
1. Loosen the screws on both sides of the guide until it
slides easily onto the camera head.
2. Re-secure the screws until the guide stays in place,
but do not over-tighten.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 15
Ball Guide Installation
Ball guides are designed to slip onto the spring and lock
into place. Depending on work conditions, you can place
a ball guide on the spring behind the camera to tilt the
camera head upward to view the top of the pipe.
1. Make sure the ball guide is unlocked.
2. Slide the ball guide beyond the camera on to the
spring.
3. Press down on the blue locks to secure the ball guide
onto the spring.
4. Slide the red locks over the blue locks to secure the
ball guide into place.
Locked Unlocked
NOTICE
If a ball guide gets snagged in a pipe, it
can fall off the spring. To avoid losing
ball guides and obstructing the pipe, do
not use excessive force to push through
the pipe when you feel resistance.
Locating the Sonde
You can use the integrated sonde to locate a point of in-
terest in the pipe at any time during the inspection. The
sonde is located in the spring and is assembled between
the end of the push cable and the camera. The sonde
transmits a locatable 512Hz signal that can be detect-
ed by receivers such as the RIDGID SeekTech SR-20,
SR-24, SR-60, Scout™, or NaviTrack®II.
Press the Sonde key to enable and disable the sonde.
When the sonde is enabled, the LED by the key is lit and
the sonde icon displays on the screen. The 512Hz
sonde signal can cause interference lines that may be
visible on captured media.
To locate the sonde, follow these steps:
1. Power on the receiver and set it to sonde mode.
2. Locate the sonde’s general direction so you know
which way the pipe goes:
• Power on the sonde and push the push cable no
more than 5m [15ft] into the pipe.
• Sweep the horizon with the receiver in a slow
arc.
3. The signal strength is highest where the receiver de-
tects the sonde.
Note: For additional instructions on sonde locating,refer
to the manual for the receiver model you are using.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

16 – English
Line Tracing the Push Cable
You can locate the path of a pipe by line tracing the push
cable. This is especially useful for inspecting non-metal-
lic or non-conductive pipes. Line trace the push cable by
using a tranceiver to induce current onto the push cable
using a transmitter.
To line trace the push cable, follow these steps:
1. Push the transmitter’s ground stake into the ground
and clip one of the transmitter’s leads to it.
2. Clip the other lead to the transmitter clip-on terminal
on the back of the monitor.
3. Power on the transmitter and set your desired fre-
quency. For best results, use frequencies 33 kHz
and higher.
4. Power on the receiver and set it to the same frequen-
cy as the transmitter.
5. Trace the line.
Note: For additional instructions on line tracing, refer to
the manual for the transmitter and receiver models you
are using.
Retrieving the Camera
After completing the inspection, pull the push cable back
out of the pipe with slow, steady force and return it to the
drum. Wipe the push cable with a paper towel or cloth as
you withdraw it. If possible, continue running water down
the pipe to clean the push cable.
To avoid damage to the camera or push cable, do not
exert excessive force during retrieval. If the camera head
is stuck behind a turn, you can pop the camera past the
turn or run water down the pipe to lubricate the push
cable.
NOTICE
Gripping close to the Compact2, always
use short strokes to feed back small
lengths of the push cable into the drum.
Pushing back longer lengths of the push
cable or forcing the push cable may
cause it to loop, kink, or break.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 17
Individual Components
Self-Leveling Camera
The bearings and weight of the self-leveling camera may
create a swinging effect when you push the push cable
through the pipe.The camera image settles quickly when
the push cable is steady.
The self-leveling camera can be removed to trouble-
shoot problems, send for repair, or to replace. Refer to
Appendices C and D for instructions on how to remove
and install the camera head.
System Cable Assembly
The system cable assembly includes the system connec-
tor, for connecting to SeeSnake digital reporting moni-
tors; 3m [10ft] of system cable; and the slip-ring assem-
bly, which is made up of the slip-ring dial and the slip-ring
cavity on the frame.
Before cleaning the Compact2, ensure the slip-ring dial
is locked in the slip-ring cavity. Avoid getting the slip-
ring assembly wet when cleaning.
NOTICE
To avoid damaging the slip-ring contact
pins or getting the internal electrical
components wet, keep the slip-ring as-
sembly locked.
System Cable Removal
1. Disconnect the system cable from the reporting
monitor and remove the monitor from the docking
system.
2. Unwrap the system cable from the cable wraps.
3. Pop the frame cable anchor off the frame and un-
hook the system cable from the frame hook.
Cable Anchor Frame Hook
4. Turn the slip-ring dial counter-clockwise to the un-
locked position .
5. Pull straight out.
NOTICE
Do not touch the contact pins inside the
slip-ring dial. Stressing the contact pins
can cause them to break.
Broken Contact Pin
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

18 – English
Docking System
WARNING
Carrying the system incorrectly can cause the mon-
itor’s docking handle to disengage from the docking
system and may result in property damage and/or
serious injury.
Do not carry the Compact2 by the monitor’s docking
handle or its front handle when transporting the sys-
tem long distances or under conditions where dis-
engagement of the docking system would be haz-
ardous.
The docking system gives you flexibility with its tilt feature
and quick-release knobs. Tilt the digital reporting moni-
tor to any angle for viewing ease or release the CS6Pak
from the docking system with the quick-release knobs
and place it somewhere more convenient.
System Cable Installation
To install the system cable, follow these steps:
1. Align the arrow on the slip-ring dial with the unlock
symbol on the frame and insert the slip-ring dial
into the slip-ring cavity.
2. Turn the slip-ring dial to the locked position .
3. Hook the system cable into the frame hook and snap
the cable anchor onto the frame.
4. Wrap the system cable around the cable wraps.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

English – 19
The SeeSnake CS6Pak is specifically designed to mount
onto the Compact2 and is sold with a compatible docking
handle installed. The Compact2 can also be used with a
retrofitted SeeSnake MiniPak using the Docking Handle
Kit, sold separately.
To make using the setup pictured bottom right most prac-
tical, press the Image Flip key on the CS6Pak for 3
seconds to rotate the user interface. Repeat to return the
screen to its normal viewing mode.
Note: Refer to the Docking Handle Kit for instructions on
how to install the docking handle.
Mounting the Monitor
1. Turn the docking joints on sides of the docking han-
dle so that the openings point down.
Docking Joint
Docking Handle
Front Handle
2. Center the CS6Pak over the docking fins and align
the docking joints with the joint sockets on the dock-
ing fins.
Docking Fins
Joint Sockets
Quick-Release Knob
3. Firmly push the monitor down into the docking sys-
tem until you feel the monitor lock into place.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com

20 – English
Removing the Monitor
1. Place the Compact2 so you can grasp both quick-re-
lease knobs.
2. Pull both knobs out and away from the docking fins.
In the same motion as pulling the knobs out, turn
the knobs together in either direction to disengage
the locks.
Note:The locks are disengaged when the yellow in-
dicator labels are visible under the knobs.
Yellow Indicator Label
3. Grip the docking handle and pull the digital reporting
monitor straight up.
Maintenance and Support
Maintaining Components
Camera Head
The camera head requires little maintenance other than
keeping the LED ring and sapphire window clean. Use
a soft nylon brush, mild detergent, and rags to clean the
camera.
Scraping tools may permanently scratch the camera.
Scratches on the LED ring have a minimal effect on the
camera’s performance.
NOTICE
Do not sand the LED ring to remove scratch-
es. Sanding the LED ring can damage the
watertight housing.
Spring
Stretch the spring end-to-end as far as it allows so you
can visually inspect the inner components. Stir the spring
in lukewarm water and a mild detergent to flush away de-
bris.
Push Cable
Keep the push cable clean. Run a rag over the push
cable as it goes back into the drum after each inspection
to clean it and reduce debris accumulation.
Visually inspect the push cable for cuts and abrasions
while pushing it back into the drum. Replace or repair the
push cable if the outer jacket is cut or abraded.
www.GlobalTestSupply.com
Find Quality Products Online at: sales@GlobalTestSupply.com
