Bartec MC 92N0ex Series User manual

BARTEC GmbH
Contact:
Max-Eyth-Straße 16
Tel.:
[phone]
Service-mobilecomput[email protected]
97980 Bad Mergentheim
Fax:
[phone]
Download:
Germany
www.bartec.de/automation-download
User Manual - TRANSLATION
Mobile Computer
MC 92N0ex Serie
Type 17-A1A3-…./…….
Type B7-A2A.-…./…….
ATEX/IECEx Zone 1
ATEX Zone 2 / 22
UL Class I, II Division 1
UL Class I, II Division 2
UL Class III
ATEX/IECEx Zone 1
Document No.: 11-A1A2-7D0001 / 357929
Status: 12 November 2013 / Revision 0
Subject to technical changes!
Content Page
English 1 - 66

Table of content Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
1.Basic security information 3
1.1Information on this User Manual...................................................................... 3
1.1.1Languages....................................................................................................... 4
1.1.2Changes in the document................................................................................ 4
1.1.3Handling the product ....................................................................................... 4
1.2Intended use.................................................................................................... 4
1.2.1Exclusive purpose ........................................................................................... 4
1.2.2Unintended use ............................................................................................... 4
1.3Duties of the operator...................................................................................... 5
1.4Safety information............................................................................................ 5
1.4.1General safety information .............................................................................. 5
1.5Maintenance.................................................................................................... 5
1.5.1Servicing.......................................................................................................... 5
1.5.2Inspection........................................................................................................ 5
1.5.3Repairs............................................................................................................ 6
1.5.4Commissioning................................................................................................ 6
1.6Protection type, test certificate and standards................................................. 6
1.7Warranty.......................................................................................................... 6
1.8Co-applicable documents – Set of documents ................................................ 8
1.9Configuration................................................................................................... 9
2.Product description 10
2.1Definition MC92N0ex-IS Version .................................................................... 10
2.2Definition MC92N0ex-NI Version.................................................................... 11
2.3Operation....................................................................................................... 12
3.Technical data 13
3.1Explosion protection IS.................................................................................. 13
3.2Explosion protection NI.................................................................................. 14
3.3Other applicable standards............................................................................ 15
3.4Features ........................................................................................................ 16
3.4.1Performance features.................................................................................... 16
3.4.2Physical features ........................................................................................... 16
3.4.3User environment .......................................................................................... 18
3.4.4Application development ............................................................................... 18
3.4.5Voice and data transmission Wireless LAN................................................... 19
3.4.6Voice and data transmission Wireless PAN .................................................. 20
3.4.7Headset......................................................................................................... 20
3.4.8Data Captur Options...................................................................................... 20
3.4.9Decodable barcode types.............................................................................. 23
3.4.10RFID Option .................................................................................................. 24
3.5Battery........................................................................................................... 27
3.6External interfaces......................................................................................... 28
3.7Product labelling............................................................................................ 29
3.8Laser labels ................................................................................................... 31
4.Transport and storage 32
4.1Transport....................................................................................................... 32
4.2Storage.......................................................................................................... 32
5.Commissioning 33
5.1Requirements in potentially explosive atmosphere ....................................... 34
5.2First steps...................................................................................................... 35
5.3Structure........................................................................................................ 35
5.4Handling accessories .................................................................................... 36
5.4.1Insert battery ................................................................................................. 37
5.4.2Change keypad ............................................................................................. 38
5.4.3Insert SD card ............................................................................................... 40
5.4.4Remove/replace screen protector ................................................................. 41

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Table of content
Subject to technical changes.
04/2013
5.4.5Holster and cases.......................................................................................... 42
5.4.6Headset......................................................................................................... 43
6.Operation 44
6.1Final inspection ............................................................................................. 44
6.2Handling ........................................................................................................ 44
6.3Operation recommendations and requirements ............................................ 45
6.3.1Basic safety and health protection requirements........................................... 45
6.3.2Equipment of the laser devices ..................................................................... 48
6.3.3LED Devices.................................................................................................. 48
6.3.4Regulatory information for wireless devices .................................................. 48
6.4Electromagnetic fields ................................................................................... 52
6.4.1International................................................................................................... 52
6.4.2Handheld devices.......................................................................................... 53
6.5Optimise operating times/change energy settings (WEH 6.5.3 only)............. 54
6.5.1Automatic shutdown in the case of lengthy standby periods......................... 54
6.5.2Change display backlight .............................................................................. 54
6.5.3Change keypad background lighting ............................................................ 55
6.5.4Switch off radio connections.......................................................................... 56
6.6Software versions.......................................................................................... 56
6.6.1OEM .............................................................................................................. 56
6.6.2Storage battery.............................................................................................. 57
6.6.3Bluetooth ....................................................................................................... 57
6.6.4“Fusion”software............................................................................................ 58
7.Faults and troubleshooting 59
7.1Resetting the MC92N0ex................................................................................ 59
7.1.1Windows Embedded Handheld and Windows CE Devices........................... 59
7.1.2On a Windows CE 7.0 device........................................................................ 60
7.1.3Warm boot..................................................................................................... 60
7.1.4Cold Boot....................................................................................................... 60
7.1.5On a Windows Embedded Handheld 6.5.3 device ........................................ 61
7.1.6Warm boot..................................................................................................... 61
7.1.7Cold Boot....................................................................................................... 61
7.1.8Clean Boot..................................................................................................... 62
8.Service, inspection, repair 63
8.1Service intervals ............................................................................................ 63
8.2Inspection...................................................................................................... 63
8.3Service and repair work................................................................................. 63
8.3.1Information on sending in for repairs............................................................. 63
9.Disposal 64
10.Forwarding and packaging information 64
11.Accessories 65

Subject to technical changes.
04/2013

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Table of content
Subject to technical changes.
04/2013

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Product description
Subject to technical changes.
04/2013
1. Basic security information
1.1 Information on this User Manual
Read carefully before putting the devices into operation.
The User Manual is a fixed part of the product. It must be kept in the direct vicinity of
the device and the installation, operating and service staff must have access to it at all
times.
The User Manual contains important information, safety instructions and test certificates
which are necessary for the perfect function of the device in operation.
The User Manual is directed at all individuals concerned with the assembly, installation,
commissioning and servicing of the product. The applicable guidelines and standards
for areas with gas and dust atmosphere (99/92/EC, EN 60079-17, EN 60079-19,
IEC 60079-17, IEC 60079-19) must be observed when conducting this work.
Knowledge of the safety and warning information in this User Manual and the strict
compliance with it is essential for safe installation and commissioning. Accidents,
injuries and material damage can be avoided by circumspect handling and
systematically following the instructions.
The figures in this User Manual serve to illustrate the information and descriptions.
They are not necessarily completely transferrable and may differ slightly from the actual
execution of the device.
Safety and warning information is particularly emphasised in this User Manual and
marked by symbols.
DANGER
DANGER describes a directly imminent danger. If not avoided, death or severe injury
will be the consequence.
WARNING
WARNING describes a possibly imminent danger. If not avoided, death or severe
injury may be the consequence.
CAUTION
CAUTION describes a possibly imminent danger. If not avoided, mild or slight injury
may be the consequence.
ATTENTION
ATTENTION describes a possibly damaging situation. If not avoided, the plant or
objects in its vicinity may be damaged.
Important information on effective, economic & environmentally compliant handling.

Product description Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
1.1.1 Languages
The original User Manual is written in German. All other available languages are
translations of the original User Manual.
The User Manual is available in German and English. If further languages are required,
these must be requested from BARTEC or stated on placing an order.
1.1.2 Changes in the document
BARTEC reserves the right to change the content of this document without notification.
No warranty is assumed for the correctness of the information. In cases of doubt, the
German safety instructions apply because it is not possible to rule out errors of translation
or printing. In the case of legal disputes, the “General Terms and Conditions of Business”
of the BARTEC Group also apply.
The current versions of the datasheets, operating instructions, certificates and EC
declarations of conformity can be downloaded from www.bartec.de under Products and
Solutions in the product area “Automation technology” or may be requested directly from
BARTEC GmbH.
1.1.3 Handling the product
The product described in this User Manual left the factory in a perfect and tested state in
terms of safety. To maintain this state and to achieve a perfect and safe operation of this
product, it may only be operated in the manner described by the manufacturer. In
addition, the perfect and safe operation of this product requires correct transportation,
proper storage and careful operation.
The safe and perfect handling of the Mobile Computer is a prerequisite for its perfect and
correct functioning.
1.2 Intended use
1.2.1 Exclusive purpose
The Mobile Computer MC92N0ex is a handheld piece of electrical equipment. It serves the
purpose of the mobile recording, processing and radio transmission of data within
potentially explosive atmospheres.
It is used exclusively in combination with devices which comply with the requirements
placed on the overvoltage category I.
The admissible operating data of the device used must be considered.
1.2.2 Unintended use
Any other use is unintended and may lead to damage and accidents. The manufacturer
shall not be liable for any use extending beyond the exclusive purpose.

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Product description
Subject to technical changes.
04/2013
1.3 Duties of the operator
The operator undertakes to only permit persons to work with the Mobile Computers who
are acquainted with the basic regulations on safety and accident prevention, and who
have been inducted in the use of the Mobile Computer;
have read and understood the documentation, the safety chapter and the warnings.
The operator checks that the safety and accident prevention regulations applicable to the
respective case of use have been observed.
1.4 Safety information
1.4.1 General safety information
Do not dry wipe or clean devices in potentially explosive atmospheres!
Do not open devices in potentially explosive atmospheres.
General statutory provisions or guidelines on occupational health and safety, accident
prevention provisions and environmental protection laws must be heeded, e.g.
Operational Safety Ordinance (BetrSichV) and nationally applicable ordinances.
Use suitable clothing and shoes with respect to the danger of hazardous electrostatic
charges.
Avoid heat influences outside the specified temperature range.
Protect device from external influences! Do not expose device to caustic/aggressive
liquids, vapours or spray. In the case of malfunction or damaged enclosure, remove
the device immediately from the potentially explosive atmosphere and bring it to a
safe place.
1.5 Maintenance
The pertinent erection and operating provisions for electrical systems must be observed!
(e.g. Directive 99/92/EC, Directive 94/9/EC, BetrSichV and nationally applicable
ordinances EN 60079-14 and the series DIN VDE 0100)!
Observe the national waste disposal regulations when disposing of the devices.
1.5.1 Servicing
No constant servicing will be necessary if operated correctly under consideration of the
assembly instructions and environmental conditions. See Chapter “Service, inspection,
repair” in this respect.
1.5.2 Inspection
According to EN 60079-19 and EN 60079-17, the operator of electrical systems in
potentially explosive atmospheres is obliged to have these inspected by an electrician to
ensure correct condition.

Product description Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
1.5.3 Repairs
Repairs to explosion-protected devices may only be performed by authorised personnel
with original spare parts and according to the state of the art. The applicable provisions
must be observed in this respect.
1.5.4 Commissioning
It must be checked that all components and documents are available before
commissioning.
1.6 Protection type, test certificate and standards
Labels on explosion protection and the test certificate are attached to the device. See
Chapter 3 “Technical data” with respect to labelling.
The guidelines and standards applicable to the Mobile Computer for devices and
protected systems for intended use in potentially explosive atmospheres are provided in
Chapter 3 “Technical data”.
1.7 Warranty
WARNING
No changes or retrofits may be made without the written consent of the manufacturer.
If non-specified components are used, the explosion protection will no longer be
guaranteed. In the case of externally procured parts, it is not guaranteed that these
have been designed and manufactured in accordance with their load and requisite
safety.
Contact the manufacturer before any changes or retrofits to receive a release.
Only use original spare and wearing parts.
The manufacturer shall exclusively assume the complete warranty only for spare parts
ordered from him.
Our “General Terms and Conditions of Sale and Delivery” shall apply in principle. These
shall be made available to the operator on signing of contract at the latest. Warranty and
liability claims in the case of injury and damage to property shall be excluded if they are
attributable to one or several of the following causes:

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Product description
Subject to technical changes.
04/2013
Unintended use of the Mobile Computers.
Incorrect assembly, commissioning, operation and servicing.
Failure to observe the information in the User Manual with respect to transport,
storage, assembly, installation, commissioning, operation and service.
Independent structural changes.
Faulty monitoring of parts subject to wear and tear.
Incorrectly performed repairs.
Cases of disaster through the impact of foreign bodies and force majeure.
We grant a warranty period of one year starting from the date of delivery from the Bad
Mergentheim factory on the Mobile Computers and their accessories (exception: battery 6
months). This warranty covers all parts of the delivery and shall be restricted to the free
replacement or repair of the defective parts in our Bad Mergentheim factory. For this
purpose, any packaging supplied must be kept where possible. In the case of warranty,
the goods must be returned to us after written agreement. There shall be no claim to
repair at the sight of erection.
The versions, components, monitors and windows shown in this User Manual are merely
examples and may deviate from the actual display.
The information contained herein refers to the explosion-protected version of series
MC92N0ex.
This User Manual contains all important information on the subject of explosion protection.
The original user manuals and product information of MOTOROLA with information on
handling and commissioning are also available. In the case of overlaps, the information in
this User Manual shall take priority and shall supersede the information from
MOTOROLA.

Product description Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
1.8 Co-applicable documents – Set of documents
BARTEC
User Manual to the Mobile Computer series MC92N0ex – The use of the explosion-
protected version of the Mobile Computer series MC92N0ex is described in this User
Manual.
Technical datasheet for the explosion-protected version of the Mobile Computer
series MC92N0ex – This technical datasheet contains the most important explosion-
relevant technical data as well as general technical data.
MOTOROLA
The set of documentation of the MC9200 contains information on the respective user
requirements and covers the following:
Quick Start Guide for the MC9200 – The commissioning of the Mobile Computer
MC9200 is described in this User Manual.
User Manual for the MC92N0 – The use of the Mobile Computer MC MC9200 is
described in this User Manual.
Integration Manual for the MC9200 – The setting up of the Mobile Computer MC9200
including accessories is described in this User Manual.

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Product description
Subject to technical changes.
04/2013
1.9 Configuration
This Manual refers to the following configurations:
Configuration Ausführung
Wireless WLAN: 802.11 a/b/g/n
WPAN: Bluetooth 2.1 EDR
Optional RFID
options LF 125 KHz / 134 KHz
HF 13,56 MHz
UHF (EU) 865,6 bis 867,5 MHZ
UHF (US) 902 bis 928 MHz
Display 3,7’’ VGA Color Display
Memory 1 GB RAM / 2 GB Flash Memory
Scanner options 1D- Laser Scanner Normal Range
1D- Laser Scanner Long Range
1D- / 2D- Imager
1D- / 2D-Long Range Imager
1D- / 2D- Imager DPM (Direct Part Marking)
Operating system
options Windows WEH 6.5.3
Windows CE 7.0
Keypad options 28 Keypad (Numeric keys can be used direct, Alpha keys and
other key functions can be used via function keys)
43 Keypad (Numeric- and Function keys can be used direct, Alpha
keys and other key functions can be used via function keys)
53 Keypad (Numeric- and Alpha keys cen be used direct, other
key functions can be used via function keys)
53 Keypad with layout for VT Emulation
53 Keypad with layout for 3270 Emulation
53 Keypad with layout for 5250 Emulation
The Emulation software is not part of the device.
Other specific information on the keypad is provided under Technical Data or in the
MOTOROLA documentation.

Product description Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
2. Product description
2.1 Definition MC92N0ex-IS Version
The MC92N0ex-IS Mobile Computer is a robust mobile computer designed for industrial
use and has been specially modified by BARTEC for use in hazardous (potentially
explosive) areas in
ATEX und IECEx Zone 1
UL Class I, II Division 1
UL Class III
This means that the extensive communication and data acquisition options which are
already standard in other areas are available to the user in hazardous areas also.
Its ergonomic design and easy operation make it an ideal support in the attainment of fast
data availability in enterprise processes. Various versions of keypad are available for
manual data capture.
Other data capture options are provided by the integrated 1D or 1D/2D scan engine for
capturing barcodes and various optional RFID readers.
The ergonomically mounted scan triggers on the MC92N0ex-IS allow data to be captured
easily in one-hand operation. Several technologies are available for data communication
with other systems and company divisions.
Wireless LAN (WLAN),
Wireless PAN (WPAN) (Bluetooth)
Ethernet or USB connection through docking station
These modules, which are integrated in the device, allow a seamless transmission of
voice and data into the company’s network.
Other advantages in use are its sturdy construction, easy-to-read 3.7'' VGA colour display
with touch technology and highly efficient lithium-ion battery.
A 1 GHz dual-core processor in the MC92N0ex-IS ensures fast process execution. Easy
application development is facilitated by the two operating systems, Microsoft Windows
WEH 6.5.3 or CE 7.0, in conjunction with the Enterprise Mobility Developer Kits (EMDK)
or RohMobile Suite from Motorola.
1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined
applications and data. For larger applications and volumes of data, BARTEC offers SD
memory cards.

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Product description
Subject to technical changes.
04/2013
2.2 Definition MC92N0ex-NI Version
The MC92N0ex-NI Mobile Computer is a robust mobile computer designed for industrial
use and has been specially modified by BARTEC for use in hazardous (potentially
explosive) areas in
ATEX Zone 2 / 22
UL Class I, II Division 2
UL Class III
This means that the extensive communication and data acquisition options which are
already standard in other areas are available to the user in hazardous areas also.
Its ergonomic design and easy operation make it an ideal support in the attainment of fast
data availability in enterprise processes. Various versions of keypad are available for
manual data capture.
Other data capture options are provided by the integrated 1D or 1D/2D scan engine for
capturing barcodes and various optional RFID readers.
The ergonomically mounted scan triggers on the MC92N0ex-NI allow data to be captured
easily in one-hand operation. Several technologies are available for data communication
with other systems and company divisions.
Wireless LAN (WLAN),
Wireless PAN (WPAN) (Bluetooth)
Ethernet or USB connection through docking station
These modules, which are integrated in the device, allow a seamless transmission of
voice and data into the company’s network.
Other advantages in use are its sturdy construction, easy-to-read 3.7'' VGA colour display
with touch technology and highly efficient lithium-ion battery.
A 1 GHz dual-core processor in the MC92N0ex-NI ensures fast process execution. Easy
application development is facilitated by the two operating systems, Microsoft Windows
WEH 6.5.3 or CE 7.0, in conjunction with the Enterprise Mobility Developer Kits (EMDK)
or RohMobile Suite from Motorola.
1 GB RAM and 2 GB flash memory are integrated in the device for storing user-defined
applications and data. For larger applications and volumes of data, BARTEC offers SD
memory cards.

Product description Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
2.3 Operation
The Mobile Computer MC92N0ex is a handheld electrical device. It serves the purposes of
the mobile entry, processing and radio transmission of data within potentially explosive
atmospheres.
It is used exclusively in combination with devices which comply with the requirements
placed on the overvoltage category I.
The Mobile Computer MC92N0ex–IS, Type 17-A1A.-…./…….. have been modified for
use in the following potentially explosive atmospheres
ATEX/IECEx Zone 1
UL Class I Division 1 Groups C and D
UL Class II Division 1 Groups F and G
UL Class III
ATEX/IECEx Zone 2
UL Class I Division 2 Groups A, B, C and D
UL Class II Division 2 Groups F and G
The Mobile Computer MC92N0ex–IS, Type 17-A1A.-…./…….. may not be used in the
following zones:
ATEX/IECEx Zone 0
ATEX/IECEx Zone 21 / 22
UL Class I Division 1 Groups A and B
UL Class II Division 1 Groups E
UL Class II Division 2 Groups E
The Mobile Computer MC92N0ex–NI, Type B7-A2A.-…./…….. have been modified for
use in the following potentially explosive atmospheres
ATEX Zone 2
ATEX Zone 22
UL Class I Division 2 Groups A, B, C and D
UL Class II Division 2 Groups F and G
UL Class III
The Mobile Computer MC92N0ex–NI, Type B7-A2A.-…./…….. may not be used in the
following zones:
ATEX/IECEx Zone 0 and 1
ATEX/IECEx Zone 21
UL Class I Division 1 Groups A, B, C and D
UL Class II Division 1 Groups E, F and G
UL Class II Division 2 Groups E

Mobile Computer MC 92N0
ex
Type 17-A1A.-………… and Type B7-A2A.-………… Technical data
Subject to technical changes.
04/2013
3. Technical data
3.1 Explosion protection IS
ATEX Zone 1
Typ 17-A1A3-0…/S……
17-A1A3-R…/S……. MC92N0ex-IS MC92N0ex-IS RFID
Ex protection II 2G Ex q [ib] IIC T4 Gb
Type 17-A1A3-R..7/S…….
17-A1A3-R..8/S……. MC92N0ex-IS RFID
Ex protection II 2G Ex q [ib] IIB T4 Gb
Certificate PTB 13 ATEX 2019 X
Standards EN 60079-0:2012
EN 60079-5:2007
EN 60079-11:2012
IECEx Zone 1
Type 17-A1A3-0…/S…….
17-A1A3-R…/S……. MC92N0ex-IS MC92N0ex-IS RFID
Ex protection Ex q [ib] IIC T4 Gb
Type 17-A1A3-R..7/S…….
17-A1A3-R..8/S……. MC92N0ex-IS RFID
Ex protection Ex q [ib] IIB T4 Gb
Certificate IECEx PTB 13.0043X
Standards IEC 60079-0:2011 Edition 6
IEC 60079-5:2007 Edition 3
IEC 60079-11:2011 Edition 6
ATEX and IECEx Directives ATEX 94/9/EC
EMV 2004/108/EC
R&TTE 1999/5/EC
Product labelling 0044
UL Class I Division 1 and UL Class I, II, III Division 1
Type 17-A1A1-0…/S…….
17-A1A1-R…/S……. MC92N0ex-IS MC92N0ex-IS RFID
Ex protection Class I Division 1 Groups C and D
Type 17-A1A2-0…/S……
17-A1A2-R…/S……. MC92N0ex-IS .MC92N0ex-IS RFID
Ex protection Class I Division 1 Groups C and D
Class II Division 1 Groups F and G
Class III
Certificate USA and Canada E226123
Standards USA Standard UL 913, 5 Edition.
Canada National Standard C22.2 Nr. 157-92

Technical data Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
3.2 Explosion protection NI
ATEX Zone 2/22
Type B7-A2A3-0…/S…….
B7-A2A4-0…/S…….
B7-A2A3-R…/S…….
B7-A2A4-R…/S…….
MC92N0ex-NI
MC92N0ex-NI RFID
Ex protection II 3G Ex nA IIC T6 Gc
II 3D Ex tc IIIC T80 °C Dc
-20 °C ≤Ta ≤+50 °C
Certificate B1-A2A3-7C0001
Type B7-A2A3-R..7/S…….
B7-A2A4-R..7/S…….
B7-A2A3-R..8/S…….
B7-A2A4-R..8/S…….
MC92N0ex-NI RFID
Ex protection II 3G Ex nA IIB T6 Gc
II 3D Ex tc IIIB T80 °C Dc
-20 °C ≤Ta ≤+50 °C
Certificate B1-A2A3-7C0002
Standards EN 60079-0:2009
EN 60079-15:2010
EN 60079-31:2009
UL Class I Division 2 and UL Class I, II, III Division 2
Type B7-A2A1-0…/S…….
B7-A2A1-R…/S……. MC92N0ex-NI MC92N0ex-NI RFID
Ex protection Class I Division 2 Groups A, B, C and D
Type B7-A2A2-0…/S…….
B7-A2A4-0…/S…….
B7-A2A2-R…/S…….
B7-A2A4-R…/S…….
MC92N0ex-NI
MC92N0ex-NI RFID
Ex protection Class I Division 2 Groups A, B, C and D
Class II Division 2 Groups F and G
Class III
Certificate USA and Canada E321557
Standards ANSI/ISA 12.12.01, UL 60950,
Canada National Standard C22.2
No. 60950-1-07 2nd edition

Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-………… Technical data
Subject to technical changes.
04/2013
3.3 Other applicable standards
Electrical safety
EN 60950-1 / IEC 60950-1 Setting up of IT safety -
Part 1. General requirements
UL 60950-1
CSA C22.2 No. 60950-1
WLAN / Bluetooth
EN 300 328 Wideband 2.4 GHz Systems
EN 301 893 Broadband Radio Access (5GHz)
FCC Part 15.247
FCC Part 15.407
Canada: RSS-210
RF Exposure (SAR)
EN 62311
Assessment of electronic and electrical
equipment related to human exposure
restrictions for electromagnetic fields (0 Hz - 300
GHz)
EN 50371
Generic standard to demonstrate the compliance
of low-power electronic and electrical apparatus
with the basic restrictions related to human
exposure to electromagnetic fields (10 MHz to
300 GHz)
FCC Part 2
FCC OET Bulletin 65
Supplement C
Canada: RSS-102
EMI/RFI
EN 301 489-1
EMC Tests on Radio and Telecommunications
Terminal Equipment Part 1: Common EMC
Requirements
EN 301 489-17
EMC Tests on Radio Equipment and
Telecommunications Terminal Equipment Part
17: Bluetooth® , WLAN
EN 55022 Class B
Information Technology Equipment – Radio
Disturbance Characteristics - Limits and
Methods of Measurement
EN 55024
Information Technology Equipment – Immunity
Characteristics - Limits and Methods of
Measurement
FCC Part 15
Canada: RSS-210
Canada: ICES 003 Class B
Laser Safety
IEC Class2 / FDA Class II in
Übereinstimmung mit IEC 60825-1
/ EN 60825-1 Laser Safety

Technical data Mobile Computer MC 92N0ex
Type 17-A1A.-………… and Type B7-A2A.-…………
Subject to technical changes.
04/2013
LED Safety
IEC / EN 60825-1 Safety of Laser Products - Part 1: Equipment
Classification and Requirements
IEC / EN 62471 Photobiological Safety of Lamps and Lamp
Systems
3.4 Features
3.4.1 Performance features
CPU Dual-Core 1 GHz OMAP 4430-Prozessor
Operating system Windows Embedded Handheld WEH 6.5.3 or
Windows CE 7.0
Memory 1 GB RAM; 2 GB Flash
Extension slot SD card slot with SDHC support
(up to 32 GB)
Optionally extendable with SD card:
1 GB Order number 17-28BE-F006/0002
2 GB Order number 17-28BE-F006/0003
4 GB Order number 17-28BE-F006/0004
8 GB Order number 17-28BE-F006/0005
16 GB Order number 17-28BE-F006/0006
32 GB Order number 17-28BE-F006/0007
Interfaces RS232
USB
3.4.2 Physical features
Dimensions in mm/inch
Gun:
Gun RFID:
Height x width x depth
231 x 91 x 193 mm 9.1 x 3.6 x 7.6 inch
231 x 115 x 193 mm 9.1 x 4.5 x 7.6 inch
Dimensions in mm/inch
Brick:
Brick RFID:
Height x width x depth
231 x 91 x 59 mm 9.1 x 3.6 x 2.3 inch
231 x 115 x 105 mm 9.1 x 4.5 x 4.1 inch
Weight ATEX/IECEx
(including battery) Gun :
Brick:
Gun RFID:
Brick RFID:
Depends on version and configuration
approx. 1060 g approx. 37 oz
approx. 980 g approx. 34 oz
approx. 1400 g approx. 49 oz
approx. 1320 g approx. 46 oz
Weight UL Division 1
(including battery) Gun :
Brick:
Gun RFID:
Brick RFID:
Depends on version and configuration
approx. 830 g approx. 29 oz
approx. 700 g approx. 24 oz
approx. 1170 g approx. 41 oz
approx. 1040 g approx. 40 oz
Weight UL Division 2 and ATEX
Zone 2/22 (including battery)
Gun :
Brick:
Gun RFID:
Depends on version and configuration
approx. 810 g approx. 26 oz
approx. 680 g approx. 22 oz
approx. 850 g approx. 30 oz
