Bartec Agile S User manual

Tablet PC Agile S
Quick Start Guide

BARTEC GmbH
Max-Eyth-Straße 16
Fon: [phone]
Support:
em[email protected]
97980 Bad Mergentheim
Fax: [phone]
Download:
http://automation.bartec.de
GERMANY
Internet:
www.bartec.com
Quick start guide - Translation
Agile S
10.1" Tablet PC
Type G7-A0B*-****/********
Document No.: G1-A0B0-7E0001
Status: December 2021 / Revision A
Proviso: Subject to technical changes. Changes, mistakes and printing errors do
not substantiate any claim to damages.
Content
Pages
English
1-16

Table of content
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Subject to technical changes.
December 2021 / Revision A
1Basic safety information ...................................................................................................................... 1
1.1 Information on this Quick Start Guide............................................................................... 1
1.1.1 Languages........................................................................................................................ 2
1.1.2 Changes in the document................................................................................................. 2
1.1.3 Registered trademarks ..................................................................................................... 2
1.2 Handling the product ........................................................................................................ 2
1.3 Intended use..................................................................................................................... 3
1.3.1 Exclusive purpose ............................................................................................................ 3
1.3.2 Unintended use ................................................................................................................ 3
1.4 Duties of the operator....................................................................................................... 3
1.5 Safety information............................................................................................................. 3
1.6 Maintenance..................................................................................................................... 4
1.6.1 Servicing........................................................................................................................... 4
1.6.2 Repairs............................................................................................................................. 4
1.6.3 Commissioning................................................................................................................. 4
1.7 Warranty........................................................................................................................... 5
1.8 Co-applicable documents - set of documents................................................................... 6
1.9 Definition of terms............................................................................................................. 6
1.10 Configuration .................................................................................................................... 6
2Product description.............................................................................................................................. 7
2.1 Agile S.............................................................................................................................. 7
2.2 Purpose of use ................................................................................................................. 7
3Technical data....................................................................................................................................... 8
3.1 Applicable standards ........................................................................................................ 8
3.1.1 User environment ............................................................................................................. 8
3.2 Battery.............................................................................................................................. 8
3.3 Product labelling............................................................................................................... 9
4Transport and storage........................................................................................................................ 11
4.1 Transport........................................................................................................................ 11
4.2 Storage........................................................................................................................... 11
5Commissioning................................................................................................................................... 12
5.1 Requirements ................................................................................................................. 12
5.2 First steps....................................................................................................................... 13
5.2.1 Activating peripheral equipment in the utility program.................................................... 13
6Disposal............................................................................................................................................... 14
7Declaration of Conformity.................................................................................................................. 15
7.1 EU Declaration of Conformity ......................................................................................... 15

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Basic safety information
Subject to technical changes.
December 2021 / Revision A
1/16
1Basic safety information
1.1 Information on this Quick Start Guide
Read carefully before putting the devices into operation.
The Quick Start Guide is a fixed part of the product. It must be kept in the direct vicinity of
the device and the installation, operating and service staff must have access to it at all
times.
The Quick Start Guide contains important information and safety instructions which are
necessary for the perfect function of the device in operation.
The Quick Start Guide is directed at all individuals concerned with the commissioning,
handling and servicing of the product.
Knowledge of the safety and warning information in this Quick Start Guide and the strict
compliance with it is essential for safe installation and commissioning. Accidents, injuries
and material damage can be avoided by circumspect handling and systematically
following the instructions.
The examples, tables, and figures provided in this Quick Start Guide are for illustration
purposes. Due to the different requirements of the respective application, the BARTEC
company cannot assume responsibility or liability for actual use based on the examples
and figures.
The BARTEC company reserves the right to carry out technical changes at any time.
In no event will BARTEC company be responsible or liable for indirect or consequential
damages resulting from the use or application of this Quick Start Guide.
Safety and warning information is particularly emphasised in this Quick Start Guide and
marked by symbols.
WARNING
WARNING describes a possibly imminent danger. If not avoided, death or severe injury
may be the consequence.
ATTENTION
ATTENTION describes a possibly damaging situation. If not avoided, the plant or
objects in its vicinity may be damaged.
Important information on effective, economical & environmentally compliant handling.

Basic safety information
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
2/16
Subject to technical changes.
December 2021 / Revision A
1.1.1 Languages
The original Quick Start Guide with safety information is written in German. All other
available languages are translations of the original Quick Start Guide.
The Quick Start Guide is available in German and English. If further languages are required,
these must be requested from BARTEC or stated on placing an order.
1.1.2 Changes in the document
BARTEC reserves the right to change the content of this document without notification. No
warranty is assumed for the correctness of the information. In cases of doubt, the German
safety instructions apply because it is not possible to rule out errors of translation or printing.
In the case of legal disputes, the “General Terms and Conditions of Business” of the
BARTEC Group also apply.
The current versions of the datasheets, user manual, certificates and declarations of
conformity can be downloaded from www.bartec.com or may be requested directly from
BARTEC GmbH.
1.1.3 Registered trademarks
Intel® is a registered trademark of Intel Corporation
Bluetooth® is a registered trademark of Bluetooth Special Interest Group
WINDOWS is a registered trademark of MICROSOFT Corporation
1.2 Handling the product
The product described in this Quick Start Guide left the factory in a perfect and tested state
in terms of safety. To maintain this state and to achieve a perfect and safe operation of this
product, it may only be operated in the manner described by the manufacturer. In addition,
the perfect and safe operation of this product requires correct transportation, proper storage
and careful operation.
The safe and perfect handling of the tablet PC is a prerequisite for its perfect and correct
functioning.

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Basic safety information
Subject to technical changes.
December 2021 / Revision A
3/16
1.3 Intended use
1.3.1 Exclusive purpose
The tablet PC series is a handheld piece of electrical equipment. It serves the purpose of
the mobile recording, processing and/or radio transmission of data.
It is used exclusively in combination with devices which comply with the requirements
placed on the overvoltage category I.
The admissible operating data of the device used must be considered.
1.3.2 Unintended use
Any other use is unintended and may lead to damage and accidents. The manufacturer
shall not be liable for any use extending beyond the exclusive purpose.
1.4 Duties of the operator
The operator undertakes to only permit persons to work with the tablet PC who
are acquainted with the basic regulations on safety and accident prevention, and who
have been inducted in the use of the tablet PC,
have read and understood the documentation, the safety chapter and the warnings.
The operator checks that the safety and accident prevention regulations applicable to the
respective case of use have been observed.
1.5 Safety information
General statutory provisions or guidelines on occupational health and safety, accident
prevention provisions and environmental protection laws must be heeded, e.g.
Operational Safety Ordinance (BetrSichV) and nationally applicable ordinances.
Use suitable clothing and shoes with respect to the danger of hazardous electrostatic
charges.
Avoid heat influences outside the specified temperature range.
Protect device from external influences! Do not expose device to caustic/aggressive
liquids, vapours or spray.

Basic safety information
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
4/16
Subject to technical changes.
December 2021 / Revision A
1.6 Maintenance
The pertinent erection and operating provisions for electrical systems must be observed!
(e.g. Directive 2014/34/EU, BetrSichV and nationally applicable ordinances DIN VDE 0100)
Observe the national waste disposal regulations when disposing of the devices.
1.6.1 Servicing
No constant servicing will be necessary if operated correctly under consideration of the
assembly instructions and environmental conditions.
1.6.2 Repairs
Repairs may only be performed by authorised personnel with original spare parts and
according to the state of the art. The applicable provisions must be observed in this respect.
1.6.3 Commissioning
It must be checked that all components and documents are available before commissioning.

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Basic safety information
Subject to technical changes.
December 2021 / Revision A
5/16
1.7 Warranty
WARNING
No changes or retrofits may be made without the written consent of the
manufacturer.
In the case of externally procured parts, it is not guaranteed that these have been
designed and manufactured in accordance with their load and requisite safety.
Contact the manufacturer before any changes or retrofits to receive a release.
Only use original spare and wearing parts.
The manufacturer shall exclusively assume the complete warranty only for spare parts
ordered from him.
Our “General Terms and Conditions of Sale and Delivery” shall apply in principle. These
shall be made available to the operator on signing of contract at the latest. Warranty and
liability claims in the case of injury and damage to property shall be excluded if they are
attributable to one or several of the following causes:
Unintended use of the tablet PC.
Incorrect handling
Failure to observe the information in the Quick Start Guide and the user manual with
respect to transport, storage, commissioning, operation and service.
Independent structural changes
Faulty monitoring of parts subject to wear and tear.
Incorrectly performed repairs.
Cases of disaster through the impact of foreign bodies and force majeure.
We grant a warranty period of one year starting from the date of delivery from the Bad
Mergentheim factory on the tablet PCs (exception: battery 6 months). The warranty period
for accessories is one year starting from the date of delivery from the Bad Mergentheim
factory. This warranty covers all parts of the delivery and shall be restricted to the free
replacement or repair of the defective parts in our Bad Mergentheim factory. For this
purpose, any packaging supplied must be kept where possible. In the case of warranty, the
goods must be returned to us after written agreement using an RMA form. There shall be
no claim to repair at the sight of erection.

Basic safety information
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
6/16
Subject to technical changes.
December 2021 / Revision A
1.8 Co-applicable documents - set of documents
Data sheet for the Tablet PC Agile S
This technical data sheet contains the most important general technical data.
1.9 Definition of terms
A few abbreviations are used in the documentation.
=
stands for the entire product series
1.10 Configuration
The devices are only supplied with preinstalled operating system.
Customer software or further applications are not contained in the delivery.
This Quick Start Guide refers to the following configurations:
Configuration
Version
Processor
Intel Core i5-7200U Kaby lake 2.5 GHz
(turbo to 3.1 GHz)
Display
10.1" with 1920 x 1200 Pixel resolution
Memory
8 GB
Mass storage
256 GB
Operating system
Windows 10 IoT Enterprise CBB / 64 Bit - MUI (Multilingual)
Windows 10 IoT Enterprise LTSC / 64 Bit - MUI (Multilingual)
WLAN
IEEE 802.11 a/b/g/n/ac
Bluetooth
5.0
WWAN
(optional)
4G/LTE module with European frequencies
and North American frequencies
GPS
u-Blox Neo-M8 with an accuracy of 2.5 m
(prepared for Galileo GPS System)
Scanner Options
(optional)
1D/2D Imager
RFID-Reader
HF/NFC
13.56 MHz
ISO 15693
ISO 14443-A
ISO 18092

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Product description
Subject to technical changes.
December 2021 / Revision A
7/16
2Product description
2.1 Agile S
The Agile S is a tough tablet PC with 10.1" display, which has been designed for use in the
industrial environments.
2.2 Purpose of use
The tablet PCs Agile S are handheld electrical devices. They serve the purpose of entry,
processing and (radio) transmission of data.

Technical data
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
8/16
Subject to technical changes.
December 2021 / Revision A
3Technical data
3.1 Applicable standards
3.1.1 User environment
Operating temperature
-20 °C to +50 °C
(-4 °F to +122 °F)
Charging temperature
0 °C to +45 °C
(+32 °F to +113 °F)
Storage temperature
(without battery)
-30 °C to +70 °C
(-22 °F to +158 °F)
Relative humidity
10 % to 90 % (non-condensing)
Class of protection (IEC 60529)
IP 65
3.2 Battery
The life of the battery will depend on different use factors and the device settings, e.g.:
Use and setting of WLAN/Bluetooth
Background lighting/screensaver
The settings in power management
Use and setting of 1D/2D Imager
Use and setting of 4G/LTE module
Use and setting of RFID module
Use and setting of the camera
Battery
Type G7-A0Z0-0039
Lithium polymer battery
7.4 V / 5140 mAh
Operating temperature
During charging
0 °C to +45 °C
(+32 °F to 113 °F)
During discharging
-20 °C to +50 °C
(-4 °F to 122 °F)
Storage temperature
-20 °C to +50 °C
(-4 °F to 122 °F)
Relative humidity
10 %-90 % (non condensing)
Lifecycle
≥ 300
Battery performance
Up to 8 hours
Battery performance depends on device
settings.
Backup battery with Hot Swap
functions
7.4 V / 330 mAh
Integrated in the device and only replaceable in
the factory.

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Technical data
Subject to technical changes.
December 2021 / Revision A
9/16
3.3 Product labelling
Serial number
RFID
Laser warning
Only for
devices with
integrated
1D/2D Imager
Microsoft
Windows
Licence
Type label
SIM card slot

Technical data
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
10/16
Subject to technical changes.
December 2021 / Revision A
Battery, type G7-A0Z0-0039
Rear side

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Transport and storage
Subject to technical changes.
December 2021 / Revision A
11/16
4Transport and storage
4.1 Transport
Report any transport damage or incomplete deliveries immediately after receipt in writing
to the forwarding company and BARTEC GmbH.
Any damage caused through incorrect storage shall not be covered by the warranty
provisions of BARTEC GmbH.
4.2 Storage
ATTENTION
Property damage through incorrect storage!
Observe storage temperatures.
Keep humidity away from the tablet PC.
Additional information on the batteries
The batteries of BARTEC (type G7-A0Z0-0039) are developed and manufactured in
accordance with the highest industrial standards. The operating time or storage period of a
battery is restricted, however. The actual life of a battery is influenced by different factors,
e.g. hot, cold, rough operating environment and falling from a great height. If a battery is
kept longer than six months, the performance may be impaired on a permanent basis. Keep
the batteries in a dry, cool place. For longer periods of storage, remove the batteries from
the device to prevent self-discharge, rusting of the metallic and the escape of electrolyte.
Batteries kept for a duration of six months or longer should be charged and discharged
again at least every three months. If electrolyte has escaped, do not touch the areas
affected and dispose of the batteries as prescribed. Replace the battery if the operating
time has shortened considerably.
The standard warranty period for all BARTEC batteries is six months, whereby it is irrelevant
whether the battery was acquired separately or was contained in the scope of the delivery
of the tablet PC.

Commissioning
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
12/16
Subject to technical changes.
December 2021 / Revision A
5Commissioning
5.1 Requirements
Tablet PC
The tablet PC may not be opened.
One exception is the cover for the 4G/LTE Module/SIM card for installation.
Do not use, swap or replace and non-specified components.
Do not retrofit any components to the internal plugs or slots. One exception if the
4G/LTE module, the SIM card and the slot for the microSD card.
Protect the tablet PC from impact!
Do not expose the tablet PC to caustic/aggressive liquids, vapours, mists!
Avoid the impact of moisture outside the specifications.
Avoid thermal impact outside the specified temperature range.
Battery
The battery may not be opened.
Only use the battery for the purpose listed in this Quick Start Guide. Is only suitable for
the tablet PC Agile S, Type G7-A0B.-…./………
There is a danger of burning if used incorrectly. Do not expose the battery to
temperatures of more than +60 °C (+140 °F).
Defective batteries must be disposed of immediately, whereby the provisions on battery
disposal applicable in the respective region must be observed.
The battery may explode if it catches fire!
Do not short circuit the battery!
Accessories
User accessories exclusively which have been tested by BARTEC for this purpose.
The end user can replace the 4G/LTE modules, SIM card, microSD card, stylus, hand
strap, leather carry case, shoulder strap and screen protector by himself.

Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
Commissioning
Subject to technical changes.
December 2021 / Revision A
13/16
5.2 First steps
5.2.1 Activating peripheral equipment in the utility program
A utility program is used to control the installed devices, e.g. barcode scanner, RFID reader,
LTE module, touch, etc. The utility program is used to switch the devices on/off.
The utility program is used to switch the devices on/off.
In the settings menu, customer-specific settings can be made for some of the devices
regarding their mode of operation.
Depending on the operating system used, a utility is available for the tablet PC.
Windows®10 IoT Enterprise CBB/SAC
Utility program HotTab
Windows® 10 IoT Enterprise LTSC
Utility program Mobility Center
The utility programs are available on the BARTEC download page as a download with
description at: http://automation.bartec.de/indexE.htm
5.2.1.1 Utility program for Windows 10 IoT Enterprise CBB/SAC - HotTab
The HotTab application offers fast access to the Tablet PC's functions (such as use of a
camera, activating/deactivating installed devices, programming the function key).
The application is already included in the image provided by BARTEC.
5.2.1.2 Utility program for Windows 10 IoT Enterprise LTSC - Mobility Center
The Mobility Center application offers fast access to the Tablet PC's functions (such as use
of a camera, activating/deactivating installed devices, programming the function key).
The application is already included in the image provided by BARTEC.

Disposal
Agile S –10.1" Tablet PC
Type G7-A0B*-****/********
14/16
Subject to technical changes.
December 2021 / Revision A
6Disposal
Tablet pc and accessories contains metallic and plastic parts and electronic components.
WEEE registration number of the BARTEC GmbH:
DE 95940350
TAs professional electrical devices, our devices are intended exclusively for commercial
use, so-called B2B devices, in accordance with the WEEE Directive. The WEEE
Directive provides the framework for the treatment of old electrical equipment throughout
Europe. This means that you may not dispose of these devices in usual household waste
but must dispose of them separately in an environmentally compatible manner and can
also bring them to the collection points of public disposal companies. All products
purchased from us can be returned to us by our customers for disposal. We will ensure
disposal in accordance with the applicable laws. The sender shall bear the costs of
postage and packaging.
