Bartscher VP3000 1R User manual

VP3000 1R
A150685
Original-Gebrauchsanleitung
V2/0418

- 17 -
ENGLISH
Table of contents
1.Safety ........................................................................................................................ 18
1.1 Key to symbols..................................................................................................... 18
1.2 Safety instructions................................................................................................ 19
1.3 Proper use............................................................................................................ 22
2. General information................................................................................................ 23
2.1 Liability and Warrantees....................................................................................... 23
2.2 Copyright protection ............................................................................................. 23
2.3 Declaration of conformity...................................................................................... 23
3. Transport, packaging and storage......................................................................... 24
3.1 Delivery check...................................................................................................... 24
3.2 Packaging............................................................................................................. 24
3.3 Storage................................................................................................................. 24
4. Technical data ......................................................................................................... 25
4.1 Overview of parts ................................................................................................. 25
Control panel.............................................................................................................. 26
4.2 Technical specification ......................................................................................... 26
5. Installation and operation....................................................................................... 27
5.1 Installation............................................................................................................ 27
5.2 Operation.............................................................................................................. 28
6. Cleaning................................................................................................................... 31
7. Waste disposal........................................................................................................ 32
Bartscher GmbH phone: [phone]
Franz-Kleine-Str. 28 fax: [phone]
33154 Salzkotten Service-Hotline: [phone]
Germany www.bartscher.com
GB/UK

- 18 -
Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation and
maintenance of the device and should be consulted as an important source of
information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance or
cleaning.
Please keep these instructions and give them to future owners of the device.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
DANGER!
This symbol highlights hazards which could lead to injury.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.

- 19 -
HOT SURFACE!
This symbol is a warning that the device surface is hot when in use.
Ignoring this warning may result in burns!
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
1.2 Safety instructions
The device is not intended for use by individuals (including
children) with physical or mental disabilities, insufficient
experience, and/or insufficient knowledge unless such persons
are under the care of a person responsible for their safety or
have received instructions regarding appropriate use of the
device.
Children should be observed to ensure that they are not playing
with or starting the device.
Never leave the device unattended when in use.
Only use the device indoors.
The device is not adapted for use with an external timer or
remote control.
The device must be operated in correct and safe technical
condition only. In case of operational problems disconnect the
device from the power supply (pull the plug from the socket)
and contact the service company.

- 20 -
Prevent access of children to the package materials like plastic
bags and foamed polystyrene elements. Suffocation hazard!
Only a qualified technician and using original spare parts and
accessories should carry out repairs and maintenance of the
device. Do not attempt to repair the device yourself.
Do not use any accessory or spare parts that have not been
recommended by the manufacturer. These can be dangerous
for the user or lead to damages of the device or personal injury,
and further, the warranty expires.
To prevent hazards and to ensure optimum efficiency, no
modifications or alterations to the device that are not explicitly
approved by the manufacturer may be undertaken.
DANGER! Electric shock hazard!
To avoid the hazard results please follow the safety instructions
below.
Never allow the power cable to come into contact with heat
sources or sharp edges. The power cable should not hang over
the side of the working surface. Ensure that no one can step on
or trip over the cable.
The power cable must not be folded, bent or tangled, and must
always remain fully unrolled. Never place the device or other
objects on the power cable.
Do not cover the cable. Keep away the cable from operating
range.
Check the power cord regularly for damage. Do not use the
appliance if the power cord is damaged. If this cable is damaged,
it must be replaced by customer service or a qualified electrician
in order to avoid dangers.

- 21 -
The supply cable must be disconnected from the socket
only by pulling the plug.
Never carry or lift the device by the supply cable.
In any case do not open the device housing. In case of
electrical or mechanical modifications the electric shock
hazard will occur.
Never immerse the appliance, the power cord and the power
plug in water or other liquids; do not put it under running water
and clean any parts of the appliance in the in the dishwasher.
Do not use any acid agents and make sure no water ingresses
the device.
Never operate the device with moist hands or standing on wet
floor.
Remove the plug from its socket:
-when the device is not used,
-in case of anomalies during operation,
-before cleaning.
HOT SURFACE! Burn hazard!
Follow the safety instructions listed in order to avoid the hazard:
During the operation, the body of the device and grill plates
become very hot. Do not touch them with bare hands. Use the
service handle to open it. Use appropriate kitchen utensils to
place and remove food products from it.
Also after switching off, the device remains hot for some time.
Before cleaning or moving it to another place wait until the
device cools down first.
Never move the device during the operation.

- 22 -
WARNING! Fire or explosion hazard!
Follow the safety instructions listed in order to avoid the hazard:
To avoid a risk of fire and damaging the device, never place
kitchen utensils, towels, paper etc. on the grill plate.
Never use the device near the flammable materials (e.g.
gasoline, spirits, alcohol, etc.). High temperature may result in
their evaporation leading to the contact with the sources of
combustion. This may result in deflagration leading to the
personal injury and property damage.
When a fire arises unplug the power cord from the socket before
you initiate appropriate measures for fire-fighting. Provide
sufficient supply of fresh air.
Caution: Never extinguish the fire with water when the power
plug is connected to the socket. Electric shock hazard!
1.3 Proper use
The operational safety of the device is assured only in case of proper use, according
to the operation manual.
All technical activities like installation and maintenance must be performed by the
qualified service personnel only.
The contact grill is designed only for grilling and heating appropriate food products.
CAUTION!
Any use going beyond the intended purpose and/or any different use of the
device is forbidden and is not considered as conventional.
Any claims against the manufacturer or his authorized representative as a
consequence of experiencing damages resulting from unconventional use
are impossible.
The operator is liable for all damages resulting from inappropriate use.

- 23 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation
of the device, and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
-violation of advice concerning operation and cleaning;
-use other than designed;
-alterations made by user;
-use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations is
copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.

- 24 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
If you liked to dispose the packing, consider the regulations applicable
in your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-do not store outdoors,
-keep it dry and dust-free,
-do not expose it to aggressive media,
-do not expose it to direct sunlight,
-avoid mechanical shocks and vibration,
-in case of longer storage (> 3 months) make sure you check the state
of the packaging and the parts regularly, if required refresh or renew.

- 25 -
4. Technical data
4.1 Overview of parts
1
Thermal insulator handle
2
Upper grill plate
3
Lower grill plate
4
Control panel
5
Feet
6
Body
7
Ventilation holes
8
Fat collecting pan
9
Fat drip spout
10
Height adjustment screw
2
1
4
3
8
7
6
9
5
10

- 26 -
Control panel
11
Heating indicator (green)
12
Temperature control knob
13
ON/OFF indicator (red)
14
Heating power control knob
4.2 Technical specification
Name
Contact grill VP3000 1R
Code-no.:
A150685
Material:
Body: stainless steel; grill plates: cast iron
Design:
corrugated grill surface, W 330 x D 300 mm
limit stop of the upper plate is adjustable
for different types of food
heating indicator
ON/OFF indicator
fat collecting pan
Power:
3.0 kW / 230 V 50/60 Hz
Temperature range:
from 100 °C to 300 °C
Dimensions:
W 470 x D 380 x H 240 mm
Weight:
26 kg
We reserve the right to make technical changes!
12
11
14
13

- 27 -
5. Installation and operation
5.1 Installation
Positioning
Unpack the device and remove all packing material.
Remove the protective foil form the device. If there are any glue residues on the
device, remove them using appropriate solvent.
Screw the supplied feet into the appropriate holes.
CAUTION!
Never remove the rating plate and any warning signs from the device.
Place the device on top of an even, stable, dry, and water-resistant surface which
supports the weight of the device and is not heat sensitive.
Never place the device in humid or wet environment.
Never place the device on the flammable surfaces.
Never place the device near flammable and combustible materials.
The surface on which the device is placed must be easily accessible and sufficiently
large. To enable easy operation of the device and ensure proper air circulation, leave
the space of at least 50 cm at the back and on the sides of the device and 50 cm
from the top of it.
Set up the appliance device in such manner that the plug is accessible, so that the
appliance can be quickly disconnected from the power network if necessary.
Connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid
specification should be compared with that of the device
(see rating plate). Connect the device only in case of
compliance!
The power supply circuit with the socket must be protected by the fuse of at least
16A. Connect the device directly to a single grounded socket. Do not use any power
bar or multiple socket.

- 28 -
5.2 Operation
Prepare the device
Before the first use, clean the device thoroughly according to the instructions
included in section 6 „Cleaning“.
Mount the fat collecting pan on the left side of the lower grill plate. The pan is used
for collecting vegetable and animal fat dripping from the device during grilling.
CAUTION!
Never use the device without the properly mounted fat collecting pan.
Juices generated during grilling and the fat flow down
through the fat drip spout (9) to the fat collecting pan. (8).
Regularly check and empty the fat collecting pan (8).
Remove the fat collecting pan (8). If necessary clean it,
dry it and remount in the device.
Before cleaning, always leave the device and the fat
collecting pan to completely cool down.
Connect the device to a grounded single socket. The green ON/OFF indicator will
come on signalling that the device is switched on.
To remove possible post-production residues, heat the device without any dishes for
at least 20 minutes with the temperature set for 200 °C (wee section „Settings“).
During the first heating of the device, there may appear some smoke resulting from
evaporation of technical grease. This smoke is not harmful and will not appear during
subsequent use of the device. When heating up the device, make sure there is
appropriate air circulation in the room.
Settings
In order to grill food, set the desired temperature by
turning the temperature control knob and heat the
device up. It is possible to choose the temperature
within the range from 100 °C to 300 °C.
The optimum grilling temperature is within the
range: from 200 °C to 280 °C.
The green heating indicator remains on during the heating of the device and
goes off after the set temperature has been reached.
8
9

- 29 -
The device allows for selecting 2 heating power
levels which are set by means of the heating power
control knob:
standard heating power with low energy
consumption (turn the control knob left).
Heaters of the upper and lower grill plates are
switched off.
TURBO heating power, when an additional
power and speed are required (turn the control
knob right). In this setting, the upper grill plate
reaches higher temperature.
Grilling of food
In the meantime, prepare food products for grilling.
Open the pre-heated device by lifting the upper grill plate using the handle until
it stops.
Using a heat resistant brush apply some vegetable oil on the lower grill play and
place the food on its surface.
Note: When preparing pastry there is no need to apply oil on the grill plates.
Close the device by lowering the upper grill plate using the handle.
Do not leave the device unattended during grilling.
HOT SURFACE! Burn hazard!
During the operation the external surface of the contact
grill is very hot.
To avoid burns, do not touch the device during the
operation and directly afterwards.
Use the appropriate handle when opening and closing
the device.
After grilling is finished, open the device with the handle and remove the grilled food.
Avoid using hard or sharp objects to prevent grill plates from damaging. You may use
wooden spatula, heat resistant tongs or heat resistant plastic forks.

- 30 -
WARNING! Risk of burns!
Protect your face and hands against possible fat splashes!
Put the temperature in the range from 50 °C do 100 °C (standby mode) during breaks
between subsequent grilling stages. If necessary set the higher temperature and the
device will heat up in a few minutes.
Limit stop of the upper grill plate
Gentle grilling and heating of food
sensitive to pressure, such as e.g. pita
bread is possible thanks to the upper
plate height adjustment.
To change the height of the upper plate,
loosen the screw at the rear of the
device (turn it counter clockwise), which
will allow for setting the appropriate
distance between the upper and lower
grill plate.
When you finish using the contact grill, set the temperature control knob to „0“
position, and disconnect the device from the power supply (pull the plug!).
Instructions for the preparation of food
The contact grill is designed for gentle preparation of food with a very low
amount of fat.
Before placing any food products on the lower gill plate, apply some oil to its
surface. Use oil with a high level of heat resistance, such as rapeseed or
sunflower seed oil.
Meat and fat require smaller amounts of oil, because they already contain grease;
when grilling fish and vegetables more oil can be applied on the lower grill plate.
By adding oil, you can prevent food from sticking to the grilling surface or from
scorching.
When preparing pastry there is no need to apply oil on the grill plates.
To avoid transmission of smell and taste of one food to another, remove their
remains from the grilling surface between subsequent grilling stages.
When preparing delicate food, adjust the height of the upper grill plate accordingly.

- 31 -
6. Cleaning
WARNING!
Before cleaning, disconnect the device from the power
supply (unplug!) and leave to cool off.
Never clean the device with use of pressurized water jet.
Protect the device from the water penetration.
Cleaning of the device
oClean the device and the end of each working day or if necessary also between the
grilling processes.
oUse soft cloth only and never use any kind of abrasive cleaning agents which may
scratch the surface of the device.
oNever use any aggressive agents or sprays.
oOpen the device and remove the grilling remains from the upper and lower grill
plate using appropriate scrapper by depositing the remains to the fat drain spout
and further down to the fat collection pan.
oClean the upper and lower grill plate with a soft cloth soaked in warm water.
Dry the grill plates and apply a small amount of vegetable oil on them.
oIn case of the hardest dirt, lubricate the still warm grill plates with vegetable oil and
leave to soak for a few minutes and then clean off the dirt with a paper towel.
oRemove the fat collection pan, empty and clean it with a soft cloth or sponge with
a mild cleaning agent. Rinse with clean water and then dry it thoroughly before
reinstalling in the device.
oClean the body and handle of the device regularly with a soft, moist cloth with a
mild c
Storage of the device
oIf the device is not used for a long time, clean it thoroughly as described and store it
in a place which is clean, dry, frost-free, protected from the sun and inaccessible for
children. Do not place any heavy objects on the device.

- 32 -
7. Waste disposal
Discarding old devices
At the end of its service life the discarded device has to be disposed in accordance with
the national regulations. It is advisable to contact a company which is specialized in
waste disposal, or just contact the local disposal service in your community.
WARNING!
To exclude any abuse and the dangers involved make
the waste device unfit for use before disposal.
For that purpose disconnect device from mains supply
and remove mains connection cable from the device.
For the disposal of the device please consider and
act according to the national and local rules and
regulations.
Bartscher GmbH phone: [phone]
Franz-Kleine-Str. 28 fax: [phone]
33154 Salzkotten Service-Hotline: [phone]
Germany www.bartscher.com
