Safety
2 / 24 1054513
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Di e Kenntnis aller enthalt enenSic herheitshinw eiseu ndH andlungs anweisungen schafft die V oraussetzung für das sichere un ds achgerechte Arbeite n mit dem Gerät. Darüber hi naus müssen die für de nEins atzbereich des Geräts gelt enden örtlich enU nfallverhütungs vorschriften und allge meinen Sicherheits bestimmungen eing ehalten werden. Diese Be dienungsanleitung is t Bestandt eild es Produkts und muss i n unmittelbarer Nähe d es Geräts für das In¬stall ations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn d as Gerät an eine dritte Pers on
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
1054513 3 / 24
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Safety During Operation of Stock-Pot Stoves
•Do not use a gas-supplied appliance in the event of a malfunction or damage or
in the case of a suspected malfunction or damage. In case of malfunction,
disconnect the appliance from gas supply (close the gas shut-off valve) and
notify the technical service company immediately.
WARNING! Fire hazard!
Do not use open flame for checking tightness of gas installation!
•Regularly conduct tightness checks using suds (a spray for detecting leakages).
WARNING!
Suffocation and explosion hazard due to leaking gas!
•When you sense gas odour, observe the following rules:
–immediately close the gas controller and the main gas valve;
–do not light up any open flame, quench flames;

Safety
4 / 24 1054513
EN
–do not smoke;
–do not operate any electric appliances in the vicinity of a gas-supplied
appliance;
–if you are not able to precisely locate the source of gas leakage, notify
the fire service or gas supply company immediately.
Flammable Materials
•Never use the appliance near flammable or easily combustible materials (e.g.:
petrol, spirit, alcohol). High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•Use the appliance only with materials designed to this end and with correct
temperature settings. Materials, food products and left-overs of food products
remaining in the appliance may catch fire.
•To avoid fire hazard, clean the appliance regularly.
•Never leave the appliance unattended, especially when cooking with fats or oils
as they may cause fire.
•Close the gas shut-off valve should the fire emerge. Never put the flame out with
water; to suppress fire, use a lid or a fire-blanket. Following extinction of fire,
ensure sufficient fresh air inflow.

Safety
1054513 5 / 24
EN
Hot Surfaces
•Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
•Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.

Safety
6 / 24 1054513
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Preparing and heating-up foods with the use of suitable cookware.
The appliance may be used outdoors only.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–usage in closed rooms
–heating of rooms.

General information
1054513 7 / 24
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
8 / 24 1054513
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.
–before storing disconnect the appliance from the gas cylinder.

Technical Data
1054513 9 / 24
EN
4 Technical Data
4.1 Technical Specifications
Name:
Stock-pot stove G-1KB 1K680
Art. No.:
1054513
Material:
CNS 18/10, cast
Load-bearing capacity, max. in kg:
50
Hob diameter, min.–max. in mm:
230 - 450
Tube length, in m:
1,5
Power supply:
6.8 kW
Dimensions (W x D x H), in mm:
400 x 445 x 400
Weight, in kg:
15,3
We reserve the right to implement technical modifications.
Version / Characteristics
•Supply type: gas
•Gas type: liquid gas
•Gas burner: powerful burner
•Ignition type: piezoelectric ignition
•Ignition protection
•The hob size may be changed with the optionally available small pot ring and
wok adapter.
•Rubber feet
•Important Indications:
–For outdoor use only
–Gas connection set not included in the delivery
–Pressure reducer is required, max. 50 mbar

Technical Data
10 / 24 1054513
EN
Gas Pressure Table / Destination Country
Category
Gas Type / Gas Pressure
Destination Country
I2H
G20:20 mbar
AT, BG, CH, CZ, DK, EE, ES,
FI, GB, GR, HR, HU, IE, IS, IT,
LT, LV, NO, PT, RO, SE, SI,
SK, TR
I2E
G20: 20 mbar
DE, LU, PL, RO
I2E+
G20/G25: 20/25 mbar
BE, FR
I2EK
G25.3: 25 mbar
NL
I3+
G30: 28-30 mbar
G31: 37 mbar
BE, BG, CH, CY, CZ, ES, FR,
GB, GR, IE, IT, LT, LU, LV, PT,
SI, SK
I3B/P
G30/G31: 30 mbar
BE, BG, CY, DK, EE, FI, FR,
HR, HU, IS, IT, LT, LU, MT,
NL, NO, PT, RO, SE, SI, SK,
TR
I3B/P
G30/G31: 37 mbar
PL
I3B/P
G30/G31: 50 mbar
AT, CH, DE, SK
Table 1
Table of Nozzles
Gas Type / Gas Pressure
Burner Nozzle
Power
G20: 20 mbar
2 mm
6,5 kW
G25: 25 mbar
2 mm
6,5 kW
G25.3: 25 mbar
2 mm
5,8 kW
G30: 28-30 mbar / G31: 37 mbar
1,15 mm
5,2 kW
G30 / G31: 30 mbar
1,15 mm
5,2 kW
G30 / G31: 37 mbar
1,15 mm
5,8 kW
G30 / G31: 50 mbar
1,15 mm
6,8 kW
Table 2

Technical Data
1054513 11 / 24
EN
4.2 List of Components of the Appliance
Fig. 1
1. Thermal flame control
2. Igniter
3. Burner's lid
4. Burner's cup
5. Cast-iron grate
6. Frame
7. Feet (4 pcs)
8. Gas connection
9. Gas supply
10.Gas controller
11.Piezoelectric ignition button

Technical Data
12 / 24 1054513
EN
Auxiliary equipment (not included in the delivery!)
Fig. 2
Fig. 3
Wok attachment G-1KB 1K680
Material: chrome-nickel steel 18/10
Wok opening diameter: 314 mm
Dimensions: W 400 x D 400 x H 96 mm
Weight: 2.2 kg
Art. No. 105452
Fig. 4
Fig. 5
Support ring for small pots G-1KB 1K680
Material: high-alloy steel
Cookware diameter: 175–230 mm
Dimensions: W 395 x D 395 x H 20 mm
Weight: 0.85 kg
Art. No. 105453

Installation and operation
1054513 13 / 24
EN
4.3 Functions of the Appliance
The mobile stock-pot stove with powerful burner provides for many possibilities of
using it outdoors. The available optional accessories, such as the support ring for
small pots and wok attachment make it possible to use various cookware.
5 Installation and operation
5.1 Installation
CAUTION!
Incorrect installation, positioning, operation, maintenance or misuse of
the appliance may lead to personal injury or property damage.
Positioning and installation, as well as repairs may be performed by
authorised technical service only and in compliance with the applicable
national law.
Observe the provisions of the following requirements and regulations in force:
1. DVGW TRGI (technical regulations for gas installations);
2. TRF (technical regulations for liquid gas);
3. DVGW G 631 (installation of commercial kitchen appliances for
combustion of gas fuels).
Moreover the appropriate construction law, trade law, OHS, and VDE regulations
must be followed in the place of installation.

Installation and operation
14 / 24 1054513
EN
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Position the applianc eout doors or in a large, open, a nd well-ventilated area (se eD VGW working she et G 631).
•When setting up, the ap pliance must be secured ag ainstti pping over with an anch ort ot he base.
•Setu p the appliance so that t heco mbustion air suppl ya ndt he exhaust gas system ar e notbl ocked.
•Position the appliance outdoors or in a large, open, and well-ventilated area.
•Make sure that there are no obstacles nor objects in the installation location,
which might be affected by high temperatures of flames (e.g.: tree branches,
furniture, curtains or other easily flammable objects).
•Never place the appliance directly next to walls, furniture, or other objects made
of flammable materials. Assure a minimum lateral clearance of the appliance of
30 mm.
•If keeping the minimum clearance is not possible, and the appliance must be
installed directly next to regular or low walls, pieces of furniture or other
flammable objects, it is necessary to install protective materials (e.g., films made
of materials resistant to high temperatures), which sustain temperatures of at
least 65°C.
•Maintain sufficient lateral clearance for service purposes should maintenance
and repair works be required.

Installation and operation
1054513 15 / 24
EN
5.2 Gas Connection
Important Indications
•Before installing the appliance and connecting it to gas supply, thoroughly check
the fixed elements of gas installation, which should meet the provisions of
construction law.
•Depending on type of gas, the intersection of gas supply line must be selected
according to regulations in force and properly installed.
•The connection may be established as fixed or detachable; if flexible tubes are
used, they must be made of stainless steel, pursuant to DIN 3383 Part 1 or
3384.
•Make sure that flexible tubes do not run on or near hot surfaces, are not subject
to stress or pressure and do not come into contact with sharp edges or other
objects that could damage the tube.
•If threaded connections are used with sealants or sealing materials, they must
be tested and approved by DVGW.
•Check if the gas cylinder (if it is included) is correctly set up and secured, and if
it is located in a dry place.
•Prior to installation of the appliance, make sure that it is set to gas and pressure
available in the installation location (see rating plate on the appliance and Table
1). If factory default settings are not suitable, the appliance must be adapted to
another type of gas (section 'Resetting to Other Type of Gas / Required
Settings').
•If the pressure in gas tube exceeds or drops below 10% of standard pressure,
install gas pressure controller, to provide for gas pressure stability.
•The attested gas shut-off valve must be installed in a easily accessible location
between the gas supply installation and the appliance, so that, if needed, gas
supply may be interrupted at any time.
•Gas connection stub is found at the back of the appliance.

Installation and operation
16 / 24 1054513
EN
Appliance Connection
1. Connect one end of the included tube with
the gas connection stub at the back of the
appliance.
2. Connect the other end to the gas cylinder or
gas supply connection in the installation
location.
Fig. 6
3. Perform tightness check of all connection points between the gas source and
the appliance. To this end, it is recommended to use suds or spray for detecting
leakages or, possibly, foam producing agents, which do not spur corrosion.
WARNING!
Do not use open fire to test tightness.
4. Apply the selected agent with a brush onto connection points (also on the shut-
off valve)
NOTE!
The connection is tight when there are no bubbles during test.
Resetting to Other Type of Gas / Required Settings
•The appliance is approved and by factory default, prepared to operate with the
type of gas stated on the rating plate (liquid gas).
•If the default factory settings of the appliance are not consistent with the type of
gas available in the installation location, do not connect the appliance to gas
supply.
•To set the appliance to the available gas type, it is necessary to exchange
nozzles and introduce the required settings.
WARNING!
This setting may be introduced by qualified gas installer only, with
consideration for technical data, through exchange of burner nozzles, as
well as through introduction of the resulting settings.
1. The proper data pertaining to the required nozzles are provide in the table of
nozzles (Tab. 2).

Installation and operation
1054513 17 / 24
EN
2. Lift and remove the burner's lid, burner's cup and burner's pipe.
3. Undo the burner's nozzle with a suitable wrench.
4. Install the nozzles suitable for a given type of gas.
After switching from liquid gas to natural gas, the bypass nozzle should be undo by
one turn.
ATTENTION!
After resetting or adjusting to another type of gas, make sure you place a
suitable sticker on the rating plate, included with the burner's nozzle.
5.3 Operation
WARNING!
Risk of burns by high, rising flames!
Never lean over the cooking place during ignition.
Risk of burns by hot elements or surfaces!
Never touch the hot surface of the gas burner during operation and
directly afterwards.
Use kitchen towels or protective gloves.
•Przed pierwszym u życiem w yczyścić urządzeni e i wyposażenie zg odnie ze ws kazówkami za wartymi w pu nkcie 6 „Czyszc zenie”. Uw ażać, aby do ins talacji elektr ycznej i skrzyn ki rozdzielczej nie do stała się wo da. Następnie do kładnie osuszyć urządzenie i elementy wypos ażenia.
•Insertt he bottom co verint o the appliance. The cover acts as a spacer between t heh eating element and lef t-over food tray.
•Carefully insert the con nection box with the heating element at the back edge o ft he appliance. A pin in bott om part oft he connection bo xm ust enter a hole in the main applia nce. This way the connec tion box is properl y mounted.
Before the First Use
1. Before use, clean the appliance, observing instructions in section 'Cleaning'.
2. Before using the appliance, make sure that its condition is flawless and that it is
located in a well ventilated place.
3. Make sure that there are no objects near or under the appliance that may
restrict the amount of air necessary for burning.
4. To start the appliance up, perform the following instructions.

Installation and operation
18 / 24 1054513
EN
•Przed pierwszym u życiem w yczyścić urządzeni e i wyposażenie zg odnie ze ws kazówkami za wartymi w pu nkcie 6 „Czyszc zenie”. Uw ażać, aby do ins talacji elektr ycznej i skrzyn ki rozdzielczej nie do stała się wo da. Następnie do kładnie osuszyć urządzenie i elementy wypos ażenia.
•Insertt he bottom co verint o the appliance. The co ver acts as a spacer between t heh eating element and left -over food tray.
•Carefully insert the con nection box with the heating element at the back edge o ft he appliance. A pin in botto m parto ft hec onnecti onb ox must enter a hole in the main ap pliance. This way the con nection box is properl y mounted.
Appliance Start-up
Fig. 7
1. Open the gas shut-off valve at the gas supply tube.
2. Set the gas controller (10) to OFF marking (a).
3. Press the rotary controller (10).
4. Press and hold the rotary controller (10) and rotate it counter-clockwise.
This way the valve is opened and gas is delivered to the burner via the gas supply
tube.
5. Keep the gas controller (10) pressed and at the same time operate the
piezoelectric ignition button (11).
A loud clicking sound is heard, and the ignition spark ignites the gas at the burner.
6. When the flame is ignited, keep the gas controller (10) pressed for a few
seconds, until the thermal element heats up.
7. Release the rotary controller (10).
Should the flame go out, it will be recorded by ignition protection at the burner and
the gas supply will be interrupted.
8. Wait until the gas escapes and repeat the above steps.
