Basler BE1-BPR-309 User manual

BE1-BPR
UHG-5
3-02
P. O. BOX 269 HIGHLAND, ILLINOIS 62249, U.S.A. PHONE [phone] FAX [phone]
BE1-BPR
BREAKER
PROTECTION RELAY
The BE1-BPR Breaker Protection Relay provides all the capabilities
required for most breaker protection and monitoring functions.
It incorporates a simple programming language to allow the user
to set up any desired logic between the inputs and outputs.
ADVANTAGES
• Vertical unit to replace obsolete Breaker Fail relays.
• Horizontal unit for rack-mount installations.
• Powerful BESTLogic programming language includes the means to
set up and control current signal filters, fault detectors, timers, counters
and logic gates.
• Many programmable inputs and outputs for virtually any application:
Four AC current and seven isolated contact inputs, five control
plus one alarm output, RS-232 and RS-485 communication ports.
• User may program the unit for a specific application or select one of
the versatile stored programs with the following functions:
- Breaker-fail protection
- Breaker opening resistor protection
- Breaker “sustained arc” protection
- Breaker contact duty monitoring
- Breaker-fail time-margin logging
- Fault data capture
- Reclosing
• Five year warranty.
INSTRUCTION MANUAL
Request publication 9272000990
ADDITIONAL INFORMATION
FEATURES
Page 2
APPLICATION
Page 2
FUNCTIONAL
DESCRIPTION
Pages 3-5
REAR VIEWS and
PANEL CUTOUTS
Page 6
SPECIFICATIONS
Page 7
ORDERING
INFORMATION
Page 8
WINDOWS®SOFTWARE
Interface for setting and communicating with Basler protection products.
Request BESTview for BE1-BPR.

BE1-BPR
2
BREAKER PROTECTION
Breaker protection includes breaker fail protection,
breaker resistor protection, and protection against
sustained arcs across one or more open breaker
contacts.
Breaker-fail protection is accomplished by initiating a
BPR timer from one or more relay trip signal inputs and
providing an output to trip upstream breakers if the
BPR fault detectors don’t drop out before the time
expires on the BPR timer.
Breaker opening resistor protection is accomplished by
providing an output to block reclosing if BPR calcula-
tions determine that additional breaker operations
could exceed the maximum resistor power rating.
Open breakers can be protected against sustained
arcs by providing an output to close the breaker and
allow it to trip again. Such sustained arcs can be
initiated by lightning or loss of dielectric strength. Arc
current may be limited to line charging current and
may go undetected by standard fault protection
elements. If the arc is allowed to continue for minutes,
the breaker will be destroyed due to the internal heat
generated. The BPR provides a separate fault detector
for detecting low level arcs.
The BE1-BPR provides both breaker protection and breaker monitoring in a single unit that can communicate with
a local or remote computer.
APPLICATIONS
• Easy setup from front panel or communications port.
• Drawout construction with shorting bars on current
inputs.
• Ability to monitor breaker contact duty separately for
each pole.
• Fault data in COMTRADE format at 12 samples per
cycle and up to 200 A.
• Can communicate with PC equipped with off-the-
shelf communications software.
• Built-in diagnostics monitor the health of all major
internal functions.
• Time margin log reveals margin on breaker fail
timers’ settings.
• A high speed relay operating within one-quarter
cycle of 60 Hz is provided for breaker-fail output.
• Fault detectors reset within ¼cycle of 60 Hz.
• Pickup setting on arc detector can be set below 0.1 A.
• Isolated communications ports.
• IRIG-B time code input to set and synchronize
on-board real time clock.
Standard model relays have the following special
features:
• Three shot recloser.
• Pre-insertion breaker resistor operations counter
with programmable reset and block reclose signal.
• Six configurable timing diagnosic logs, each with an
optional alarm setting. This feature can be used to
monitor various protection system parameters, such
as the margin between normal breaker operation
and breaker fail.
Enhanced model relays have the standard model
features plus these special features:
• Twelve entry fault log detailing the system and relay
status at the time the fault trigger occurrred.
• Twelve entry COMTRADE fault record consisting of
configuration and data files. Data contains 4 cycles
of pre-fault and 16 cycles of post-fault data.
• Integrated I2t breaker contact duty monitor with
alarm.
BREAKER MONITORING
Breaker monitoring generally consists of gathering
the data necessary to predict when the breaker con-
tacts should be serviced. This practice eliminates the
need to perform routine maintenance on breakers that
may be in good condition. Data is acquired each time a
52a/b contact input indicates opening of the breaker.
The BPR not only monitors contact wear but also
gathers data on breaker-fail timing margins. This
information may be used to help the user achieve fast,
secure breaker-fail protection. Data is acquired each
time the breaker operates.
The BPR also captures fault data on all four current
inputs, along with status on all contact inputs and relay
outputs.
The BPR stores the last 12 fault records and overwrites
the oldest when full. Recording is triggered according
to the trigger conditions that were set up while pro-
gramming the relay logic.
Fault data is stored in three forms: An oscillographic
record in COMTRADE format, a fault data summary
report, and a fault record list.
All data captured can be retrieved by a PC equipped
with standard off-the-shelf communications software.
FEATURES

BE1-BPR
3
Figure 1 - Functional blocks in BPR
PROGRAMMING LANGUAGE
The powerful nature of the BESTlogic programming language can be shown by the simple program used to
achieve the logic shown in Figure 2. The program is as follows:
LN=BFL2E LI6=4,12 LOA=T4+O14+O15* LO9=T3I6
LF1=PI,1 LI7=4,12 LO1=O2 LO10=I6+O11
LF2=NI,1 LR=0,0,0,0,0 LO2=T1O7+F1T2+O1O7 LO11=I3+I4+IT5
LF3=PI,2 LT=D,O8,/O8 LO3=O13 LO12=F3I1
LI1=4,12 LT2=D,O9,/O9 LO4=T5
LI2=4,12 LT3=C,O10,/O10 LO5=T3
LI3=4,12 LT4=D,O6,/O6 LO6=/I1/I2
LI4=4,12 LT5=D,O12,/O12 LO7=F1+F2
LI5=4,12 LT6=0,0,0 LO8=T3O11
*The non-maskable alarms are always ORed with the programmable diagnostics to aprovide an alarm output.
The BESTlogic commands provide an easy way to define functional elements and use them in logical expressions
to achieve the operation desired. Once programmed, different logic sets are activated simply by changing the
name of the active logic set using the LOGIC command. Please see the instruction manual for details.
FUNCTIONAL BLOCKS

BE1-BPR
4
FUNCTIONAL DESCRIPTION
Figure 2 - Example of programmable logic (BFL2E)
BFL2E logic in figure 2 provides the following application features:
1. Three-Pole Tripping BF Logic (Output latch-in provided and Control timer limits operational window). Three
BFI inputs are available at IN3, IN4, and IN5 to start delay timer T1. If the BFI inputs are not reset by the time
T1 times out and either the phase (F1) or neutral (F2) fault detector is still picked up, then outputs BFO1 and
BFO2 will close to trip the backup breakers. Control timer (T3) is used to limit the breaker failure window of
opportunity.
2. Single-Pole Tripping BF Logic (Features: Output latch-in provided and Control timer limits operational
window). If single-pole tripping is used, a BFI input is available (IN6) to start delay timer T2. This input is only
supervised by the phase fault detector (F1). If the BFI input (IN6) is not reset by the time the timer T2 times
out and the phase fault detector (F1) is picked up, outputs BFO1 and BFO2 close, tripping the backup
breakers. Control timer T3 is used to limit the breaker failure window of opportunity. Neutral fault detector (F2)
is not used to supervise the single-pole BF logic, because F2 is still picked up by the phase imbalance after the
fault clears. Three-phase BF logic is inhibited during this period, because there is no 3-phase BFI input active.

BE1-BPR
5
3. Trip Coil Status Monitor. Preprogrammed logic is provided using IN1 to provide breaker status and IN2 for
trip coil continuity.
4. Breaker Arc Protection. Preprogrammed logic is provided using fault detector (F3) for the moving average
fault detector, IN1 for breaker status and OUT4 for the arc detector output.
5. Block Reclose Output. Preprogrammed logic is provided using breaker resistor protection output (O13) to
drive the Block Reclose (BR) output (OUT3).
6. Retrip Output. A Retrip output is provided to give a backup trip signal to the breaker trip coil. This can either
provide a separate path to a single trip coil or be hooked to the backup trip coil if available.
7. External Fault Trigger. The enhanced BE1-BPR relay provides the ability to save COMTRADE fault records for
twelve events in memory at one time. An external fault trigger is provided to allow other multiple units to record
the same event.
8. Alarm Output. An Alarm output is provided to signal relay failure or diagnostic alarm.
Figure 3 - Typical External Sensing Connections
Figure 4 - Typical External Connections
FUNCTIONAL DESCRIPTION, continued

BE1-BPR
6Figure 7 - Panel Cutout Dimensions, Vertical Unit
Figure 5 - Panel Cutout Dimensions, Horizontal Unit
Figure 8 - Rear View, Vertical Unit
Figure 6 - Rear View, Horizontal Unit
DIMENSIONS

BE1-BPR
SPECIFICATIONS
7
AC CURRENT INPUT
5A CT: 20A continuous, 400A for one second
1A CT: 4A continuous, 80A for 1 second
OVERCURRENT DETECTORS
Three are provided and may be set up for
3-phase or neutral
INSTANTANEOUS OC PICKUP RANGE
5A CT: 0.25 to 9.99 amperes in 0.01 steps
1A CT: 0.05 to 2.00 amperes in 0.01 steps
AVERAGING OC PICKUP RANGE
5A CT: 0.05 to 1.00 amperes in 0.01 steps
1A CT: 0.01 to 0.20 amperes in 0.01 steps
OVERCURRENT PICKUP TIME
21 ms maximum @ 60 Hz
OVERCURRENT DROP OUT TIME
4.2 ms @ 60 Hz
OSCILLOGRAPHIC RECORDING RANGE
5A CT: 0 to 200 amperes, RMS
1A CT: 0 to 40 amperes, RMS
OSCILLOGRAPHIC RECORDING
12 samples per cycle in COMTRADE format
TIMERS, Standard
Six microprocessor controlled timers
adjustable from 10 to 999 ms in 1 ms steps,
or 1 to 60 sec in 0.1 sec steps, or 1-3600 cycles
in 1 cycle steps
REAL TIME CLOCK
Resolution: ±1 sec
Stability: ±30ppm typical
INPUT CONTACT SENSING RANGE
Within DC power supply input rating range
Programmable recognition time, 4-255 ms
OUTPUT RELAY SPEED
4 ms typical, 5 ms maximum on Output #1
8 ms typical, 10 ms maximum on Outputs #2-5
DISPLAY
2 line x 16 character backlit LCD display
OUTPUT CONTACT RATINGS
120/240Vac: Make and carry 30 A for 0.2 sec,
carry 7 A continuously and break 7A.
250Vdc: Make and carry 30A for 0.2 sec,
carry 7A continuously and break 0.3A
TARGETS
Five diagnostic LEDs are provided plus
target display of all I/O contacts
COMMUNICATIONS
Includes front and rear RS-232 ports and a
rear RS-485 port. Only one port can be active at
a time.
Oscillographic records conform to IEEE C37.111-
1991 IEEE Standard Common Format for
Transient Data Exchange (COMTRADE) for Power
Systems. Protocol: ASCII or binary data
transmissions.
BESTview for Windows™ is a free software
application program that enables communication
between PCs and BE1-BPR relays. Through
BESTview, you can retrieve and display
COMTRADE oscillographic fault data, access the
front panel from a remote location to change
settings, retrieve a computer file of the relay
settings, or send a computer file to the relay
to perform all relay settings.
RADIO FREQUENCY INTERFERENCE
Field tested using a five watt tranceiver from
144 to 440 MHz
POWER SUPPLIES
48/125 V: 40 to 150 Vdc, 100 to 130Vac
125/250 V: 90 to 300 Vdc, 200 to 260Vac
MECHANICAL
OPERATING TEMPERATURE
-40°C to +70°C (-40°F to +158°F)
VIBRATION
2g over the range of 10 to 500 Hz
CASE SIZE (Vertical unit)
M1 case size
6.61”W x 16.2”H x 9.45”D behind panel
CASE SIZE (Horizontal unit)
Nineteen inch rack mount
19”W x 3.48”H x 9.4”D behind panel
or 8.4”D with movable flanges
WEIGHT
12 pounds maximum.

BE1-BPR
ROUTE 143, BOX 269, HIGHLAND, ILLINOIS U.S.A. 62249
PHONE [phone] FAX [phone]
P.A.E. Les Pins, 67319 Wasselonne Cedex FRANCE
PHONE [phone] FAX [phone]
http://www.basler.com, [e-mail]
ORDERING INFORMATION
PART NUMBER
VERTICAL HORIZONTAL POWER SUPPLY CONFIGURATION
BE1-BPR-309 BE1-BPR-300 48/125 Vac/dc Basic model
BE1-BPR-311 BE1-BPR-302 48/125 Vac/dc Enhanced model
BE1-BPR-310 BE1-BPR-301 125/250 Vac/dc Basic model
BE1-BPR-312 BE1-BPR-303 125/250 Vac/dc Enhanced model
STANDARD ACCESSORIES
9272013101 Escutcheon plate to panel-mount
horizontal relay (shown below)
