Application Note Y99AB-4
Issue Date December 10, 2019
Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 1
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
Y99AB-4 BASO® Test Kit
MILLIAMPS
MILLIVOLTS
20
0
10
100
300
DC MI LLIVOLTS
PENN-BASO CONTROLS
500
700
900
30
40
50
MILLIAMPS
0-500
0-1000 0-50
MILLIVOLTS
JOHNSON CONTROLS, INC
WATERTOWN, WI., U.S.A
ADJUST
TCN10-4
Thermocouple Nut
31543-3
Thermocouple
Terminal Nut
40073-4
Lead Nut
64119-1D
Adapter Assembly
44549-4
Lead Assembly
44549-7
Lead Assembly
Figure 1: Y99AB-4 Test Kit
Description
The Y99AB-4 Test Kit combines four test functions
to enable service contractors to test BASO® controls
and thermocouples in the field. These four functions
are:
Millivoltmeter with 0 to 50 and 0 to 1000 ranges
for checking the open and closed circuit
millivoltage of thermocouple leads.
Performance Tester with a source of power for
holding open BASO power units while taking
open circuit millivolt readings of the
thermocouple when the main burner is in
operation.
Milliammeter with a 0 to 500 (50 on scale)
range for checking the current dropout range of
BASO power unit assemblies. (There are
10 milliamperes for each division on the dial.)
Continuity Tester for detecting a broken or
open circuit.
Definitions
Automatic Pilot - A device employed with gas burning
equipment, which automatically shuts off the gas supply
to the burner being served by either direct or indirect
means when the pilot flame is extinguished. The pilot
burner may or may not be constructed integrally with the
device.
Closed Circuit - Millivoltage measured with the BASO
control attached to the thermocouple.
Couple Lead - The thermocouple, current carrying
conductors, and attaching nut.
Dropout - The point, defined by a millivolt or milliampere
reading, at which the electromagnet releases the
armature.
Milliampere - One thousandth of an ampere.
Abbreviation mA used to check BASO control dropout.
Millivolt - One thousandth of a volt. Abbreviation mV
used to measure thermocouple output.
Open Circuit - Millivoltage measured without the BASO
control attached to the thermocouple.
Power Unit - Electromagnet unit that is internally
connected to the seat of the gas valve and cuts off the
gas when pilot flame fails. Also called a power unit
assembly or hood.
Reset Button - The button that is manually depressed to
place the BASO control in operation.
Thermocouple - The pair of dissimilar metallic elements
joined to produce a millivoltage when the junctions are at
different temperatures.

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 2
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
General Instructions
When using the test kit, insert the plugs securely
and squarely into the jacks. The thermocouple
adapters and nuts must be clean and tight. Any
meter fluctuation caused by the movement of these
parts may be due to loose connections. Poor
connections cause false readings. Three “D” size
batteries are required.
!
WARNING: Risk of Fire or Explosion.
In order to test the thermocouple under actual
flame conditions, it is necessary to hold the BASO
power unit open with the DC power pack provided
with the test kit. This eliminates the safety function
provided by the BASO power unit. Care must be
exercised during this test to ensure that gas is not
permitted to flow to the main burner.
!
CAUTION: Risk of Equipment Damage.
This meter is designed and calibrated for
Direct Current (DC) voltages up to 1000 millivolts
only. Any attempt to measure Alternating Current
(AC) voltage or DC voltage over 1000 millivolts will
damage the meter.
Open Circuit Millivolt Readings
Refer to Figure 8 through Figure 10 for typical
thermocouple-operated gas valve,
electrically-operated gas valve, and safety shutoff
device connection diagrams.
Perform the following procedure for taking open
circuit millivolt readings.
1. Shut off the gas supply at the main manual
shutoff valve.
2. Disconnect the thermocouple from the BASO
control.
3. Attach the test cable lead 44549-8 to the
thermocouple. Connect the red clip to the
copper tubing of the thermocouple and the black
clip to the terminal at the end of the
thermocouple (see Figure 2).
4. Set the slide switch on the meter to the 0-50 or
0-1000 position.
5. Re-establish pilot flame.
6. The millivolt reading should agree with the
values listed in Table 1 with a normal pilot flame
(see Figure 3).
Note: When taking an open circuit millivolt reading on
a junction block thermocouple, the junction block
terminal must be shorted (see Figure 4). This will isolate
the thermocouple from the high limit.
DC MILLIVOTS
PENN-BASO CONTROLS
0
10
20
30
40
50
100
300
500
700
900
MILLIAMPS
0-500
MILLIVOLTS
0-1000 0-50
ADJUST
MILLIVOLTS
MILLIAMPS
44549-8
Black
Red
Thermocouple
Lead
Figure 2: Open Circuit Millivolt Reading Connection
Diagram
Approximately
12.7 mm (1/2 in.)
Figure 3: Normal Pilot Flame
High
Limit
Switch
Shorting Wire
Figure 4: Junction Block Thermocouple

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 3
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
Table 1: Thermocouple Output
Thermocouple
Lead Turndown mV Range
Minimum Fixed Load
Adapter Voltage
Normal Not Less Than
K14 4 mV 20-28 15 8
K15 4 mV 20-28 15 8
K16 4 mV 25-35 17 8
K17 4 mV 30-40 25 8
K19 4 mV 25-35 17 8
Fixed Load Millivolt Readings
Perform the following procedure for taking fixed load
millivolt readings:
1. Disconnect the thermocouple from the BASO
control and attach the adapter assembly
(64119-1D) to the thermocouple.
2. Attach the test cable lead 44549-8 to the
adapter assembly. Connect the red clip to the
copper tubing of the adapter assembly and the
black clip to the control end of the adapter
assembly (see Figure 5).
3. Set the slide switch on the meter to the 0-50 or
0-1000 position.
4. Reestablish pilot flame.
5. The millivolt reading should agree with the
values listed in Table 1 with a normal pilot flame
(see Figure 3).
Note: When taking a fixed load millivolt reading
on a junction block thermocouple, the junction
block terminal must be shorted (see Figure 4).
DC MILLIVOLTS
PENN-BASO CONTROLS
0
10
20
30
40
50
100
300
500
700
900
MILLIAMPS
0-500
MILLIVOLTS
0-1000 0-50
ADJUST
MILLIVOLTS
MILLIAMPS
44549-8
Red Black
Shorting
Jumper Clip
Thermocouple
Lead 64119-1D
Adapter
Assembly
Figure 5: Fixed Load Millivolt Reading Connection
Diagram

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 4
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
Dropout Testing
Refer to Figure 8 through Figure 10 for typical
thermocouple-operated gas valve,
electrically-operated gas valve, and safety shutoff
device connection diagrams.
Perform the following procedure using the
milliammeter for dropout testing.
1. Shut off the gas at the main manual shutoff
valve.
2. Disconnect the thermocouple lead from the
BASO control.
3. Connect the test cable lead 44549-7 to the
milliamperes jack on the test kit meter, connect
the other end to the BASO control
(see Figure 6).
4. Set the slide switch on the meter to the 0-500
(50 on scale) position.
5. Turn the adjust knob on the meter clockwise to
the full-scale deflection of the needle. Reset the
control by pressing in the reset button on the
control firmly.
6. Turn the adjust knob on the meter
counterclockwise slowly until the BASO control
power unit releases. The milliampere reading at
the moment of release is the dropout point of the
BASO power unit. Take two more readings by
the same process, and average the readings.
The milliampere dropout point must lie within the
high and low range listed in Table 2.
7. Pilot and main burner should extinguish within a
few seconds. If flames do not extinguish, refer to
the Troubleshooting section.
44549-8
H17
Gas Valve
Reset
Button
44549-7
MILLIAMPS
MILLIVOLTS
20
0
10
100
300
DC MILLIVOLTS
PENN-BASO CONTROLS
500
700
900
30
40
50
MILLIAMPS
0-500
0-1000 0-50
MILLIVOLTS
JOHNSON CONTROLS, INC
WATERTOWN, WI., U.S.A
ADJUST
Figure 6: Dropout Testing Connection Diagram
Table 2: Milliampere Dropout Range
BASO Control
Part Number mA Range of Power Unit Assembly
Low High
H15A_, H15C_, H15D_, H15H_ 100 300
H15E_, H15F_ 60 150
H17_A 100 300
H17_B 50 165
H19A_ 100 300
H19ME 45 165
H19L_, H19N_, H19R_, H19T_ 100 300
H43AA, H43BA, H43GA 100 300
H43AB, H43BB 50 165
G92 (All models except
G92CAA-19 and G92CBA-10) 100 300
G92CAA-19 and G92CBA-10 100 200
G93 100 300
G292 100 300
L61LL 75 200
L62AA 100 300
L62GB 100 300

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 5
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
Continuity Testing
!
CAUTION: Risk of Equipment Damage.
Turn off the power to the appliance. When the
meter is being used as a continuity tester, it should
never be put across line voltage potential.
Perform the following procedure for continuity
testing.
1. Connect the test cable lead 44549-4 to the
milliampere jack on the test kit meter.
2. Set the slide switch on the meter to the 0-500
(50 on scale) position.
3. Connect the red and black alligator clips
together; turn the adjust knob clockwise until the
needle is above 500 (50 on scale). If unable to
get a reading of 500, check the alligator clip
connection or replace the batteries.
4. Test for open circuits by touching or connecting
the alligator clips to terminals or points in the
circuit.
Closed Circuit Test
Perform the following procedure for closed circuit testing.
1. Disconnect the thermocouple from the BASO
control.
2. Attach the adapter assembly (64119-1D) to the
control and thermocouple.
3. Remove the shorting jumper clip from the adapter
assembly.
4. Set the slide switch on the meter to the 0-50
position.
5. Attach the test cable lead 44549-8. Connect the red
clip to the copper tubing of the thermocouple and the
black clip to the adapter block terminal
(see Figure 7).
6. Depress the reset button on the BASO control and
light the pilot using a safe lighting procedure. Hold
the reset button in for approximately 60 seconds or
until the output is high enough to hold the energized
valve.
7. Observe output. The millivolt reading should agree
with the values listed in Table 1.
DC MILLIVOLTS
PENN-BASO CONTROLS
0
10
20
30
40
50
100
300
500
700
900
MILLIAMPS
0-500
MILLIVOLTS
0-1000 0-50
ADJUST
MILLIVOLTS
MILLIAMPS
44549-8
Black
Red
Thermocouple
Lead H19
High Pressure
Gas Valve
Reset
Button
Figure 7: Closed Circuit Test Connection Diagram

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 6
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
“A”
Valve
Reset
Button
Pilot Burner
Gas Line
44549-7
Thermocouple
Lead
BlackRed
44549-8
Figure 8: Typical Thermocouple-operated Gas Valve Connection Diagram
Power
Source Thermostat
Transformer
44549-7
44549-8
BASO
Magnetic
Operator
BASO
Power
Unit Reset
Button
“B”
Valve
Shutoff
Valve
Pilot Burner
Gas Line
Thermocouple
Lead
Red Black
Figure 9: Typical Electrically-operated Gas Valve Connection Diagram

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 7
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
Transformer
Shutoff
Valve
Pilot Burner
Gas Line
44549-7
BlackRed
44549-8
“B”
Valve
“L” Series
Control
Power
Source Thermostat
Thermocouple
Lead
Figure 10: Typical Safety Shutoff Device Connection Diagram

Y99AB-4 BASO® Test Kit
© 2019 BASO Gas Products 8
Part No. BASO-AN-Y99AB, Rev. B www.baso.com
Troubleshooting
The following table indicates symptoms and corrective actions.
Table 3: Troubleshooting Symptoms and Corrective Actions
Symptom Possible Cause Corrective Action
Pilot burner outage, varying
performance, or poor mV output. Excessive draft Baffle secondary air or shield pilot burner.
Recirculation of flue products Check venting and main orifice sizing and
correct where necessary.
Excessive temperature Check main burner input and correct if
necessary.
Improper pilot flame size or
characteristic Check gas pressure, clean pilot burner, and adjust flame.
Defective thermocouple Perform the Open Circuit Millivolt Readings
procedure.
Weak holding BASO power unit Perform the Dropout Testing procedure.
Pilot burner burning, manual valve
(if included) turned to the “On”
position, thermostat calling for
heat. Main burner does not come
on.
Defective thermostat Perform the Continuity Testing procedure.
Defective operator Check for operator input voltage. If present,
replace the valve. If not, check voltage
source.
Thermostat not calling for heat, or
turned down, manual valve (if
included) in the “On” position. Main
burner does not shut off.
Shorted thermostat circuit Perform the Continuity Testing procedure.
Foreign particles lodged between
the valve seat Replace the valve.
No burner flame or flame does not
stay on. Thermocouple out of position Reposition thermocouple properly.
Thermocouple lead dirty or loose Clean and tighten thermocouple lead
connection.
Defective thermocouple Perform the Open Circuit Millivolt Readings
procedure.
Defective BASO power unit Perform the Dropout Testing procedure.
Defective orifice Clean or replace orifice.
Unusually strong drafts Baffle secondary air or shield burner.
450 East Horseshoe Road
PO Box 170
Watertown, WI 53094 www.baso.com
1-877-227-6427 (1-877-BASOGAS) Printed in U.S.A.
