Basta Boatlifts Over-Center 2x2k User manual

READ complete manual CAREFULLY
BEFORE attempting assembly or operation
04/21
L392-0097B
tm
Over-Center Hydraulic Aluminum Lift
4,000 lbs Capacity (2,000 lbs + 2,000 lbs) Model 2x2k
866-GO-BASTA
www.gobasta.com
ASSEMBLY
INSTALLATION
REPLACEMENT PARTS
Copyright 2018 Basta Marine
©
2x2k

Assembly Instructions .........................................................................Pages 6 - 17
First Use / Adjustments ..……………...........................................................Page 18
Basta Marine Boat Lift Accessories ....…………………............….….….Page 23
Parts List and Diagrams ..................................................................Pages 4 - 5, 19
Troubleshooting / FAQ
Maintenance
.…...........................................................................Page 21
......................…...........................................................................Page 20
2
INDEX
Warning......………………..............................................................................Page 2, 3
Warranty .............................…...........................................................................Page 22
NOTE:Your boat lift is a very heavy piece of equipment. Improper use could result in
serious injury or death. For the safety of people and property please review the safety
guidelines below for your new boat lift.
Do not exceed the maximum weight capacity
specified for the lift. SEE PAGE 17.
Passengers should stand clear of the lift and not
be aboard when the lift is in operation.
Do not play on or near the lift.
Leave your automatic bilge pump turned on the
automatic setting to prevent the accumulation of
rain water.
Service your lift regularly.
Do not service the unit with the boat on the lift.
Use a mooring line for additional security.
Only use Basta Marine approved oil in lift.
Special biodegradable non-toxic hydraulic fluid
Visually inspect all parts and assemblies for
defects and damage prior to assembling the
lift.
Do not install the lift alone.
Install the lift on firm and level ground.
Verify the lower frame of the lift is level
before each use.
Turn the power off during periods of non-use.
This hoist is a heavy piece of equipment please
use with care.
The lift should not be used for any other
purpose besides the lifting of boats & watercraft.
WARNING
part # Y354-0001
Manufactured under one or more of the following patents:
#4895479, #4900187, #5143182, #5184914, #5311970,
#6318929, #6602022, #6837651, #7021861, #7210420,
#7712425, #D503692 Canada #2089044
Other patents pending P A T E N T E D D E S I G N
Do not exceed the maximum weight capacity
specified for the lift.
4,000 LBS
DANGER
MAXIMUM CAPACITY
T O T A L
B O T H
L I F T S
before each use.
3
In the following pages various symbols are used:
indicates an illustration for a procedure.
indicates a major part described in the parts list on pages 4 and 5.
or indicate hardware items shown above and described in the parts list
on pages 4 and 5.
1&2
23
AA
1
After the lift is assembled and installed, all
fasteners should be checked for proper tightness
and reinspected periodically.
INSPECT
the lift monthly
for frayed hoses, loose
fasteners and corrosion
Before Using:
Read this manual
completely!
!
!
!
lift unattended
OIL INJECTED INTO THE SKIN FROM HIGH PRESSURE
LEAKS IN HYDRAULIC SYSTEMS CAN CAUSE SEVERE
INJURY. MOST DAMAGE OCCURS DURING THE FIRST
FEW HOURS. SEEK MEDICAL ATTENTION IMMEDIATELY.
SURGICAL REMOVAL OF OIL MAY BE NECESSARY.
USE ONLY BASTA APPROVED BIODEGRADABLE HYDRAULIC FLUID

Assembly Instructions .........................................................................Pages 6 - 17
First Use / Adjustments ..……………...........................................................Page 18
Basta Marine Boat Lift Accessories ....…………………............….….….Page 23
Parts List and Diagrams ..................................................................Pages 4 - 5, 19
Troubleshooting / FAQ
Maintenance
.…...........................................................................Page 21
......................…...........................................................................Page 20
2
INDEX
Warning......………………..............................................................................Page 2, 3
Warranty .............................…...........................................................................Page 22
NOTE:Your boat lift is a very heavy piece of equipment. Improper use could result in
serious injury or death. For the safety of people and property please review the safety
guidelines below for your new boat lift.
Do not exceed the maximum weight capacity
specified for the lift. SEE PAGE 17.
Passengers should stand clear of the lift and not
be aboard when the lift is in operation.
Do not play on or near the lift.
Leave your automatic bilge pump turned on the
automatic setting to prevent the accumulation of
rain water.
Service your lift regularly.
Do not service the unit with the boat on the lift.
Use a mooring line for additional security.
Only use Basta Marine approved oil in lift.
Special biodegradable non-toxic hydraulic fluid
Visually inspect all parts and assemblies for
defects and damage prior to assembling the
lift.
Do not install the lift alone.
Install the lift on firm and level ground.
Verify the lower frame of the lift is level
before each use.
Turn the power off during periods of non-use.
This hoist is a heavy piece of equipment please
use with care.
The lift should not be used for any other
purpose besides the lifting of boats & watercraft.
WARNING
part # Y354-0001
Manufactured under one or more of the following patents:
#4895479, #4900187, #5143182, #5184914, #5311970,
#6318929, #6602022, #6837651, #7021861, #7210420,
#7712425, #D503692 Canada #2089044
Other patents pending P A T E N T E D D E S I G N
Do not exceed the maximum weight capacity
specified for the lift.
4,000 LBS
DANGER
MAXIMUM CAPACITY
T O T A L
B O T H
L I F T S
before each use.
3
In the following pages various symbols are used:
indicates an illustration for a procedure.
indicates a major part described in the parts list on pages 4 and 5.
or indicate hardware items shown above and described in the parts list
on pages 4 and 5.
1&2
23
AA
1
After the lift is assembled and installed, all
fasteners should be checked for proper tightness
and reinspected periodically.
INSPECT
the lift monthly
for frayed hoses, loose
fasteners and corrosion
Before Using:
Read this manual
completely!
!
!
!
lift unattended
OIL INJECTED INTO THE SKIN FROM HIGH PRESSURE
LEAKS IN HYDRAULIC SYSTEMS CAN CAUSE SEVERE
INJURY. MOST DAMAGE OCCURS DURING THE FIRST
FEW HOURS. SEEK MEDICAL ATTENTION IMMEDIATELY.
SURGICAL REMOVAL OF OIL MAY BE NECESSARY.
USE ONLY BASTA APPROVED BIODEGRADABLE HYDRAULIC FLUID

4
GG
MM
MM
MM
MM
CC
FF
EE
CC
HH
HH
LL LL
LL
DD AA
AA AA
AA
BB
BB
BB
BB
DD
7&2
1&2
9
7&2
1&2
9
7&2
1&2
7&2
7&2
1&2
9
9
7&2
1&2
7&2 1&2
1&2
7&2
5
54
4
11&2
4
5
5
4
11&2
19
19
6
14
8
15
15
17&18
15
17&18
3
8
15
13
13 13
13
16
16
16
16
17&18
17&18
17&18
10
10
10
10
KK
JJ
ONLY ONE
LIFT SHOWN
FOR CLARITY
OPTIONAL
5
(8 )
MECHANISM PARTS LIST
SEE PAGES 14-15 FOR ELECTRICAL AND HYDRAULIC PARTS
ITEM PART NO. DESCRIPTION QTY.
JJ
HH
A427-0014
W102-0045
Bunk Rail Assembly, Left
H-frame Arm, Inner
2
8*
KK A427-0015 Bunk Rail Assembly, Right 2
LL
W410-0067 Bunk Board Assembly (part of JJ, KK) (4)
MM
NN
N/A
M621-1002
K200-0127
Base Pivot Bushing
Pivot Block
16
8
ITEM PART NO. DESCRIPTION QTY.
AA
BB
CC
DD
EE
FF
GG
K200-0125
W117-0001
W105-0012
W111-0019
A431-0040
A431-0039
SEE PG. 14
Leg
Foot Pad
Side Rail
Base Crossmember
H-frame, Forward
H-frame, Aft
Hydraulic Cylinder
4
4
4
2
2
2
2
ITEM PART NO. DESCRIPTION QTY.
Y356-0003 anti-seize grease packet 2
S532-1801 P pin SS 4
14
S503-0010 bunk pin SS 8
15
16
S362-0108 nut, 3/8-16 nylock thin SS 8
17
18
F730-0021
plastic cap for 2" ID sq tube
4
19
S503-0016
clevis pin, 3/4 x 3.5 SS
2
20
S503-0011 extension pin SS 0
21
22
23
24
25
S103-0705
S103-0338
S322-0006
bolt, hex head 1/4-20 x 1.75 full thread SS
bolt, hex head 1/2-13 x 1.0 SS
washer, lock 1/4 SS
4
8
8
ITEM PART NO. DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
S362-0008
S313-0008
S313-0007
S322-0007
S342-0007
S503-0015
S103-0515
S503-0012
S314-0032
S103-0516
S522-0801
S520-1706
nut, 3/8-16 nylock SS
washer, flat 3/8 SS
washer, flat 5/16 SS
washer, lock 5/16 SS
nut, 5/16-18 SS
clevis pin 3/4 x 5.0 SS
bolt, hex head 3/8 - 16 x 3-1/2 SS
base pivot pin SS
washer, flat 3/4 nylon
bolt, hex head 3/8 - 16 x 3-3/4 SS
ring cotter pin 3/4 x .091 SS
cotter pin 3/16 x 2.0 SS
12
32
12
12
12
2
8
8
4
12
4
8
(8 )
(16 )
(16 )
QUANTITIES INCLUDED WITH
OPTIONAL EXTENSION ARMS
20
13
25
24
16
3
11
5
4
23
15
8
10
14
22
7
2
18
6
9
2
2
1
21
17&18
17&18
17&18
10
KK

4
GG
MM
MM
MM
MM
CC
FF
EE
CC
HH
HH
LL LL
LL
DD AA
AA AA
AA
BB
BB
BB
BB
DD
7&2
1&2
9
7&2
1&2
9
7&2
1&2
7&2
7&2
1&2
9
9
7&2
1&2
7&2 1&2
1&2
7&2
5
54
4
11&2
4
5
5
4
11&2
19
19
6
14
8
15
15
17&18
15
17&18
3
8
15
13
13 13
13
16
16
16
16
17&18
17&18
17&18
10
10
10
10
KK
JJ
ONLY ONE
LIFT SHOWN
FOR CLARITY
OPTIONAL
5
(8 )
MECHANISM PARTS LIST
SEE PAGES 14-15 FOR ELECTRICAL AND HYDRAULIC PARTS
ITEM PART NO. DESCRIPTION QTY.
JJ
HH
A427-0014
W102-0045
Bunk Rail Assembly, Left
H-frame Arm, Inner
2
8*
KK A427-0015 Bunk Rail Assembly, Right 2
LL
W410-0067 Bunk Board Assembly (part of JJ, KK) (4)
MM
NN
N/A
M621-1002
K200-0127
Base Pivot Bushing
Pivot Block
16
8
ITEM PART NO. DESCRIPTION QTY.
AA
BB
CC
DD
EE
FF
GG
K200-0125
W117-0001
W105-0012
W111-0019
A431-0040
A431-0039
SEE PG. 14
Leg
Foot Pad
Side Rail
Base Crossmember
H-frame, Forward
H-frame, Aft
Hydraulic Cylinder
4
4
4
2
2
2
2
ITEM PART NO. DESCRIPTION QTY.
Y356-0003 anti-seize grease packet 2
S532-1801 P pin SS 4
14
S503-0010 bunk pin SS 8
15
16
S362-0108 nut, 3/8-16 nylock thin SS 8
17
18
F730-0021
plastic cap for 2" ID sq tube
4
19
S503-0016
clevis pin, 3/4 x 3.5 SS
2
20
S503-0011 extension pin SS 0
21
22
23
24
25
S103-0705
S103-0338
S322-0006
bolt, hex head 1/4-20 x 1.75 full thread SS
bolt, hex head 1/2-13 x 1.0 SS
washer, lock 1/4 SS
4
8
8
ITEM PART NO. DESCRIPTION QTY.
1
2
3
4
5
6
7
8
9
10
11
12
13
S362-0008
S313-0008
S313-0007
S322-0007
S342-0007
S503-0015
S103-0515
S503-0012
S314-0032
S103-0516
S522-0801
S520-1706
nut, 3/8-16 nylock SS
washer, flat 3/8 SS
washer, flat 5/16 SS
washer, lock 5/16 SS
nut, 5/16-18 SS
clevis pin 3/4 x 5.0 SS
bolt, hex head 3/8 - 16 x 3-1/2 SS
base pivot pin SS
washer, flat 3/4 nylon
bolt, hex head 3/8 - 16 x 3-3/4 SS
ring cotter pin 3/4 x .091 SS
cotter pin 3/16 x 2.0 SS
12
32
12
12
12
2
8
8
4
12
4
8
(8 )
(16 )
(16 )
QUANTITIES INCLUDED WITH
OPTIONAL EXTENSION ARMS
20
13
25
24
16
3
11
5
4
23
15
8
10
14
22
7
2
18
6
9
2
2
1
21
17&18
17&18
17&18
10
KK

6
ASSEMBLY INSTRUCTIONS
1
1
1
2
3
1
3
2
NOTE: assemble lift on level ground
and adjust legs so that lift base
frame is level during lift assembly.
NOTE: use a small amount of 'moly' lube on bolt threads
QTY 4: 3/8 x 3.75" bolts ("10")
QTY 4: 3/8 nylon insert lock nuts ("1")
QTY 8: 3/8 flat washers ("2")
QTY 4: leg P pins ("15")
QTY 4: 1/2 x 1.0" bolts ("23")
A A
BB
DD
NOTE:
the 3 different holes shown
can be used for pin '15' to
allow fine height adjustment
after installation
15
1+2
DOWN
to lock 23
NOTE:
do not tighten bolt ‘23’ until Step 18
Feet and Legs [4 places]
1Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.
10+2
7
QTY 4: 3/8 x 3.75" bolts ("10")
QTY 8: 3/8 flat washers ("2")
QTY 4: 3/8 nylon insert lock nuts ("1")
QTY 4: 3/8 x 3.75" bolts ("10")
QTY 8: 3/8 flat washers ("2")
QTY 4: 3/8 nylon insert lock nuts ("1")
CC
DD
DD
Forward Crossmember
2
Aft Crossmember
3
1+2
10+2
10+2
10+2
1+2
Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.

6
ASSEMBLY INSTRUCTIONS
1
1
1
2
3
1
3
2
NOTE: assemble lift on level ground
and adjust legs so that lift base
frame is level during lift assembly.
NOTE: use a small amount of 'moly' lube on bolt threads
QTY 4: 3/8 x 3.75" bolts ("10")
QTY 4: 3/8 nylon insert lock nuts ("1")
QTY 8: 3/8 flat washers ("2")
QTY 4: leg P pins ("15")
QTY 4: 1/2 x 1.0" bolts ("23")
A A
BB
DD
NOTE:
the 3 different holes shown
can be used for pin '15' to
allow fine height adjustment
after installation
15
1+2
DOWN
to lock 23
NOTE:
do not tighten bolt ‘23’ until Step 18
Feet and Legs [4 places]
1Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.
10+2
7
QTY 4: 3/8 x 3.75" bolts ("10")
QTY 8: 3/8 flat washers ("2")
QTY 4: 3/8 nylon insert lock nuts ("1")
QTY 4: 3/8 x 3.75" bolts ("10")
QTY 8: 3/8 flat washers ("2")
QTY 4: 3/8 nylon insert lock nuts ("1")
CC
DD
DD
Forward Crossmember
2
Aft Crossmember
3
1+2
10+2
10+2
10+2
1+2
Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.

8
MM
NOTE: orient flat faces toward lift center
Pivot Blocks [8 places]
4Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
QTY 8: pivot blocks ("MM")
6
4
6
5
4
4
5
6
5
4
5
6
6
5
4
9
QTY 16: plastic bushings ("LL")
13
78
NOTE: forward H-frame
is shown. Aft H-frame
installation is the same
LL
LL
18+2
H-frame Bushings [fwd & aft]
BOTH
H-FRAMES
5
H-frames [4 places]
6Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.
are installed
with curved
side up
EE
NOTE: no washer on this end
QTY 8: THIN 3/8 nylon insert lock nuts ("18")
QTY 8: 3/8 flat washers ("2")
QTY 8: 3/8 x 3.5 bolts ("7")
QTY 8: cotter pins ("13")
QTY 8: base pivot pins ("8")
- note shorter length!
bend out

8
MM
NOTE: orient flat faces toward lift center
Pivot Blocks [8 places]
4Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
QTY 8: pivot blocks ("MM")
6
4
6
5
4
4
5
6
5
4
5
6
6
5
4
9
QTY 16: plastic bushings ("LL")
13
78
NOTE: forward H-frame
is shown. Aft H-frame
installation is the same
LL
LL
18+2
H-frame Bushings [fwd & aft]
BOTH
H-FRAMES
5
H-frames [4 places]
6Assemble lift on level ground and adjust legs so
that lift base frame is level during lift assembly.
are installed
with curved
side up
EE
NOTE: no washer on this end
QTY 8: THIN 3/8 nylon insert lock nuts ("18")
QTY 8: 3/8 flat washers ("2")
QTY 8: 3/8 x 3.5 bolts ("7")
QTY 8: cotter pins ("13")
QTY 8: base pivot pins ("8")
- note shorter length!
bend out

10
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
Install cylinder with lift in 'down' position
QTY 2: 3/4 x 3.5" clevis pin ("21")
QTY 2: 3/4 x 5" clevis pin ("6")
QTY 4: ring type cotter pins ("11")
QTY 4: 3/4 nylon flat washers ("9")
Cylinders
7NOTE: install cylinders with hose fittings facing down!
NOTE:
install plastic
washers here
NO
washers
here
11+6
11+21
9
8
7
9
11
Important note:
Install cylinder with hose fittings facing down!
Cylinders
8
port
points
down
Optional extension arms only:
Inner Arms [8 places if used]
QTY 4: extension pins ("22")
QTY 4: 1/4 x 1.75" bolt ("24")
QTY 4: 1/4 lock washer ("25")
9
HH
22
24+25
7
8
9
6

10
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
Install cylinder with lift in 'down' position
QTY 2: 3/4 x 3.5" clevis pin ("21")
QTY 2: 3/4 x 5" clevis pin ("6")
QTY 4: ring type cotter pins ("11")
QTY 4: 3/4 nylon flat washers ("9")
Cylinders
7NOTE: install cylinders with hose fittings facing down!
NOTE:
install plastic
washers here
NO
washers
here
11+6
11+21
9
8
7
9
11
Important note:
Install cylinder with hose fittings facing down!
Cylinders
8
port
points
down
Optional extension arms only:
Inner Arms [8 places if used]
QTY 4: extension pins ("22")
QTY 4: 1/4 x 1.75" bolt ("24")
QTY 4: 1/4 lock washer ("25")
9
HH
22
24+25
7
8
9
6

12
10
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
12
12
10
10
12
12
10
10
Complete Step 11 to raise lift to install
screws for pins. See Step 12 for details.
16
16
KK
JJ
16
16
Bunk Rail Assembly
QTY 8: bunk pivot pins ("16")
13
Power unit
NOTE: always turn unit OFF when not in use
11
CONNECT POWER UNIT
6. Test the lift on dry ground using the Up/Down Switch
and the Key Fob Transmitters. Inspect the system
for leaks.
1. The Hydraulic Power Unit will arrive fully assembled.
Make sure all the connections are snug to prevent
leaks or loss of power to the unit.
Install a Group 31 Deep Discharge AGM Battery as
shown above. Be sure to connect the Red Battery
Cable to the p ositive terminal and the Black Battery
Cable to the negative terminal.
NOTE: Ensure battery cables are correctly connected
3. Slide the Hydraulic Hose Assembly through the
access hole in the side of the fiberglass Enclosure
and attach the ends to their corresponding
Quick Couplers.
and their terminals are tight (use a wrench).
one
inch
only add fluid with lift
in DOWN position
Ensure each Quick Coupler is
completely seated and tight with
no gap at the connection joint.
Connection must be tight to open internal
check valve and allow fluid to flow. USE PLIERS
DO NOT SUBMERSE
Keep inside dry
4. Plug the cable from the Solar Panel into the connector
on the wiring harness that comes from the Remote
Control Unit as shown in the picture on Page 14.
NO GAP!
Prevent unauthorized use -
KEEP BOX LOCKED
hydraulic fluid level shown
with lift in DOWN position 2.
COMPLETE POWER UNIT
# H653-0001
power
switch
POSITIVE BATTERY
CABLE (RED)
# R711-1010
NEGATIVE BATTERY
CABLE (BLACK)
# R711-1005
HOSE ASSEMBLIES
# H123-0001
remote
receivers
up/down
switches
MALE QUICK COUPLER
# H770-0002
FEMALE QUICK COUPLER
# H770-0001
5. Read Operating Instructions on Page 17.
SHORT
AT AFT
END
LONG AT
FORWARD
END
plate plate
pre-installed
bushings are

12
10
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
12
12
10
10
12
12
10
10
Complete Step 11 to raise lift to install
screws for pins. See Step 12 for details.
16
16
KK
JJ
16
16
Bunk Rail Assembly
QTY 8: bunk pivot pins ("16")
13
Power unit
NOTE: always turn unit OFF when not in use
11
CONNECT POWER UNIT
6. Test the lift on dry ground using the Up/Down Switch
and the Key Fob Transmitters. Inspect the system
for leaks.
1. The Hydraulic Power Unit will arrive fully assembled.
Make sure all the connections are snug to prevent
leaks or loss of power to the unit.
Install a Group 31 Deep Discharge AGM Battery as
shown above. Be sure to connect the Red Battery
Cable to the p ositive terminal and the Black Battery
Cable to the negative terminal.
NOTE: Ensure battery cables are correctly connected
3. Slide the Hydraulic Hose Assembly through the
access hole in the side of the fiberglass Enclosure
and attach the ends to their corresponding
Quick Couplers.
and their terminals are tight (use a wrench).
one
inch
only add fluid with lift
in DOWN position
Ensure each Quick Coupler is
completely seated and tight with
no gap at the connection joint.
Connection must be tight to open internal
check valve and allow fluid to flow. USE PLIERS
DO NOT SUBMERSE
Keep inside dry
4. Plug the cable from the Solar Panel into the connector
on the wiring harness that comes from the Remote
Control Unit as shown in the picture on Page 14.
NO GAP!
Prevent unauthorized use -
KEEP BOX LOCKED
hydraulic fluid level shown
with lift in DOWN position 2.
COMPLETE POWER UNIT
# H653-0001
power
switch
POSITIVE BATTERY
CABLE (RED)
# R711-1010
NEGATIVE BATTERY
CABLE (BLACK)
# R711-1005
HOSE ASSEMBLIES
# H123-0001
remote
receivers
up/down
switches
MALE QUICK COUPLER
# H770-0002
FEMALE QUICK COUPLER
# H770-0001
5. Read Operating Instructions on Page 17.
SHORT
AT AFT
END
LONG AT
FORWARD
END
plate plate
pre-installed
bushings are

14
# R811-0010
Remote Control Receiver with Fobs
Remote Key Fobs
Please order replacement parts by PART NO. and DESCRIPTION
Hydraulic Fluid (quart)
pre-charged with
hydraulic fluid
Hydraulic Cylinder Assembly
#H310-0008
(Item GG on pg 4)
CONTROL PANEL
ASSEMBLY
# R815-0010
BATTERY SAFETY IS IMPORTANT
Follow all battery manufacturer’s
warnings and safety information.
# R812-0011 # Y354-0001
Hydraulic Cylinder
#H412-4201
Hydraulic Fitting
#H711-0002
Hose Assembly
#H123-0001
15
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
12
12
Bunk Rail Assembly
12
QTY 4: 1/4 x 1.75” bolts ("24")
QTY 4: 1/4 lock washers ("25")
24+25
KK
JJ
raise lift to install 1/4 x 1.75” bolts ("24")
24+25 24+25
POWER UNIT
SUB-ASSEMBLY
# H603-0013
POWER SYSTEM COMPONENTS
Padlock
not included
SOLAR PANEL
# R281-0004
ENCLOSURE
# C243-0004
pre-wired
with wiring
harness
12
12
17+18

14
# R811-0010
Remote Control Receiver with Fobs
Remote Key Fobs
Please order replacement parts by PART NO. and DESCRIPTION
Hydraulic Fluid (quart)
pre-charged with
hydraulic fluid
Hydraulic Cylinder Assembly
#H310-0008
(Item GG on pg 4)
CONTROL PANEL
ASSEMBLY
# R815-0010
BATTERY SAFETY IS IMPORTANT
Follow all battery manufacturer’s
warnings and safety information.
# R812-0011 # Y354-0001
Hydraulic Cylinder
#H412-4201
Hydraulic Fitting
#H711-0002
Hose Assembly
#H123-0001
15
NOTE: use a small amount of 'moly' lube on bolt threads
ASSEMBLY INSTRUCTIONS
12
12
Bunk Rail Assembly
12
QTY 4: 1/4 x 1.75” bolts ("24")
QTY 4: 1/4 lock washers ("25")
24+25
KK
JJ
raise lift to install 1/4 x 1.75” bolts ("24")
24+25 24+25
POWER UNIT
SUB-ASSEMBLY
# H603-0013
POWER SYSTEM COMPONENTS
Padlock
not included
SOLAR PANEL
# R281-0004
ENCLOSURE
# C243-0004
pre-wired
with wiring
harness
12
12
17+18

Lower the lift completely, then raise it slightly.
Disconnect the hydraulic hose quick couplers in the Power Unit box to
separate it from the lift.
14
13
Move the lift into its operational position
17
16
Go to 'First Use' instructions on Page 17.
Re-connect the hydraulic hose quick couplers in the Power Unit box.
Raise the lift fully and finish adjusting the legs so that the base frame
is level side-to-side and forward-to-aft.
15 Adjust the legs to provide enough water over the lift so that the boat
will not have to be "driven" hard up onto the bunks.
86.75"
117"
21" 36"
28"
shown
without
extension
arms 15"
without extensions - 57"
with extensions - 62” - 80"
78"
17"
Use these diagrams to help place the lift
18
FIRST USE AND ADJUSTMENTS
Follow this “first use section” during your first loading of a boat onto the boat lift.
These are required adjustments to make the lift work correctly.
1. Place the boat or water craft over the lift to the following specifications:
a. The craft should be centered between the bunks side-to side.
b. Move the craft forward to position its center of buoyancy near the bunks' centers.
Centering Devices may be helpful when positioning your craft. See rear cover.
Disembark and raise the boat. If more than two inches of settling occurs, STOP, carefully
lower the lift to remove the boat and re-level the lift. Continue repeating this step until the
boat lift can be raised into the full Over-Center position without settling.
tm
3. Remove the boat. Verify that the lift frame is level. Re-level the framework if necessary.
NOTE: If you purchased a new water craft, be sure it is within the weight
capacity limits of the lift. Also remember that these adjustments will
have to be done again to accommodate the new craft.
First test lift on dry ground for oil leaks, remote control function and correct operation.
2.
IMPORTANT: After installation, the legs MUST be adjusted so that the lift frame is level.
TM
Always turn unit OFF when not in use
Lift must move into Over-Center position when fully raised.
H-frame arms should appear to be tilted slightly forward.
Tighten the pinch bolts
that were installed in Step 1.
4. Check all bolts for proper tightness.
Maximum lifting capacity is 2,000 pounds per side.
DO NOT OVERLOAD!
Do not exceed the maximum weight capacity
specified for the lift.
4,000 LBS
DANGER
MAXIMUM CAPACITY
T O T A L
B O T H
L I F T S
16 17

Lower the lift completely, then raise it slightly.
Disconnect the hydraulic hose quick couplers in the Power Unit box to
separate it from the lift.
14
13
Move the lift into its operational position
17
16
Go to 'First Use' instructions on Page 17.
Re-connect the hydraulic hose quick couplers in the Power Unit box.
Raise the lift fully and finish adjusting the legs so that the base frame
is level side-to-side and forward-to-aft.
15 Adjust the legs to provide enough water over the lift so that the boat
will not have to be "driven" hard up onto the bunks.
86.75"
117"
21" 36"
28"
shown
without
extension
arms 15"
without extensions - 57"
with extensions - 62” - 80"
78"
17"
Use these diagrams to help place the lift
18
FIRST USE AND ADJUSTMENTS
Follow this “first use section” during your first loading of a boat onto the boat lift.
These are required adjustments to make the lift work correctly.
1. Place the boat or water craft over the lift to the following specifications:
a. The craft should be centered between the bunks side-to side.
b. Move the craft forward to position its center of buoyancy near the bunks' centers.
Centering Devices may be helpful when positioning your craft. See rear cover.
Disembark and raise the boat. If more than two inches of settling occurs, STOP, carefully
lower the lift to remove the boat and re-level the lift. Continue repeating this step until the
boat lift can be raised into the full Over-Center position without settling.
tm
3. Remove the boat. Verify that the lift frame is level. Re-level the framework if necessary.
NOTE: If you purchased a new water craft, be sure it is within the weight
capacity limits of the lift. Also remember that these adjustments will
have to be done again to accommodate the new craft.
First test lift on dry ground for oil leaks, remote control function and correct operation.
2.
IMPORTANT: After installation, the legs MUST be adjusted so that the lift frame is level.
TM
Always turn unit OFF when not in use
Lift must move into Over-Center position when fully raised.
H-frame arms should appear to be tilted slightly forward.
Tighten the pinch bolts
that were installed in Step 1.
4. Check all bolts for proper tightness.
Maximum lifting capacity is 2,000 pounds per side.
DO NOT OVERLOAD!
Do not exceed the maximum weight capacity
specified for the lift.
4,000 LBS
DANGER
MAXIMUM CAPACITY
T O T A L
B O T H
L I F T S
16 17

18
TROUBLESHOOTING PROBLEMS AND FAQ TROUBLESHOOTING PROBLEMS AND FAQ
Q: THE PUMP DOESN’T RUN
A: Check the battery charge and recharge if necessary.
A: Check the battery connections, clean and re-secure
if necessary.
Q: THE BATTERY WILL NOT HOLD A CHARGE
A: Verify that the loaded boat is not exceeding the weight
capacity of the lift. If the battery is a flooded-cell type,
check the electrolyte level.
A: Ensure the solar panel is properly connected.
A: Re-align the solar panel for proper exposure to the sun.
A: Recharge the battery with a 10 amp charger and
check the charge again.
A: Have the battery tested. It may be old and
require replacement.
A: If the lift is being used frequently during the day, it
may be necessary to use a 110-volt maintainer/charger.
Q: THE REMOTE CONTROL IS NOT FUNCTIONING
A:
A: Verify that the power unit battery is charged and connections are tight.
A: Reprogram the remote key fobs.
Q: HOW DOES THE REMOTE CONTROL WORK?
Q: DOES THE LIFT HAVE TO GO ALL THE WAY UP?
A: YES - in order for your lift to function as intended the lift
must ALWAYS be stored in the full upright position when
the boat is unattended.
Q: IS MY BOAT SECURE?
A: Yes, once you verify that the lift is Over-Center , switch
off the power and lock the power unit box, there is less
chance of theft.
™
Q: DO I NEED A MOORING LINE?
A: Under most circumstances one mooring line is sufficient
to prevent the boat from drifting away if the lift is
inadvertently lowered or the water level rises.
Q: HOW MUCH SUN DOES THE SOLAR PANEL NEED?
A: The panel should receive constant sun for at least 8 hours a day.
Q: WHAT IF I GET A NEW BOAT?
A: Re-leveling the boat lift may be necessary. A new lift
will be required if the boat exceeds the weight capacity
of your current lift.
Q: THE PUMP RUNS, BUT THE LIFT DOESN’T MOVE
A: Check the 'quick couplers' in the Power Unit. If they are not
screwed together tight enough, built-in check valves will
not allow fluid to flow. See Page 12.
A: Check the fluid level. See Page 12.
Q: IS THE HYDRAULIC FLUID SAFE FOR THE FISH?
A: We use a special low-toxicity hydraulic fluid that is safe
for the environment. This fluid is different than food-grade
oil. Only use Basta Boatlifts approved fluid in your
hydraulic system.
Q: HOW DO I CHANGE THE HYDRAULIC FLUID?
A: Our fluid should not require replacement for a considerable
amount of time. If yours has been contaminated or the
hydraulic power unit has been replaced, visit our web site at
www.gobasta.com for detailed instructions.
POWER-UP
At power-up the remote fob function has a ten second delay.
Failure to wait for this ten seconds can make the wait time much
longer.
LIFT OPERATION
The remote fob is non-functional until it is enabled by
depressing the lower right button momentarily. After the
initial ten second delay, depressing the unlock button enables
operation using the remote fob. The lockout is re-enabled after
60 seconds without a button press.
Lift operation using the fob is limited to 120 seconds of
continuous operation. If a longer cycle is needed it is necessary
to release and then re-depress the button.
LOW BATTERY LOCKOUT
This control incorporates a low voltage lockout which is
intended to protect the battery from abuse and over-discharge.
When the battery drops below the low battery threshold during
pump operation, further activation using the Fob is not allowed.
The battery needs to be checked prior to further operation. The
manual switches will allow the lift to operate if sufficient battery
power is present.
FOB PROGRAMMING
At initial power up there is a five second window when it is
possible to reprogram the receiver to enroll a remote fob. Up to
four fobs may be enrolled. If a fifth fob is enrolled, the first
enrolled fob will fall off the list.
To enroll a fob, turn off the power to the lift for fifteen or more
seconds. When power is turned back on press both the UP and
DOWN buttons on the fob simultaneously. This must be done
within the first five seconds after power is applied.
LIGHTING CIRCUIT
The lighting circuit is activated whenever the lift is operated. The
lights stay on for 2 minutes after the lift is operated
The lights may be manually turned on or off by depressing the
lower left button on the remote Fob. When manually enabled the
lights will automatically turn off after 4 minutes. This is prevents
accidental battery discharge.
STORAGE
Always leave the boat in the fully raised, Over-Center™
position with the power off.
FOR ASSISTANCE OR SERVICE:
Contact your local dealer or call 1 - 866 - GO - BASTA
website: www.gobasta.com email: [email protected]
19
MAINTENANCE
tm
Your Basta Boatlift requires very little maintenance once installed.
Occasionally wipe the solar panel with a clean, damp cloth to preserve its charging performance.
Every 6 months, we recommend:
Inspect the hoses, cylinders and fittings for leaks and wear.
Check the wire terminals for snugness and corrosion.
Check the hydraulic fluid and battery electrolyte levels:
The battery electrolyte should be slightly above the indicator ring in each cell.
Carefully add DISTILLED water if necessary. Do not over-fill.
The hydraulic fluid level should be about one inch below the top of the reservoir with the lift DOWN.
DO NOT add fluid with the lift in the raised position!
Use only Basta approved fluid.
We recommend Chevron Clarity® AW ISO 32 or CITGO Aquamarine® 46 hydraulic oils.
DATE: WHAT WAS DONE:
The battery in the key fob transmitter may be low. Replace it with a
new lithium CR2032. These are widely available at variety, hardware
and even grocery stores. Polarity is marked on the battery holder.

18
TROUBLESHOOTING PROBLEMS AND FAQ TROUBLESHOOTING PROBLEMS AND FAQ
Q: THE PUMP DOESN’T RUN
A: Check the battery charge and recharge if necessary.
A: Check the battery connections, clean and re-secure
if necessary.
Q: THE BATTERY WILL NOT HOLD A CHARGE
A: Verify that the loaded boat is not exceeding the weight
capacity of the lift. If the battery is a flooded-cell type,
check the electrolyte level.
A: Ensure the solar panel is properly connected.
A: Re-align the solar panel for proper exposure to the sun.
A: Recharge the battery with a 10 amp charger and
check the charge again.
A: Have the battery tested. It may be old and
require replacement.
A: If the lift is being used frequently during the day, it
may be necessary to use a 110-volt maintainer/charger.
Q: THE REMOTE CONTROL IS NOT FUNCTIONING
A:
A: Verify that the power unit battery is charged and connections are tight.
A: Reprogram the remote key fobs.
Q: HOW DOES THE REMOTE CONTROL WORK?
Q: DOES THE LIFT HAVE TO GO ALL THE WAY UP?
A: YES - in order for your lift to function as intended the lift
must ALWAYS be stored in the full upright position when
the boat is unattended.
Q: IS MY BOAT SECURE?
A: Yes, once you verify that the lift is Over-Center , switch
off the power and lock the power unit box, there is less
chance of theft.
™
Q: DO I NEED A MOORING LINE?
A: Under most circumstances one mooring line is sufficient
to prevent the boat from drifting away if the lift is
inadvertently lowered or the water level rises.
Q: HOW MUCH SUN DOES THE SOLAR PANEL NEED?
A: The panel should receive constant sun for at least 8 hours a day.
Q: WHAT IF I GET A NEW BOAT?
A: Re-leveling the boat lift may be necessary. A new lift
will be required if the boat exceeds the weight capacity
of your current lift.
Q: THE PUMP RUNS, BUT THE LIFT DOESN’T MOVE
A: Check the 'quick couplers' in the Power Unit. If they are not
screwed together tight enough, built-in check valves will
not allow fluid to flow. See Page 12.
A: Check the fluid level. See Page 12.
Q: IS THE HYDRAULIC FLUID SAFE FOR THE FISH?
A: We use a special low-toxicity hydraulic fluid that is safe
for the environment. This fluid is different than food-grade
oil. Only use Basta Boatlifts approved fluid in your
hydraulic system.
Q: HOW DO I CHANGE THE HYDRAULIC FLUID?
A: Our fluid should not require replacement for a considerable
amount of time. If yours has been contaminated or the
hydraulic power unit has been replaced, visit our web site at
www.gobasta.com for detailed instructions.
POWER-UP
At power-up the remote fob function has a ten second delay.
Failure to wait for this ten seconds can make the wait time much
longer.
LIFT OPERATION
The remote fob is non-functional until it is enabled by
depressing the lower right button momentarily. After the
initial ten second delay, depressing the unlock button enables
operation using the remote fob. The lockout is re-enabled after
60 seconds without a button press.
Lift operation using the fob is limited to 120 seconds of
continuous operation. If a longer cycle is needed it is necessary
to release and then re-depress the button.
LOW BATTERY LOCKOUT
This control incorporates a low voltage lockout which is
intended to protect the battery from abuse and over-discharge.
When the battery drops below the low battery threshold during
pump operation, further activation using the Fob is not allowed.
The battery needs to be checked prior to further operation. The
manual switches will allow the lift to operate if sufficient battery
power is present.
FOB PROGRAMMING
At initial power up there is a five second window when it is
possible to reprogram the receiver to enroll a remote fob. Up to
four fobs may be enrolled. If a fifth fob is enrolled, the first
enrolled fob will fall off the list.
To enroll a fob, turn off the power to the lift for fifteen or more
seconds. When power is turned back on press both the UP and
DOWN buttons on the fob simultaneously. This must be done
within the first five seconds after power is applied.
LIGHTING CIRCUIT
The lighting circuit is activated whenever the lift is operated. The
lights stay on for 2 minutes after the lift is operated
The lights may be manually turned on or off by depressing the
lower left button on the remote Fob. When manually enabled the
lights will automatically turn off after 4 minutes. This is prevents
accidental battery discharge.
STORAGE
Always leave the boat in the fully raised, Over-Center™
position with the power off.
FOR ASSISTANCE OR SERVICE:
Contact your local dealer or call 1 - 866 - GO - BASTA
website: www.gobasta.com email: [email protected]
19
MAINTENANCE
tm
Your Basta Boatlift requires very little maintenance once installed.
Occasionally wipe the solar panel with a clean, damp cloth to preserve its charging performance.
Every 6 months, we recommend:
Inspect the hoses, cylinders and fittings for leaks and wear.
Check the wire terminals for snugness and corrosion.
Check the hydraulic fluid and battery electrolyte levels:
The battery electrolyte should be slightly above the indicator ring in each cell.
Carefully add DISTILLED water if necessary. Do not over-fill.
The hydraulic fluid level should be about one inch below the top of the reservoir with the lift DOWN.
DO NOT add fluid with the lift in the raised position!
Use only Basta approved fluid.
We recommend Chevron Clarity® AW ISO 32 or CITGO Aquamarine® 46 hydraulic oils.
DATE: WHAT WAS DONE:
The battery in the key fob transmitter may be low. Replace it with a
new lithium CR2032. These are widely available at variety, hardware
and even grocery stores. Polarity is marked on the battery holder.

21
Basta Boatlifts Limited Warranty
Thank you for investing in one of the finest PWC lifts in the world. We pride
ourselves in knowing our product will safely and reliably be the conduit to your fun
on the water. Welcome to the Basta Boatlifts family and Boat Happy!
Basta Inc. dba Basta Boatlifts (“Company”) warrants its Products (purchased
after January 1, 2020) for non-commercial use for a period of,
. 16 years against manufacturing defects in steel and aluminum
lift frame welds.
. 3 years against defects in materials and workmanship including
hydraulic components, charging system, remote controls, dock box,
bunks, canopies, and accessories.
. 1 year battery warranty when maintained in accordance with
battery manufacturer’s guidance for batteries supplied
by the Company,
to the original Purchaser (“Purchaser”), beginning from date of purchase of the
Product from Company. If the Product is purchased from an authorized Company
Reseller, the warranty term begins upon the date the new Product is sold to the end
Purchaser (“Warranty Start Date”).
Annual inspection of the Product bolts, pins, hydraulics, pump, electronics, and
welds, by a Company employee or Company authorized agent, shall be conducted.
Failure to undertake such maintenance shall constitute “abuse” under Exclusions
below.
Company has the right to modify Products at any time without incurring any
obligation to make the same or similar modifications on Products previously
manufactured or purchased.
Terms And Conditions:
Purchaser must register Product for a valid Warranty. Warranty registration may be
found and submitted at:
https://bastaboatlifts.com/support.
Notice requirements and remedies:
If the Purchaser discovers a defect, the purchaser shall immediately notify the
Company in writing by submission of a Warranty Request form. Warranty Request
forms may be found and submitted at https://bastaboatlifts.com/support. Upon
receipt of a complete Warranty Request form and after confirmation by Company
that the Product is defective, the Company, or its authorized Company dealer or
agent, will, at the Company’s sole discretion:
1- repair the Product or,
2-replace the defective part with a new or reconditioned part, or
3-refund the purchase price of the Product.
Confirmation of the defect shall require that reasonable proof of the defect
be provided by Purchaser to Company or Company authorized agent, and
may include that the Product or part be returned to Company for inspection
at the Company’s initial expense. Replacement parts for Products outside the
United States will be shipped in the next authorized Dealer shipment unless
Purchaser agrees to pay for door to door freight of warranted Product. Warranty
replacement shall not extend the original warranty of the defective Products.
Labor for warranty work to be provided by the Company’s Authorized dealer for a
period of 3 years from Warranty Start Date, provided there is an active Authorized
Dealer within 50 miles of the location of the Product. Labor will not be provided for
direct purchases from Company or when an active Authorized Dealer is not located
within 50 miles of the location of the Product.
Warranty requests received after expiration of warranty term will not be
covered under this warranty regardless of when the defect occurred or was
discovered.
Confirmation of the defect shall require that reasonable proof of the defect be
provided by Purchaser to Company or Company authorized agent, and may include
that the Product or part be Returned to Company for inspection at the Company’s
initial expense. Replacement parts for Products outside the United States will be
shipped in the next authorized Dealer shipment unless Purchaser agrees to pay for
door to door freight of warranted Product. Warranty replacement shall not extend
the original warranty of the defective Products.
Labor for warranty work to be provided by the Company’s Authorized dealer for
a period of 3 years from Warranty Start Date, provided there is an active
Authorized Dealer within 50 miles of the location of the Product. Labor will not be
provided for direct purchases from Company or when an active Authorized Dealer
is not located within 50 miles of the location of the Product.
Warranty requests received after expiration of warranty term will not be covered
under this warranty regardless of when the defect occurred or was discovered.
Exclusions:
Product changes caused by age or environment (such as marine growth,
heat, corrosion or electrolysis) shall not constitute a defect. In addition, this
warranty does not cover or apply to the following: damages caused by or due to
without limitation: accidents, collision, fire, flood, wind, ice, or any other natural
disaster or acts of God, abuse, misuse, overloading, improper watercraft loading,
use when out of level, faulty assembly or installation. Lift components’ fluid levels
and condition, including battery electrolyte (water and acid), hydraulic fluid and
strainer cleaning are maintenance items and are not covered by this warranty.
Sacrificial anodes (zincs), cosmetic concerns and custom coatings are not covered
by this warranty.
Warranty is void if the Product has been modified in any way or if any
Company serial number has been removed or defaced. Product purchased from
Company, but used on non-Company Products are excluded from this warranty.
Limitations:
To the maximum extent permitted by law except as expressly stated herein, there
are no warranties, expressed or implied, by operation of law or otherwise, of the
Product furnished under this Agreement. Seller disclaims any implied warranty of
merchantability or fitness for a particular purpose. The sole remedy for liability of
any kind shall be limited to the remedies provided in this warranty and shall in no
event include any incidental, indirect, special or consequential damages or loss of
use, revenue or profit. Should the company nevertheless be found liable for any
damages, the total liability of the company shall
be limited to the purchase price of the Product.
