Baumatic BCC2220SS User manual

That 1
BCC2220SS 120 cm
Multi-function twin
cavity cooking theatre

User Manual for your Baumatic
BCC2220SS
120 cm Multi-function twin cavity cooking
theatre
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
DD 30/07/08
2

3
Contents
Environmentalnote 4
Important safety information 5 – 9
Specifications 9 – 13
Controlpanel 11
Main oven thermostat control knob 11
Main oven function selector knob 11
Secondary oven function selector and thermostat control knob 12
Hobcontrolknobs 12
Frytopcontrolknob 12
Oven programmer/timer 13
Oven programmer/timer display 13
Setting and using the oven programmer/timer 13 - 18
Setting the time of day and selecting manual operation mode 13
Beforefirstuse 14
Setting the minute minder function 14
Setting the duration function 15
Setting the end cook function 16
Setting the start and end time function 17
Cancelling an automatic cooking function 18
Adjusting the audible signal 18
Selecting a cooking function and temperature 17 - 20
Selecting a main oven function 17 - 18
Main oven function selector knob 18
Main oven cooking function descriptions 19
Main oven thermostat control knob 20
Secondary oven function and thermostat control knob 20
Secondary oven cooking function descriptions 20
Ovenoperatinglight 20
Using and assembling the rotisserie 21 - 22
Cooking guidelines 22
Warnings 23
Using the hob top 23 - 25
Automatic electric ignition 24
Energysavingtips 24
Thefrytopburner 25
Automatic electric ignition 25
Cleaning and maintenance 26 - 28
Cleaning the hob burners 27
Replacing the oven bulb 27
Removing the oven door for cleaning 28
Installation 29 - 38
Positioning 29-31
Gasconnection 31
Ventilation requirements 31 - 32
Gas Safety (Installation and Use) Regulations 32
Gasconnection 33
Gas adjustment 34-35
Minimum flow adjustment for hob gas taps 35
Fittingastabilitychain 36
Electricalconnection 37
Connecting the main supply cable 37 - 38
Replacing the mains supply cable 38
My appliance isn’t working correctly 39 – 40
Contactdetails 41

Environmental note
4
oBaumatic uses are environmentally
friendly and can be recycled.
oall packaging material with due regard for the
environment.
The packaging materials that
Please discard

5
Important safety information
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If yo
are unsure of any of the information contained i
booklet, pleas
u
n this
e contact the Baumatic Technical
ent.
e
otic household use and for
oin
ient temperature of the
on at
o
20 mm to the appliance, will be
ormation given in the installation instructions
ohat this
o
f Baumatic Ltd.
o
uarantee. The foregoing does not
affect your statutory rights.
oService
Engineers or their authorised service agent.
Departm
G neral Information
This appliance is designed for domes
the cooking of domestic foodstuffs.
IMPORTANT: The adjacent furniture and all materials used
the installation must be able to withstand a minimum
temperature of 85°C above the amb
room it is located in, whilst in use.
Certain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouratio
temperatures below the guidelines given above.
Any damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than
the liability of the owner.
For use in leisure accommodation vehicles, please refer to
the appropriate info
for this appliance.
IMPORTANT: Baumatic Ltd. DO NOT recommend t
appliance is installed on any type of marine vessel.
The use of this appliance for any other purpose or in any other
environment without the express agreement o
will invalidate any warranty or liability claim.
Your new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of G
Repairs may only be carried out by Baumatic

6
arning and safety instructions
oiance
become hot during use and retain heat after operation.
hild Safety
od
ny time. During and after use, all
surfaces will become hot.
ose ensure that they are kept under close supervision
at all times.
eneral Safety
W
This appliance complies with all current European safety
legislation. Baumatic do wish to emphasise that this compl
does not remove the fact that the appliance surfaces will
C
Baumatic strongly recommend that babies and young children
are prevented from being near to the appliance and not allowe
to touch the appliance at a
If it is necessary for younger family members to be in the
kitchen, plea
G
hat you understand the controls before using the
appliance.
Make sure t
all of the controls on the appliance are turned off
after use.
Check that
when opening the oven door, this will allow
eat to disperse.
Always stand back
h
en removing items from the oven, as the contents
may be hot.
Take care wh
Always keep the oven doors closed when the oven is not in use.
nd hygiene,
this will prevent the possibility of bacterial growth.
Always follow the basic principles of food handling a
Always keep ventilation slots clear of obstructions.
ge areas when closing the door,
otherwise you may trap them.
Keep fingers away from the hin
vity
id direct
contact with any of the elements in the appliance.
oT LEAVE THE APPLIANCE UNATTENDED WHILST IN
USE.
Oven gloves should be used when placing food in the oven ca
and when removing it. Care should be taken to avo
DO NO

7
oDo not place heavy objects on the oven door or lean on the
oven door when it is open, as this can cause damage to the oven
door hinges. Nobody should be allowed to sit or stand on any
part of the cooker.
oDo not store chemicals, food stuffs, pressurised containers in or
on the cooker or in cabinets immediately above or next to the
cooker.
oDo not heat up unopened food containers, as pressure can build
up which may cause the container to burst.
oDo not place flammable or plastic items on or near the hob
burners, these types of materials should also not be placed in
the oven or the compartment below the oven.
oDo not leave heated oil or fat unattended, as this is a fire risk.
You should not fill a deep fat frying pan more than one third full
of fat or oil, you should also not use a lid.
oDo not allow fat or oil to build up in the oven trays, grill pan or
oven base.
oDo not place pans or baking trays directly on the base of the
oven cavity, or line it with aluminium foil.
oDo not grill food containing fat without using the grill trivet. The
grill trivet should never be covered with aluminium foil.
oDo not place hot enamel parts in water, leave them to cool first.
oDo not allow vinegar, coffee, milk, saltwater, lemon, tomato
juice or any liquid with high sugar content to remain in contact
with the enamel parts of the appliance. Spillages should be
wiped up immediately.
oDo not allow electrical fittings or cables to come into contact
with areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in or to
dry clothing. No clothing should be placed over or near to the
hob burners or oven door.
oDo not install the appliance next to curtains or soft furnishings.

oDo not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance
or result in injury to the person lifting the appliance.
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.
oIMPORTANT: Care must be taken when cleaning between
the door glasses, and inside the inner frame as some of
the edges maybe sharp due to the manufacturing process.
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions. Please see
the specific section of this booklet that refers to
installation.
oBaumatic Ltd. declines any responsibility for injury or
damage, to person or property, as a result of improper
use or installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
oPlease consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
Declaration of conformity
This appliance complies with the following European Directives:
-73/23/EEC regarding “low voltage”
-89/336/EEC regarding “electromagnetic disturbances”
-90/396/EEC regarding “gas appliances”
-89/109/EEC regarding “materials in contact with food”.
8

oThe above directives comply with 93/68/EEC regarding CE
marking.
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.
Specifications
Product dimensions:
Height: 950 - 965 mm
Width: 1220 mm
Depth: 700 mm
Product specifications:
o7 burner gas hob:
o2 x 4.30 kW hypergas burners
o2 x 3.00 kW rapid burners
o1 x 1.95 kW fry top over ceramic burner
o1 x 1.75 kW semi-rapid burner
o1 x 1.00 kW auxiliary burner
oCast iron pan stands
oUnderknob auto-ignition
o8 function main oven
o5 function secondary oven
oOven energy efficiency class: B
oMain oven capacity: 73 litres
oSecondary oven capacity: 34 litres
oStorage compartment capacity: 52 litres
oLED fully programmable timer
oThermostatically controlled grills
o2 Cooling fans
oTriple glazed removable doors
oAdjustable feet
9

10
Standard accessories:
oRemovable side racks
o2 x Safety shelves
o2 x Enamelled drip trays
oRotisserie skewer with removable handle
oLPG conversion jets
Optional extras:
oBPS1 Pizza stone
Electrical details
Rated Voltage: 230 Vac 50 Hz
Supply Connection: 20 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 3.85 kW
Mains Supply Lead: 3 core x 1.5 mm²
Oven Light Bulb: E14 15 W/300°C screw type pigmy
Gas details
Gas Connection Type: 1/2” BSP
Gas Type (Natural Gas): 20 mbar
Gas Type (LPG): See table on page 34 for this
information.
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your oven can be
located by opening the door of the storage compartment.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….

Control Panel
1. Main oven rotisserie ON/OFF button
2. Hob control knobs
3. Main oven function selector knob
4. Main oven power indicator light
5. Main oven operating indicator neon
6. Main oven thermostat control knob
7. Fry top control knob
8. Oven programmer/timer buttons
9. Oven programmer/timer display
10. Secondary oven rotisserie ON/OFF button
11. Secondary oven power indicator light
12. Secondary oven operating indicator neon
13. Secondary oven function and thermostat control knob
14. Hob control knobs
Main oven thermostat control knob
oUse this control knob to control the
temperature in the oven.
Main oven function selector control knob
oUse this control knob to select the oven
function and turn on the oven light in
the main oven.
11

Secondary oven function selector and thermostat control knob
oUse this control knob to select the oven
function and turn on the oven light in
the secondary oven.
Hob control knobs
oUse these control knobs to light and
control the hob burners.
Fry top control knob
oUse this control knob to control the power
of the fry top.
12

Oven programmer/timer display
1. Auto function symbol
2. Minute minder symbol
3. Manual operation symbol
= Minute minder button
= Duration button
= Cooking end time button
= Timer minus button
= Timer plus button
Setting and using the oven programmer/timer
Setting the time of day and selecting manual operation mode
After your appliance is connected to your mains supply for the
first time, the numbers on the timer display will flash 00.00.
Before you can select a cooking function or set a temperature,
you must put the appliance into manual operation mode and
set the time of day.
oTo select manual operation mode, press the duration and
cooking end time buttons simultaneously.
oUse the plus and minus buttons to adjust the time that appears
in the timer display.
oWhen the time shown in the timer display is correct, release the
plus and minus buttons. After 5 seconds, the Auto function
symbol (1) will disappear from the timer display and the manual
operation symbol (3) will appear instead.
13

14
Before first use
oTo remove any residue from the oven cavities that may have
been left from the manufacturing process, you should select the
fan oven function for the main oven and the conventional oven
function for the secondary oven. Separately set each oven to its
maximum temperature setting.
oIt is perfectly normal for a smell to be produced during this
process.
oYou should make sure that any windows in the room are left
open during this process.
oIt is advisable for you not to remain in the room whilst the
burning off process is taking place.
oYou should leave each oven on maximum setting for 30 – 40
minutes.
oIMPORTANT: You should not burn off both ovens
simultaneously.
Setting the minute minder function (main and secondary oven)
You are able to set the minute minder at any time, regardless
of whether an oven function has been selected. You can set a
period of time using the minute minder function and an alarm
will sound when this period of time has elapsed.
oPress the minute minder button, and then use the plus and
minus buttons to set the length of time that you require.
oAfter releasing the plus and minus buttons, the minute minder
symbol will appear on the display.
oAn alarm will sound when the countdown time has elapsed. The
alarm can be silenced by pressing the cooking end time button.
oImportant: If the oven is on, then it will continue to heat, even
if you silence the audible alarm. If you have finished cooking,
then you should turn off the oven by turning the relevant oven
function selector knob and thermostat control knob to the off
position.

15
Setting the duration function (main oven only)
This function will allow you to set a countdown time similar to
the minute minder function. However the oven will no longer
continue to heat, once the countdown period has elapsed.
oUse the main oven function selector control knob to select the
cooking function that you require and the main oven thermostat
control knob to set the temperature that you want to cook at.
oIt is then possible to set the duration of the cooking time that
you require.
oPress the duration button and the display will show a value of
00:00. Set the period of time that you wish the duration function
to countdown for, by using the plus and minus buttons.
oOnce the display has got to the desired countdown time, let go
of the plus and minus buttons. The countdown will start
immediately and the Auto function symbol and the manual
operation symbol will appear on the timer display.
oAn alarm will sound when the countdown time has elapsed and
the oven will switch off. The Auto function symbol will flash.
oTo silence the alarm and return the oven to manual operation
mode you should press the duration and cooking end time
buttons simultaneously. The Auto function symbol will disappear
from the timer display.
oImportant: The oven will continue to heat once you have
returned it to manual operation mode. If you have finished
cooking, then you should switch off the oven by turning the main
oven function selector control knob and the main oven
thermostat control knob to their off positions.

16
Setting the end cook function (main oven only)
This function is similar to the duration function, however
instead of selecting a period of time that you wish the oven to
switch off after. You select the time of day that you wish the
oven to switch off at.
oUse the main oven function selector control knob to select the
cooking function that you require and the main oven thermostat
control knob to set the temperature that you want to cook at.
oPress the cooking end time button and the display will show a
value of 00:00. Set the time of day that you wish the oven to
stop cooking at by using the plus and minus buttons.
oOnce the display has got to the time of day that you want the
oven to stop cooking at, let go of the timer plus and minus
buttons. The countdown will start immediately and the Auto
function symbol and the manual operation symbol will appear on
the timer display.
oWhen the time of day reaches the end of the cooking time that
you have set, the oven will switch off and an alarm will sound.
The manual operation symbol will disappear and the Auto
function symbol will flash.
oTo silence the alarm and return the oven to manual operation
mode, you should press the duration and cooking end time
buttons simultaneously. The Auto function symbol will disappear
from the timer display.
oImportant: The oven will continue to heat once you have
returned it to manual operation mode. If you have finished
cooking, then you should switch off the oven by turning the main
oven function selector control knob and the main oven
thermostat control knob to their off positions.

17
Setting the start and end time function (main oven only)
This function will allow you to set a time in the future that the
oven switches on at and a time that the oven will switch off at.
oUse the main oven function selector control knob to select the
cooking function that you require and the main oven thermostat
control knob to set the temperature that you want to cook at.
oPress the duration button and the display will show a value of
00:00. Set the period of time that you wish to cook for, by using
the plus and minus buttons.
oImmediately press the cooking end time button and the timer
display will show the value 00:00 again. Set the time of day that
you want the oven to switch off at, using the plus and minus
buttons. The Auto function symbol will appear on the timer
display.
oThe oven will calculate what time it needs to switch on at, so
that your food will cook for the length of time that you have
selected. When it does the manual operation symbol will appear
on the timer display and the oven will switch on.
oWhen the time of day reaches the end of cooking time that you
set, the oven will switch off and an alarm will sound. The manual
operation symbol will disappear and Auto function symbol will
flash.
oTo silence the alarm and return the oven to manual operation
mode, once the start and end time function has been used. You
should press the duration and cooking end time buttons
simultaneously. The Auto function symbol will disappear from
the timer display.
oImportant: The oven will continue to heat once you have
returned it to manual operation mode. If you have finished
cooking, then you should switch off the oven by turning the main
oven function selector control knob and the main oven
thermostat control knob to their off positions.

Cancelling an automatic cooking function
If an automatic cooking function has been set and you wish to
use the oven in manual operation mode, you will need to cancel
the automatic cooking function.
oTo select manual operation mode, press the duration and
cooking end time buttons simultaneously.
oThe Auto function symbol will disappear from the timer display
and the manual operation symbol will appear instead.
Adjusting the audible signal
There are 3 levels of audible signal available; to adjust it you should
do the following:
oWhen the time of day is shown on the timer display, press the
minus button for approximately 2 seconds. You will then hear
the current level of audible signal.
oRepeat this process until the audible signal reaches the level that
you require, and then release the minus button.
Selecting a cooking function and temperature
Main oven function selector knob
The main oven function selector knob should
be turned clockwise and used to select the
particular mode of cooking that you require.
The appliance will utilise different elements
within the oven cavity, depending on the oven
function that you select. When a function is
selected, the power indicator light will come
on.
Please note that the symbols shown in the drawing above will not
necessarily correspond EXACTLY with the symbols on the control knob
of the appliance itself.
18

There are eight cooking functions available on your appliance:
FAN AND LOWER ELEMENT: This method of cooking
utilises the bottom element in conjunction with the fan,
which helps to circulate the heat. This function is suitable for
sterilising and preserving jars.
FAN AND GRILL: This method of cooking utilises the top
element in conjunction with the fan, which helps to provide a
quick circulation of heat. This function is suitable where quick
browning is required and “sealing” the juices in, such as
steaks, hamburgers, some vegetables etc.
19
eaks, fish
g.
FULL GRILL: This method of cooking utilises the inner and
outer parts of the top element, which directs heat
downwards onto the food. This function is suitable for grilling
medium or large portions of sausages, bacon, st
etc. Ideally the thermostat control knob should be set to
200°C
HALF GRILL: This method of cooking utilises the inner part
only of the top element, which directs heat downwards onto
the food. This function is suitable for grilling small portions
of bacon, toast and meat etc. The thermostat control knob
must be turned to its maximum setting.
FAN OVEN: This method of cooking uses the circular
element while the heat is distributed by the fan. This results
in a faster and more economical cooking process. The fan
oven allows food to be cooked simultaneously on different
shelves, preventing the transmission of smells and tastes
from one dish onto another.
CONVENTIONAL OVEN (top and lower element): This
method of cooking provides traditional cooking, with heat
from the top and lower elements. This function is suitable for
roasting and baking on one shelf only.
DEFROST MODE: The fan runs without heat to reduce the
defrosting time of frozen foods. The time required to defrost
the food will depend on the room temperature, the quantity
and type of food. Always check food packaging for the
defrosting instructions.
OVEN LIGHT: Separate light control which allows the light
to be switched on, even when the oven is not heatin

Main oven thermostat control knob
The oven thermostat control knob should be
turned clockwise and it sets the required
temperature of the oven. It is possible to
regulate the temperature within a range of 50 -
250°C.
Secondary oven function and thermostat control knob
If you turn the control knob anti clockwise, it
will automatically select the oven light
function first. If you continue turning the
control knob, you will select the conventional
oven function. You can regulate the
conventional oven between a temperature of
50 - 250°C.
To use one of the other functions, you should turn the dial past the
250°C setting and select the following functions.
UPPER ELEMENT ONLY: This method of cooking uses the
outer part of the top element to direct gentle heat
downwards onto the food. For gentle cooking, browning or
keeping cooked dishes warm.
LOWER ELEMENT ONLY: This method of cooking uses the
lower element to direct heat upwards to the food. For slow-
cooking recipes or for warming up meals.
GRILL ELEMENT ONLY: This method of cooking utilises the
top element, which directs heat downwards onto the food.
This function is suitable for grilling small portions of bacon,
toast and meat etc.
Oven operating light
This light will come on to indicate that the oven’s heating elements are
in operation. The light will turn off when the temperature set on the
thermostat control knob has been reached. It will cycle on and off
throughout the cooking time.
You should not place food inside the cavity, until the correct
cooking temperature has been reached.
20
