Baumatic 720 series Operating instructions

THE 720 SERIES
USER AND INSTALLATION
INSTRUCTIONS

For future reference please record the following information
which be found on the Rating Plate and the date of purchase
which can be found in the invoice:
Model Number…………………….
Serial Number…………………….
Date of Purchase…………………….

CONTENTS
General information Pages 3-4
Warning and safety instructions Pages 5-6
Installation instructions Pages 7-11
Timer instructions Pages 12-14
Before the first use Page 15
Operating instructions Pages 16-18
Cooking guide Pages 19-21
Cleaning and maintenance Pages 21-24
Fault finding Page 24
Technical data Page 25
Conditions of guarantee Pages 27-28

GENERAL INFORMATION
Please read this booklet thoroughly before you use this
appliance. It is important that you understand all the control
functions before commencing to cook with your Baumatic
appliance.
Please remember the advice and warnings shown on page 4
which is headed ‘IMPORTANT – Warning and Safety
Instructions’.
This appliance is designed for domestic household use and can
be built into a standard kitchen cabinet or housing unit.
NOTE: The adjacent furniture or the housing and all materials
used in the installation must be able to withstand a minimum
temperature rise of 85 ° C above ambient during periods of use.
Certain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discoloration at
temperatures below the above guidelines.
Installing the appliance in contravention of this temperature
limit or the placing of adjacent cabinet materials closer than
4mm to the appliance, will be at the liability of the owner.
For use in Leisure Accommodation Vehicles, notice must be
taken of the appropriate statement in the Installation
Instructions.
The use for any other purpose or in any other environment
without the express agreement of Baumatic Ltd, would
invalidate any warranty or liability claim
Your new appliance is guaranteed against electrical or
mechanical defects subject to certain exclusions noted in
Baumatic Ltd Conditions of Guarantee.
The foregoing does not affect your statutory rights.
3

The Warranty applies to Great Britain and Northern Ireland
only.
In the event that you require any After Sales Service or advice,
please contact the Baumatic Service Department on telephone
number – 0118 933 6911.
Before using this appliance ensure that any protective
packaging or coatings have been removed. To aid the protection
of the environment, please sort the packing materials into
different types and dispose of them in accordance with the local
waste disposal laws.
Any further information on waste disposal can be obtained from
your local Environmental Agency office.
When first used, an odour may be emitted by any residual
protective finish or moisture, which will cease after a short
period of time.
This Appliance has been Constructed and Distributed in
compliance with the essential requirements of the following
EEC DIRECTIVES and EUROPEAN NORMS:-
CE Marking – 93/68 Low Voltage – 73/23 EMC – 89/336
Safety Standards – EN 60 335-1, EN 60 335 – 2 – 6.
As Baumatic have a policy of continued product improvement,
the right is reserved to adjust and make any modifications
deemed necessary without notification.
4

IMPORTANT NOTE – WARNING and SAFETY
INSTRUCTIONS
This appliance complies with all current European safety
legislation, however Baumatic do wish to emphasise that
compliance does not remove the fact that the appliance surfaces
will become hot during use and retain heat after operation.
Baumatic therefore strongly advise that babies and young
children are prevented from being near or touching the
appliance at any time.
If it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
We also advise that great care is taken during use and cleaning
operations.
Do not place heavy objects on or lean on the oven door when
open as this can cause damage to the hinging.
Do not leave heated oil or fat unattended as there is a risk of
fire.
Do not place pans or baking trays on the bottom of oven
cavities or line with Aluminium Foil.
Do not allow electrical fittings or cables to be in contact with
hot areas of the appliance.
Do not use the appliance for space heating or to dry clothes.
Do not install the appliance next to curtains or soft furnishings.
Do not attempt to lift or move cooking appliances by pulling on
any door or handle as this can cause damage.
5

NOTE: This appliance must be correctly installed by a
suitably qualified person, strictly in accordance with the
manufacturer’s instructions.
For electrical installations, NICEIC registration is
recommended.
Baumatic Ltd declines any responsibility for injury or
damage to persons or property as a result of improper use
or installation of this appliance.
Heat, steam and moisture will be created during use, take
care to avoid injury and ensure that the room is adequately
ventilated. If prolonged use occurs, additional ventilation
may be required – please consult your Qualified Installer if
you are in any doubt about the amount required.
6

INSTALLATION INSTRUCTIONS
This appliance must be correctly installed by a suitable
qualified person strictly in accordance with the manufacturer's
instructions.
The manufacturer declines any responsibility for injury or
damage to persons or property as a result of improper
installation of this appliance.
The housing, adjacent furniture and all materials used in
installation must be able to withstand a minimum temperature
of 85°C plus ambient during periods of operation. In addition,
adjacent furniture cabinet doors must be at least 3mm from the
appliance at all points. Certain types of vinyl or laminate
kitchen furniture cabinetry are particularly prone to heat
damage and discoloration of materials which occurs below
85°C plus ambient or where materials are less than 3mm from
the appliance will be the liability of the owner.
This range of ovens has been designed to be located under a
worktop surface.
Two systems can be used to fit your appliance to a chosen
furniture layout:
A) Between two side panels of two distinct cabinet units
without the aid of a support shelf, by fitting four support steel
brackets provided with the product. (See Sys A, fig. 1, page 9).
B) Between two side panels each fixed to the side of a
cabinet unit without the aid of a support shelf. In this case only
the two lower support brackets will be necessary. (See Sys B,
fig. 2, page 10).
7

Note : In both the above cases you must measure 717mm from
the underside of the worktop and mark the correct position of
the lower support brackets before fixing them to the sides. With
reference to (Sys A, fig. 1) ensure side support brackets are
positioned 40mm from the front of the cabinet door exterior
surface, as illustrated, before securing them to the cabinet sides.
If necessary, this product can be installed in a housing unit. The
housing unit will not be a standard one but will have to be of a
size to accept the full height of the oven –minimum height
717mm.
Furthermore it will have to respect all the ventilation required.
IMPORTANT
Ventilation requirements
Ventilation forms a very important part of the installation of this
appliance.
The ventilation requirements are shown on page 11 of this
booklet and must be adhered to.
Failure to do this can cause adverse effects to the operation of
the appliance.
8
