8” Electric Tile Saw - BTS90

User Manual

[Revision 1.0 May 2020]

READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND

MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in

appearance, assembly, inclusions, specifications, description and packaging.

8” Electric Tile Saw - BTS90

Safety

Safety messages are designed to alert you to possible dangers or hazards that could cause death, injury or

equipment or property damage if not understood or followed. Safety messages have the following symbols:

You WILL be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be KILLED or

SERIOUSLY INJURED if you do

not follow instructions.

You CAN be INJURED if you do

not follow instructions or equipment

damage may occur.

It is vital that you read and understand this

user manual before using the product,

including safety warnings, and any assembly

and operating instructions. Keep the manual

for future reference.

Safety precautions and recommendations

detailed here must be fully understood and

followed to reduce the risk of injury, fire,

explosion, electrical hazard, and/or property

damage.

Safety information presented here is generic

in nature – some advice may not be

applicable to every product. The term

"equipment" refers to the product, be it

electrical mains powered, battery powered or

combustion engine powered.

•Before Use - If you are not familiar with the

safe operation/handling of the equipment or

are in any way unsure of any aspect of

suitability or correct use for your

application, you should complete training

conducted by a person or organization

qualified in safe use and operation of this

equipment, including fuel/electrical handling

and safety.

•Do NOT operate the equipment in

flammable or explosive environments, such

as in the presence of flammable liquids,

gases or dust. The equipment may create

sparks or heat that may ignite flammable

substances.

•Keep clear of moving parts.

•Equipment may be a potential source of

electric shock or injury if misused.

•Do NOT operate the equipment if it is

damaged, malfunctioning or is in an

excessively worn state.

•Do NOT allow others to use the equipment

unless they have read this manual and are

adequately trained.

•Keep packaging away from children - risk

of suffocation! Operators must use the

equipment correctly. When using the

equipment, consider conditions and pay

due care to persons and property.

General Work Area Safety

•Work areas should be clean and well it.

•Do not operate the equipment if

bystanders, animals etc are within

operating range of the equipment or the

general work area.

•If devices are provided for connecting dust

extraction / collection facilities, ensure

these are connected and used properly.

Dust collection can reduce dust-related

hazards.

General Personal Safety

•Wear appropriate protective equipment

when operating, servicing, or when in the

operating area of the equipment to help

protect from eye and ear injury, poisoning,

burns, cutting and crush injuries. Protective

equipment such as safety goggles,

respirators, non-slip safety footwear, hard

hat, hearing protection etc should be used

for appropriate equipment / conditions.

Other people nearby should also wear

appropriate personal protective equipment.

Do not wear loose clothing or jewellery,

which can be caught in moving parts. Keep

hair and clothing away from the equipment.

•Stay alert and use common sense when

operating the equipment. Do not over-

reach. Always maintain secure footing and

balance.

•Do not use the equipment if tired or under

the influence of drugs, alcohol or

medication.

•This equipment is not intended for use by

persons with reduced physical, sensory or

mental capabilities.

General Fuel Safety

•Petrol/fuel/gasoline is extremely flammable

– keep clear of naked flames or other

ignition sources.

•Do not spill fuel. If you spill fuel, wipe it off

the equipment immediately – if fuel gets on

your clothing, change clothing.

•Do NOT smoke near fuel or when

refuelling.

•Always shut off the engine before

refuelling.

•Do NOT refuel a hot engine.

•Open the fuel cap carefully to allow any

pressure build-up in the tank to release

slowly.

•Always refuel in well ventilated areas.

•Always check for fuel leakage. If fuel

leakage is found, do not start or run the

engine until all leaks are fixed.

General Carbon-Monoxide Safety

•Using a combustion engine indoors CAN

KILL IN MINUTES. Engine exhaust

contains carbon-monoxide – a poison you

cannot smell or see.

•Use combustion engines OUTSIDE only,

and far away from windows, doors and

vents.

General Equipment Use and Care

•The equipment is designed for domestic

use only.

•Handle the equipment safely and carefully.

•Before use, inspect the equipment for

misalignment or binding of moving parts,

loose components, damage or any other

condition that may affect its operation. If

damaged, have the equipment repaired by

an authorised service centre or technician

before use.

•Prevent unintentional starting of the

equipment - ensure equipment and power

switches are in the OFF position before

connecting or moving equipment. Do not

carry equipment with hands or fingers

touching any controls. Remove any tools or

other items that are not a part of the

equipment from it before starting or

switching on.

•Do not force the equipment. Use the

correct equipment for your application.

Equipment will perform better and be safer

when used within its design and usage

parameters.

•Use the equipment and accessories etc. in

accordance with these instructions,

considering working conditions and the

work to be performed. Using the equipment

for operations different from those intended

could result in hazardous situations.

•Always keep equipment components

(engines, hoses, handles, controls, frames,

housings, guards etc) and accessories

(cutting tools, nozzles, bits etc) properly

maintained. Keep the equipment clean and,

where applicable, properly lubricated.

•Store the equipment out of reach of

children or untrained persons. To avoid

burns or fire hazards, let the equipment

cool completely before transporting or

storing. Never place or store the equipment

near flammable materials, combustible

gases or liquids etc.

•The equipment is not weather-proof, and

should not be stored in direct sunlight, at

high ambient temperatures or locations that

are damp or humid.

•Do not clean equipment with solvents,

flammable liquids or harsh abrasives.

•For specific equipment safety use and care,

see Equipment Safety.

8” Electric Tile Saw - BTS90

General Electrical Safety

•Inspect electrical equipment, extension

cords, power bars, and electrical fittings for

damage or wear before each use. Repair or

replace damaged equipment immediately.

•Ensure all power sources conform to

equipment voltage requirements and are

disconnected before connecting or

disconnecting equipment.

•When wiring electrically powered

equipment, follow all electrical and safety

codes.

•Wherever possible, use a residual current

device (RCD).

•High voltage / high current power lines may

be present. Use extreme caution to avoid

contact or interference with power lines.

Electrical shock can be fatal.

General Electrical Safety

•Electrically grounded equipment must have

an approved cord and plug and be

connected to a grounded electrical outlet.

•Do NOT bypass the ON/OFF switch and

operate equipment by connecting and

disconnecting the electrical cord.

•Do NOT use equipment that has exposed

wiring, damaged switches, covers or

guards.

•Do NOT use electrical equipment in wet

conditions or in damp locations.

•Do NOT use electrical cords to lift, move or

carry equipment.

•Do NOT coil or knot electrical cords, and

ensure electrical cords are not trip hazards.

General Service Information

•The equipment must be serviced or

repaired at authorised service centres by

qualified personnel only.

•Replacement parts must be original

equipment manufacturer (OEM) to ensure

equipment safety is maintained.

•Do NOT attempt any maintenance or repair

work not described in this manual.

•After use, the equipment and components

may still be hot – allow the equipment to

cool and disconnect spark plugs and/or

electrical power sources and/or batteries

from it before adjusting, changing

accessories or performing repair or

maintenance.

•Do NOT adjust while the equipment is

running.

•Perform service related activities in suitable

conditions, such as a workshop.

•Replace worn, damaged or missing

warning/safety labels immediately.

Electric Tile Saw Safety

Read all the instructions and warnings carefully before using this product. Failure to follow warnings and instructions can result in severe injury,

death, or property damage. Before installation, check if all accessories are complete and without damage. If not, contact customer service. Keep

these instructions in a safe place for future reference. Use this product with its original parts only. The manufacturer cannot be held responsible in

the event of damage or injury due to incorrect use of this product. The information contained in this manual is believed to be correct at the time of

printing. However, the manufacturer reserves the right to change or modify any of the specifications without notice or obligation to update existing

units. Repairs should only be carried out by a specialist or a professional and experienced technician. Never attempt to repair the product yourself.

Intended Use. This power tool is designed to cut small to medium size tiles (glazed tiles, ceramic tiles or similar), which can be placed on the power

tool. It is designed for DIY applications and craft businesses in particular. It should never be used to cut wood or metal.

Warnings and Personal Safety

•WARNING! When using electric tools basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal

injury including the following: Do not expose tools to rain. Do not use tools in damp or wet locations. Keep work area well lit. Do not use tools in

the presence of flammable liquids or gases.

•Guard against electric shock: Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators, ranges, refrigerators).

•Do not let persons, especially children, not involved in the work touch the tool or the extension cord and keep them away from the work area.

•When not in use, tools should be stored in a dry locked-up place, out of reach of children.

•It will do the job better and safer at the rate for which it was intended. Do not force small tools to do the job of a heavy-duty tool. Do not use tools

for purposes not intended; for example, do not use circular saws to cut tree limbs or logs.

•Do not wear loose clothing or jewellery, they can be caught in moving parts. Non-skid footwear is recommended when working outdoors. Wear

protective hair covering to contain long hair.

•Use safety glasses. Use face or dust mask if working operations create dust.

•Never yank the cord to disconnect it from the socket. Keep the cord away from heat, oil and sharp edges.

•Wherever possible use clamps or a vice to hold the work. It is safer than using your hand.

•Keep cutting tools sharp and clean for better and safer performance. Follow instruction for lubricating and changing accessories. Inspect tool

cords periodically and if damaged have them repaired by an authorized service facility. Inspect extension cords periodically and replace if

damaged. Keep handles dry, clean and free from oil and grease.

•When not in use, before servicing and when changing accessories such as blades, bits and cutters, disconnect tools from the power supply.

•Form the habit of checking to see that keys and adjusting wrenches are removed from the tool before turning it on.

•Ensure switch is in "OFF" position when plugging in.

•Watch what you are doing, use common sense and do not operate the tool when you are tired.

•Before further use of tool, it should be carefully checked to determine that it will operate properly and perform its intended function. Check for

alignment of moving parts, binding of moving parts, breakage of parts, mounting and any other conditions that may affect its operation. A guard or

other part that is damaged should be properly repaired or replaced by an authorized service centre unless otherwise indicated in this instruction

manual. Have defective switches replaced by an authorized service centre. Do not use the tool if the switch does not turn it on and off.

•The use of any accessory or attachment other than one recommended in this instruction manual may present a risk of personal injury.

•This electric tool complies with the relevant safety rules. Repairs should only be carried out by qualified persons using original spare parts,

otherwise this may result in considerable danger to the user.

General Safety Instructions

When using electric tools, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal

injury including the following. Read all these instructions before attempting to operate this product and keep these instructions for future

reference.

8” Electric Tile Saw - BTS90

•Keep the work area clear: Cluttered areas and benches invite injuries.

•Consider your work area environment: Do not expose power tools to rain. Do not use power tools in damp or wet locations. Keep your work area

well lit. Do not use power tools near flammable liquids or gases.

•Guard against electric shock: Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators, ranges, refrigerators).

•Keep other persons away: Do not let persons, especially children, not involved in the work touch the tool or the extension cord and keep them

away from the work area.

•Store idle tools: When not in use, tools should be stored in a dry, locked place, out of reach of children.

•Do not force the tool: It will do the job better and safer at the rate for which it was intended. Use the right tool: Do not force small tools to do the

job of a heavy-duty tool. Do not use tools for purposes for which they are not intended; for example, do not use circular saws to cut tree limbs or

logs.

•Dress properly: Do not wear loose clothing or jewellery, they can be caught in moving parts. Non-skid footwear is recommended when working

outdoors. Wear a protective hair covering to contain long hair.

•Use protective equipment: Use safety glasses. Use a face or dust mask if the operation creates dust.

•Connect dust extraction equipment: If the tool is equipped with a connection for dust extraction and collecting equipment, ensure these are

connected and properly used.

•Do not abuse the cord: Never yank the cord to disconnect it from the socket. Keep the cord away from heat, oil and sharp edges.

•Secure work: Where possible, use clamps or a vise to hold the workpiece. It is safer than using your hand.

•Do not overreach: Keep proper footing and balance at all times.

•Maintain tool with care: Keep cutting tools sharp and clean for a better and safer performance. Follow the instructions for lubrication and changing

accessories. Inspect the tool’s power cord periodically, and, if damaged, have it repaired by an authorised service facility. Inspect extension cords

periodically and replace them if damaged. Keep the handles dry, clean and free of oil and grease.

•Disconnect tools: When not in use, before servicing and when changing accessories such as blades, bits and cutters, disconnect tools from the

power supply.

•Remove adjusting keys and wrenches: Form the habit of checking to see that keys and adjusting wrenches are removed from the tool before

turning it on.

•Avoid unintentional starting: Ensure the switch is in "off" position when plugging in.

•Stay alert: Watch what you are doing, use common sense and do not operate the tool when you are tired.

•Check for damaged parts: Before further use of the tool, it should be carefully checked to determine that it will operate properly and perform its

intended function. Check for alignment of moving parts, binding of moving parts, damaged parts, tightness of parts and any other conditions that

may affect its operation. A guard or other part that is damaged should be properly repaired or replaced by an authorised service centre unless

otherwise indicated in this instruction manual. Have defective switches replaced by an authorised service centre. Do not use the tool if the switch

does not turn it on and off.

•Warning: The use of any accessory or attachment other than one recommended in this instruction manual may present a risk of personal injury.

•Have your tool repaired by a qualified person: This electric tool complies with the relevant safety rules. Repairs should only be carried out by

qualified persons using original spare parts, otherwise this may result in considerable danger to the user.

•A PRCD must be used, which will trip with a fault current of up to max. 30mA.: Replacement of the plug or the supply cord shall always be carried

out by the manufacturer of the tool or his service organization; Keep water clear of the electronic parts of the tool and away from persons in the

working area.

Specific Safety Rules

•The stone cutting machine is designed exclusively for cutting ceramic, marble, clinker, etc. It must never be used for cutting wood or similar

material.

•Special diamond discs are required for machining granite, fine stoneware and glazed tiles (available from the trade and DIY stores).

•NOTE: The machine is designed exclusively for wet cutting.

•It is suitable for both private and professional use.

•The manufacturer assumes no liability whatsoever for improper use, or if the machine has been tampered with.

•Give equal attention to the safety instructions, assembly and operating instructions as well as prevailing accident preventions regulations.

•Set up the machine on level, non-slippery ground. The machine should not wobble.

•Make sure that the voltage on the rating plate is the same as your supply system.

•Only then are you to insert the power plug in the mains socket outlet.

•Never use cracked diamond cutting wheels but replace them immediately.

•Never use segmented cutting wheels.

•WARNING: The cutting wheel continues to rotate after switching off.

•Do not slow down the cutting wheel by applying pressure to its side.

•The diamond cutting wheel has to run in the water bath!

•Pull out the power plug before you exchange the cutting wheel.

•Use only suitable diamond cutting wheels: ø 200 mm, bore ø 25.4 mm.

•Note the width of the adjusting bracket!

•Close the guard hood when you are finished with your work.

•This machine is not designed for working outdoors.

•Remove the power plug before you check the electric motor compartment system.

8” Electric Tile Saw - BTS90

Safety Symbols

The product may have safety warning labels attached to it, explained below. Understand the symbols on your

product and their meanings. If any stickers become unreadable, unattached etc., replace them.

Flammable Material Hazard

Flammable liquids, gases or

substances etc may present.

Avoid ignition sources and open

flames. Danger of fire.

Read User Manual

Read and fully understand

product safety warnings,

operation, procedures etc before

using the product.

Use Hand Protection

Wear appropriate hand protection

and take due care as the product

or use of the product may present

hand hazards.

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Electrocution / Electrical Shock

Hazard

High voltage or high current

electricity may be present or

required by the product. Take

due care when handling electrical

products, cables, plugs and

leads. Electrical shock can be

fatal.

Toxic Fumes / Dust Hazard

Using the product or by-products

from use may produce fumes,

smoke or particles that could be

harmful if inhaled. Wear

appropriate breathing protection

and have adequate ventilation.

Explosive Material Hazard

Combustible liquids, gases or

substances etc may be present.

Avoid ignition sources and open

flames. Danger of explosion.

Cutting / Amputation Hazard

The product may have blades,

edges or mechanical devices that

can cause severe cut injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Crush Hazard

The product may have blades,

edges or mechanical devices that

can cause severe crush injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Single Operator Only

The product must be operated by

a single person only. More than

one person operating the product

may introduce additional hazards.

Use Face Protection

Wear appropriate full-face

protection and take due care as

the product or use of the product

may present face and eye

hazards.

Use Foot Protection

Wear appropriate foot protection

and take due care as the product

or use of the product may present

foot hazards.

Use Eye / Ear / Head Protection

Wear appropriate eye and / or

ear and / or head protection and

take due care as the product or

use of the product may present

eye, hearing and head hazards.

Running Hazard

Do not run on or near the product

as doing so may present a fall

hazard.

Diving Hazard

Do not dive into the product as

doing so may present a neck /

head injury hazard.

Adult Supervision Required

Always supervise children and

other users of a product to

prevent drowning or injury.

Skin Penetration / Puncture

Hazard

The product may produce

pressure, emit liquids or objects

that can cause severe injury to

fingers, limbs, blood etc. Take

due care when handling and

using the product.

Hot Surface Hazard

Be aware that the product may

produce high temperatures and

hot surfaces that can cause burn

injuries.

Flying Debris Hazard

Be aware that the product or use

of the product may present

hazards produced by flying

debris. Wear appropriate clothing

and protective devices.

Moving Parts Hazard

Be aware that the product

contains or uses mechanical

devices that move or rotate.

Always wait for moving parts to

stop fully before handling the

product, adjusting, maintenance

etc.

8” Electric Tile Saw - BTS90

Carbon-Monoxide Hazard

Do not use the product in

confined areas or without

adequate ventilation. Carbon-

monoxide poisoning can be fatal.

Pull Hazard

Be aware that the product

contains or uses mechanical

devices that can pull in objects

and can cause severe injury to

fingers, limbs etc. Take due care

when handling and using the

product.

Slope / Fall Injury Hazard

Be aware that using the product

on sloping surfaces or in slippery

conditions may present additional

dangers from falls and contact

with blades, moving parts, hot

surfaces etc.

"Slam Dunk" Warning

Do NOT attempt "slam dunk"

manoeuvres as this may result in

severe injury due to falling,

product breakage or collapse etc.

Electrocution / Electrical Shock

Hazard - Outdoor

High voltage or high current

electricity may be present or

required by the product. Do NOT

use in rain, damp or wet

conditions. Electrical shock can

be fatal.

Electrocution / Electrical Shock

Hazard - Disconnect

High voltage or high current

electricity may be present or

required by the product. Always

disconnect the product from the

electrical supply before handling

the product, adjusting,

maintenance etc.

Power Line Electrocution

Hazard

High voltage / high current power

lines may be present. Use

extreme caution to avoid contact

or interference with power lines.

Electrical shock can be fatal.

"Kick-Back" Hazard

High level of "kick-back" hazard

that can cause the machine to

suddenly rotate towards operator.

Kick-back injury can be fatal.

Winch Operator Position

Hazard

Do NOT stand between winch

and load. Do NOT use winch to

move people.

Winch Lift Hazard

Do NOT LIFT load vertically. Use

machine to PULL only.

Cable Hazard

Ensure that load bearing cable is

not kinked or knotted.

Winch Cable Hazard

Ensure that there is a minimum

number of cable coils on

winching mechanism.

Winch Hook Hazard

Carry hook to load – do NOT

throw or run.

Flash / Blinding Hazard

Wear appropriate eye protection

for welding. Direct exposure to

weld arcs may cause permanent

eye injury.

Laser Hazard

Laser may be in use – do NOT

look directly at laser or allow

others to.

8” Electric Tile Saw - BTS90

Table of Contents

Safety .............................................................................................................................................................2

Safety Symbols...........................................................................................................................................................5

Parts Identification .......................................................................................................................................8

Assembly.......................................................................................................................................................9

Sub-Frame Assembly .................................................................................................................................................9

Operation.....................................................................................................................................................10

Working with the Tile Saw ........................................................................................................................................10

Mitre Cuts .................................................................................................................................................................11

Diagonal Cuts ...........................................................................................................................................................11

Changing the Cutting Disc........................................................................................................................................11

Maintenance and Cleaning ........................................................................................................................12

Maintenance .............................................................................................................................................................12

Cleaning....................................................................................................................................................................12

Repairs .....................................................................................................................................................................12

Troubleshooting .........................................................................................................................................13

Specifications .............................................................................................................................................14

8” Electric Tile Saw - BTS90

Parts Identification

Note: Colours may vary

No. Name

1

Folding sub-frame

2

Locking knobs

3

Transit packaging

4 Cutting table

5

ON/OFF Switch

6 Star handle

7 Straight guide

8

Angled guide

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

8” Electric Tile Saw - BTS90

Assembly

Sub-Frame Assembly

1. The tile cutting machine is supplied completely assembled and ready for use. To unfold the sub-frame (1),

press the internal locking knob (2) and unfold the frame outwards until it engages (B1).

You can use the machine as a tabletop machine with the subframe.

2. Fill the tank with water to approximately 5mm below the tank edge. Remove the transport packaging (3)

(B3).

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

8” Electric Tile Saw - BTS90

Operation

Working with the Tile Saw

1. Connect the machine to the mains supply. Ensure that the voltage is correct (see model plate).

2. Place the workpiece on the cutting table (B4) (4) and align it.

3. Switch the machine to ON with the ON/OFF switch (5) (B5).

4. Wait until the cutting disc has reached its maximum speed and the pump is transporting water onto the

cutting disc.

5. Pull the motor carriage slowly and evenly through the workpiece.

6. To switch off the machine move the ON/OFF (5) switch to OFF.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

8” Electric Tile Saw - BTS90

Mitre Cuts

1. For mitre cuts from 90° to 45°, swing the whole machine head with the cutting disc.

2. Undo the two star handles on the side (6), adjust the head to the angle you require and tighten the star

handles again (B6).

3. Pull the cutting disc slowly and evenly through the workpiece.

Diagonal Cuts

1. Clamp the angle guide (8) in the straight guide (7) and adjust it to the angle you require (B7).

2. Set the angle guide to 45° or the angle you require and pull the cutting disc slowly and evenly through the

workpiece (B7).

Changing the Cutting Disc

Please refer to image B8

1. Disconnect the mains plug.

2. Wear safety gloves.

3. Undo the three screws on the saw blade guard (10) and remove the guard.

4. Place an open-ended wrench on the motor shaft and turn the flange nut anti-clockwise to undo it.

5. Remove the flange nut (11), external flange (12) and cutting disc (13) (B8).

6. Fit a new cutting disc by following the instructions above in reverse.

IMPORTANT! Check the direction of rotation of the cutting disc.

7. Fit the saw blade guard again with three screws.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

8” Electric Tile Saw - BTS90

Maintenance and Cleaning

Maintenance

•Depending on the frequency of use, the pump must be cleaned at regular intervals.

−Remove the pump from the water tank.

−Remove the filter and the pump impeller cover by turning them.

−Pull out the impeller and clean all the parts under running water. Remove any deposits.

•Changing the cutting disc:

−Disconnect the mains plug from the supply.

−Wear safety gloves.

−Undo the three screws on the blade guard (18) and remove the guard.

−Place an open-ended spanner (19) on the motor shaft and undo the flange nut by turning it anti-

clockwise with the open-ended spanner (20).

−Remove the flange nut and cutting disc.

IMPORTANT! Check the direction of rotation of the cutting disc.

−Fit a new cutting disc by following the instructions above in reverse.

−Fit the blade guard again with the three screws.

Cleaning

•Empty and rinse out the water tank at regular intervals.

•Keep the motor ventilation grille clean at all times.

•Treat all the moving parts at regular intervals with biodegradable grease or oil.

•Do not treat plastic covers with solvents.

•Use only damp cloths and brushes for cleaning purposes.

Repairs

Only use accessories and spare parts recommended by the manufacturer. If the equipment should fail some day

in spite of our quality controls and your maintenance, only have it repaired by a n authorised electrician.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

8” Electric Tile Saw - BTS90

Troubleshooting

Problems Causes Solutions

Motor does not start.

Motor has no power supply.

Check the main power supply.

Power cable not connected.

Defective on/off switch. Replace the switch.

Machine does not run smoothly and

not true.

Check the cutting disc for any

damage. Replace the cutting disc.

Starting capacitator is defective. Get it repaired by a qualified

technician.

The bearing is worn-out. Get it repaired by a qualified

technician.

Cutting power is too weak.

Flange on the cutting disc is loose. Tighten the flange.

Cutting disc was not fitted correctly. Refit the disc correctly.

Edge of the diamond cutting disc is

blunt. Sharpen it with a whetstone.

Water cooling is too weak. The pump is not transporting enough

water.

Clean the pump.

Add more water to the tank.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

8” Electric Tile Saw - BTS90

Specifications

Rated power 800W

Motor speed 3000rpm

Table size 680 x 380mm

Max cutting length 620mm

Max cutting depth 40mm @90°, 30mm @ 45°

Mitre range 0-45º

Blade diameter 200mm

Rated speed 3000/min

Input voltage 220-240V~50Hz

Power Plug Australian Standard

Protection class IP54

Please Note: Performing angled bevel cuts can be arduous, if you choose to perform such cuts please ensure

that you are qualified to do so before operating the machine. Please also be aware of any adjustable parts of the

machine that may be in the cutting line when performing an angled cut that are otherwise not in the way when in

normal operation. It is recommended to guide the circular saw blade along the full range of the cutting table

before activating its power to ensure no object is obstructing an angled cut.

Please Note: The supplied blade may not be suitable for all applications, refer to a tile supplier for the

recommended blade.

BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG BAUMR-AG

Some experts believe that the incorrect or prolonged use of almost any

product may cause serious injury or death. To help reduce your risk of

serious injury or death, refer to the information below. For more information,

see www.datastreamserver.com/safety

Consult all documentation, packaging

and product labelling before use. Note

that some products feature

documentation available online. It is

recommended to print and retain the

documentation.

Before each use, check the product for

loose/broken/damaged/missing parts,

wear or leaks (if applicable). Never use a

product with

loose/broken/damaged/missing parts,

wear or leaks.

Products must be inspected and serviced

(if applicable) by a qualified technician

every 6 months. This is based on

average residential use by persons of

average size and strength, and on a

property of average metropolitan size.

Use beyond these recommendations may

require more frequent

inspections/servicing.

Ensure that all users of the product have

completed a suitable industry recognised

training course before being allowed

access to the product.

The product has been supplied by a general merchandise

retailer that may not be familiar with your specific

application or description of application. Be sure to attain

third-party approval from a qualified specialist for your

application before use, regardless of any assurances from

the retailer or its representatives.

This product is not intended for use where fail-safe

operation is required. As with any product (for example,

automobile, computer, toaster), there is the possibility of

technical issues that may require the repair or

replacement of parts, or the product itself. If the possibility

of such failure and the associated time it may take to

rectify could in any way inconvenience the user, business

or employee, or financially affect the user, business or

employee, then the product is not suitable for your

requirements. This product is not intended for use where

incorrect operation or a failure of any kind, including but

not limited to, a condition requiring product return,

replacement, parts replacement or service by a technician

may cause financial loss, loss of employee time or an

inconvenience requiring compensation.

If this product has been purchased in error when

considering the information presented here, contact the

retailer directly for details of their returns policy, if

required.
