Baumuller BUC64 S User manual

E5.02024.03a
Manual
BUC64 S/A/F
Feed/Feedback Unit with
analog Controller

Title Manual
Product Feed/Feedback Unit with analog Controller BUC64 S/A/F
Version 5.02024.03a
Status 2005-01-11
Copyright These operating instructions may be copied by the owner in
any quantity but only for internal use. For other purposes
these operating instructions and extracts thereof must not
be copied or reproduced.
Use and disclosure of information contained in these oper-
ating instructions are not permitted.
Designations and company marks contained in these oper-
ating instructions may be brand names, the use of which by
third parties for their own purposes may violate the rights of
the holders.
Obligatory These operating instructions are part of the equipment/ma-
chine. These operating instructions must be available to the
operator at all times and must be in a legible condition. If the
equipment/machine is sold or moved to a different location
these operating instructions must be passed on by the own-
er together with the equipment/machine.
After any sale of the equipment/machine this original and all
copies must be handed over to the buyer. After disposal or
any other end of use this original and all copies must be de-
stroyed.
When the present operating instructions are handed over,
corresponding sets of operating instructions of a previous
version are automatically invalidated. Please notice that
specifications/data/information are current values accord-
ing to the printing date. These statements are not legally
binding according to the measurement, computation and
calculations.
Baumüller Nürnberg GmbH reserves the right, in developing
its products further, to change the technical specifications
and the handling of the products concerned without prior no-
tice.
No liability can be accepted concerning the correctness of
the operating instructions unless otherwise specified in the
General Conditions of Sale and Delivery.
Manufacturer Baumüller Nürnberg GmbH
Ostendstr. 80 - 90
D-90482 Nürnberg
Germany
Tel. [phone] - 0 Fax: [phone] - 1 30
www.baumueller.de

Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
3
of 104
Table of contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.1 First steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.2 Terms used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3 Obligation and liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.1 Observing danger- and safety information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
1.3.2 Dangers when handling this appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
1.3.3 Guarantee and liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Fundamental security information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1 Hazard information and commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
2.1.1 Hazard information structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.1.2 Form of the hazard sign (triangular or round) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1.2.1 Hazard information on personal injury . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.1.2.2 Hazard information on property damage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.1.2.3 Command signs used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2.2 Information sign . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.3 Application according to the terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.4 Non-appropriate application. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.5 Reconstructing the appliance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.6 Disposal of the appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.7 Fire fighting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3 Packing and Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1 Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.2 Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.3 Disposal of the packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.4 Transportation precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4 Description of the Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1 Charging circuit for the DC link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2 Variants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.3 Overview of hazardous areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.4 Characteristics of the unit - type key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.5 Block switching diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
4.6 Construction diagram. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
4.7 Example for PowerOn/Off control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5 Mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.1 Hazardous areas during mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.2 Mounting steps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.2.1 Select a switching cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
5.2.1.1 Space requirements - dimensional drawings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
5.3 Producing the drill holes/threaded holes and the cut-out. . . . . . . . . . . . . . . . . . . . . . . 38
5.4 Mounting the unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.4.1 BUC64S mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.4.2 Mounting BUC64 window variant A/F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
5.4.2.1 Coolant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
5.4.2.2 Connecting the coolant circulation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
4
of 104
Table of contents
6 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.1 General hazard information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.1.1 Voltage test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.2 Hazardous areas at installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.3 Cable requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
6.4 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6.4.1 Power terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
6.4.2 Control connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.4.2.1 Control terminal X99A . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
6.4.2.2 Control terminal X99AB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
6.4.2.3 X1 connection of the charging circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6.4.2.4 LED display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.5 EMC requirements on cable routing (EMC information). . . . . . . . . . . . . . . . . . . . . . . . 54
6.5.1 German EMC law (EMVG). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.5.2 Measures to ensure EMC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.5.2.1 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
6.5.2.2 Grounding. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
6.5.2.3 Screening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
6.5.2.4 Discharge currents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
6.6 Connection diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
7 Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.1 Requirements the executing personnel must meet . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
7.2 Checking the mounting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.3 Checking the installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
7.4 Checking the safety devices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.5 Appliance start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
7.5.1 Step-by-step starting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
8 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.2 Switch-on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
8.3 Monitoring functions and „ready-for-use“ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.4 Monitoring functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
8.5 Ready-for-use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
8.6 Pre-warning error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
8.6.1 Power unit temperature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
8.6.2 PLL synchronous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
9.1 Inspection interval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
10 Repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
11 Setting out of Operation, storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
11.1 Demands on the personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
11.2 Safety regulations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
11.3 Setting out of operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11.4 Demounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11.5 Storage conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11.6 Maintenance during the storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
11.7 Re-commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
12 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
12.1 Safety regulations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
12.2 Demands on the personnel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
5
of 104
Table of contents
12.3 Disposal instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
12.3.1 Modules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
12.4 Recycling plants / offices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Appendix A - Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Appendix B - Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
B.1 EMC accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
B.2 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
B.2.1 Semic line fuse (F3,ZFigure 4– on page 29) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
B.3 Line reactor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
B.4 Water cooler . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Appendix C - Declaration of Conformity / Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
C.1 What is an EU directive? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
C.2 What the CE symbol indicates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
C.3 Definition of the term Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
C.4 Definition of the term Declaration by Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
C.5 Declaration of Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
C.6 Declaration by Manufacturer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Appendix D - Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
D.1 Requirements on the power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
D.2 Burst immunity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
D.3 Required environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
D.4 Electrical specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
D.5 BUC64S - non-electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
D.6 BUC64A - non-electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
D.7 BUC64F - non-electrical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
D.8 Cable for control voltage supply / signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
D.9 Cable for mains supply to appliance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Table of figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
6
of 104
Table of contents

7
of 104
Manual Feed/Feedback Unit with analog Controller
Document no.: 5.02024.03a
1INTRODUCTION
In this chapter we describe the first steps you should carry out after you have received
your appliance. We will give you a definition of terms used throughout this documentation
and we will give you information about what must be observed when using this appliance.
1.1 First steps
1check the scope of delivery, see ZPacking and Transport– from page 23.
2pass on the supplied documentation to the respective departments
3take care of suitable personnel for mounting, installation and commissioning.
4hand over this manual to the personnel for mounting, installation and commissioning.
Make sure, that particularly the safety information is understood and will be observed.
1.2 Terms used
In this documentation for the Baumüller product “Feed/Feed back unit with analogue con-
troller“ we will also use the term "appliance". In the appendix you will find a list of all terms
used, see ZAppendix A - Abbreviations– from page 83
1.3 Obligation and liability
In order to enable you to run this appliance with maximum safety it is essential that you
know and obey the danger- and safety information given in this documentation.
1.3.1 Observing danger- and safety information
To keep you from damage of personnel and property we will use unified danger informa-
tion signs in this documentation.

Obligation and liability
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
8
of 104
1.3
1.3.2 Dangers when handling this appliance
This "Feed/Feed back unit with analogue controller" appliance has been developed and
produced according to the state-of-the-art technics also keeping the respective guidelines
and standards. Still the handling of the appliance can hold dangers. An overview of pos-
sible dangers you will find in chapter ZFundamental security information– from page 11.
When there is a hazard you will always find a detailed security information at the respec-
tive location.
1.3.3 Guarantee and liability
The “Terms of sale and delivery“ of Baumüller Nürnberg GmbH are applied generally.
These you have available at last since the contract was assured. Claims of guarantee or
liability towards Baumüller Nürnberg GmbH are rejected if one or more of the examples
listed below has/have been the cause of the damage/s:
myou have disregarded the information given in this manual
myou have used this appliance within a non-appropriate application
nthis appliance you have
munskillfully mounted
munskillfully connected
munskillfully commissioned
munskillfully operated
munskillfully or not maintained
mlet be mounted, connected, commissioned, operated and/or maintained by not or
not adequate qualified personnel
moverloaded
noperated it with
mdefective security devices
mnot properly mounted or without security devices
mnot efficient safety- and protection devices
menvironmental conditions being not within the specified values
myou have reconstructed this appliance without written permission of Baumüller Nürn-
berg GmbH.
myou have disregarded instructions concerning maintenance in the component manuals
myou have failed to monitor parts of wear and tear properly
myou have carried out a repair job unskillfully
WARNING
The following may occur,if you do not observe this warning information:
mserious personal injury mdeath
All persons, who work at or with this appliance, must have knowledge of and observe all haz-
ard and security information given in this manual.
Furthermore all persons who work with this appliance must in addition know and observe all
local instructions and regulations.

Introduction
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
9
of 104
1
myou have unskillfully combined the appliance with products of other manufacturers
myou have combined the drive system with defective and/or incorrectly documented
products of other manufacturers
The “General terms of sale and delivery“ of Baumüller Nürnberg GmbH apply generally.
Those you have available at least since the contract has been confirmed.

Obligation and liability
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
10
of 104
1.3

11
of 104
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
2FUNDAMENTAL SECURITY
INFORMATION
Every Baumüller appliance was constructed and produced under strict safety guidelines.
Nevertheless working with the appliance can still be dangerous for you.
In this chapter we describe the possible dangers which may occur when you work with
this Baumüller appliance. Dangers are indicated within this documentation by symbols
(icons). All the symbols used in this documentation you will find listed and explained be-
low.
How you can protect yourself against every single danger in detail, we however cannot
state in this chapter. Here only information about general safety measures will be given
to you. The respective safety measures against an occurring hazardous situation you will
find in the following chapters always directly where the hazard arises.
2.1 Hazard information and commands
Hazard information shows you the dangers, which can cause injuries or even your
death.
Please always consider the hazard information which is given to you in this doc-
umentation.

Hazard information and commands
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
12
of 104
2.1
2.1.1 Hazard information structure
The following two examples show you how the hazard informations are constructed. The
triangle is used when indicating a hazard for human beings. When there is a circle instead
of the triangle, the hazard information is only for possible property damage.
Each hazard is classified in one of three different hazard classes. Every hazard class
has one of the following characteristic signal words:
DANGER
mserious property damage mserious personal injury mdeath - will occur
WARNING
mserious property damage mserious personal injury mdeath - may occur
CAUTION
mminor to medium personal injury or
menvironmental pollution or
mproperty damage - may occur
A triangle indicates hazard for human beings.
The shade of grey of the outline reflects the severity of the hazard - darker grey means rising
hazard.
The icon within the square illustrates the hazard.
The outline´s shade of grey reflects the severity of the hazard - darker grey means rising haz-
ard. (Not every hazard information has a square representing the hazard, so we have shown
it as draft here)
The icon in the circle represents a command.
(Not every hazard information has a circle representing the hazard, so we have shown it as
draft here)
The circle indicates hazard for property.
The icon within the square illustrates the hazard.
The outline´s shade of grey reflects the severity of the hazard - darker grey means rising haz-
ard. (Not every hazard information has a square representing the hazard, so we have shown
it as draft here)

Fundamental security information
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
13
of 104
2
The text beneath the icons is constructed as follows:
2.1.2 Form of the hazard sign (triangular or round)
If there is a triangle like or or in front of the signal word, the hazard information
is referring to personal damage.
If there is a round hazard signal like in front of the signal word, the hazard information
is referring to property damage.
2.1.2.1 Hazard information on personal injury
To distinguish each class of hazard information, we use a characteristic outline for both
the triangular hazard signs and the square-form icons
For the hazard class DANGER we use the danger sign. The hazard information of
this hazard class we use in this documentation is listed below:
HERE STANDS THE SIGNAL WORD WHICH INDICATES THE DEGREE OF THE HAZ-
ARD
Here we tell if one or more of the consequences described lower will occur if this hazard in-
formation is not observed.
mhere we describe the possible consequences. The worst consequence stands on the right
side.
Here we describe the hazard.
Here we describe what you can do to avoid this hazard.
DANGER
The following will occur,if you do not observe this danger information:
mserious personal injury mdeath
The hazard is: electricity. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
DANGER
The following will occur,if you do not observe this danger information:
mserious personal injury mdeath
The hazard is: mechanical influence. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.

Hazard information and commands
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
14
of 104
2.1
For the hazard class WARNING we use the warning sign . The following hazard infor-
mation of this hazard class we will use in this documentation.
WARNING
The following may occur,if you do not observe this warning information:
mserious personal injury mdeath
The hazard is: electricity. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
WARNING
The following may occur,if you do not observe this warning information:
mserious personal injury mdeath
The hazard is: mechanical influence. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
WARNING
The following may occur,if you do not observe this warning information:
mserious personal injury mdeath
The hazard is: electro-conductive liquid together with electricity. Here the hazard may be
described in detail.
Here we describe what you can do to avoid the hazard.
WARNING
The following may occur,if you do not observe this warning information:
mserious personal injury mdeath
The hazard is: electro-magnetic radiation. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.

Fundamental security information
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
15
of 104
2
WARNING
The following may occur,if you do not observe this warning information:
mserious personal injury mdeath
The hazard is: liquid coolant. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.

Hazard information and commands
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
16
of 104
2.1
For the hazard class CAUTION we use the caution sign when there is hazard for per-
sons or of environmental pollution. The following hazard information of this hazard class
we will use in this documentation.
CAUTION
The following may occur,if you do not observe this caution information:
mminor to medium personal injury.
The hazard is: hot surface. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
CAUTION
The following may occur,if you do not observe this caution information:
mminor to medium personal injury.
The hazard is: sharp edges. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
CAUTION
The following may occur,if you do not observe this caution information:
mminor to medium personal injury.
The hazard is: rotating parts. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
CAUTION
The following may occur,if you do not observe this caution information:
mminor to medium personal injury.
The hazard is: injury of the eye caused by ricochetting particles. Here the hazard may be
described in detail.
Here we describe what you can do to avoid the hazard.

Fundamental security information
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
17
of 104
2
CAUTION
The following may occur,if you do not observe this caution information:
mminor to medium personal injury.
The hazard is: noise. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
CAUTION
The following may occur,if you do not observe this caution information:
mminor to medium personal injury.
The hazard is: hazard of sliding caused by liquid. Here the hazard may be described in de-
tail.
Here we describe what you can do to avoid the hazard.
CAUTION
The following may occur,if you do not observe this danger information:
menvironmental pollution.
The hazard is: unadequate disposal. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.

Hazard information and commands
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
18
of 104
2.1
2.1.2.2 Hazard information on property damage
If there is a round caution sign in front of the signal word, the safety information refers
to property damage.
2.1.2.3 Command signs used
CAUTION
The following may occur,if you do not observe this caution information:
mproperty damage.
The hazard is: electro-static discharge. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
CAUTION
The following may occur,if you do not observe this caution information:
mproperty damage.
The hazard is: damage of the coolant hose. Here the hazard may be described in detail.
Here we describe what you can do to avoid the hazard.
carry safety gloves
carry safety shoes
carry eye protection
carry ear protection
Use this fire extinguishing agent:
ABC powder.

Fundamental security information
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a
19
of 104
2
2.2 Information sign
2.3 Application according to the terms
You must always use this appliance properly. Listed below you will find some important
information. The information given is intended to give you some impression on how to op-
erate this appliance according to the terms. The information below is not a complete list;
you must always observe the information given throughout this documentation.
mproject this application in a way, that the appliance is run within its specifications.
mtake care that only qualified personnel is working with or at this appliance.
mmount this appliance only at a reasonable steady wall.
minstall this appliance according to the way shown in this documentation.
mtake care that the power supply always meets the requested specifications.
moperate this appliance only if it is in a correct technical state.
moperate this appliance always in an environment according to the information given in
the “Technical specifications“.
moperate this appliance always in the regular condition.
For safety reasons you are not allowed to reconstruct this appliance.
mobserve all respective information given if you want to store this appliance.
You are using this appliance according to the terms, if you observe all notes and informa-
tion given in this operating manual.
2.4 Non-appropriate application
Listed below you will find some examples of non-appropriate application. The information
below is intended to give you some impression of what non-appropriate application is.
However we cannot state all possible non-appropriate applications here. All applications,
where the notes and information given in this documentation is disregarded, are non-ap-
propriate and therefore forbidden.
Examples:
myou have disregarded the information given in this manual
myou have used this appliance within a non-appropriate application
nthis appliance you have
munskillfully mounted
munskillfully connected
munskillfully commissioned
munskillfully operated
munskillfully or not maintained
NOTE
This note is a very important information.

Reconstructing the appliance
Manual Feed/Feedback Unit with analog Controller BUC64 S/A/F
Document no.: 5.02024.03a Baumüller Nürnberg GmbH
20
of 104
2.5
mlet be mounted, connected, commissioned, operated and/or maintained by not or
not adequate qualified personnel
moverloaded
noperated it with
mdefective security devices
mnot properly mounted or without security devices
mnot efficient safety- and protection devices
menvironmental conditions being not within the specified values
myou have reconstructed this appliance without written permission of Baumüller Nürn-
berg GmbH.
myou have disregarded instructions concerning maintenance in the component manuals
myou have failed to monitor parts of wear and tear properly
myou have carried out a repair job unskillfully
myou have unskillfully combined the appliance with products of other manufacturers
myou have combined the drive system with defective and/or incorrectly documented
products of other manufacturers
The “General terms of sale and delivery“ of Baumüller Nürnberg GmbH apply generally.
Those you have available at least since the contract has been confirmed.
mEducation of the personnel
Qualified
personnel
Qualified personnel are persons who have been authorized by the plant manager to carry
out the activities required, who are able to recognize possible dangers and to avoid them.
They must have the skills, experience, instruction and knowledge of the operational con-
ditions and the respective standards, regulations and rules to detect and avoid accidents.
2.5 Reconstructing the appliance
Unauthorized reconstructions without written permission of Baumüller Nürnberg GmbH
are not allowed.
2.6 Disposal of the appliance
The correct disposal of the appliance is described in ZDisposal– from page 79.
The appliances of Baumüller Nürnberg GmbH are only to be mounted, installed, oper-
ated and maintained by qualified personnel.
