Baxton Studio LC21020902 User manual

ASSEMBLY INSTRUCTION
Console Table
1
Date last updated:8-27-2021

PARTS LITS
HARDWARE LITS
2

Fix handle J to part 14 using screws (F), as shown.
3
Fix Part 10 and 11 to part 12 using screws (D).
Slide part 13 into grooves between part 10, 11 and 12.
Insert quickfit screws (A) to part 14.
Insert cam locks (B) to part 10 and 11.
Fit part 14 to part 10 and 11.
Turn cam locks clockwise to tighten.
Fix inner drawer runner (DR) and (DL) to assembled drawer using screw(F), as shown.
ASSEMBLY STEPS

Fix outer drawer runner (CL) to part 2 using screws (F), as shown.
Fix outer drawer runner (CR) to part 3 using screws (F), as shown.
Insert wooden dowels (C) to part 6.
Fit part 2, 3 and 4 to part 6, as shown.
Secure part 2, 3 and 4 to part 6 using screws (I), as shown.
Slide part 5 into grooves between part 2 and 4.
4

Insert quickfit screws (A) and wooden dowels (C) to part 1.
Insert cam locks (B) to part 2, 3 and 4.
Fit part 1 to assembled parts.
Turn cam locks clockwise to tighten.
Fix part 8, 9 and 15 to parts 7 using screws (G), as shown.
5
HX1

Fix assembled feet parts to part 6 using screws (E), as shown.
Fix wall straps (N) to assembled unit using washers (M) and screws (L), as shown.
Fix parts 16 on to back of assembled unit using screws (K), as shown.
6

Fit Drawer into the assembled unit.
For extra stability, it is recommended that you fix your console
table to the wall using the additional hardwares (O, M and I), as shown.
Should you choose not to affix the product to the wall, serious
injury may be caused if the product tips over.
7
