BCP SKY3079 User manual

SKY3079 + SKY3526
INSTRUCTION
MANUAL
Over-the-Toilet Bathroom
Storage Cabinet
Ver. 2

HARDWARE
TOOLS REQUIRED
1
24 PCS
M8 DOWEL CAM BOLT
2
17 PCS
• Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this product as a step ladder.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void
the product warranty.
NOTICE
3
7 PCS
9.5MM CAM
LOCK
UPPER DOOR
HINGE
4
1 PC
5
1 PC
LOWER DOOR
HINGE
M4 X 16MM
SCREW
6
1 PC
7
1 PC
KNOB METAL PLATE
8
1 PC
9
1 PC
M3 X 12MM
SCREW
MAGNETIC
CATCH
10
1 PC
11
8 PCS
SHELF PEG M3 X 14MM
SCREW
12
2 PCS
PHILLIPS
SCREWDRIVER
PENCIL
& RULER
DRILL &
DRILL BIT
APPROXIMATELY
30 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
2|

PARTS
MIDDLE SHELF I
B
1 PC
A
1 PC
TOP PANEL MIDDLE SHELF II
C
1 PC
DIVIDER
F
1 PC
E
1 PC
BOTTOM PANEL DOOR
G
1 PC
LOWER SHELF
D
1 PC
LEFT PANEL
H
1 PC
| 3
HARDWARE
13
10 PCS
12MM CAM
LOCK
M4 X 35MM
SCREW
14
6 PCS
15
2 PCS
BRACKET M3 X 14MM
SCREW
16
6 PCS
17
2 PCS
M3.5 X 40vvMM
SCREW
WALL
ANCHOR
18
2 PCS

4|
LOWER
RIGHT PANEL
K
1 PC
LOWER
LEFT PANEL
J
1 PC
I
1 PC
RIGHT PANEL FRONT
SUPPORT
L
1 PC
PARTS
TOP SUPPORT
N
1 PC
M
2 PCS
BACK SUPPORT BACK PANEL I
O
1 PC
BACK PANEL II
P
1 PC
TIGHTENING CAMLOCKS
1. Screw cam bolt
in completely.
2. Insert cam bolt and cam lock into
designated holes.
3. Screw cam lock
clockwise to secure
cam bolt.

PRODUCT ASSEMBLY
1Attach a part 7 knob to the part G door with a part 6 screw. Attach a part 8 metal plate with a
part 9 screw.
Insert a part 4 upper door hinge and part 5 lower door hinge.
2Screw a part 2 cam bolt into the part A top panel. Attach the part 10 magnetic catch with two
part 12 screws.
| 5
G
5
49
8
7
6
A
12
10
x2
2

PRODUCT ASSEMBLY
3Screw six part 2 cam bolts into part H left panel and part I right panel.
6 |
H
I
2x6
4Screw six part 2 cam bolts into part J lower left panel and part K lower right panel.
J
K
2x6

PRODUCT ASSEMBLY
5Attach the lower panels to a part L front support and two part M back supports with six part 1
dowels and six part 13 cam locks.
| 7
J
M
L
K
1x6
13 x6
x2
6Attach the part F divider to part A top panel with two part 1 dowels and a part 3 cam lock.
3
A
F
1x2

PRODUCT ASSEMBLY
7Attach part D lower shelf with a part 1 dowel and two part 14 screws.
8|
D
14 x2
1
8Attach part N top support to part H left panel with a part 1 dowel and part 3 cam lock.
H
N
3
1

PRODUCT ASSEMBLY
9Attach shelf assembly to left panel with four part 1 dowels and two part 3 cam locks.
| 9
H
1x4
3x2
10 Slide in the part O back panel.
O

10 |
I
3x3
1x5
PRODUCT ASSEMBLY
11 Attach part I right panel with five part 1 dowels and three part 3 cam locks.
12 Slide in part P back panel.
P
