BCP SKY6645 User manual

SKY6645Ver. 1
3-Piece Dinette Set
with Side Cabinet
INSTRUCTION
MANUAL

2|
HARDWARE
A
28 PCS
CAM BOLT CAM LOCK
B
28 PCS
DOWEL
C
12 PCS
HANDLE
D
2 PCS
E
8 PCS
SHELF
SUPPORT
MAGNETIC
FASTENER
F
2 PCS
FASTENER
PLATE
G
2 PCS
FASTENER
SCREW
H
8 PCS
TOOLS REQUIRED
PHILLIPS
SCREWDRIVER
UP TO 60 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
286 LBS
CHAIR
CAPACITY
LBS
44 LBS
SHELF
CAPACITY
LBS
220 LBS
TABLE
CAPACITY
LBS
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws, and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during initial assembly. Do not firmly tighten the screws until the item is
completely assembled.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
•Assemble this product on a flat, level surface near its intended space.
•This product is intended for residential use only.
Please retain these instructions for future reference.
NOTICE
I
4 PCS
CABINET FEET HANDLE
SCREW
J
4 PCS
M8 x 12mm
SCREW
K
2 PCS
M6 x 35mm
SCREW
L
2 PCS
ALLEN WRENCH
(PROVIDED)

| 3
4
1 PC
CABINET SIDE II
PARTS
1 PC
TABLETOP
1
1 PC
CABINET BACK
2
1 PC
CABINET BOTTOM
FRAME
6
5
1 PC
CABINET BOTTOM
PANEL
7
2 PCS
SHELF
1 PC
CABINET DOOR II
9
8
1 PC
CABINET DOOR I
1 PC
CABINET SIDE I
3
HARDWARE
M
1 PC
M8 x 45mm
SCREW
M6 x 30mm
SCREW
N
16 PCS
M6 x 40mm
SCREW
O
12 PCS
DOOR HINGE
P
4 PCS

4|
13
1 PC
TABLE LEGS
PARTS
1 PC
CABINET TOP FRAME
10
2 PCS
BACKREST
11
2 PCS
CHAIR SIDE II
15
14
2 PCS
CHAIR SIDE I
16
2 PCS
CHAIR FRONT FRAME
19
1 PC
TABLE SUPPORT BAR
2 PCS
CHAIR BACK FRAME
18
17
2 PCS
FOOTBAR
2 PCS
SEAT
12

| 5
PRODUCT ASSEMBLY
1
2Locate the part 3 & 4 cabinet sides (I&II) and insert nine part A cam bolts into each panel,
eighteen bolts total.
Insert two part A cam bolts and two part C dowels into the part 5 cabinet bottom panel.
Insert two part B cam locks into the part 6 cabinet bottom frame, then attach it to the part 5
panel. Turn the cam locks to secure.
6
5
Ax2
Cx2
Bx2
4
3
Ax9
Ax9
Use a screwdriver
to turn the cam lock to
secure the cam bolt.

6|
PRODUCT ASSEMBLY
3
4Locate the part 5&6 panel assembly, insert part B two cam locks each into the part 5&6
panels, then attach it to the part 3 cabinet side.
Insert two part B cam locks into the part 10 cabinet top frame, and attach it to the part 3
cabinet side. Turn the cam locks to secure.
Insert three part B cam locks into the part 2 cabinet back, then attach it to the part 3 cabinet
side (see previous step). Turn the cam locks to secure.
3
2
B
x3
x2
C
10
6
Bx6
Use a screwdriver
to turn the cam lock to
secure the cam bolt.

| 7
PRODUCT ASSEMBLY
5Insert three part B cam locks into the part 2 cabinet back.
Insert two part B cam locks each into the part 10 cabinet
top frame, part 6 cabinet bottom frame, and part 5
cabinet bottom, six locks total.
Attach the part 4 cabinet side to the cabinet assembly.
Turn the cam locks to secure.
Use a screwdriver
to turn the cam lock to
secure the cam bolt.
4
x2
C
Bx9
6Insert eight part A cam bolts and six part C dowels into the part 1 tabletop.
1
Bx8
x6
C

8|
PRODUCT ASSEMBLY
7Place the part 1 tabletop on a flat, padded
surface with the bottom facing upward.
Locate the cabinet assembly and insert three
part B cam locks into both the part 3&4
cabinet sides. Insert two part B cam locks
into the part cabinet back.
Attach the cabinet to the tabletop, then turn
the cam locks to secure.
Attach the part 13 table legs to the tabletop
with two part L screws.
Bx8
1
13
3
Lx2

| 9
PRODUCT ASSEMBLY
8
9Flip the assembly upright, then attach
two part F magnetic fasteners to the
part 5 cabinet bottom with four part
H screws, two screws per fastener.
Insert eight part E shelf supports into
the part 3&4 cabinet sides, four
supports per side, then insert two
part 7 shelves.
Insert four part I cabinet feet into the bottom of the cabinet assembly.
Attach the part 19 support beam to the part 2 cabinet back with two part K screws, then
attach the part 13 table legs with one part M screw.
Ix4
K
x2
M
19
7
x2
x8
x8
E
Hx4
F
x2

PRODUCT ASSEMBLY
10
11 Insert two part P door hinges into each cabinet door, then insert the doors into the
cabinet assembly.
NOTE: Make sure the door handles sit in the center of the cabinet assembly.
Locate the part 8&9 cabinet doors, then
attach two part D handles with four part J
screws, two screws per handle.
Turn the part 8&9 cabinet doors around
and attach two part G fastener plates with
four part H screws, two screws per plate.
10 |
9
8
x2x2
Dx2x4
J
x2x2
G
x2
x4
H
BACK VIEW
Px2
1.
2.
3.
