BCP SKY5232 User manual

SKY5232 + SKY5233 + SKY6020 + SKY6021
Ver. 2
INSTRUCTION
MANUAL
3-Piece Wicker
Swivel Chair Set

2|
Please retain these instructions for future reference.
HARDWARE
1
28 PCS
M6 x 35mm
SCREW
M6 x 15mm
SCREW
M6 x 12mm
SCREW
2
8 PCS
3
12 PCS
TOOLS REQUIRED
APPROXIMATELY
40 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
125 LBS
TABLE
CAPACITY
LBS
250 LBS
CHAIR
CAPACITY
LBS
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Do not lean backwards when sitting in chair.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during assembly. Do not firmly tighten screws until item is fully assembled.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
NOTICE
SPRING
WASHER
4
8 PCS
ALLEN WRENCH
(PROVIDED)
5
48 PCS
M6 WASHER
WRENCH
(PROVIDED)
M6 NUT
6
16 PCS

2 PCS
BASE
D
2 PCS
SEAT F
4 PCS
TABLE LEG
I
E
2 PCS
INNER FRAME
G
2 PCS
SEAT CUSHION H
2 PCS
BACK CUSHION
J
1 PC
TABLETOP K
1 PC
TABLE SHELF
| 3
PARTS
2 PCS
LEFT ARM
2 PCS
RIGHT ARM
2 PCS
ABBACKREST
C

4|
1Attach part A left arm and part B right arm to part C
backrest with four part 2 screws and four part 5 washers.
NOTE: Fasten screws loosely during assembly. Do not
firmly tighten screws until item is fully assembled.
PRODUCT ASSEMBLY - CHAIR
x4
2
x4
5
B
A
C

| 5
2Attach part D seat with six part 1
screws and six part 5 washers.
3Carefully flip chair over.
Attach part E inner frame with four part 1 screws and four part 6 nuts.
PRODUCT ASSEMBLY - CHAIR
x4
1
x6
5
x6
1
x4
6
E
D
