BCP SKY6513 User manual

SKY6513 + SKY6891 + SKY6892
INSTRUCTION
MANUAL
2-Door Storage Cabinet
Ver. 2

| 3
HARDWARE
TOOLS REQUIRED
A
8 PCS
M6 X 35MM
CAM BOLT
Ø15 X 15MM
CAM LOCK
B
8 PCS
•Please do not exceed the weight limitations of this item.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws, and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every
90 days.
•Fasten screws loosely during initial assembly. Do not firmly
tighten the screws until the item is completely assembled.
•Do not use or store this item in the proximity of open flame
or flammable/combustible chemicals.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop
using this product until repairs are made and/or factory
replacement parts are installed.
•Do not use this item in a way inconsistent with the
manufacturer’s instructions as this could void the product
warranty.
•This product is intended for residential use only.
NOTICE
PHILLIPS + FLATHEAD
SCREWDRIVER
C
12 PCS
Ø7.8 X 30MM
DOWEL
D
4 PCS
M7 X 38MM
SCREW
H
2 PCS
M4 X 18MM
SCREW
G
2 PCS
HANDLE
E
4 PCS
M6 X 40MM
BOLT
M6 X 28MM
BOLT
F
6PCS
Please retain these instructions for future reference.
L
4 PCS
M3 X 14MM
SCREW
K
4 PCS
SCREW GUIDE
I
4 PCS
HINGE M3.5 X 14MM
SCREW
J
24 PCS
M
4 PCS
FOOT CAP
UP TO 45 MIN.
ASSEMBLY
2 PERSON
ASSEMBLY
66 LBS
BOTTOM BOARD
CAPACITY
LBS
33 LBS
SHELF
CAPACITY
LBS
66 LBS
TOP BOARD
CAPACITY
LBS
4mm
ALLEN WRENCH
(PROVIDED)

4|
4
1 PC
CABINET RIGHT SIDE
PARTS
1 PC
CABINET TOP
1
1 PC
CABINET BOTTOM
2
1 PC
CABINET SHELF
6
5
2 PCS
CABINET BACK PANEL
1 PC
CABINET LEFT SIDE
3
10
2 PCS
BASE FRAME
CONNECTOR
1 PC
LEFT DOOR
7
1 PC
RIGHT DOOR
8
2 PCS
BASE SIDE FRAME
9

PRODUCT ASSEMBLY
1Insert four
part A cam bolts into the part 3 & 4 left & right side panels , two bolts per panel.
2Insert four
part B cam locks into the part 6 cabinet shelf . Attach the part 3 & 4 side panels
with four
part C dowels . Secure by turning the cam locks.
| 5
4
3
Ax4
46
3
Bx4
Cx4

6|
PRODUCT ASSEMBLY
3Insert four
part A cam bolts into the bottom of the part 1 cabinet top.Place the board on a
level, padded surface with the cam bolts facing upward.
4Insert four
part B cam locks and eight part C dowels into the part 3 & 4 side panels , two locks
and four dowels per side.
Slide two
part 5 back panels into the grooves above and below the part 6 cabinet shelf .
Attach the part 1 cabinet top to the
part 3 & 4 side panels , secure by turning the cam locks.
Attach the part 2 cabinet bottom to the
part 3 & 4 side panels with four part D screws .
Flip the assembly upright.
Ax4
Cx8
1
D
x4
Bx4
2
5
43
6
5
1

PRODUCT ASSEMBLY
5Attach two
part I hinges to each door with eight part J screws , two screws per hinge.
Secure the
part 8 right door by attaching the hinges to the part 4 side panel with eight part J
screws
, four screws per hinge. Repeat on the part 3 side panel to attach the part 7 left door .
NOTE :Use a philip’s screwdriver to secure the (2) pre-installed screws on each hinge after
attaching the part J screws.
Attach one
part G handle each to the part 7 & 8 cabinet doors with two part H screws .
6 Turn the cabinet assembly the back panels are facing outward. Insert four
part K screw guides
into the bottom corners of the two part 5 back panels , secure with four part L screws , one
screw per guide.
Ix2
Jx2
Gx2
Hx2
Kx4 Lx4
| 7
Use a philip’s screwdriver to secure the
(2) pre-installed screws on each hinge
after attaching the part J screws.

8|
PRODUCT ASSEMBLY
7Attach two
part 10 base frame connectors to one part 9 base side frame with two part E
bolts
, connect the remaining side frame with two more part E bolts .
Screw four
part M foot caps into the side panels, adjust so all feet are level.
10
10
9
9
Ex4
Mx4

| 9
PRODUCT ASSEMBLY
8Attach the base assembly to the cabinet assembly with six
part F bolts . Attach the two part 10
frame connectors
to the part 2 bottom with four bolts, and the part 9 side frames with
two bolts.
Fx6
