INSTRUCTION
MANUAL
Counter Height
Dining Table Set

As shoppers, we’re always trying
to find the perfect balance between
quality & value. At BCP, we believe
we’ve achieved that. Our diverse
catalog of everyday essentials is
tailored especially to our customers
& guaranteed to hit that sweet
spot of high quality & low price.
Always.
Fasten screws loosely
during assembly.
Do not firmly tighten
screws until item is
fully assembled.
bestchoiceproducts.com

| 3
• Please do not exceed the weight limitations of this item.
• Do not stand on or use any part of this item as a step ladder.
• Firmly secure all bolts, screws, and knobs before use.
• Reconfirm that all bolts, screws, and knobs are secure every 90 days.
• Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
• If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or
factory replacement parts are installed.
• Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
Please retain these instructions for future reference.
NOTICE
TIGHTENING CAMLOCKS
1. Screw cam bolt
in completely.
2. Insert cam bolt and cam lock into
designated holes.
3. Screw cam lock
clockwise to secure
cam bolt.
K
38 PCS
CAM BOLT CAM LOCK
L
38 PCS
M6 X 12MM
SCREW
M
12 PCS
M6 X 35MM
SCREW
N
2 PCS
TABLE HARDWARE
TOOLS REQUIRED
PHILLIPS
SCREWDRIVER
APPROXIMATELY
45 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
285 LBS
CAPACITY
CHAIR
LBS
90 LBS
CAPACITY
TABLE
LBS
ALLEN WRENCH
(PROVIDED)

4|
TABLE PARTS
1 PC
SHELF SIDE I
A
1 PC
SHELF SIDE II
B
D
1 PC
SHELF SUPPORT II
1 PC
BACK PANEL
F
E
3 PCS
SHELF
2 PCS
SHELF SUPPORT I
C
J
2 PCS
BRACKET
1 PC
TABLETOP
G
1 PC
SIDE FRAME
H
1 PC
SUPPORT
I

Kx16
PRODUCT ASSEMBLY - TABLE
Screw thirty-two part K cam bolts into the part A and part B shelf sides, sixteen cam bolts per
shelf side.
1
A
x16
K
B
| 5

Attach two part C and a part D shelf support to the part A shelf side with six part L cam locks.
2
6|
x6
L
C
C
D
A
PRODUCT ASSEMBLY - TABLE

| 7
Attach three part E shelves with six part L cam locks.
3
E
E
E
Lx6
PRODUCT ASSEMBLY - TABLE

Flip assembly over.
Attach part F back panel with four part L cam locks.
4
F
Lx6
8|
PRODUCT ASSEMBLY - TABLE

| 9
Attach the part B shelf side with sixteen part L cam locks.
5
Lx16
B
PRODUCT ASSEMBLY - TABLE

Attach two part J brackets and part I support to the part H side frame with six part M screws.
6
10 |
Attach the assembled frame to the part G tabletop with four part M screws and two part N screws.
Screw in six part K cam bolts.
7
Mx6
x2
Kx6
x2
N
x4
M
H
I
G
J
PRODUCT ASSEMBLY - TABLE
