BCP SKY5948 User manual

SKY5948
INSTRUCTION
MANUAL
Mirrored Jewelry Armoire
with Drawer
Ver. 2

2|
HARDWARE
TOOLS REQUIRED
1
8 PCS
LAG BOLT LAG NUT
2
8 PCS
•Firmly secure all bolts, screws, and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is
completely assembled.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•Be aware that some parts are heavy and have sharp edges.
•If any parts are missing, broken, damaged, or worn, stop using this product until repairs are made
and/or factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void
the product warranty.
• This product is intended for residential use only.
NOTICE
PHILLIPS
SCREWDRIVER
3
10 PCS
M6 X 30MM
DOWEL
4
12 PCS
M2.5 X 12MM
SCREW
8
1 PC
M4 X 16MM
SCREW
7
6 PCS
BARREL NUT
5
8 PCS
M4 X 35MM
SCREW
M6 X 45MM
BARREL BOLT
6
6 PCS
Please retain these instructions for future reference.
12
2 PCS
PIVOT
CONNECTER
SET
11
2 PCS
M8 X 30MM
DOWEL
9
1 PC
KNOB M3 X 12MM
SCREW
10
12 PCS
UP TO 30 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
3 AA BATTERIES
+AA -

D
1 PC
CABINET TOP
PARTS
1 PC
ARMOIRE
A
2 PCS
ARMOIRE SUPPORT
B
1 PC
CABINET SIDE
E2
E1
1 SET
CABINET SIDE
1 PC
SUPPORT BRACE
C
1 PC
CABINET BACK
F
1 SET
CABINET BASE
G
1 PC
DRAWER SIDE
H1
| 3
HARDWARE
13
1 SET
FEMALE
RUNNER (L/R)
MALE
RUNNER (L/R)
14
1 SET
15
2 PCS
LARGE WASHER SMALL WASHER
16
2 PCS

PRODUCT ASSEMBLY
1Attach one set of part H1 & H2 drawer sides to the part I drawer back with four part 5 screws.
Insert the part J drawer bottom.
4|
PARTS
1 PC
DRAWER SIDE
H2
1 PC
DRAWER BACK
I
1 PC
DRAWER FRONT
K
1 PC
DRAWER BOTTOM
J
I
H2
H1
5x4
J

Attach the runner sets as
shown with the runner wheels
at the back of the drawer.
| 5
PRODUCT ASSEMBLY
2Attach the part 9 knob to the part K drawer front with one part 8 screw.
Attach the drawer front to the drawer assembly with four part 2 lag nuts and four part 1
lag bolts.
Flip the drawer assembly attach the part 14 male runner set to the
drawer sides with six part 10 screws.
14
K
8
2x4 1x2 9
14
10
x6

Attach the runner sets as shown
with the runner wheel at the
drawer compartment opening.
6|
PRODUCT ASSEMBLY
3Locate the part E1 & E2 cabinet sides and attach the part 13 female runner set with six part 10
screws.
4Attach the cabinet side set to the part G cabinet base with four part 3 dowels and four
part 5 screws.
E2
E2
E1
E1
G
13
10
x6
5
x4
3
x4

| 7
PRODUCT ASSEMBLY
5Attach two part B armoire supports to the part C support brace with two part 3 dowels, two
part 7 barrel nuts, and two part 6 barrel bolts.
Attach the support assembly to the part D cabinet top with four part 7 barrel nuts and four
part 6 barrel bolts.
B
B
7x4
3x2
6x2
7x2
D
C
6
x4

PRODUCT ASSEMBLY
6Attach the part D cabinet top to the cabinet assembly with four part 3 dowels, four part 1 lag
bolts, and four part 2 lag nuts.
8|
D
2x4
1x4
3
x4

PRODUCT ASSEMBLY
7Attach the part F cabinet back with twelve part 4 screws.
| 9
4x12
F

10 |
PRODUCT ASSEMBLY
8Attach the part A armoire to the supports with two part 12 connector sets, two part 15
washers, and part 16 washers.
Insert two part 11 dowels into the corresponding holes, depending on your desired angle.
A
11 x2
12 x2
A
11 x2
12 x2 15
x2 16
x2
