BE E4025 User manual

AIR COMPRESSOR
OPERATORS MANUAL
Version 5.1

1 | Page
Congratulations on purchasing your new
BE Air Compressor
Your BE Compressor has been designed to give many years of reliable service when used in accordance with
the following instructions.
The following should be carried out before using your new compressor:
1. READ INSTURCTION MANUAL
Carefully read this instruction manual and understand before starting your new compressor.
2. CHECK OIL LEVEL
(Refer Lubrication – Page 8)
3. CHECK VOLTAGE
For electric models ensure voltage supply and amp rating are compatible with motor (Typically 240
volts).
4. RUNNING-IN PERIOD
Before using your new air compressor run it for 15-30 minutes under no load by opening tank drain
valve to permit air to escape. This will lubricate pistons and bearings.
TABLE OF CONTENTS
Warranty
____________________________ 1
Introduction
_________________________ 1
Knowing your Air
Compressor__________ 2
Safety Instructions
___________________ 2.3
Warning label guidelines
______________ 2.3
Specifications
_______________________ 4
Glossary
____________________________ 4
Duty Cycle
__________________________ 4
Parts & Features
_____________________ 5.6
Installation & Assembly
_______________ 7
Lubrication and Oil
___________________ 8
Operating procedures
_________________ 8.9
Preventative Maintenance
______________ 10
Storage
_____________________________ 11
Trouble Shooting
_____________________ 11
Maintenance and repair record
_________ 12
WARRANTY, TERMS & CONDITIONS
BE Australia warrants to the original purchaser of each BE
Compressor, to be free from defects in material and
workmanship.
Industrial Series:3yr Pump, 5yr Tank and 12 months Limited
Warranty on accessories and motor from the date of initial
purchase.
Commercial & Workshop Series: 12 months Limited Warranty
on complete unit. All Engines are covered by manufacturer’s
warranty.
BE Australia will provide a new part or total replacement at its
discretion in place of any part or complete which is found upon
its inspection to be defective in material and workmanship
during the warranty period.
Such parts will be repaired or replaced without charge to the
initial user upon proof of purchase to the store of purchase at
the time of claiming under this warranty.
This warranty does not apply to failure occurring because of
abuse, misuse, negligent repairs, corrosion, erosion and normal
wear and tear. Alterations or modifications made to the product
without express written consent of BE Australia or failure to
follow the recommended operating and maintenance
procedures as provided in this publication are also not
warranted or guaranteed by BE Australia.
Irrespective of whether warranty is approved or rejected, the
following costs are not covered under this warranty policy.
Fares, charter fees, car hires, freight, tolls, hire or loan
equipment, loss of earnings or stock, medications.

2 | Page
SAFETY INSTRUCTIONS
The information listed below should be read and understood by the operator. This information is
given to protect the user while operating and storing the air compressor. We utilise the symbols
below to allow the reader to recognize important information about their safety.
Indicates an imminently hazardous situation
which, if avoided, will result in death or
serious injury.
Indicates a potentially hazardous situation
which, if avoided, may result in minor or
moderate injury.
Indicates a potentially hazardous situation
which, if avoided, could result in death or
serious injury.
When used without the safety alert symbol
indicates a potentially hazardous situation
which, if avoided, may result in property
damage.
Improper operation or maintenance of this
product could result in serious and/or property
damage. Read and understand all the
warnings and safety instructions provided
before using this equipment.
Air compressor model E7025 should be operated on a
dedicated 10amp circuit, for model E7035 + E16035 these units
should be operated on a 15amp circuit. Always use more air
hose before utilising extension cords. Low voltage will cause
damage to the motor and void motor warranty.
If the air compressor is in operation, all guards and covers
should be attached and installed correctly. If any guard or
cover has been damaged, do not operate the equipment until
the proper personnel has correctly repaired the equipment. The
power cord should be free of any moving parts, twisting and/or
crimping while in use and while in storage.
Always wear AS/NZS1336 approved safety glasses/eye
protectors with side shields when the air compressor is in use.
Turn off the air compressor and drain the air tank before
performing any type of maintenance or disassembly of the
hoses or fittings. Never point any nozzle or sprayer toward any
part of the body or at other people or animals.

3 | Page
Avoid using the air compressor in confined areas. Always have
adequate space (30cm) on all sides of the air compressor. Also
keep children, pets, and others out of the area of operation.
This air compressor does not provide breathable air for anyone
or any auxiliary breathing device. Spraying material always
needs to be in an area away from the air compressor to prevent
damage to the air compressor filter.
Never utilise the air compressor in the rain or wet conditions.
Any electrical issues or repairs should be performed by
authorised personnel such as an electrician and should comply
with all Australian electrical codes. The air compressor should
also have the proper three prong grounding plug, correct
voltage, and adequate fuse protection.
Never operate the compressor near combustible materials, petrol,
or solvent vapours. If spraying flammable materials, locate the air
compressor at least 10 metres away from the spray area. Never
operate the air compressor indoors or in a confined area.
Always drain the air compressor tank daily or after each use. If the
air tank develops a leak, then replace the air compressor. Never
use the air compressor after a leak has been found or attempt to
make any modifications to the air tank. Never modify the air
compressor’s factory settings which control the tank pressure or
any other function.
Modification of the 15amp power plug will void warranty. Electric
compressors are not recommended to be run on generators.
It is NOT RECOMMENDED to use an electric extension lead/cord.
Use longer pneumatic hose for remote locations.

4 | Page
SPECIFICATIONS
MODEL
LENGTH cm
HEIGHT cm
WIDTH cm
WEIGHT kg
E 4025
72
66
33
30.5
E 4030V
72
66
33
38.5
E 5020-S
78
68
33
45
E 5025-C
88
73
38
56
E 5030-C
88
73
38
57
E 7025
94
85
43
70
E 7035
94
85
43
85
E 10030-C
106
78
38
65
E 11035
122
95
42
120
E 16035
135
95
55
140
E 30075
160
118
60
280
E 30010
160
118
60
290
P 5065C-H
88
73
38
38
P 5070C-R
88
73
38
55
P 7065 + P7070
94
85
43
85
D 7048 + D7050
94
95
43
90
P 16065
135
100
55
130
P 16013 + P 16015
135
104
55
135
D 16010
135
115
55
150
GLOSSARY
L/Min: Litres per minute. a metric unit of air flow
C.F.M Cubic Feet per Minute; an imperial unit of air flow (convert to metric multiply
by 28.32)
K.P.A Kilopascals; a metric unit of measure for pressure.
Psi:Pounds per square inch; an imperial unit of measure for pressure.
F.A.D: Free air delivery (L/Min or C.F.M)
Cut-In Pressure: The air compressor will automatically start to refill the tank when the
pressure drops below the prescribed minimum.
Cut-Out Pressure: The point at which the motor stops when the tank has reached maximum
air pressure
Code Certification: Products that bear one or more of the following marks: UL, CUL, ETL,
CSA, EMC, have been evaluated by OSHA-certified independent safety
laboratories and meet the applicable Underwriters Laboratories Standards
for Safety
DUTY CYCLE
BE recommend a maximum duty cycle of 60% of on-load and 40% off-load for all BE Industrial compressors
and 30% on load and 70% off load on domestic range. Cycle times over this may cause damage to your
compressor.

5 | Page
AIR COMPRESSOR PARTS AND FEATURES

6 | Page
AIR COMPRESSOR PARTS AND FEATURES
Drain Valve: Used to drain condensation from the air receiver. Located at bottom of tank.
Motor Thermal Overload: The motor has an automatic thermal overload protector. If the motor overheats,
this protector will shut off the motor. The motor must be allowed 30 minutes to cool before restarting (not
shown).
Pressure Switch: This controls the power to the motor and the cut-in/cut-out pressure settings. This switch
serves as the Auto-On/Off positions for the unit.
Air Intake Filter: Provides clean air to the pump and must always be kept free of debris. Check daily or
before each use. Picture shown in assembly section.
Air Compressor Pump: Oil lubricated pump that compresses air which is distributed to the tank.
Non-Return Valve: When the pump is not in operation the valve closes to retain air pressure inside the
receiver.
Air Relief Valve:The air relief valve located on the bottom of the pressure switch is designed to
automatically release compressed air when the air compressor reaches cut-out pressure. The released air
should only escape momentarily, and the valve should then close.
Safety Valve:Used to allow excess tank pressure to escape into the atmosphere. This valve should only
open when the air tank pressure is above the maximum rated pressure.
Outlet Pressure Gauge: Indicates the outgoing air pressure to the tool and is controlled by the filter
regulator.
Tank Pressure Gauge:Indicates the reserve air pressure in the tank.
Filter Regulator: The air pressure coming from the air tank is controlled by the filter regulator. To increase
the pressure, turn the knob clockwise and to decrease the pressure turn the knob counter clockwise

7 | Page
INSTALLATION AND ASSEMBLY
The air compressor should be turned off and unplugged from the power source before any maintenance is
performed as well as the air bled from the tank and the unit allowed time to cool. Personal injuries could
occur from moving parts, electrical sources, compressed air, or hot surfaces. The filter regulator assembly
must be attached before use. Failure to assemble correctly could result in leaks and possible injury. If
unsure of assembly instructions or you have trouble with assembly, please call your local service dealer
for further instruction.
LOCATION OF THE AIR COMPRESSOR
The air compressor should always be in a level, clean, dry, and well-ventilated environment. The unit should
have a minimum, 30cm of space on each side. The air filter intake should be free of any debris or obstructions.
Check the air filter daily to be sure it is clean and in working order.
GROUNDING INSTRUCTIONS
This product should be grounded. In the event of an electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the electric current. This product is equipped with a cord having
a grounding wire with an appropriate grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded in accordance with all local codes and ordinances. Check with qualified electrician or
service personnel if these instructions are not completely understood of if in doubt as to whether the tool is
properly grounded. For 3 phase machines ensure correct rotation.
Improper installation of the grounding plug will result in a risk of electric shock. If repair or replacement of the
cord or plug is necessary. Only use a qualified electrician. Do not modify the plug provided; if it will not fit
the outlet, have the proper outlet installed by a qualified electrician.
This product is for use on a circuit having a nominal rating of 240v or 415v and is factory-equipped with a
specific electric cord and plug to permit connection to a proper electric circuit. Make sure that the product is
connected to an outlet having the same configuration as the plug. No adaptor should be used with this
product. If the product must be reconnected for use on a different type of electric circuit, a qualified
electrician should make the reconnection.
TO INSTALL THE AIR INTAKE FILTER
Remove the air intake filter from the poly bag and screw it onto the head of the compressor.

8 | Page
LUBRICATION AND OIL
1. Stop compressor.
2. Check oil level.
3. Add or replace oil as required.
Oil level should be maintained above midpoint of sight glass and filled to
the centre of the red circle in the sight glass (as shown below).
Remove the oil fill cap by turning it counter clockwise by hand. Fill the compressor pump with Air compressor
oil at slow intervals until the oil reaches the centre of the red circle in the sight glass (as shown).
Use oil such as SAE-30 (measured@100OC) Mineral based Compressor Oil.
BE Pump Oil part number 85.490.000 is recommended.
Drain the tank to release all tank air pressure before removing the
oil fill cap. Be sure the air vent in the oil fill cap (see figure to the
right) is free from debris. If air vent is blocked, pressure can build
in crankcase causing damage to the compressor and possible
personal injury.
OPERATING PROCEDURES
DAILY START-UP PROCEDURES
1. Before connecting your Air compressor to a power source, be sure that the voltage supply is the
same as that specified on the name plate of the compressor.
2. Set the Auto-On/Off lever to the Off position.
3. Check the air compressor visually for any damage or obstruction.
4. Ensure that the location for the air compressor is clean, dry, and well ventilated.
5. Close the drain valve.
6. Check the oil level of the pump.
7. Connect plug to main power supply, do not use extension leads as this may result in a drop in
voltage causing motor damage.
8. Start compressor by switching the knob on the pressure switch to the on position and the
compressor will start and build air pressure in the tank to cut-out pressure and then shut off
automatically.
9. Adjust the filter regulator to a psi/kpa setting that is needed for your application and be sure it is
within the safety standards required to perform the task. If using a pneumatic tool, the
manufacturer should have recommendations in the manual for that tool on operating pressure
(psi/kpa) settings.
10. The air compressor is now ready for use

9 | Page
DAILY SHUT-DOWN PROCEDURES
1. The on/off lever located on the pressure switch MUST BE USED TO SHUT DOWN
COMPRESSOR. To ensure pressure is unloaded through the vented check valve via the pressure
switch in the loader valve.
2. Unplug the power cord from the receptacle.
3. Set the outlet pressure to zero on the filter regulator.
4. Remove any air tools or accessories.
5. When draining air tank always use ear and eye protection. Drain the air tank in a suitable location;
condensation will be present in most cases of draining.
6. Open the drain valve allowing air to bleed from the tank. After all the air has bled from the tank
close the drain valve to prevent debris build-up in the valve.
7. When draining the air tank always use ear and eye protection.
Water that remains in the air tank during storage will corrode and weaken the air tank which could cause it to
rupture. To avoid serious injury, be sure to drain the tank after each use or daily.
Do not use your electric or engine drive air Compressor outdoors while it is raining or on a wet surface. Either
of these situations could result in electric shock or damage to the machine.
IMPORTANT
It is important to re-tension the head bolts on the compressor pump after the first 2 hours
of use and every 3 months thereafter.
Head tensions should be set to 24Nm QH 50+80 pumps and 43 Nm on JC pump

10 | Page
PREVENTATIVE MAINTENANCE
The air compressor should be turned off and disconnected from the power source before any
maintenance is performed as well as the air bled from the air tank and the unit allowed time to cool.
Personal injuries could occur from moving parts, electrical sources, compressed air, or hot surfaces.
To ensure efficient operation and longer life of the air compressor unit a routine maintenance schedule should
be followed. The following schedule is geared toward a consumer whose compressor is used in a normal
working environment daily. If necessary, the schedule should be modified to suit the conditions under which
your compressor is used. The modifications will depend upon the hours of operation and the working
environment. Air compressors used in an extremely dirty and/or hostile environment will require a greater
frequency of all maintenance checks.
Disconnect compressor from power supply and release air prior to any servicing/maintenance.
A good maintenance program will add years of service to your air compressor. The following is recommended
as a minimum maintenance program.
DAILY MAINTENANCE
1. Check and maintain oil level and add oil as necessary
2. Drain air tank of moisture via drain valve
3. Check for unusual noise or vibration (see “Troubleshooting”)
WEEKLY MAINTENANCE
1. Clean the air filters. A clogged air filter can seriously affect the efficiency of the compressor and
cause overheating and excessive oil usage.
2. Clean all external parts of the compressor. A dirty compressor can cause abnormally high
discharge temperature and resulting oil carbonisation on internal valve components.
3. Check the safety valve manually (by pulling ring or lever) to ensure correct operation.
MONTHLY MAINTENANCE
1. Inspect condition of oil and change if necessary
2. Check drive belt tension and tighten if needed
EVERY THREE MONTHS OR 600 HOURS OF OPERATION
We recommend an Authorised BE service agent carry out this service.
1. Change oil
2. Inspect valves. Clean the carbon from valves and head if necessary
3. Check all nuts, bolts, etc and tighten as necessary
4. Check non return valve operation.

11 | Page
STORAGE
For storing the air compressor, be sure to do the following:
1. Turn the unit off and unplug the power cord from the receptacle.
2. Remove all air hoses, accessories, and air tools from the air compressor.
3. Perform the daily maintenance schedule.
4. Open the drain valve to bleed all air from the air tank.
5. Close the drain valve.
6. Store the air compressor in a clean and dry location.
TROUBLESHOOTING GUIDE
Trouble Reference..........................................................................................................Checkpoint
Oil in discharge air..........................................................................................................1,4,7,14,19
Knocks or rattles.............................................................................................................2,14,15,16,17
Air delivery has dropped off............................................................................................1,6,14.17
Trips motor overload or draws excessive current............................................................5,11,12,14
Moisture in frame or rusting in cylinders..........................................................................9
Excessive starting and stopping......................................................................................6,10,14,19
Compressor runs excessively hot...................................................................................3, 8,10,13,14.19
Compressor does not come up to speed ........................................................................2,11,17
Motor will not run ............................................................................................................12,13,18
Check Point
Possible Cause
Corrective Action
1
Clogged or dirty air inlet filter.
Clean or replace filter element.
2
Loose belt wheel or motor pulley.
Excessive end play in motor shaft.
Check belt wheel, motor pulley and shaft.
Repair or replace as required.
3
Inadequate ventilation around flywheel.
Relocate compressor for adequate airflow.
4
Oil viscosity too low
Drain oil from pump and refill with correct oil.
5
Oil viscosity too high
Drain oil from pump and refill with correct oil.
6
Air leaks in piping (on compressor or
external piping/system).
Check hoses and connections. Repair or
replace as required.
7
Oil level too high
Drain oil to proper level
8
Oil level too low
Add oil to bring level up to acceptable point.
9
Compressor located in damp or humid spot
Relocate compressor
10
Tank non return valve leaking
Tighten or replace non return valve
11
Improper line voltage
Check line voltage, change lines as required
12
Poor power supply
Consult local power company
13
V-belt is pulled too tight
Adjust belt tension
14
Compressor pump worn or damaged
Contact BE authorised service agent
15
Excessive condensate in air tank
Drain tank
16
Loose guard or fittings
Tighten all fittings
17
V-belt is too loose
Tighten V belt
18
19
Motor overloaded
Compressor rating too small (air delivery)
Reset motor overload
Refer dealer for correctly rated machine

12 | Page
MAINTENANCE AND REPAIR RECORD
DATE OF
PURCHASE
MODEL
NUMBER
SERIAL
NUMBER
PLACE OF
PURCHASE
DATE
MAINTENANCE AND REPAIR ACTIVITY

13 | Page
Distributed in Australia by
CONTACT DETAILS
B.A.R Group P/L
15 Hudson Place,
Mulgrave, NSW, Australia 2756
Phone: [phone]
www.bargroup.com.au
Distributed in New Zealand by
CONTACT DETAILS
BE Pressure Supply
541D Te Rapa Road, Te Rapa,
Hamilton 3200, New Zealand
Phone: [phone]
www.bepressure.co.nz
Errors and omissions excepted
Specifications and performance may change
Version 5.1; 2021
