Using the Operator’s manual
Thank you for choosing our compressor. The manual gives information
with respect to operation and maintenance of the AC205 Compressor
and be sure to read it carefully first before operation.
Following the manual can ensure the user’s safety and get the best
results from the compressor. All information and diagrams in this manual
are in accordance with the newest products at the publishing time. We
strive for accuracy and this manual is accurate for the models described
at the time of printing. We reserve the right to make improvements or
changes at any time without notice or obligation.
Please keep this manual with the engine permanently, even if the engine
ownership is transferred.
Attention: Read through the complete
manual prior to the initial use of your
compressor.
i n t r o d u c t i o n
Specifications
· 4 Gallon Twin Tank Design
· Oil Lubricated for Extended Durability
· 3450 Rpm Induction Motor for Long Life
· 120V, 60Hz, 12.4Amps
· Air Delivery: 4.2CFM output @ 40 PSI and 3.5 CFM output @90 PSI
· Maximum Pressure: 125 PSI
· Thermal Overload Protection for safety
· High Flow regulator and Dual Pressure Gauges for Precision Air Flow
Control
· Control Panel, Two quick Connect Couplers
s p e c i f i c at i o n s

5
p r o d u c t i d e n t i f i c at i o n
Record Identification Numbers
Compressor
If you need to contact an Authorized Dealer or Customer Service line
(1-866-850-6662) for information on servicing, always provide the
product model and identification numbers.
You will need to locate the model and serial number for the machine and
record the information in the places provided below.
Date of Purchase:
Dealer Name:
Dealer Phone:
Product Identification Numbers
Model Number:
Serial Number:

6
s a f e t y
Safety Instructions
· Carefully read through the entire owners manual before operating this
compressor.
· Keep manual with important records for safety instructions, operating
procedures and warranty.
· After unpacking your new air compressor, please inspect it carefully for
any damage that may have occurred during transit.
· Do not operate this air compressor if damaged during shipment,
handling or misuse.
· Damage may result in bursting, which can cause serious injury or
property damage.
· All damaged parts must be repaired or replaced as needed prior to
operating this air compressor.
· Check to see that all nuts, bolts and fittings are secure.
· Check to see that the proper lubrication oil, which has been included
with the air compressor, is used to fill the compressor crankcase to the
proper level.
· Please contact our customer service department at the numbers listed
on the back of this instruction manual for any questions or comments
regarding this air compressor.

7
The safety alert symbol ( ) is used with a signal word (DANGER,
CAUTION, WARNING), a pictorial and/or a safety message to alert
you to hazards.
DANGER indicates a hazard which, if not avoided, will result in death
or serious injury.
WARNING indicates a hazard which, if not avoided, could result in
death or serious injury.
CAUTION indicates a hazard which, if not avoided, might result in
minor or moderate injury.
NOTICE indicates a situation that could result in equipment damage.
Follow safety messages to avoid or reduce the risk of injury or
death.
Hazard Symbols and Meanings
Save these Instructions
Safety Rules
s a f e t y
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety
messages that follow this symbol to
avoid possible injury or death.
e x p l o s i o n
k i c k b a c k
f a l l f l u i d i n j e c t i o n m o v i n g p a r t s r e a d m a n u a l
h o t s u r f a c e w e a r e y e
p r o t e c t i o n
s l i p p e r y
f i r e e l e c t r i c s h o c k t o x i c f u m e s

8
s a f e t y
WARNING
AIR TANK WARNING: Drain liquid from air tank daily,
or after each use, using the drain valve located on the
bottom of the lower air tank. Failure to properly drain
liquid from the tank will cause rust from moisture build-
up, which weakens the tank and could lead to a violent
tank explosion, Periodically inspect the tanks for unsafe
conditions such as corrosion.
Never attempt to repair or make modifications to the tank or its at-
tachments. Welding, drilling or any other modifications may weaken
the tank, which may result in damage from rupture or explosion. Never
remove or attempt to adjust the pressure switch, safety valve, or other
factory set operating pressures.
WARNING
FIRE WARNING: Avoid dangerous environments. Do
not use compressor near gasoline or other flammable
materials. Keep work area well lit. Normal sparking of
a motor or sparking from grinding metal could ignite
fumes. Do not spray flammable materials in the vicinity
of an open flame or other ignition source, including the
air compressor itself. Do not direct paint or other spray
material towards the compressor.
Read and follow all safely instructions for the material you are spray-
ing. Be sure to use an approved respirator designed for use with your
specific application.
WARNING
BREATHABLE AIR WARNING: This air compressor in
not designed, nor intended for the supply of breathable
quality air. Air produced by this unit may contain carbon
monoxide or other toxic vapors.
Do not inhale air from the compressor or from a breathing device con-
nected to it.

9
s a f e t y
WARNING
ELECTRIC SHOCK WARNING: When using electric
powered tools, machines or equipment, basic safety
precautions should always be followed to minimize the
risk of electrical shock or personal injury to yourself and
others.
This air compressor is powered by electricity and should never be used
without properly grounded electrical connections. Do not use in wet or
damp locations or expose to rain.
WARNING
AIR TOOLS AND ACCESSORIES WARNING: Do
not exceed the pressure rating of any air tools, spray
guns, air accessories, or inflatables. Excess pressure
can cause them to explode, resulting in serious injury.
Follow the manufacturers recommended pressure set-
tings for all air tools and air accessories.
WARNING
Do not direct compressed air stream at people or pets.
The powerful compressed air stream can damage
exposed skin and easily propel loose dirt and other
small objects. Always wear eye protection that meets
ANSI Z28.1 specifications.
WARNING
Keep hands and fingers away from exposed metal parts
on a running air compressor. Air compressors gener-
ate significant heat during normal operation, which can
cause serious burns. The compressor will remain hot for
some time after operation and should not be touched or
moved until cool.

10
s a f e t y
General Safety Information
Do not operate unit if damaged during shipping, handling or use. Damage
may result in bursting and cause injury or property damage.
Since the air compressor and other components (filters, lubricators,
hoses, etc.) used, make up a high pressure pumping system, the follow-
ing safety precautions must be observed at all times:
1. Read all manuals included with this product carefully. Be thoroughly
familiar with the controls and the proper use of the equipment.
2. Follow all local electrical and safety codes
3. Only persons well acquainted with these rules of safe operation should
be allowed to use the compressor.
4. Keep visitors away and NEVER allow children in the work area.
5. Wear safety glasses and use hearing protection when operating the
pump or unit.
6. Do not stand on or use the pump or unit as a handhold.
7. Before each use, inspect compressed air system and electrical
components for signs of damage, deterioration, weakness or leakage.
Repair or replace defective items before using.
8. Check all fasteners at frequent intervals for proper tightness.
WARNING
Compressor parts may be hot even if the unit is
stopped.
9. Keep fingers away from a running compressor; fast moving and hot
parts will cause injury and/or burns.
10. If the equipment should start to abnormally vibrate, STOP the engine/
motor and check immediately for the cause. Vibration is generally a
warning of trouble.
11. To reduce fire hazard, keep engine/motor exterior free of oil, solvent,
or excessive grease. Never remove or attempt to adjust safety valve.
Keep safety valve free from paint and other accumulations.
12. Never attempt to repair or modify a tank! Welding, drilling or any other
WARNING
Motors, electrical equipment and controls can cause
electrical arcs that will ignite a flammable gas or vapor.
Never operate or repair in or near a flammable gas or
vapor. Never store flammable liquids or gases in the
vicinity of the compressor.

11
s a f e t y
WARNING
Do not spray flammable materials in vicinity of open
flame or near ignition sources including the compressor
unit.
modification will weaken the tank resulting in damage from rupture or
explosion. Always replace worn or damaged tanks. Drain liquid from
tank daily.
13. Tanks rust from moisture build-up, which weakens the tank. Make
sure to drain tank daily and inspect periodically for unsafe conditions
such as rust formation and corrosion.
14. Fast moving air will stir up dust and debris which may be harmful.
Release air slowly when draining moisture or depressurizing the
compressor system.
Spraying Precautions
15. Do not smoke when spraying paint, insecticides, or other flammable
substances.
16. Use a face mask/respirator when spraying and spray in a well
ventilated area to prevent health and fire hazards.
17. Do not direct paint or other sprayed material at the compressor.
Locate compressor as far away from the spraying area as possible to
minimize overspray accumulation on the compressor.
18. When spraying or cleaning with solvents or toxic chemicals, follow
the instructions provided by the chemical manufacturer.
Hose Precautions
19. Inspect hose before use. Do not exceed working pressure marked on
hose. Do not twist, bend knot, or abrade hose. Do not wrap hose
around body.
20. Keep away from hot surfaces and chemicals.
WARNING
Arcing Parts. Keep the compressor/motor at least 6m
away from explosive vapour.

12
i n s t a l l a t i o n & g r o u n d i n g
Installation and Location
The compressor must be used on a stable level surface. The air compres-
sor must be used in a clean and well-ventilated area. The compressor
requires an unobstructed airflow and must be located a minimum of 18
inches from any walls or other obstructions.
Grounding Instructions
This product should be grounded. In the event of an electrical short cir-
cuit, grounding reduces the risk of electric shock by providing an escape
wire for the electric current. This product is equipped with a cord having
a grounding wire with an appropriate grounding plug. The plug must be
plugged into an outlet that is properly installed and grounded in accor-
dance with all local codes and ordinances.
This product is for use on a nominal 120-volt circuit and has a three-
prong grounding plug that looks like the plug illustrated in Figure 2. Make
sure that the product is connected to an outlet having the same
configuration as the plug. No adapter could be used with this product.
The use of a GFCI outlet is strongly recommended. The third prong is
to be used ground the tool and provide protection against electrical
shock. Never remove the third prong.
Check with a qualified electrician or serviceman if the grounding instruc-
tions are not completely understood, or if In doubt as to whether the
product is properly grounded. Do not modify the plug provided; if it will
not fit the outlet, have the proper outlet installed by a qualified electrician.
DANGER
ELECTRIC SHOCK: Improper installation of the
grounding plug can result in a risk of electric shock. If
repair or replacement of the cord is necessary, do not
connect the grounding wire to either flat blade terminal.
The wire with insulation having an outer surface that is
green with or without yellow stripes is the grounding
wire.
Figure 2
Grounding Pin Grounded Outlet

13
i n s t a l l a t i o n & g r o u n d i n g
Extension Cords
We do not recommend the use on an extension cord with this product as
this may result in the loss of power and overheating of the motor. An
additional air hose should be used instead of an extension cord. However,
if the use of an extension cord is unavoidable, use only UL listed wire
extension cords that have three-pronged grounding type plugs and three
prong receptacles that accept the tool’s plug. Improper use of extension
cords may cause inefficient operation of you tool, which can result an
overheating.
Be sure your extension cord is rated to allow sufficient flow to motor.
Refer to the guide for minimum gauge required for extension cords.
Use of an extension cord heavy enough to carry the current the tool will
draw is very important. Especially when the power source is of great
distance. An extension cord that is insufficient will cause a drop in line
voltage, resulting in power loss and causing the motor to overheat.
Guard against electrical shock. Avoid body contact with grounded ser-
vices such as pipes, radiators, ovens, stoves, and refrigerator enclosures.
If not properly grounded, this power tool can incur the potential hazard of
light trickle shock, particularly when used in damp locations. If an electri-
cal shock occurs, there is the potential of a secondary hazard such as
your hands contacting an operating air tool.
Extension Cord Length Wire Size (A.W.C.)
Up to 25 Feet 14
26 to 50 Feet 12
51 to 100 Feet 10

14
a s s e m b l y i n s t r u c t i o n s
WARNING
The compressor is shipped without oil in the crankcase.
Add oil as indicated below.
Assembly
Read all safety instructions before using air compressor.
1. After opening the carton, please remove all parts and check
against photograph on carton. If any parts are missing, please call at
1-866-850-6662.
2. Place air compressor on a flat, level surface.
3. Pour supplied oil into crankcase until the oil level reaches the red dot in
the oil level sight glass. Be careful not to overfill.
4. Install oil fill plug, supplied for compressor operation, before starting
compressor.
5. Close tank drain valve on the bottom of the air tank by turning the valve
clockwise until fully closed.
6. Attach the air coupler to the compressor regulator valve. Use Teflon
thread-sealing tape on the threads to make sure you have an airtight
connection. Do not over tighten fittings.
7. Attach the supplied air filter to the air intake port on the pump head.
8. Attach air hose and any desired air accessories (which are not
included). Use Teflon thread-sealing tape on the threads to make sure
you have an airtight connection. Do not over tighten fittings.
Refill Oil
Immediately
Check Oil
Level Daily
Oil Level OK
NOTICE
Do not operate the compressor without lubricant or with low lubricant
level. We are not responsible for damage caused to the compressor
due to operation without proper lubrication.
p r o d u c t f e a t u r e s

15
a s s e m b l y i n s t r u c t i o n s
Product Features
1. Automatic ON/OFF Pressure Switch
The compressor is equipped with an automatic on/off pressure switch.
The compressor will only run when the switch is in the “I”(ON) position.
Once the tank has reached the desired preset pressure (see Operation
Instructions), the pump motor will automatically shut off. While the
switch is in the “I”(ON) position, the pump motor will automatically turn
back on once the pressure in the tank drops below the minimum preset
pressure. Do not leave the compressor unattended while the power
switch is in the “I”(ON) position.
2. Regulator
The regulator allows you to select the amount of air pressure that is
output through the air hose into tools and
accessories. Please refer to the air delivery requirements of your tools
for the proper pressure settings.
3. Tank Pressure Gauge
The tank pressure gauge provides a reading of the air pressure inside
of the compressor tank.
4. Safety Valve
This compressor is equipped with a safely valve switch that will engage
when the pressure in the tank exceeds the
maximum rated pressure. DO NOT attempt to modify or remove safely
valve.
5. Tank Drain Fitting
Water is produced whenever air is compressed. It is critical to drain
water from the air tank on this compressor frequently. If unit is used
only occasionally, tank should be drained after each use and prior to
the next use. To drain the tank, slowly open the tank drain fitting by
turning clockwise. Once all water has drained out, close the fitting
securely.
NOTE: tank will not pressurize while fitting is open.
6. Thermal Shutdown Switch
The electric motor is equipped with an automatic thermal overload
protector. If the unit is overheating, the motor will automatically shut
down. Turn the unit off and wait 5-10 minutes before turning the unit
back to the “I”(ON) position. If the unit shuts down again, please
contact the manufacturer for assistance.
p r o d u c t f e a t u r e s

16
o p e r a t i o n
Operating Instructions
Initial Start Up
1. Disconnect tools and/or accessories from the air hose.
2. Open the tank drain valve to allow air to escape preventing air pressure
buildup in the air tank.
3. Plug power supply cord into proper power source receptacle. (See
Grounding Instructions)
4. Run the compressor for a minimum or twenty minutes in this no-load
position to lubricate the bearings and piston.
5. Turn off compressor, drain liquid from tanks and close drain valve.
6. The compressor is now ready for use.
Start Up
1. Slowly open tank drain by turning clockwise. Allow any water in tank to
drain out. Close fitting securely.
2. Before connecting the compressor to the grounded outlet, check for
broken components and accessories, and check for damage to the
hose.
3. Make sure the power switch is turned “O”(OFF) position.
4. Plug the unit into a grounded outlet.
5. Attach desired tool to the end of the air hose.
6. Turn the switch on the “I”(ON) position.
7. Adjust regulator knob to desired pressure level once the pump has
shut off and the compressor has stopped running.
Storage
1. Disconnect unit from grounded outlet.
2. Disconnect tools and/or accessories from the air hose.
3. Locate drain valve on bottom side of tank.
4. Open drain valve to release remaining pressurized air and moisture
from the air tank. Moisture buildup in the tank is normal with air
compressors, so a small amount of water may come out while
draining the tank. Draining the tank is vital for longevity and safety of
your air compressor.
5. Close valve and store the compressor in a cool, dry place.
Shut Down
1. Do not turn off the air compressor by unplugging it from the power
receptacle as damage may result.
2. Turn the ON/OFF lever to the OFF position.
3. Unplug power cord from outlet.
4. Rotate the pressure regulator knob counterclockwise until it is fully
closed. Check regulated pressure gauge to ensure that it reads 0 PSI.
5. Remove air hose and other connected accessories.
o p e r a t i o n & m a i n t e n a n c e

17
o p e r a t i o n o p e r a t i o n & m a i n t e n a n c e
6. Slowly open air tank drain valve to release remaining pressurized air,
and tilt unit to fully drain accumulated liquid from air tanks. Moisture
build-up in the tank is normal with air compressor, so a small amount of
water may come out while draining the tank. Draining the tank is vital
for the longevity and safely of your air compressor.
7. Close drain valve.
8. Allow compressor to cool down.
9. Clean and store compressor.
Maintenance
When performing any maintenance or service
· The air compressor must be turned off.
· Disconnect compressor from the power source.
· Drain tanks.
· Allow compressor to cool down.
Daily
· Check oil level.
· Drain accumulated liquid from tanks.
· Check for oil leaks.
· Check for unusual noise and/or vibrations
· Check that all fasteners are secure.
Weekly
· Check safety relief valve.
· Inspect and clean air filter.
· Clean breather holes on oil check dipstick.
Monthly
· Check for air leaks.
· Apply a solution of soapy water around joints.
· Look for air bubbles around joints when compressor reaches the
pressure cut-out limit and pump turns off.
Six Months or 250 Operating Hours
· Change compressor oil.
· Use only SAE 20 or SAE 30 weight non-detergent oil.
· Replace oil more frequently when used in dusty operating environments.
Oil Change
1. Place oil drain pan below oil drain plug.
2. Remove dipstick to allow air to enter crankcase.
3. Remove oil drain plug.
4. Allow oil to drain completely.
5. Clean and replace oil drain plug.
6. Refill crankcase with SAE 20 or SAE 30 weight non-detergent oil to
red dot on oil level sight glass. Be careful not to overfill.

18
p a r t s
AC205 Parts Diagram
p a r t s

19
p a r t sp a r t s
AC205 Parts List
No. Description Qty
1 Bolt 4
2 Washer 4
3 Air Filter includes element 1
4 Cylinder Head 1
5 Elbow 1
6 Shroud 1
7 Washer 4
8 Washer 4
9 Bolt 4
10 Head Gasket 1
11 Valve plate 2
12 Valve 2
13 Metal gasket 1
14 Valve plate gasket 1
15 Nut 2
16 Bolt 2
17 Washer 2
18 Cylinder 1
19 Cylinder Gasket 1
20 Piston Ring Set 1
21 Compression Ring 2
22 Oil Ring 1
23 Piston 1
24 Wrist pin 1
25 Wrist pin retainer 2
26 Connecting Rod 1
27 Bolt 1
28 Washer 1
29 Camshaft lobe 1
30 Breather tube 1
31 "O'' Ring 1
32 Crankcase Cover gasket 1
33 Crankcase Cover 1
34 "O'' Ring 1
35 Sight glass 1
36 "O'' Ring 1
37 Bolt 1
38 Bolt 4
No. Description Qty
39 Washer 4
40 Crankcase 1
41 Over-load 1
42 Nut 1
43 Capacitor 1
44 Motor 1
45 Rear cover 1
46 Fan 1
47 Clip 1
48 Outlet Tube Assy 1
49 Rubber strip 1
50 Control panel 1
51 Bolt 8
52 Pressure Regulator 1
53 Safety Valve 1
54 Pressure Gauge 2
55 Coupler 2
56 Plug 3
57 Bolt 2
58 Elbow 2
59 Pressure Switch 1
60 Hoop 2
61 Pipe 1
62 Unloader tube 1
63 Handle 1
64 Tank 1
65 Drain valve 1
66 Check valve 1
67 Foot 4
68 Bolt 4
69 Bolt 4
70 Base 1
71 Connecting pad 4
72 Washer 4
73 Washer 4
74 Nut 4
75 Power Cord 1
76 Motor cord 0.85m

If you need assistance with the
assembly or operation of this
Compressor please call
1-866-850-6662
