BE Deluxe Series User manual

SAVE THIS MANUAL: 
 
  

OWNER'S MANUAL & OPERATION INSTRUCTION
G3800 - G6800 - G8000 - G11000
Version  2.0  -  2021

g1 g
Thank you for choosing a BE Generator Set.
This manual contains the information on how to operate the generator .
Please read it carefully before operating. Operating safely and correctly
can help you get the best results.
All information in this publication is based on the latest product
information available at the time of printing. The contents in this manual
may be different from the actual parts due to revision and other changes.
Our company reserves the right to make changes at any time without
notice and without incurring any obligation. No part of this publication
may be reproduced without our company’s written permission.
This manual should be considered a permanent part of the generator and
should accompany the generator if it is resold.

g2 g
SAFETY MESSAGES
Your safety and the safety of others are very important. We have provided
important safety messages in this manual and on the generator. Please
read these messages carefully.
A safety message alerts you to potential hazards that could hurt you or
others. Each safety message is preceded by a safety alert symbol and
one of three words: DANGER, WARNING, or CAUTION. Meaning as
follows:
You WILL be KILLED or SERIOUSLY HURT if you don’t follow
instructions.
You CAN be KILLED or SERIOUSLY HURT if you don’t follow
instructions.
You CAN be HURT if you don’t follow instructions.
Your generator or other property could be damaged if you don’t follow
instructions.

g3 g
CONTENTS
SAFETY MESSAGES ……………………………………………… 2
CONTENTS ………………………………………………………… 3
1. SAFETY NOTICE………………………………………………… 5
1. Safety Standard ……………………………………………… 5
2. Special Requirements………………………………………… 6
2. COMPONENT IDENTIFICATION ……………………………… 8
1. Structure Feature……………………………………………… 8
2. Engine Type & Serial Number …………………………… 12
3. CONTROL……………………………………………………… 11
1. Generator Switch ………………………………………… 11
2. Recoil Starter ……………………………………………… 11
3. Fuel Valve ………………………………………………… 12
4. Choke Lever ……………………………………………… 12
5. AC Circuit Breaker ……………………………………… 13
6. Ground Terminal ………………………………………… 13
7. Oil Alert System…………………………………………… 13
4. GENERATOR OPERATION…………………………………… 14
1. Connection to the Household Power Supply ……………… 14
2. Generator Grounding ……………………………………… 15
3. AC Current ………………………………………………… 15
4. DC Current………………………………………………… 16
5. PRE-OPERATION CHECK …………………………………… 18
1. Engine Oil ………………………………………………… 18
2. Fuel ……………………………………………………… 19
CONTENTS

g4 g
3. Battery …………………………………………………… 20
6. STARTING THE ENGINE …………………………………… 21
1. Recoil Starter ……………………………………………… 21
2. Electric starting …………………………………………… 21
7. STOPPING THE ENGINE …………………………………… 22
8. MAINTENANCE ……………………………………………… 23
1. Engine Oil Change………………………………………… 24
2. Air Cleaner Service ……………………………………… 25
3. Fuel Sediment Cup Cleaning ……………………………… 26
4. Spark Plug Service………………………………………… 27
9. STORAGE ……………………………………………………… 28
10. TROUBLESHOOTING ……………………………………… 30
11.
WIRING DIAGRAM ……………………………………………… 31
12. SPECIFICATIONS …………………………………………… 34
13. WHEEL (OPTION) …………………………………………… 36
CONTENTS

g5 g
1. SAFETY NOTICE
1. Safety Standard
Read and understand this owner’s manual before operating your
generator. You can help prevent accidents by being familiar with your
generator’s controls, and by observing safe operating procedures.
Don’t operate indoors. Don’t operate in the wet condition
Don’t directly connect to the household
power supply Don’t smoke when refueling
SAFETY NOTICE

g6 g
'RQ¶WRYHUÀRZWKHIXHOZKHQUHIXHOLQJ Stop the engine before refueling
3OHDVHNHHSLWPDWOHDVWIDUDZD\IURPWKHLQÀDPPDEOHPDWHULDOV
2. Special Requirements
· Electrical equipment,including lines and plug connections should be
free from being bare.
· The circuit breakers should match with the generator equipment. If
the circuit breakers require replacement, they must be replaced with a
circuit breaker of the same ratings and performance characteristics.
· Don’t operate the generator before grounding.
SAFETY NOTICE

g7 g
· If using extension cords, the requirement should be met as
following: for 1.5mm2, the line should not be exceeded 60m; for
2.5mm2, the line not exceeded 100m.
North American Users:
Do not switch between 110v and 220v while under a load.
Do not switch between 115v and 230v while under a load.
SAFETY NOTICE

g8 g
2. COMPONENT IDENTIFICATION
1. Basic Features
COMPONENT IDENTIFICATION
Recoil Start
GROUND
TERMINAL
AIR FILTER
MUFFLER
FUEL METER
FUEL TANK CAP
RECOIL STARTER GRIP
GENERATOR SWITCH
AC RECEPTACLES
AC OVERCURRENT
OR RCD PROTECTOR

g9 g
Recoil/Electric Start
COMPONENT IDENTIFICATION
GENERATOR SWITCH
AC RECEPTACLES
GROUND
TERMINAL
AIR FILTER
MUFFLER
FUEL METER
FUEL TANK CAP
BATTERY
RECOIL STARTER GRIP
AC OVERCURRENT
OR RCD PROTECTOR

g10 g
2. Engine Type & Serial Number
MODEL NO.
FINISHED
PRODUCT NO.
SER. NO.
COMPONENT IDENTIFICATION
Recoil Starter(3 Phase)
BINDING POSTS GROUND TERMINAL
GENERATOR SWITCH
AC RECEPTACLES AC CIRCUIT BREAKER

g11 g
3. CONTROL
1. Generator Switch
2. Recoil Start
Tostart the engine, pull the starter grip lightly until resistance is felt, then
pull briskly.
Do not allow the starter grip to snap back against the engine.
Return it gently to prevent damage to the starter.
STARTER GRIP
CONTROL
ON
ON
ON
OFF
OFF
OFF
START
START
GENERATOR SWITCH
Recoil Starter
Recoil/Electric Starter
GENERATOR SWITCH

g12 g
3. Fuel Valve
7KHIXHOYDOYHFRQWUROVIXHOÀRZLQJIURPWKHIXHOWDQNWRFDUEXUHWRU%H
sure to return the lever to “OFF” after stopping the engine.
4. Choke Lever
The choke lever is used to provide an enriched fuel mixture when starting
a cold engine. Slowly put the choke lever to “OPEN” position after the
engine is started.
ON
OFF
FUEL VALVE
CONTROL
CHOKE
LEVER
CHOKE LEVER
OPEN
CLOSE
CLOSE OPEN

g13 g
CONTROL
5. AC Circuit Breaker/RCD Protector
The RCD/RCBO will automatically trip if has earth leakage has been detected
to avoid electrocution, short circuiting of the load or overload. If the circuit
breaker or RCD is switched OFF, switch the circuit breaker ON for power to the
outlets. NOTE: generators fitted with RCD will be fitted with an M.E.N Link in the
alternator or behind the control panel.
6. Ground Terminal
This ground terminal is dedicated to reliably grounding the whole generator.
7. Oil Alert System
The oil alert system is especially designed to prevent engine damage
caused by an insufficient amount of oil in the crankcase. When the oil
level in the crankcase fall down below the safe limit, the oil alert system
will automatically shut down the engine(though the generator switch still
remain in the ON position), so that the engine can’t be damaged due to
AC CIRCUIT
BREAKER ON
OFF
OFF
ON
AC OVERCURRENT PROTECTOR

GROUND TERMINAL
NOTE: This is
not required for
generators fitted
with RCD and
M.E.N Link

g14 g
4. GENERATOR OPERATION
Generator operation environment:
· Temperature:-15ď40ď
· Humidity:below 95%.
· Height above sea level: below 1,000m(If the area is over 1,000m
high, the power should be lowered for operation).
1. Connection to the Household Power Supply
When connecting the generator to a household power supply, connection
must be made by a qualified electrician. After connecting, carefully
check electric connection for their safety and reliability, if not,
damage WRWKHJHQHUDWRU and house electrical system PD\EHFDXVHG
OK NO
OK
GENERATOR OPERATION

g15 g
2. Generator Grounding
To prevent electrical shock or misuse from faulty appliances, the
generator should be grounded with an insulated lead.
3. AC Current
Before starting the generator,make sure that total power of loads(total of
resistive,capactive and inductive loads)does not exceed rated power of
the generator.
Overload operation will greatly shorten generator service life.
If the generator set is connected to multiple loads or electric
appliances,please first connect to one with the highest starting
power,then,the one with the second highest starting power,and connect
others one by one,each with a lower starting power than the preceding
GENERATOR OPERATION
GROUND TERMINAL

NOTE: This is
not required for
generators fitted
with RCD and
M.E.N Link

g16 g
In general, capacitive and inductive loads, especially, motor-driven
devices have a big starting current when starting. The following table is a
reference for when connecting to the electric appliances
Type Wattage Typical Device Examples
Start Rated Device Starting Rated
Incandescent Lamp
Heating Device
h1h1
Incandescent
Lamp
Tv Set
Incandescent
Lamp 100W
100VA
(W)
100VA
(W)
Fluorescent Lamp h2h1.5
Fluorescent Lamp Fluorescent Lamp
40W
80VA
(W)
60VA
(W)
Motor Drive Device h3-5 h2
Refrigerator
Electric Fan
Refrigerator
150W
450-
750VA
(W)
300VA
(W)
4. DC Current
DC Terminals
The DC terminals are used to provide power supply for lower-power DC
loads and charging other batteries.
The terminals are colored as such:red to identify the positive (+) terminal
and black to identify the negative (-) terminal. Load connection method:
The load must be connected to DC terminals with the proper polarity
(load's positive to positive of DC terminal and load's negative to negative
of DC terminal).
GENERATOR OPERATION

g17 g
GENERATOR OPERATION
DC OVERCURRENT PROTECTOR
The overload current will automatically switch off overcurrent protector to
avoid short circuit of the load or overload. If the indicator of overcurrent
protector is raised, the overcurrent protector is now in the “OFF” position.
Press the button of overcurrent protector to the “ON” position again.
POSITIVE
POLE
NEGATIVE POLE
OVERCURRENT
PROTECTOR

g18 g
5. PRE-OPERATION CHECK
1. Engine Oil
Engine oil is a major factor affecting engine performance and service
life. Non-detergent and 2-stroke engine oils will damage the engine
and are not recommended.Check the oil level before each use with
the generator on a level surface with the engine stopped.
Recommended engine oil
4-stroke gasoline engine oil
6)XQGHU$3,VHUYLFHFODVVL¿FDWLRQ
or SAE10W-30(equivalent to SG class).
Method of checking engine oil level:
5HPRYHWKHRLO¿OOHUFDSDQGZLSHWKHGLSVWLFNWRFOHDQLW
&KHFNWKHRLOOHYHOE\LQVHUWLQJWKHGLSVWLFNLQWRWKH¿OOHUQHFNZLWKRXW
screwing it in.
If the level is low, add the recommended engine oil until level can reach
the upper mark on the dipstick.
$IWHUDGGLQJGRQ¶WIRUJHWWRUH¿WDQGVFUHZWKHRLOGLSVWLFNWLJKW
OIL DIPSTICK OIL UPPER MARK
OIL LOWE MARK
PRE-OPERATION CHECK
